Spraying Systems 1550+ AutoJet User manual

Model 1550+ AutoJet
Modular Spray System
Owner’s Manual
Note:
 This manual covers the complete Model 1550+ Modular Spray System and all its versions, configurations and options. Your system
may vary based on the version, configuration and options that you have purchased.
 Pictures in this manual may include options which are not part of your System Configuration.
 Statements in this manual may describe options which are not part of your System Configuration.
 Pictures in this manual may represent components which are different than those in your System Configuration.
 Statements in this manual may describe components which are different than those in your System Configuration.
 The manufacturer reserves the right to make changes in this standard system without notification.
spray.com
ML001550PLUS v5
Read this manual carefully before operating your Modular Spray System.
Keep this manual for reference when the system is in operation.
All safety related, and operating instruction should always be followed.

2
CONTENTS
CONTENTS .................................................................................................................................................................................... 2
WARNING LEGEND....................................................................................................................................................................... 5
READ AND FOLLOW INSTRUCTIONS ................................................................................................................................................... 5
WARNINGS ................................................................................................................................................................................. 5
INTRODUCTION ............................................................................................................................................................................ 6
PRODUCT FEATURES & SPECIFICATIONS ............................................................................................................................................ 6
STANDARD COMPONENTS: ............................................................................................................................................................. 9
COMPONENTS USED TO CREATE CONFIGURATIONS ........................................................................................................................... 10
OPTIONAL COMPONENTS REQUIRED FOR A COMPLETE SPRAY SYSTEM .................................................................................................. 10
SAFETY INFORMATION .............................................................................................................................................................. 10
GENERAL SAFETY INFORMATION .................................................................................................................................................... 10
WARNINGS ............................................................................................................................................................................... 10
INSTALLING THE SYSTEM ........................................................................................................................................................... 11
UNPACK THE COMPONENTS ......................................................................................................................................................... 11
POSITION OR MOUNT THE SYSTEM ................................................................................................................................................ 12
ELECTRICAL CONNECTIONS ........................................................................................................................................................... 14
AIR AND LIQUID CONNECTIONS ..................................................................................................................................................... 18
MOUNTING SPRAY NOZZLES ...................................................................................................................................................... 20
NOTES ON NOZZLE LOCATION ....................................................................................................................................................... 20
SYSTEM OPERATION .................................................................................................................................................................. 21
START UP .................................................................................................................................................................................. 21
PRIMING THE PUMP (PUMP VERSION ONLY) ................................................................................................................................... 22
HMI OPERATION - SET SPRAY PARAMETERS ............................................................................................................................. 23
HMI ........................................................................................................................................................................................ 23
PASSWORD SETTINGS .................................................................................................................................................................. 31
SPRAY INSTRUCTIONS SIMPLIFIED: ............................................................................................................................................ 32
TIMING MODES ......................................................................................................................................................................... 32
SETUP SCREEN. .......................................................................................................................................................................... 33
FIXED SPRAY TIME ...................................................................................................................................................................... 33
VARIABLE SPRAY TIME ................................................................................................................................................................. 35
REPEAT .................................................................................................................................................................................... 37
MANUAL TRIGGER ...................................................................................................................................................................... 39
DUTY CYCLE PERCENTAGE ......................................................................................................................................................... 40
SETTING DUTY CYCLE PERCENTAGE – USING PWM .......................................................................................................................... 40
USING THE RECIRCULATION FEATURE ....................................................................................................................................... 41

3
RECIRCULATION ......................................................................................................................................................................... 41
SETTING THE RECIRCULATION FLOW FOR THE SYSTEM ........................................................................................................................ 42
SPECIFICATIONS ......................................................................................................................................................................... 43
STANDARD ENVIRONMENTAL SPECIFICATIONS: ................................................................................................................................. 43
CONSTRUCTION DETAILS: ............................................................................................................................................................. 43
SYSTEM SPECIFICATIONS: ............................................................................................................................................................. 43
PUMP SPECIFICATIONS .............................................................................................................................................................. 45
EXTERNAL INPUT OFFERINGS .................................................................................................................................................... 46
TRIGGER CABLE OFFERING......................................................................................................................................................... 47
REQUIRED INPUT: ....................................................................................................................................................................... 47
ASSEMBLY SPECIFICATIONS: .......................................................................................................................................................... 47
OPTIONAL TRIGGERING OFFERINGS .......................................................................................................................................... 49
PHOTOELECTRIC OBJECT SENSOR ................................................................................................................................................... 49
THRU BEAM SENSOR ................................................................................................................................................................... 50
PROXIMITY SENSOR KIT ............................................................................................................................................................... 50
LASER SENSOR (SHORT DISTANCES) SENSOR KIT ............................................................................................................................... 51
LASER SENSOR (LONG DISTANCES) SENSOR KIT ................................................................................................................................. 51
HAND HELD PENDANT ................................................................................................................................................................. 51
FOOT SWITCH ............................................................................................................................................................................ 51
OPTIONAL INPUT SIGNAL OFFERING ......................................................................................................................................... 52
ASSEMBLY SPECIFICATIONS: .......................................................................................................................................................... 52
OPTIONAL ELECTRIC NOZZLE CORD SET OFFERING ................................................................................................................... 53
FAULT OUTPUT SIGNAL ............................................................................................................................................................... 54
ASSEMBLY SPECIFICATIONS: .......................................................................................................................................................... 55
EXTENSION CABLE ...................................................................................................................................................................... 56
LEVEL SWITCH CABLE KIT ............................................................................................................................................................. 56
ASSEMBLY SPECIFICATIONS: .......................................................................................................................................................... 57
TROUBLESHOOTING................................................................................................................................................................... 60
FAULTS ....................................................................................................................................................................................... 63
HMI COMMUNICATION FAULT ..................................................................................................................................................... 64
RE-CALIBRATING THE HMI ........................................................................................................................................................... 65
RECOMMENDED SYSTEM MAINTENANCE ................................................................................................................................. 67
PNEUMATIC CONTROLS ............................................................................................................................................................... 67
LIQUID CONTROLS ...................................................................................................................................................................... 67
SPRAY NOZZLES ......................................................................................................................................................................... 67
SPARE PARTS LIST ...................................................................................................................................................................... 68
RECOMMENDED & OPTIONAL SPARE PARTS .................................................................................................................................... 68

4
WARRANTY INFORMATION ....................................................................................................................................................... 73
DATA SHEETS - PUMP VERSIONS ............................................................................................................................................... 74
DATA SHEETS – PUMP LESS VERSIONS ...................................................................................................................................... 77
DATA SHEETS – PRESSURE POT VERSIONS................................................................................................................................. 80
CONTROL PANEL ONLY VERSION ............................................................................................................................................... 84
NOTES ........................................................................................................................................................................................ 85
Manual Version No.
Description of
Change
Date
1 Original release of second generation system 2010
2 Update – HMI release 2012
3 Update – minor functionality improvements 2016
4 Update – System minor redesign, improved maintenance and connections 2018
5 Update – new regulator packages 2020

5
WARNING LEGEND
Read and follow instructions
All safety related, and operating instructions should be read before the system is operated.
Follow all operating instructions.
Warnings
Red warning denotes a critical note regarding safety
The User can be injured (seriously) or his health can be damaged.
Or the Machine can be seriously damaged
Yellow warning denotes an issue to be heeded. Ignoring this warning note can result in damage to the unit, injury to an
individual.
Blue warning denotes supplementary information for the user:
Drawing attention to possible problems

6
INTRODUCTION
The Model 1550+ AutoJet Modular Spray System featuring an HMI Touch Screen Display is a self-contained,
electronic/pneumatic panel that provides control of various aspects of a spray system. These systems come in a variety of
design configurations depending on the requirements of your spray application, therefore, you may or may not have all the
features described in this owner’s manual.
Product Features & Specifications
The Spraying Systems Co. 1550+ AutoJet Modular Spray System is a self-contained unit that can provide you with precise
liquid delivery and spray nozzle control in an affordable easy to use turn-key spray system. The system comes in a variety of
designs and configurations based on the type of spray nozzle used in your application.
The system can be used with water, oils, lubricants, inks, stains, water-based solvents, non-abrasive slurries. The system is
designed to spray most non-flammable or non-volatile materials. Liquids and materials that flow with viscosities below
1000 cP at 68° F (20° C) can be sprayed with the correct spray nozzle and controlled with this unique spray system solution.
System Usage
 The 1550+ AutoJet Modular Spray System is designed to run continuously or intermittently.
 The 1550+ AutoJet Modular Spray System features a high-quality HMI Touchscreen interface.
 System can control spray timing.
 Customer can set spray period, start delay and stop delay times.
 The controller is designed to run both electric and air actuated spray nozzles.
 Can drive Spraying Systems Co. electric spray nozzles (3 amps. max.) with Pulse Width Modulation (PWM).
Specifically, the PulsaJet® spray nozzle line and the AA250AUH Electric spray nozzles can be used.
 PWM (Pulse Width Modulation) is a technique used to control flow rate by rapidly pulsing the
nozzle on and off. PWM uses a duty cycle within the spray time. By definition duty cycle is the
percent of time of the total cycle time the nozzle is spraying. If the nozzle is spraying 50% of the
time, the DC is 50% thus the flow is ½ that if the nozzle being fully open.
Platform Configu ration
 The 1550+ AutoJet Modular Spray System is available in the following versions which are available in both
English and Metric connections:
 1550+ Pump Version - features a durable air operated diaphragm pump for continuously run spray
applications.
 This design requires liquid to be drawn from a tote or a tank.
 This version is designed to re-circulate liquid from the system back to the supply tote or tank.
 1550+ Food Contact Pump Version – features food-contact wetted components (pump, liquid
regulator, gauges, tube fittings, etc.).
o Note this version does not qualify under EC 1935/2004
 1550+ Pump Less Version - for applications were the systems liquid delivery is provided by a pressurized
vessel or other pressurized supply from the customer. The Pump Less system controls the flow of liquid
using an internal air piloted liquid pressure regulator. The liquid passes through this which is located
inside the Valve Panel.
 1550+ Food Contact Pump Less Version – features food-contact wetted components (liquid
regulator, gauges, tube fittings, etc.).
o Note this version does not qualify under EC 1935/2004

7
 1550+ Pressure Pot Version – for applications were the fluid is supplied by pressurized vessel and the
system controls the air pressurizing the vessel. The Pressure Pot version controls the flow of the liquid by
using an air regulator to pressurize the pot. The liquid flows from the pot and does not flow through the
systems Valve Panel.
 1550+ Electrical Control Panel Only Version - for electric spray nozzle applications where the customer
will supply the liquid delivery portion of the system.
 The full system versions are equipped with electric valves, manual pressure regulators and gauges to control:
 Pneumatic nozzle actuation.
 Liquid spray pressure and recirculation rate.
 The 1550+ AutoJet Modular Spray System comes in the following configurations:
 Configuration 1: Liquid and cylinder air – for automatic hydraulic or electric spray nozzles.
Pump Less version, configuration 1, shown.
 Configuration 2: Liquid with cylinder and atomizing air – for automatic air atomizing spray nozzles.
Pressure Pot version, configuration 2, shown.

8
 Configuration 3: Liquid with cylinder, atomizing and fan air – for SSCo. VAU and VMAU spray nozzles.
Pump version, configuration 3, shown.
HMI Control Panel Specifications
 4.3” HMI Touch Screen display unit featuring custom programming.
 UL Type 1, stainless steel control panel.
o Not explosion proof (Non-Ex).
 Power ON/OFF switch with Power on LED indicator light.
 Power input 110-240VAC, 50/60 1 ph., 5A.
o Global compatibility Multi-voltage power cords available
 Output 24 Vdc
o 3 amps dedicated to electric spray nozzles and sensors
 Inputs for 1 analog inputs, 2 digital inputs and 1 digital output.
 Features local and remote triggering options.
 Can control and drive up to eight (8) Spraying Systems Co. electric spray nozzles
o AA10000AUH-03 PulsaJet® spray nozzles – Eight (8)
o AA10000JJAU PulsaJet air atomizing spray nozzles – Eight (8)
o AA10000AUH-10 PulsaJet spray nozzles – Three (3)
o AA10000AUH-30 PulsaJet spray nozzles – One (1)
o AA250AUH Electric spray nozzles - Eight (8)
 Digital output for air atomizing solenoids.
 Offers dual digital inputs for conveyor interlock type trigger.
 Independent timing ranges for spray and delay adjustable from 0 to 9999 seconds.
 Delays for atomizing air (anticipator and follower times) can be set 0 to 60 seconds.
 0 – 100% duty cycle adjustment for PulsaJet and other electric spray nozzles.
 Offers easy to use timing modes of Fixed Spray Time; Variable Spray Time, and Repeat.
 Power cord, 6 ft. (2m) length.
 Ambient temperature ratings for electric control panel:
o 41° F Minimum (5°C)
o 104° F Maximum (40°C)
Enclosure and Process Components
 Air piloted liquid pressure regulator.
 Externally mounted liquid strainer with 100 mesh filter.
 1/2” NPT female inlet for compressed air feed - 100 psi (7 bar) max. – English connections
o 1/2” BSPT female inlet for compressed air feed - 7 bar (100 psi) max. – Metric connections
 1/2” O.D. tube inlet and outlet connections for air and liquid - English
o 12 mm O.D. tube inlet and outlet connections for air and liquid - Metric
 1/4” O.D. tube cylinder air outlet - English

9
o 6 mm O.D. tube cylinder air outlet - Metric
 Pressure regulator with gauge for liquid pressure.
 Pressure regulators with gauges for atomizing air, and fan air.
 Materials of construction
o For air lines: Nickel plated brass, brass, coated aluminum, and Nylon.
o Wetted components
 Pump version
 PVC, stainless steel, Polypropylene, PTFE, nickel plated brass, Viton®, Nitrile and Nylon
for liquid lines
 Food Contact Pump version
 Food Contact Acetal, stainless steel, PTFE, Viton®, FKM and Polyethylene for liquid lines
 Pump Less version
 PVC, stainless steel, Polypropylene, PTFE, nickel plated brass, Viton®, Nitrile and Nylon
for liquid lines
 Food Contact Pump Less version
 Food Contact Acetal, stainless steel, Viton®, FKM and Polyethylene for liquid lines
 Pressure Pot Version
 Stainless steel
Liquid Delivery Component s
Pu mp - St a nd ard and Sta in less St eel
 Double diaphragm air operated pump
 2 gpm liquid @ 40 psi (7.57 l/min @ 2.75 bar) rating based on water
o Less with higher viscosities
Pr e ssu re Pot - Opti ona l fo r Pu mp L ess & Pre s su re Pot V e rs io n s
 Stainless steel pot with stainless steel fittings and accessories.
 Sizes:
o 1 gallon (3.8 liters)
o 2 gallons (7.6 liters)
o 5 gallons (9 liters)
o 10 gallons (38 liters)
o 16 gallons (61 liters)
Standard Components:
Standard on all designs except the Panel Only version of the Model 1550+ Modular Spray System spray system are the
following components:
 Electrical Control Panel w/ HMI
 Air Shut off/Lock out and Filter Unit
 System Frame, stainless steel
 Liquid Filtration Unit
 Air piloted liquid pressure regulator – Not included on Pressure Pot version
 Air solenoid valve for controlling cylinder air
 Power Cord
 Trigger Device – The system must be triggered in a production environment. Therefore, it can use one of the
following options:
o Local on/off button on HMI.
o Trigger cable – to connect customer provided signal
o Object sensor
o Thru beam sensor
o Laser sensor
o Short distance laser sensor

10
o Hand held pendant trigger
Components Used to Create Configurations
 Air regulator to control liquid pressure
 Air regulator and solenoid valve for controlling atomizing air
 Air regulator and solenoid valve for controlling fan air
 Air Piloted Fluid Regulator – Not part of the Pressure Pot version
Optional Components Required for a Complete Spray System
 Spray nozzles with spray tips or spray set ups
 Spray nozzle mounting kits
 Spray nozzle hook-up kits
Safety Information
General Safety Information
Read and follow instruction s
All safety related, and operating instructions should be read before the system is operated. Follow all operating
instructions.
Note: If the Model 1550+ AutoJet Modular Spray System is used in a manner other than as described in this Manual,
protection afforded by the equipment may be impaired.
Water and Moisture
The control panels are rated NEMA 1, unless otherwise specified. The rating is only with the door closed and properly
locked. Being NEMA 1 rated, the control panels can withstand streams of water directed at them; however, we
recommend avoiding spraying on the unit externally if possible. The control panel is not washdown rated.
Servicing
For servicing of valves and pumps please refer to the appropriate manuals.
Do not attempt to service the 1550+ Modular Spray System Electrical Control Panel.
 For service, contact your local Spraying Systems Co. sales representative by calling
1-800-95-SPRAY (1-800-957-7729)
 For corporate support contact 1-866-321-2250.
 Only authorized qualified service personnel should attempt to service the Control Panel.
o Service by unauthorized personnel will void all warranties.
Replacement Parts
The 1550+ AutoJet Modular Spray System has been designed with components that work together to provide the best
system performance. When the system requires replacement parts, contact your local sales engineer, only Spraying
Systems Co. recommended components should be used to maintain proper system operation and safety.
Warnings
WA RNIN G: It is important to recognize proper safety precautions when using a pressurized spray system. Fluids under
pressure can penetrate skin and cause severe injury.
WA RNIN G: When dealing with pressure applications, the system pressure should never exceed the lowest rated
component. Always know your system and all component capabilities, maximum pressures and flow rates.

11
WA RNIN G: Before performing any maintenance, make sure all electrical, air and liquid supply lines to the system are shut
off and /or disconnected.
WA RNIN G: The use of any chemicals requires careful control of all worker safety.
WA RNIN G: Spraying Systems Co. does not manufacture or supply any of the chemical components used in this equipment
and is not responsible for their effects. Because of the large number of chemicals that could be used and their different
chemical reactions, the buyer and user of this equipment should determine compatibility of the materials used and any of
the potential hazards involved.
WA RNIN G: Spraying Systems Co. strongly recommends the use of appropriate safety equipment when working with
potentially hazardous chemicals.
This equipment includes but is not limited to:
 Protective hat
 Safety glasses or face shield
 Chemical-resistant gloves and apron
 Long sleeve shirt and long pants
WA RNIN G: Always remember to carefully read the chemical manufacturer’s label and follow all directions.
Installing the System
Unpack the Components
The system components come carefully packaged to protect them from damage and consist of the enclosure, which
contains the electronic and pneumatic controls, plus a separate box which contains accessories. Open all boxes! Check
inside every box for various components.
All units include the following accessories:
o Electrical power cord - installed on unit
o Air supply lockout valve/filter unit (not with Panel Only version)
o Liquid strainer (not with Panel Only version)
o Liquid re-circulation fitting (not with Pressure Pot or Panel Only versions)
Depending on your system configuration, the following additional accessories may be included:
o Trigger input cable(s)
o Photoelectric object sensor with cable and bracket
o Thru beam sensor with cables and brackets
o Hand held trigger switch
o Input signal cable for remote Duty Cycle control
o Fault output cable kit
o PulsaJet® nozzle or electric spray nozzle connector cable(s)
o Spray nozzle(s)
o Spray nozzle hook up kit
Please check the packaging slip for confirmation of contents and quantity of packages. Pump less and Pressure Pot versions
sold with a pressure pot will be shipped in multiple packages.
NO TE: The packing boxes may contain exposed cables and hoses. Always use caution when opening the boxes to avoid
accidental damage or slicing of various components.
Remove everything from all of the boxes and carefully remove any packaging material protecting the components.
Caution should be used when using a knife to cut the packaging. Be careful not to cut through and scratch the panel.
Verify that the accessories required for your specific system configuration are included. Check all boxes and any packing
materials for parts and components. If anything is missing, or if there are any questions, contact Spraying Systems Co.
Customer Service immediately.

12
Position or Mount the System
Find a convenient location for the Model 1550+ AutoJet Modular Spray System within a reasonable distance of your spray
application. Additionally, the system should be located within a reasonable distance to an easily accessible and properly
grounded power outlet. The unit must be installed in such a manner that when the cord is connected, the plug can be
easily reached and not difficult to remove it from the outlet.
Determine if the unit will be free-standing or wall mounted.
The unit may be wall mounted by using the keyholes near the top of the enclosure back plate. If the unit is to be wall
mounted, install wall anchors that are designed to support at least 200 lbs. (90.7 kg) according to the anchor manufacturers
specifications.
The mounting holes are on 8” centers and are made for 5/16” (8 mm) screws with ½” (12 mm) diameter screw heads.
Secure the Model 1550 to its selected location.
Note: If it is a system with a pump, keep the pump close to the liquid level in the tote. Keep suction level to a maximum of
5 feet (1.5m).
Note: For safety the unit should be removed from the wall to perform any maintenance or repair.

13
Control Panel Only Version
IF you have the Control Panel Only version the unit should be wall mounted.
Install wall anchors that are designed to support at least 50 lbs. (90.7 kg) according to the anchor manufacturers’
specifications.
The mounting holes are on 5 7/16” centers and are made for 1/4” (6 mm) screws with 3/8” (10 mm) diameter screw heads.
Secure the Model 1550+ to its selected location.
Mount the Air Supply Lockout Valve/F ilter Unit
o The included air supply lockout valve/filter unit must be connected to the 1550+ AutoJet Modular Spray System.
(not applicable for Control Panel only version)
o The lockout valve/filter unit can be mounted to the system or mounted to your air line directly. If so desired for
your convenience.
o Locate the connection bulkhead fitting on the right side of the system's valve panel/enclosure.
 Locate the “AIR IN” threaded inlet.

14
 The inlet is 1/2” NPT (F) [1/2” BSPT (F) for Metric versions]. Connect the air supply lockout valve/filter
unit to the Air Inlet connection of the manifold using supplied ½” pipe nipple.
Electrical Connections
Full System Versions
The electrical connections for the system are all conveniently located on the right-hand side of the frame. The
connections are as follows.
External electrical connection location
Direction of flow
If your inlet filter assembly looks like this,
you can set the maximum pressure to the
system by using the built-in regulator and
gauge. Set to a recommend ed range
between 40 to 80 PSI (2.75 to 5.5 bar).
NOTE: Setting pressure higher than this will
damage the system.
Direction of flow
If your inlet filter assembly looks
like this, you must regulate the
air going to the system with your
own regulator. Set to a
recommend ed range between 40
to 80 PSI (2.75 to 5.5 bar).
NOTE: Setting pressure higher
than this will damage the system.

15
 Power input connection, route power cord through oval opening on right-hand side of frame and plug in 120VAC
outlet rated for at least 5A.
From bottom to top.
 Remote current “4-20 mA” analog input connections.
o To be connected if using remote set point PWM controls, (analog 4-20mA).
o M8 (F) 4 pin connection.
 Electric spray nozzle output connection “Main” electric spray nozzle connection.
o M12 (F) 4 pin connection.
 Trigger input connections “Trig”
o For remote triggers or digital sensor inputs, connected at installation
o Follow the installation instructions for the sensor you have.
o M12 (M) 4 pin connection.
 Trigger interlock connection “T. int.”.
o M8 (M) 4 pin connection.
o Used when a secondary run signal is required.
Control Panel Only Versions
All the connections are the same as the full system. Located on the bottom of the panel the connections are as follows.
 Power input connection, route power cord through oval opening on right-hand side of frame and plug in 120VAC
outlet rated for at least 5A.
 4-20 mA - Analog input is accessible through this connection.
 Main - Output is the connection for all electric spray nozzles or cylinder/atomizing air solenoids and fault output.
 Trig - Is the input connection for the system trigger or sensor.
 Aux - Is the output connection for the atomizing and fan air solenoids. This is typically not used in this
configuration, since solenoids are not provided.
 T. int. – Used for the optional trigger interlock or level switch input.

16
Full Version Internal Electrical Connections
The full version system is designed with a wire harness to bring the connections typically used by the customer to an easily
accessible point. The Aux connection is not on the external panel. If you need to access it for trouble shooting or
maintenance, it is accessible through either of the two removable access panels.
Bot tom V iew o f Cont ro l Pa nel Con nect io ns:
Full System version
Control Panel Only version

17
External Device Connections for Control Panel O nly
Connections from left to right are the following:
 4-20 mA - Analog input is accessible through this connection. M8 (F) connection.
 Main - Output is the connection for all electric spray nozzles or cylinder/atomizing air solenoids and fault output. M12
(F) connection.
 Trig - Is the input connection for the system trigger or sensor. M12 (M) connection.
 Aux - Is the output connection for the atomizing and fan air solenoids. M8 (F) connection.
 T. int. – Used for the optional trigger interlock or level switch input. M8 (M) connection.
 If a trigger cable is included (P/N LE00M12F5M, note this cable is M12 female 4 pin to bare leads), wire the
non-terminated end to the user-provided signal source (e.g. photoelectric sensor, limit switch, PLC, relay, etc.)
and connect the cable to the trigger [Trig. M12 (M)] input connection of the control panel.
 If the photoelectric sensor is included (Kit P/N 040TS04000014W0), mount the sensor in a location where it
will be able to sense the leading edge of the object to be sprayed and connect the cable to the trigger input
[Trig. M12 (M)] connection of the control panel.
 If the thru beam sensor is included (Kit P/N 040TS04000028W0), mount the sender and receiver in a location
where they will be able to sense the leading edge of the object to be sprayed and connect the cable to the
trigger input [Trig. M12 (M)] connection of the control panel.
 If one of the laser sensors are included (Kit P/N 040TS04000087W0 or 040TS04000135W0), mount the sensor
in a location where it will be able to sense the leading edge of the object to be sprayed and connect the cable
to the trigger input [Trig. M12 (M)] connection of the control panel.
 If the proximity sensor is included (Kit P/N 040TS04000118W0), mount the sensor in a location where it will be
able to sense the metallic object to be sprayed (less than 10mm) and connect the cable to the trigger input
[Trig. M12 (M)] connection of the control panel.
 If the Hand Trigger is included (Kit P/N SW001550M12HT), connect the cable to the trigger input [Trig. M12
(M)] connection of the control panel.
 If PulsaJet® or other automatic electric actuated spray nozzles are used, and an output cord set is included,
connect the output cord set cable to the [Main M12 (F)] output connection of the control panel. The (Main)
output connection is also used for driving the cylinder air solenoid valve used with automatic air actuated
spray nozzles like the 1/4JAU or the AA10000JJAU.
 NO TE: All systems ship with cylinder air solenoid wire plugged into a splitter wired to (Main) output.
Possible External Devices going to controller – cables, sensors, etc.
Description Connects To Part Number
Trigger Cable – Flying leads - 16.4’ (5m) length Trig. LE00M12F5M
Hand Pendant Trigger - 16.4’ (5m) length Trig. SW001550M12HT
Foot switch - 16.4’ (5m) length Trig. 040TS04000130W0
Object Sensor - Photoelectric - 16.4’ (5m) length with mounting bracket Trig. 040TS04000014W0
Object Sensor - Thru Beam - 16.4’ (5m) length with mounting bracket Trig. 040TS04000028W0
Object Sensor – Laser short dist. - 16.4’ (5m) length with mounting bracket Trig. 040TS04000135W0
Object Sensor – Laser long dist. - 16.4’ (5m) length with mounting bracket Trig. 040TS04000087W0
Object Sensor – Proximity - 16.4’ (5m) length with mounting bracket Trig. 040TS04000118W0
Sensor Extension Cable – Connector - 16.4’ (5m) length M12FxM12F, 4 pole Trig./Main LEXXSD4FD4F0050
Nozzle extension cable – connector 16.4’ (5m) length M12(f)xM12(m), 4 pole Main LEXXSD4FD4M005P
4-20mA Input Signal Cable - 16.4’ (5m) length, M8 male x bare leads, 4 pole 4-20mA LE00M8M5M
Trigger Interlock Cable, M8 Female, 4 pole, bare leads, 16.4’ (5m) T int. LE00M8F5M
1550+ Alarm Output Cable Kit, M12 male, 4 pole x bare leads, 19.7’ (6m) Main 040TS04000054W0
Junction Block - 4 connectors – with cable, 16.4’ (5m) length, M12 male Main JCPCNS000005-00_AC01
Junction Block - 8 connectors – with cable, 16.4’ (5m) length, M12 male Main JCPCNS000004-00_AC01
PulsaJet Nozzle Cable to Controller of Multiport Junction Block 9.8’ (3m) length Main LEXXSD3M83F030P
AA250 Nozzle Cable to Controller of Multiport Junction Block 9.8’ (3m) length Main LE00M12MMDIN3MU

18
Electrical Power Connection
o Connect one end of the electrical power cord to the receptacle on the control panel and connect the other end into a
120/60/1 VAC power source. (US voltage). For International applications be sure that you have the correct power cord.
System is capable of using up to 240v 50/60 Hz Single Phase power.
Air and Liquid Connections
The system comes with push tube bulkhead fittings for making air and liquid connections. The fittings are located on the
right side of the unit. The push tube fittings make connecting the system easy.
The fully configured 1550+ AutoJet modular spray system has the following air and liquid connections:
Air Connections
o The system is provided with an air filter and lock out valve assembly. The unit is provided loose for you to mount either
directly to the unit or your preferred location.
o Connect a dry, clean 80-100 psi max air supply line to the input fitting of the lockout valve. Make sure that the lockout
valve and the ball valve on the pump inlet are both in the closed position prior to connecting the unit to the air supply.
o For systems that control pneumatically actuated nozzles connect 1/4” O.D. tubing from the Cylinder Air out port of the
bulkhead to the spray nozzle(s) cylinder air ports.
o Tubing may be supplied with optional spray nozzle hook up kit
 Note metric nozzle hook up kits are not available
o Metric systems use 6 mm O.D. tubing
o Connect 3/8” O.D. poly tubing from the Atomization Air and Fan Air push-in fittings (if needed) on the side of the
enclosure to their corresponding fittings on the spray nozzle(s).
o Tubing may be supplied with optional spray nozzle hook up kit
 Note metric nozzle hook up kits are not available
o Metric systems use 10 mm O.D. tubing
Liquid Connectio ns - Pump version
The 1550+ Pump Version is designed to draw fluid from tote or vessel using the systems pump. It is not designed to receive
pressurized fluid.
Air and liquid connection
locations

19
o Connect suitable 1/2” O.D. tubing from the Liquid Inlet fitting to the liquid tote/tank.
 Metric systems use 12 mm O.D. tubing
o Customer to supply tubing
o NOTE: For pump version systems the liquid source should not be pressurized
o Connect suitable 1/2” O.D. tubing from the Liquid Out fitting to the corresponding fitting on the spray nozzle(s).
o Tubing may be supplied with optional spray nozzle hook up kit
o Note metric nozzle hook up kits are not available
 Metric systems use 12 mm O.D. tubing
o Optional - Connect suitable 3/8” O.D. tubing from the Liquid In Return fitting to the liquid return line.
o Tubing may be supplied with optional spray nozzle hook up kit only if it is a recirculating style hook up kit
o Note metric nozzle hook up kits are not available
 Metric systems use 10 mm O.D. tubing
o Optional - Connect suitable 3/8” O.D. tubing from the Recirculation Liquid Out fitting to the return inlet of the liquid
source.
o Customer to supply tubing
o Metric systems use 10 mm O.D. tubing
Liquid Connectio ns - Pump Less version
The 1550+ Pump Less Version is designed to control the pressure down from a pressurized source. If the system is supplied
with a pressure pot, the customer must supply air to the pressure pot. The liquid out line of the pressure pot must then be
connected to the Liquid In fitting on the 1550.
NOTE: Pump less version systems require the liquid source to be pressurized to a minimum of 10 psi above the maximum
application pressure. The maximum required application or discharge pressure must not exceed 100 psi.
NOTE: The Pump Less version is not designed to pressurize a vessel or pressure pot. Only to control the liquid pressure
from a pressurized source to the spray nozzles.
o Connect suitable 1/2” O.D. tubing from the Liquid Inlet fitting to the liquid source.
 Metric systems use 12 mm O.D. tubing
o Tubing to be supplied by the customer.
o Connect suitable 1/2” O.D. tubing from the Liquid Out fitting to the corresponding fitting on the spray nozzle(s).
o Metric systems use 12 mm O.D. tubing
o Tubing may be supplied with optional spray nozzle hook up kit
 Note metric nozzle hook up kits are not available
o Optional - Connect suitable 3/8” O.D. tubing from the Liquid In Return fitting to the liquid return line.
o Metric systems use 10 mm O.D. tubing
o Tubing may be supplied with optional spray nozzle hook up kit only if it is a recirculating style hook up kit
 Note metric nozzle hook up kits are not available
o Optional - Connect suitable 3/8” O.D. tubing from the Recirculation Liquid Out fitting to the return inlet of the liquid
source.
o Metric systems use 10 mm O.D. tubing
o Tubing may be supplied with optional spray nozzle hook up kit only if it is a recirculating style hook up kit
o Note metric nozzle hook up kits are not available
Liquid Connectio ns – Pressure Pot version
The 1550+ Pressure Pot Version is designed to pressurize a vessel. It is not designed to receive pressurized fluid. It is not
designed to supply liquid directly to the spray nozzles. It only controls the air pressure going to the pressure pot. The
Pressure Pot system controls the flow of liquid using an internal manual liquid pressure regulator. This sets the air pressure
going to the pressure pot. For most materials the reading on the gauge should be close to the pressure at the liquid exit.
Note for high viscous and high-density materials this will deviate.
o Connect suitable 3/8” O.D. tubing from the Tank Air outlet fitting to the pressure pot air inlet.
o Tubing supplied if system is purchased with standard pressure pot.
 Metric systems use 10 mm O.D. tubing

20
o Connect suitable 3/8” O.D. tubing from the Liquid Out fitting on the pressure pot to the corresponding fitting on the
spray nozzle(s).
o Tubing supplied if system is purchased with standard pressure pot.
 Metric systems use 10 mm O.D. tubing
Mounting Spray Nozzles
Locate and mount the spray nozzles for your spray application. Depending on your application the spray nozzle lines and
connections will vary. It is recommended to run the lines starting from the spray nozzles to the system for easier
adjustment of lengths of the tubing. Note length should be kept to a minimum to reduce pressure drop. Note: If liquid
lines are long (>10ft.or 3m) flowrates and pressures will be affected. This can be worse when viscous fluids are being
pumped.
Notes on Nozzle Location
When locating the system in relation to the nozzles note these typical lengths of connecting items
You may or may not have these items depending on your project and order.
Nozzle hook up kits – Tubing 12 ft. (3.6m)
If your system was ordered with optional nozzle hook up kit the design of the hook up kit allows for 12’ of tubing from the
nozzle to the system for a single nozzle hook up kit. For multiple nozzle hook up kits they are designed to provide 12’
(3.6m) of tubing from each nozzle to the manifold and 12’ (3.6m) of tubing from the manifold to the system.
Electric nozzle cables – 10 ft. (3m) & 16.4 ft. (5 m)
All systems design to use electric nozzles comes with the required cables. IF your system did not come with these cables
please contact your local sales engineer.
 For a single electric nozzle system, the cable length is 10’ (3m) [Cable P/N LEXXSD3M83F030P, for AA10000 series;
P/N LE00M12MMDIN3MU for AA250 series]. For multiple electrical nozzles the system comes with cable from the
nozzle (one per nozzle) to a junction block that is 10’ (3m) [Cable P/N LEXXSD3M83F030P, for AA10000 series; P/N
LE00M12MMDIN3MU for AA250 series] and a cable from the junction block to the system that is 16.4 ft (5m)
{Cable P/N LE00M12M5M].
 If longer length cables are required, we offer an extension cable that is 16.4’ (5m) [Cable P/N LEXXSD4FD4M005P].
o This cable can be used to go between the nozzle cable and the junction block or the junction block cable
and the system.
o This cable can also be used to extend the trigger devise cable lengths stated below.
o Note due to voltage drop we recommend keeping the cable length to a reasonable length (approx. <50ft.).
Never attempt to chain more than four (4) cables together. Electric spray nozzle speed and performance
will suffer.
Trigger device cables – 16.4 ft. (5m)
All systems must be purchased with a trigger device to activate the system during operation. All of our offerings have a
cable length of 16.4’ (5m).
 If longer length cables are required we offer an extension cable that is 16.4’ (5m) [Cable P/N LEXXSD4FD4M005P].
o This cable can be used to go between the trigger cable and the system.
o This cable can also be used to extend the electric nozzle cable lengths stated above.
