Spirax Sarco PP6 User manual

IM-P704-03 CTLS Issue 3 1
PP6 Positioner
© Copyright 2021
Printed in GB
PP6 Positioner
Quick Start Guide
IM-P704-03
CTLS Issue 3
This guide covers only a brief description of installation and maintenance for
Spiratrol and QL valves. For detailed installation, operations, maintenance
including safety, precautions, and warnings, please refer to our official instruction
manual at www.spiraxsarco.com (IM-P704-02).
PP6 is Pneumatic-Pneumatic Positioner that accurately controls valve stroke in response to a pneumatic
input signal of 0.02~0.1 MPa (0.2~1 bar) from the controller.
! NOTE: Use of the positioner in a hazardous area.
1 The positioner must be suitably earthed to prevent static electricity
2 Operation with air hotter than 70 °C is to be avoided
3The positioner must not be used in a Zone 0 area.
4Only wipe the positioner with a damp cloth to prevent static build up.

IM-P704-03 CTLS Issue 3
2
PP6 Positioner
1. Installation
Side view
shown for
clarity
1.1 Linear positioner
1.1.1 Assemble feedback pin locator and feedback
pin to actuator coupling firmly.
Mounting
Positions
Pin
Locator
Marking
Valve
stroke
MTG
kit
Feedback
pin
locator
direction
Central N/A
20
PY1
30
50
PY2
70
Left hand
side
D20
UY3
A30
B50
UY1
E70
1.1.2 Assemble the supplied feedback lever and
bracket to positioner firmly, then loosely
mount the assembly on the left hand side of
the actuator yoke. For central mount, mount
on the right hand side of the actuator yoke.
1.1.3 Make sure that Positioner’s feedback lever is
perpendicular to the valve stem at 50% of the
valve stroke.
1.1.4 The feedback pin coming from the actuator
coupling should be inserted inside slot of the
feedback lever in such a way that the length
of valve stroke coincides with the
corresponding figures in “mm” marked on the
feedback lever.
Improper setting may cause poor linearity or
damage to positioner.
1.1.5 At 0% or 100% position, the linear lever or
linear lever stopper should not touch the
stopping bosses of positioner.
1.1.6 As a final step, tighten the bracket to the
actuator yoke.
50%
90°
Lever spring
Feedback pin
Stopping bosses Linear lever stopper
Stopping bosses
Linear lever stopper
No touch

IM-P704-03 CTLS Issue 3 3
PP6 Positioner
1.2 Rotary positioner
1.2 .1 There are three brackets in the positioner box.
1.2.2 Refer to the figure and check the bolting
positions of the upper and lower brackets to
be fastened depending on the actuator’s stem
height. And then assemble the positioner with
the brackets by using M6 bolts, washers and
nuts.
1.2.3 Make sure that the center of positioner's main
shaft is well aligned with the center of
actuator's stem.
1.2.4 Tighten the positioner and bracket, taking into
account the alignment described in step 3
above.
Actuator stem
Actuator
30 (H)
Actuator
Actuator stem height
20 45.5 26.5 39.5 52
30 55.5 26.5 39.5 52
50 75.5 41.5 39.5 72

IM-P704-03 CTLS Issue 3
4
PP6 Positioner
2. Connection – Air
2.1 Single acting actuator (side mount positioner)
2.1.1 Piping and span direction setting for linear DA single actuator
Move upward at pneumatic failure
Direct action
Note: For central mount, reverse Span lever
Reverse action
Note: For central mount reverse the Span
lever
Supply When increasing
input signal
DA
actuator
Move upward at pneumatic failure
RA
actuator
When increasing
input signal
Supply
Span
Signal Signal
2.1. 2 Piping and span direction setting for linear RA single actuator
2.1. 3 Piping and cam direction setting for rotary single actuator
Move downward at pneumatic failure Move downward at pneumatic failure
When increasing
input signal When increasing
input signal
Direct action
Note: For central mount reverse the Span
lever
Reverse action
Note: For central mount reverse the Span
lever
Direct action Reverse action
RA
actuator RA
actuator
Signal
Supply
Span
Supply
Signal
Bearing
Supply When increasing
input signal When increasing
input signal
Span
Cam
Span
Cam
Bearing
Supply
Signal
Signal

IM-P704-03 CTLS Issue 3 5
PP6 Positioner
2.2 Double acting actuator (side mount positioner)
2.2.1 Piping and ‘Span’ direction setting for linear double actuator
When increasing
input signal
Direct action
Note: For central mount reverse the Span
lever
Supply
Span
When increasing
input signal
Reverse action
Note: For central mount reverse the Span
lever
Signal
Supply
Signal
2.2.2 Piping and cam direction setting for rotary double actuator
Span
Cam
Bearing
Supply
Direct action Reverse action
Bearing
Supply
Signal
When increasing
input signal
Span
Cam
Signal
When increasing
input signal

IM-P704-03 CTLS Issue 3
6
PP6 Positioner
3. Adjustments
3.1 Adjustment - Zero Point
Set input signal pressure at 0.02MPa (or 0.1MPa)
as the initial signal and rotate the adjust wheel
of zero setting unit upward or downward to set
actuator’s zero point. Please refer to the gure
opposite.
3.2 Adjustment - Span
3. 2.1 After setting zero point, supply input signal
pressure at 0.1MPa (or 0.02MPa) as the
end point pressure and check the actuator
stroke. If the stroke is low, the span should
be stretched. If the stroke is high, the span
should be reduced.
3.2.2 Changing span will a󰀨ect zero point setting
so zero point should be set again after span
has been adjusted.
3.2.3 Above two steps are required several times
until both zero and span are properly set.
3.2.4 After proper setting, tighten lock screw of the
span unit.
3.3 Adjustment –
A/M switch (Auto/Manual)
3.3.1 Auto manual switch is located on the
top of pilot unit. Auto manual switch
allows the positioner to be functioned
as bypass.
If the switch is rotated counterclockwise
(toward “M”, Manual), then the supply
pressure will be directly supplied to the
actuator regardless of input signal. On
the other hand, if the switch is turned
clockwise (toward “A”, Auto), then the
positioner will operate normally by
input signal.
3.3.2 Make sure that the supply pressure
does not exceed the rated pressure
level of the actuator before the switch
is loosened toward “M”.
3.3.3 After using the “Manual” function,
return the auto manual switch to
“Auto”.
Lock screw
Lock screw
Auto
manual
switch
Manual Auto

IM-P704-03 CTLS Issue 3 7
PP6 Positioner
spiraxsarco.com EN
Pneumatic Positioner
PP6
0
0
Spirax Sarco Ltd,
Runnings Road
Cheltenham
GL51 9NQ
United Kingdom
2014/34/EU ATEX Directive
0 0
0 0
0 0
ATEX Directive EN 1127-1:2019
0EN ISO 80079-36:2016
0EN ISO 80079-37:2016
0 0
0 0
0 0
0 0
0 0
0 0
0 0
Notified Body number Performed Certificate
0 0 00
0 0 00
Additional information:
ATEX coding: II 2GD Ex h IIC T6 Gb
0Ex h IIIC T85°C Db
On behalf of: Spirax Sarco Ltd,
M Sadler
Cheltenham
2021-06-24
GNP234-EU-C/03 issue 2 (EN)
Product Integrity & Compliance Manager
(place and date of issue):
This declaration of conformity is issued under the sole responsibility of the manufacturer.
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
References to the relevant harmonised standards used or references to the other technical specifications in relation to which
conformity is declared:
Where applicable, the notified body:
(name, function):
Steam Business Development Engineering
Name and address of the manufacturer or his
authorised representative:
EU DECLARATION OF CONFORMITY
Apparatus model/Product:
0
0
0
Page 1/1
8. Approvals
Declaration of Conformity

IM-P704-03 CTLS Issue 3
