Spray Master Technologies POWER CLEAN GO 2.0 User manual

POWER CLEAN GO 2.0
OWNER’S MANUAL
IMPORTANT DOCUMENT - DO NOT DISCARD
FOR COMMERCIAL USE ONLY
www.spraymastertech.com
MANUFACTURED DATE SHIPPED SERIAL NUMBER

2
Congratulations!
You have just purchased the best
spray washer on the market today.
It incorporates the very latest
in technological advances. To
assure you the best and safest
performance as well as longest
equipment life, please read the
enclosed information.
After reading the material in
this manual, should you need
assistance, please call customer
service at our toll free number
[phone] or [phone].
SPRAY MASTER SERVICE
Mon-Fri, 8:00 am - 5:00 am CST
[phone]
[e-mail]
Spray Master Technologies will repair or replace any originally
installed parts on the Power Clean series which are found
to be defective in material or workmanship for a period of
two (2) years and on the Power Clean Go series for a period
of one (1) year from the date of shipment to the original
purchaser, excluding items listed below. The defect must
occur during normal use of the product and within the length
of warranty coverage. The repair or replacement of that part
will be provided according to the time limits of the warranty
policy. Repairs must be completed using only Spray Master
Technologies approved parts.
EXCLUDED ITEMS
The following items are covered by the above warranty for
ninety (90) days from date of shipment:
Wear Items* - Spray guns, wands, hoses, nozzles, quick
couplers, Hummer Jet Sr. and Hummer Jet Jr. casters and
handles, check valves and chemical injectors.
The following items are covered by the above warranty for
1 year from the date of shipment:
Unloaders, Chemical Valves†
Electrical Components - float switch, temperature
switch, Solid-State Relay, Master Control Panel,
electronic injectors, wiring harnesses and flow
switch.
LABOR AND TRAVEL
Labor and travel to repair or replace defective parts shall be
covered for a period of 1 year from date of shipment. Labor and
travel for warranty wear items shall be covered for a period of
90 days.
ITEMS VOIDING WARRANTY
The following voids all warranty claims: Accidental breakage;
abuse; misuse; failures caused by incorrect installation if
not installed by authorized factory representative; failure
to correctly wire the system at the electrical source;
foreign items, chemical or mineral buildup in the pumps
and water lines caused by untreated or unfiltered tap, hard
or recaptured water; excessive hot water temperatures
exceeding 150˚ Fahrenheit; failures due to injecting bleach or
harsh or corrosive chemicals; not following Owners Operation
instructions; damage due to freezing temperatures; natural
disasters, electrical surges; and, tampering, aempted
repair by unauthorized service personnel, and not following
prescribed Preventive Maintenance Program.
*Wear Items Not Covered – O-rings, gaskets, filters. †O-rings,
gaskets, pulse pump diaphragm, check valves or failures due to
chemical damage are not covered by this Limited Warranty.
LIMITED WARRANTY
Spray Master Technologies®
Effective May 20, 2020

3
LIMITED WARRANTY >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
OWNER / USER RESPONSIBILITY >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
FIRST STEPS
Receiving Your Pressure Washer >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Returning Your Pressure Washer >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Pressure Washer Utility Requirements >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
What To Do For Service >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Model Identification >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
IMPORTANT SAFETY WARNING INSTRUCTIONS
Safety Warnings >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Ground Fault Circuit Interrupter (GFCI) Protection >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Grounding >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Extension Cords >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
OPERATING THE PRESSURE WASHER
User Operated Controls >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Pre-Operation Check >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Daily Maintenance >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Preparation for Use >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Operation >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Accessories >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
MAINTENANCE
General Maintenance >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Moving & Storage >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
CHEMICAL METERING
Chemical Metering Instructions >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
Manufacturer’s Recommended Dilution Chart >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>
OWNER / USER RESPONSIBILITY
The owner and/or user must understand the operating instructions and warnings before using this
pressure washer. Warning information should be emphasized and understood. Owner and operator
must study this manual and keep handy for future reference. The operator must know how to stop
the machine quickly and understand the operation of all controls. Never allow anyone to operate
the engine without proper instructions.
TABLE OF CONTENTS
POWER CLEAN GO 2.0 OWNER’S MANUAL
2
3
4
4
4
4
4
5
7
7
7
8
8
8
8
9
9
10
10
11
11

FIRST STEPS
POWER CLEAN GO 2.0 OWNER’S MANUAL
4
RECEIVING YOUR PRESSURE
WASHER
Damage: Check for damage in shipping. Report any
damage to the shipping carton or contents to the
freight carrier. File a claim with the carrier within ten
(10) days. Spray Master Technologies is not responsible
for damage to the equipment caused by the freight
carrier.
Package Contents: Carefully check the contents of
the shipping cartons to ensure the contents match
with the packing list. Please call our Customer Service
Department if items are missing at 1-800-548-3373 or
1-479-636-5776.
SAVE THESE INSTRUCTIONS!
This manual should be considered a permanent part of the machine and should remain with it. When
ordering parts, please specify model and serial number. Use only identical replacement parts. This
machine is to be used only by trained operators.
PRESSURE WASHER
UTILITY REQUIREMENTS
WATER
Flow Rate:
Minimum 5 GPM
Pressure:
30 PSI min. to 80 PSI max.
Temperature:
150° F max, 65.5° C
ELECTRICAL
Power Clean Go 2.0:
120V, 60Hz @20AMP
RETURNING YOUR PRESSURE
WASHER
Any item returned for warranty or for credit must have
a Returned Authorization Number. Call our Customer
Service Department to discuss your return request.
Please note that all items returned must be F.O.B.
Rogers, Arkansas. No collect or C.O.D. shipments will
be accepted unless prior arrangements have been made
with Customer Service. A restocking fee may be applied
to the items returned for credit that are not under
warranty.
WHAT TO DO FOR SERVICE
If a problem occurs, first refer to the Power Clean
Go 2.0 Service Manual in the “Trouble Shooting and
Diagnostics” section starting on page 38.
MODEL IDENTIFICATION
The model and serial numbers will be found on a decal on
the pressure washer. Please record these along with date
of purchase for future reference.
MODEL NUMBER
SERIAL NUMBER
PURCHASE DATE
SERVICE PHONE [phone]

IMPORTANT SAFETY
WARNING INSTRUCTIONS
POWER CLEAN GO 2.0 OWNER’S MANUAL
5
Indicates a hazardous
situation which, if not
avoided, could result in
death or serious injury.
Indicates a hazardous
situation which, if not
avoided, could result in
minor or moderate injury.
THIS IS THE SAFETY ALERT SYMBOL.
THIS SYMBOL ALERTS YOU TO
POTENTIAL HAZARDS THAT CAN
KILL YOU OR HURT YOU AND
OTHERS. ALL SAFETY MESSAGES
WILL FOLLOW THE SAFETY ALERT
SYMBOL AND THE WORD “DANGER”,
“WARNING”, OR “CAUTION”.
THESE WORDS ARE DEFINED AS:
Indicates a hazardous
situation which, if not
avoided, will result in death
or serious injury.
READ OPERATOR’S MANUAL
THOROUGHLY PRIOR TO USE.
Read the owner’s manual thoroughly. Failure to
follow instructions could cause malfunction of the
machine and result in death, serious bodily injury
and/or property damage.
1. Read these instructions before using the product.
2. To reduce the risk of injury, close supervision is
necessary when a product is used near children.
3. Know how to stop the machine and bleed pressure
quickly. Be thoroughly familiar with the controls.
4. Stay alert – Watch what you are doing.
5. Do not operate the product when fatigued or under
the influence of alcohol or drugs.
6. Keep operating area clear of all persons.
7. Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
8. Follow the maintenance instructions specified in
the manual.
9. For a grounded or double-insulated product rated
250 volts or less, single phase:
THIS PRODUCT IS PROVIDED WITH A
GROUND FAULT CIRCUIT INTERRUPTER
BUILT INTO THE POWER CORD PLUG.
IF REPLACEMENT OF THE PLUG OR
CORD IS NEEDED, USE ONLY IDENTICAL
REPLACEMENT PARTS.
SAVE THESE INSTRUCTIONS!

6
IMPORTANT SAFETY
WARNING INSTRUCTIONS
(Continued...)
POWER CLEAN GO 2.0 OWNER’S MANUAL
KEEP WATER SPRAY AWAY FROM
ELECTRICAL WIRING.
Keep wand, hose, and water spray away from
electric wiring or fatal electric shock may result.
To protect the operator from electrical shock, the
machine must be electrically grounded. It is the
responsibility of the owner to connect this machine to a
UL grounded receptable of proper voltage and amperage
ratings. Do not spray water on or near electrical
components. Do not touch machine with wet hands
or while standing in water. Always disconnect power
before servicing.
TRIGGER GUN KICKS BACK – HOLD WITH
BOTH HANDS.
Grip cleaning wand securely with both hands before
starting. Failure to do this could result in injury from a
whipping wand.
DO NOT SPRAY MACHINE, PEOPLE, ANIMALS
OR ELECTRICAL PARTS.
RISK OF EXPLOSION. DO NOT SPRAY
FLAMMABLE LIQUIDS.
»Do not allow acids, caustic or abrasive fluids to pass
through the pump.
»Never run pump dry or leave spray gun closed longer
than 1-2 minutes.
»Keep operating area clear of all persons.
RISK OF INJECTION OR SEVERE INJURY TO
PERSONS. KEEP CLEAR OF NOZZLE.
»To reduce the risk of injury, close supervision is
necessary when a machine is used near children. Do
not allow children to operate the pressure washer.
This machine must be attended during operation.
»Never make adjustments on machine while in
operation.
»Be certain all quick coupler fittings are secured
before using pressure washer.
SOME DETERGENTS MAY BE HARMFUL IF
INHALED OR INGESTED.
Some detergents may be harmful if inhaled or
ingested, causing severe nausea, fainting or
poisoning. The harmful elements may cause property
damage or severe injury.
PROTECTIVE EYE WEAR AND CLOTHING
MUST BE WORN.
High pressure spray can cause paint chips or other
particles to become airborne and fly at high speeds. To
avoid personal injury, eye, hand, and foot protection
must be worn when using this equipment.
Always wear properly-rated eye protection, such as
safety goggles or face shield, while spraying. (Safety
glasses do not provide full protections.)
RISK OF EXPLOSION – OPERATE ONLY
WHERE OPEN FLAME OR TORCH IS
PERMITTED.
Flammable liquids can create fumes which can ignite,
causing property damage or severe injury.

7
IF CONNECTED TO A POTABLE WATER
SUPPLY, PROTECT AGAINST BACK-FLOW.
PROTECT FROM FREEZING.
»To keep machine in best operating conditions, it
is important you protect machine from freezing.
Failure to protect machine from freezing could cause
malfunction of the machine and result in death,
serious bodily injury, and/or property damage. Follow
storage instructions specified in this manual.
»Inlet water must be clean fresh water and no hotter
than 150˚F.
»Manufacturer will not be liable for any changes made
to our machines or any components not purchased
from us.
»The best insurance against an accident is precaution
and knowledge of the machine.
RISK OF INJURY FROM FALLS WHEN USING
LADDER.
Be extremely careful when using a ladder, scaffolding
or any other relatively unstable location. The cleaning
area should have adequate slopes and drainage to
reduce the possibility of a fall due to slippery surfaces.
»Do not overreach or stand on unstable support. Keep
good footing and balance at all times.
»Do not operate this machine when fatigued or under
the influence of alcohol, prescription medications, or
drugs.
GROUND FAULT CIRCUIT
INTERRUPTER (GFCI) PROTECTION
This pressure washer is provided with a ground
fault circuit interrupter (GFCI) built into the plug of
the power supply. This device provides additional
protection from the risk of electric shock. Should
replacement of the plug or cord become necessary,
use only identical replacement parts from the factory.
Replace complete GFCI cord if the GFCI plug or cord is
damaged, frayed or worn.
EXTENSION CORDS
Use only 3-wire extension cords that have 3-prong
grounding type plugs and 3-pole cord connectors that
accept the plug from the products. Use only extension
cords that are intended for outdoor use. These
extension cords are identified by a marking “Acceptable
for use with outdoor appliances, store indoors while
not in use.” Use only extension cords having an
electrical rating not less than the rating of the product.
Do not use damaged extension cords. Examine
extension cord before using and replace if damaged.
Do not abuse extension cords and do not yank on any
cord to disconnect. Keep cord away from heat and
sharp edges. Always disconnect the extension cord
from the receptacle before disconnecting the product
from the extension cord.
Improper connection of the equipment grounding
conductor can result in a risk of electrocution.
Check with qualified electrician or service
personnel if you are in doubt as to whether the
outlet is properly grounded. Do not modify the
plug provided with the product – if it will not
fit the outlet, have a proper outlet installed by
a qualified electrician. Do not use any type of
adapter with this product.
TO REDUCE THE RISK OF ELECTROCUTION,
KEEP ALL CONNECTIONS DRY AND OFF THE
GROUND. DO NOT TOUCH THE PLUG WITH
WET HANDS.
GROUNDING
This product must be grounded. If it should
malfunction or breakdown, grounding provides a path
of least resistance for electric current to reduce the
risk of electric shock. This product is equipped with
a cord having an equipment grounding conductor
and a grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and
ordinances.

8
OPERATING THE
PRESSURE WASHER
POWER CLEAN GO 2.0 OWNER’S MANUAL
USER OPERATED CONTROLS
OFF/ON Switch:The power OFF/ON Switch is used to turn
the pump motor on and off as necessary for operation. The
OFF/ON Switch is located on the control panel located on
the handle of the unit.
Spray Gun: The spray gun assembly provides the
operator control of the flow, pressure, and pattern of the
high-pressure spray. Squeezing the gun trigger while
directing the spray nozzle toward the surface to be
cleaned operates the spray gun. Your spray gun may be
equipped with a dual nozzle or vari-nozzle.
»Dual Nozzle: The dual nozzle selector is used to select
either the low-pressure “soap” nozzle or the high
pressure “rinse” nozzle. Selection of the desired nozzle
must be made while the spray gun trigger is released.
To select the low-pressure nozzle, rotate the spray gun
90˚ counterclockwise so that the spray gun handle
is parallel to the ground with the hose connection
extending to the operators right, then squeeze the
trigger. To select the high-pressure nozzle, rotate the
spray gun 90˚ clockwise so that the spray gun handle
is parallel to the ground with the hose extending to
the operator’s left, then squeeze the spray gun trigger.
Once the nozzle has been selected and the spray gun
trigger held open, the spray gun may be rotated and
aimed at the surface.
»Vari-Nozzle: The vari-nozzle is used to select either
low-pressure “soap” or high-pressure “rinse”, and to
adjust the spray-pattern from a wide-angle spray to
a zero-degree stream. For high-pressure, pull the
nozzle-body firmly toward the spray-gun handle. To
select low-pressure, push the black nozzle body firmly
away from the spray gun handle. To vary the spray
pattern of the nozzle, twist the black nozzle body
clock ways to narrow pattern and counter clock ways
to widen the spray pattern.
Chemical Metering:The chemical metering knobs are
located on the control panel located on the handle of the
unit. Turning the knobs counter clockwise will increase
the flow of chemical selected. Turn knob to the off
position when chemical is not desired. Chemical is drawn
from included chemical containers and must be filled if
chemical is selected. Please refer to the Chemical Dilution
Chart at back of this Owner’s Manual.
PRE-OPERATION CHECK
»Perform the pre-operation daily maintenance check
prior to operating the unit to ensure safe operation
and prolonged equipment life.
»Read safety, operation, and maintenance instructions
before starting machine.
DAILY MAINTENANCE
»Check oil level. Fill to center of sight glass. See “Oil” in
General Maintenance Section.
»Check to see that the GFCI power cord is in good
condition. Replace complete GFC cord assembly if
either the GFCI, plug or cord is damaged, frayed or
worn. Test the GFCI circuit weekly by pressing the
TEST button on the GFCI. Reset the GFCI after test by
pressing the RESET button on the GFCI.
»Hoses – Check hoses for breaks and damaged fittings.
Replace as needed.
»Spray Gun – Check spray gun for damaged fittings,
nozzle, and trigger. Replace as needed.
PREPARATION FOR USE
»Verify that the surface or equipment to be cleaned can
withstand the high-pressure spray.
»Wear safety googles or other approved eye protection
when cleaning with high-pressure spray washers.
»Check with your Safety Representative for other
Personnel Protective Equipment (PPE) that may be
required for the job being performed.
»Clear area of slip or trip hazards. Keep area clear while
cleaning.
»Ensure the OFF/ON switch is set to the “OFF” position.
»Attach high-pressure hose to discharge nipple with
quick coupler. Lock quick coupler in place by pulling

9
back coupler collar and inserting it into the discharge
nipple then pulling back on coupler collar to lock into
place.
»Attach spray gun to hose.
»Attach water supply hose to the water supply.
»Verify that the GFCI power cord/plug if equipped is fully
inserted into the electrical receptacle or that the power
cord is fully seated in a GFCI protected outlet. Press
reset button on the GFCI.
»If using a cleaning chemical, ensure chemical
containers are full prior to use.
»This machine will siphon chemical and mix with water
at the Venturi Injector.
OPERATION
»Turn the water on at the supply valve.
»Firmly grasp spray gun.
»Point the spray gun in safe direction.
»Flip the OFF/ON switch to “ON
»Direct the spray gun nozzle toward the surface or
equipment to be cleaned and squeeze the spray gun
trigger. (Note: Use low-pressure for SOAP application
and high-pressure for RINSE.)
»If using a cleaner, priming will best occur by turning the
chemical metering dial counterclockwise to open all
the way. Turn clockwise after cleaner starts to flow till
you get the desired ratio. If using a thick cleaning agent
then first prime with water and switch to cleaner after
primed.
»Apply chemical solution on low-pressure to the surface
or equipment to be cleaned and let soak according to
the instructions for the chemical you are using.
»Use high-pressure spray to rinse the surface or
equipment being cleaned. Rinse thoroughly.
»Upon completion of the cleaning job, flush the chemical
from the chemical injector by rotating the chemical
metering dial fully clockwise to the flush position.
Operate the spray gun on low-pressure for one minute.
»Turn the OFF/ON switch to “OFF”.
»Squeeze the spray gun trigger to release system
pressure. Hose and spray guns cannot be
disconnected while the system is pressurized.
»Disconnect and store all equipment.
ACCESSORIES
The accessories listed below are available for use
with your Spray Master Technologies high-pressure
cleaning system.
»Hummer Jet™ Jr. – Indoor floor surface cleaner.
Focuses high-pressure spray in centralized area
for thorough cleaning. Reduces misting and over
spray.
»Dual-Nozzle Spray Gun – Single spray gun unit
designed to quickly change from low pressure
soap to high pressure rinse with the flip of a
wrist.
»Vari-Nozzle Spray Gun – Single spray gun unit
designed to quickly change from low pressure
soap to high pressure rinse by a simple push/
pull on the nozzle head.
»Tornado Spray Gun – High impact spray gun
used to focus on small trouble areas.
»Foamer Gun – Specialized low-pressure spray
gun that foams cleaning chemicals. Ideal for
soak operations.
»6” Shorty Spray Gun – Specialized spray gun for
tight spots.
»Wall and Tile Brush – 10” scrub brush hooks up
to pressure hose and enables soap and rinse
features.
»Trap Shooter – Specialized spray gun for
cleaning drains and interior of containers.

10
MAINTENANCE
POWER CLEAN GO 2.0 OWNER’S MANUAL
MOVING & STORAGE
Moving:Spray Master Power Clean Go units are portable
spray washers.
Storage:Store Spray Master equipment and accessories
indoors and so that they do not present a trip or fall hazard.
When storing Spray Master units for extended periods or in
freezing conditions, store indoors.
Protect From Freezing: Store Power Clean Go pressure
washers inside where temperature is above freezing.
GENERAL MAINTENANCE
Oil: Add oil to the pump reservoir as needed to keep the
oil level at the center of the oil-level sight glass between
the arrows. Check oil level with the machine “OFF”.
»First oil change must be done at 50 hours of
operation.
»Follow-on oil changes must be done every 3 months
or after 500 hours of operation.
»Use ISO-68 non-detergent hydraulic oil only.
Use of any other type of oil will VOID warranty and may
damage the pump. Oil may be purchased from Spray
Master by calling 800-548-3373 or 479-636-5776.
Chemical Foot Screen: Flush the chemical foot screens
and injector with warm water to remove chemical buildup
that can restrict water flow.
»Remove the chemical pickup tube with foot screen
from the chemical supply and submerse in warm
water.
TO PREVENT DAMAGE TO THE PUMP, DO
NOT RUN THE PUMP AFTER THE UNIT HAS
BEEN EMPTIED.
IF YOUR SYSTEM IS USED TO CLEAN FOOD-
PROCESSING EQUIPMENT, CONSULT YOUR
CHEMICAL SUPPLIER FOR ANTI-FREEZE
THAT IS SUITABLE FOR THAT APPLICATION.

11
CHEMICAL METERING
POWER CLEAN GO2.0 OWNER’S MANUAL
CHEMICAL METERING
INSTRUCTIONS
The chemical dilution chart below display’s ounces of
chemical per gallon of water.
Follow the steps below to calculate and adjust the chemical
dilution for a Spray Master cleaning system.
»Find your pump GPM rating on the left side of the chart.
»Follow the row identified in Step 1 to the right until
you find the column heading with the chemical
manufactures ounces per gallon to be injected into the
water.
»The value at the point where the row, Step 1, and the
column, Step 2, intersect is the duration of time, in
seconds, it should take for the Spray Master system to
draw 5 ounces of chemical.
»Example: The 2.1 gallon per minute (GPM) pump used to
apply a chemical requiring a mix ration of 4 ounces per
gallon will need to inject 5 ounces of chemical over a 36
second period.
»Fill a measuring cup, graduated in ounces, with the
chemical to be injected and submerge the chemical
pick-up tube with the foot screen into the chemical.
»Turn the pump ON and set it to inject chemical.
»Adjust the chemical metering device so that 5 ounces of
chemical is injected in the duration of time identified in
Step 3.
Failures due to bleach or injecting harsh or
corrosive chemicals in non-compatible equipment
will void the warranty.
CHEMICAL MANUFACTURERS RECOMMENDED OUNCES PER GALLON (OZ/GAL.)
1/4 1/2 1 2 3 4 5 6 7 8 OTHER DILUTIONS USE
PUMP
FLOW
(GPM)
2.1 571 286 143 71 48 36 29 24 20 18 143 / (Oz per Gal.)
2.6 462 231 115 58 38 29 23 19 16 14 115 / (Oz per Gal.)
3.0 400 200 100 50 33 25 20 17 14 13 100 / (Oz per Gal.)
3.6 333 167 83 42 28 21 17 14 12 10 83 / (Oz per Gal.)
Time in Seconds to Draw Five (5) Ounces of Chemical
NOTE: Check the chemical metering regularly to ensure
accurate chemical dispensing.

© 2020 Assembled Products Corp, Inc. | 190122_SMT_2.0_PCG-OM_EN Rev 00
115 Linden St. • Rogers, AR 72756 USA • [phone]
