Spectrum Industries Inspiration Keyboard Tray User manual

Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt. To
report information regarding missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
0191393 Page 1 of 2
1. Attach slide assemblies to worksurface
1. Open the lectern instructor-side door (if equipped).
2. Extend the slides.
3. Align and attach each slide assembly to the worksurface using (3)
#8 x 3/4” PHSM screws. Figure 1. (Note left and right orientation).
4. Tighten screws securely.
Figure 1
(4) 021588
8-32 Keps nut
(6) 026073
#8 x 3/4” PHSM
(1) 0141715
Keyboard Tray
Inspiration Keyboard Tray
95538
Tools
Required
11
/
32
”
Left and Right slide assemblies
consisting of:
(1pr) 0114747 14” Slide set
(2) 0141718 Keyboard bracket
(2) 0141728 Slide bracket
(3) #8 x 3/4”
PHSM screw
Left slide assembly
Worksurface
Right slide assembly

0191393 Page 2 of 2
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2019 Spectrum Industries Inc., All rights reserved.
Figure 2
Releasing keyboard tray slides
1. To ip, pull the tray out fully and locate the plastic lever on each slide. Figure 3.
2. Release the levers on the both slides while pulling the tray out.
2. Attach keyboard tray to slides
1. Place the keyboard tray onto the extended slides and align studs with
mounting holes.
2. Install (1) 8-32 Keps nut on each stud to secure. Figure 2.
3. Tighten Keps nuts securely.
Keyboard Tray
(2) 8-32
Keps nut
Push here on both
slides to release Keyboard Tray
Figure 3
