Speco O2iD9 User manual

Intensifier® Technology IP Dome Camera
QUICK INSTALLATION GUIDE
O2iD9
Please read this manual carefully before installation and operation of the product.

1
Notice
Thank you for purchasing this product. This guide is designed to be a reference tool for the product. Please read
it carefully before operating the product and retain it for future reference. Should you require any technical
assistance, please contact Speco Technologies Technical Support.
INFORMATION
This equipment has been tested and found to comply with limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at its own expense.
WARNING
Changes or modifications not expressly approved by the manufacturer could void the user’s authority
to operate the equipment.
CAUTION –To prevent electric shock and risk of the fire hazards
Do NOT use power source other than that specified.
Do NOT expose this appliance to rain or moisture.
PRECAUTIONS
Please read the manual carefully before the installation in order to set up the camera correctly and
to obtain the best picture quality.
Please keep the manual in good condition for your future reference and service application.
Installation and services should only be carried out by an authorized personnel according to local
This installation should be made by a qualified service person and should conform to all local codes.
The lighting flash with an arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of non-insulated dangerous voltage within
the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION

2
safety regulations.
If any liquid or solid matter gets into the housing, immediately disconnect the camera from power
supply and have it checked by your authorized dealer before reusing.
Avoid installing the camera at extremely hot or cold places.
If you are not a certified person, never try to dismantle the camera.
To avoid electric shock, never remove the screws or covers. There are no parts inside that need
maintenance by the user. All maintenance should be carried out by qualified personnel.
Avoid installing the camera at a place of high humidity.
Avoid installing the camera at the place exposed to gas or oil.
Keep the top glass of the lens always clean in order to obtain the best picture quality all the time.
Be careful not to be stained by fingerprint.
Don't face the camera directly toward sunlight or sunlight reflecting area.
IMAGE SENSOR may go defective at this condition.
Please give a special attention to keep the unit from dangerous drop or external shock during the
process of transportation or handling.
Never try to touch the camera in wet hand. It may cause an electric shock.
Do not expose the camera to radioactivity. It causes a serious damage on the IMAGE SENSOR.
LIMITATION OF LIABILITY
This publication is provided “AS IS” without warranty of any kind, either express or implied, including
but not limited to, the implied warranties of merchantability, fitness for any particular purpose, or non-
infringement of the third party's right.
This publication could include technical inaccuracies or typographical errors. Changes are added to
the information herein, at any time, for the improvements of this publication and / or the corresponding
product(s).
DISCLAIMER OF WARRANTY
In no event shall seller be liable to any party or any person, except for replacement or reasonable
maintenance of the product, for the cases, including but not limited to below :
(1) Any damage and loss, including without limitation, direct or indirect, special, consequential or
exemplary, arising out of or relating to the product.
(2) Personal injury or any damage caused by inappropriate use or negligent operation of the user.
(3) Unauthorized disassemble, repair or modification of the product by the user.
(4) Inconvenience or any loss arising when images are not displayed, due to any reason or cause
including any failure or problem of the product.
(5) Any problem, consequential inconvenience, or loss or damage, arising out of the system
combined by the devices of third party.
(6) Any claim or action for damages, brought by any person or organization being photogenic subject,
due to violation of privacy with the result of that surveillance-camera's or video server’s picture,
including saved data, for some reason, becomes public or is used for the purpose other than
surveillance.
1. PRODUCT OVERVIEW
Key Features
2.0 Mega pixel 1/2.9" SONY progressive scan CMOS image sensor for excellent image quality
Low light, Ultra high sensitivity camera
2.8mm Fixed Lens
Perfect tool-free 3-Axis mechanism inside

3
Triple Streaming of H.264 and M-JPEG
Up to 30 frames per second at all image resolutions
Supports image resolutions Full HD (1920 x 1080)
Integrated motion detection with pre- and post-alarm image / video buffering
Supports CBR (Constant Bit Rate) and VBR (Variable Bit Rate) modes
Supports Tampering-Alarm in VA (Video Analytics) function
Controllable frame rate
Video access through any standard Web browser
Privacy Masking up to 8 areas
Supports IEEE 802.3af Power over Ethernet injectors, mid- and end-spans
Integrated HTTP Web server supporting 8 simultaneous user connections
HTTPS supported (Hyper Text Transfer Protocol Secured)
DDNS and DHCP client
Specification
CLASSIFICATION
Night Vision Outdoor Camera
General
CPU
ARM1176JZF-STM ( 400 MHz, Instruction cache : 32kbyte,
data cache : 16kbyte, MMU )
Flash
2Gbit Flash Memory
SDRAM
2Gbit DDR3 Memory
Image Pickup
Image Sensor
2.0 Megapixel 1/2.9" SONY progressive scan CMOS image
sensor
Total Pixels
1952(H) x 1116(V) 2.18 Megapixel
Effective Pixels
1944(H) x 1104(V) 2.14 Megapixel
S/N Ratio
More than 50dB
Min. Illumination
0.1Lux
Day & Night
ICR Filter Changer
Lens Control
Manual Iris
Lens
2.8mm Fixed Lens
Video
Video Compression
H.264 High profile @ Level 5.0 (1920 x 1080),
4.1 (Other resolutions), Motion JPEG
Resolutions
Up to 1920 x 1080
Frame rate
H.264 Up to 30fps with 1920 x 1080
H.264 Up to 30fps with VGA
MJPEG Up to 30fps with VGA resolution
Video Streaming
Support multi stream with H.264, MJPEG
Adjustable Frame Rate
VBR / CBR in H.264
Image Setting
Brightness, contrast, Sharpness
Day & Night
Auto White Balance
Auto Exposure
Privacy Mask
DSS, 2DNR (On / Off), 3DNR (On / Off)
Defog function
Corridor-View, Mirror / V-Flip, etc.
WDR (Low / Middle / High)
Smart IR (Off / 0 ~ 15)
Network
Security
Password Protection
User Access Log
HTTPS Encryption
Supported Protocol
HTTP, HTTPS, DNS, RTSP, RTP, TCP, UDP, ICMP, DHCP
System
Integration
Intelligent Video
Motion detection 12 x 12 blocks
Alarm Trigger
Motion detection
Firmware Upgrade
Remote Upgrade via Network
Physical
Etc
1 x Factory Reset Button

4
Power Source
DC 12V / 1.5A, POE (Power Over Ethernet) : 802.3af
Power Consumption
Max. 3.0W
Net Weight
570g (Camera Only)
LED's
Power, Network Connection
Dimension(mm)
121.2(Ø) x 96.3(H)
Environment
Operating Temperature
-10 degree ~ 50 degree Celsius (-14F ~ 122F)
Storage Temperature
-20 degree ~ 60 degree Celsius (-4F ~ 140F)
Software
Included Software
IP Scanner (Windows only)
Package
Package Contents
Network Camera, Use Manual, External Power Adaptor
(option)
Specifications are subject to change without prior notice for improvement.
2. NAME AND FUNCTION OF EACH PART
2.1 Package Contents
APPEARANCE
DESCRIPTION
IP Camera x 1
Installation Guide x 1
Drilling Template x 1
Tapping screw x 3
Plastic anchor x 3
Torx Wrench x 1
CD x 1
2.2 Name and Function
3
2
1

5
NO.
ITEM
DESCRIPTION
Power Connector
DC12V
Network and
POE Connector
POE (Power over Ethernet) and LAN cable
Lens
2.8mm Fixed Lens
3. INSTALLATION
3.1 Adjust Pan, tilt and Rotation and the View Angle
-Pan, Tilt, Rotate (3-Axis mechanism) makes easy to monitor the desired view
Panning axis can be adjusted 360°
Tilting axis can be adjusted 0°~ 90°
Rotating axis can be adjusted
between +180°(clockwise)
and -180°(counter-clockwise)
Do not rotate more 180°as this
might cause the internal cables to
twist and disconnect or break.
-How to adjust the View Angle
a. Panning 360 degree
Turn the pan base right or
left to adjust the pan angle.
b. Tilting 90 degree
Loosen the tilt lever on the right or left side of the camera board.
Control the camera tilt angle and fasten the tilt lever again.
c. Rotation 180 degree
Grasp the front side of the camera board and turn it right or left to set the exact angle of image.
3.2 How to Mount to Ceiling / Wall
Ceiling
1
2
3
The front side of the
camera
Tilt lever
Rotation
180°
Pan
360°
Tilt
90°
Pan base

6
①Paste a Drilling Template on the ceiling. (or wall)
②Drill screw points which will be done for installation.
Fix the plastic anchors in the holes. (in case of masonry ceiling or wall)
③Mount the camera set by using Tapping Screws with Ø4 provided.
④Set the position and angle of the cameras to a desired direction and assemble the dome cover.
Wall Mount Bracket <Option>
Ceiling Tile
Drilling template
Plastic Anchor x 3
Tapping Screw
(4 x 30) x 3
Dome Cover Ass'y
Torx Screw
(3 x 15) x 3
Torx L-Wrench
Camera Ass'y
Safety Wire

7
3.3 INSTALLATION EXAMPLE
3.3.1 Installation Example
Tapping Screw
(6 x 50) x 4
Wall Mount Bracket
Plastic Anchor x 4
Adaptor Plate
Camera Ass'y
Safety Wire
Dome
Cover Ass'y
Torx Screw
(3 x 15) x 3
Torx L-Wrench
Machine Screw x 2

8
3.3.2 Connecting to the Network
Open up IP Scanner.
IP Scanner can search for the device on the local network.
Please note that only devices that are on the same subnet can be discovered.
The device is set to DHCP mode by default.
In the device list, you can view the IP address, model number, and MAC address of each device. Select the
applicable device and double click to open up the web viewer.
3.3.3 Accessing the Camera’s Web Setup Page
1) Open the browser and enter the camera’s IP address in the address bar or double click the device in IP
Scanner.
LAN Switch Router Internet Remote Access
Local Access E-Mail / FTP

9
2) Enter the user name and password when prompted.
3) Default user name is admin and password is 1234.
4) If prompted for installation of the Active-X plug-in, allow the installation. Active-X is needed to view video
from Internet Explorer.
4. DIMENSION (mm)
Enter the IP
address here
