SSCOR DCell Suction Instructions for use

Model DM10-001
Clearing The Airway Is Our #1 Priority
Operating Instructions
& Maintenance Manual
The world’s 1st and only full size portable suction
device powered by ALKALINE BATTERIES.
Tel 1+818-504-4054
Tel 1+800-434-5211
Fax 1+818-504-6032
, INC.
11064 Randall Street
Sun Valley, CA 91352 USA
www.sscor.com
shop.sscor.com
Email: [email protected]
[e-mail]

Clearing The Airway Is Our #1 Priority
Caution-Notice
SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
1. Federal law restricts this device to the sale, distri-
bution, and use by, or on the order of a physician,
emergency medical technician, or other medical
practitioner. For use by medical personnel trained
in suctioning techniques and in the use of medical
suction equipment.
2. SSCOR suction units are not designed or intend-
ed for use in extended procedures that require
prolonged high vacuum/low airflow applications,
as is the case in wound drainage or endoscopic
use or in any other procedure that produces high
vacuum levels within an occluded system for an
extended period of time. Turn the suction unit off
when it is not in use.
3. This manual is restricted to the discussion of the
use and maintenance of this device. It does not
attempt to discuss professional techniques in suc-
tioning procedures.
4. Operator should be thoroughly familiar with these
operating instructions before this device is used.
5. Do not use in the presence of flammable agents
or anesthetics.
6. Before testing for vacuum over -300mmHg look
for an expiration date on the canister (where appli-
cable) and change the canister if the canister has
passed the expiration date to minimize the possi-
bility of implosion, which can occur when a canis-
ter is aged or damaged.
7. Do not use the batteries after the “Use By” date
on the battery label.
8. Do not store batteries in the SSCOR DCell Suc-
tion device if it is not expected to be used for sev-
eral months.
9. Keep battery contact surfaces and battery com-
partment contacts clean by rubbing them with a
rough cloth each time you replace batteries.
10. Make sure you insert batteries into your device
properly, with the + (plus) and – (minus) terminals
aligned correctly. Always install batteries per the
labeling on the battery holder.
11. Store batteries in a dry place at normal room tem-
perature. Extreme temperatures reduce battery
performance.
12. Any battery may leak harmful chemicals which
may damage skin, clothing, or the inside of the
battery holder. To avoid risk of injury, do not let
any material leaked from a battery come in con-
tact with eyes or skin. If batteries leak, replace the
battery holder.
13. Any battery may rupture or explode if put in a fire
or otherwise exposed to excessive heat. To avoid
risk of injury, do not expose batteries to excessive
heat, or moisture.
14. Use only D Cell alkaline batteries from a reputable
manufacturer.
15. Do not use different brands or chemistries of bat-
teries in the same battery holder.
16. Do not use Lithium batteries in the battery holder.
17. When replacing batteries, always replace the
whole set.
18. Batteries will not recharge when installed in the
suction device.
19. Follow battery manufacturer’s instructions as to
proper handling, storage and disposal of batteries.
20. When using the SSCOR DCell Suction Device,
ensure that the canister is in an upright position.
21. Connect the suction tubing from the device to the
vacuum port of the canister prior to use.
2
Revision D (02/17)

Clearing The Airway Is Our #1 Priority
Table of Contents
SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
Caution Notice Page 2
General Description and Warranty Page 3
Description of Symbols Page 4
Operating Instructions Pages 5 & 6
Trouble Shooting Page 7
General Specifications Page 8
Maintenance Page 9
Internal Access Page 10
General Description
Warranty
A battery pack containing 12 fully charged alkaline batteries at full capacity will power the device for ap-
proximately 6-9 hours. This run time is defined as the period of time the device generates more than
300mmHg negative pressure. This run time specification is based upon tests conducted using new Du-
racell® CopperTop batteries. Run times are affected by many variables which include the brand of bat-
tery, the age of the battery, and ambient temperature. The red LED on the control panel will light indi-
cating the batteries are losing capacity and new batteries should be installed in the 12 X D battery hold-
er. See page 5 for instructions on battery replacement. For replacement parts and accessories, please
visit shop.sscor.com.
The SSCOR DCell Suction device is designed for hospital crash carts, patient transport and emergency
medical service. Suction power can be regulated when full power may be considered harmful to the pa-
tient. SSCOR suction units are designed to provide instant, effective suctioning, independent of exter-
nal sources of power and can be pre-set to be activated immediately upon reaching the distressed pa-
tient. All controls are clearly labeled and easily accessible.
SSCOR warrants that each new product is free from defects in material and workmanship under normal
use and service for a period of three years from the date of purchase. This warranty gives you specific
legal rights and you may also have other rights that vary from jurisdiction to jurisdiction. For countries
where minimum warranty terms are determined by statute, the warranty term is the longer of the statuto-
ry period or the term listed above. Batteries, disposable items including collection canisters, patient tub-
ing and catheters are excluded from this warranty.
See the SSCOR Warranty for terms and conditions, available on www.sscor.com.
3

SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
4
Clearing The Airway Is Our #1 Priority
Description of Symbols
Symbol Location Meaning
Control Panel Label 12V DC Power Input
On/Off Switch Turns Device On/Off
Control Panel Label Battery Voltage Indicator
Serialized Label Separate Collection for Electronic Equipment
Serialized Label Type BF Equipment
Serialized Label Attention—Consult Accompanying Documents
Shipping Carton Authorized Representative in the European Community
Shipping Carton Date of Manufacture
Shipping Carton Manufacturer
Shipping Carton Transport Storage Range
Shipping Carton Humidity
Shipping Carton Atmospheric Pressure

SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
5
Clearing The Airway Is Our #1 Priority
Operating Instructions
2
WARNING:
The tandem port on the canister is not an inlet port. Do not connect tubing to the tandem
port of the canister.
Battery Level of Charge Verification
Once the unit is running from the internal battery pack, check the control panel and observe the battery
voltage indicator to gauge the level of battery charge. The green LED when lit, indicates a high level of
charge.
WARNING:
The red LED when lit, indicates the battery voltage is nearly depleted and the negative
pressure level of the device will soon be below 300mmHg. Immediately install fresh
batteries into the battery holder or connect device to an appropriate 12V DC power
source.
5
Replacing the 12xD Cell Batteries
When the red Battery Voltage LED is lit indicating low battery voltage, the batteries in the 12xD Cell bat-
tery holder should be replaced with fresh D Cell Alkaline batteries. To access the battery holder, open
the top of the chassis exposing the battery holder:
1. Disconnect the Molex on the 12xD Cell battery holder from the wiring harness;
2. Lift the 12xD Cell battery holder out of the chassis, noting the orientation of the battery holder. The
battery holder only fits in this orientation. Do not lift the battery holder by the exposed wires, use the
fabric pull tab to lift the 12xD Cell battery holder out of the chassis. Replacement battery holder may be
purchased at shop.sscor.com.
1
Running the unit from the 12xD Cell Alkaline
battery holder
1. Press the ON/OFF switch on the control
panel to start the vacuum pump.
Adjusting the vacuum level
• Occlude the patient tube and turn the vacuum
regulator clockwise to the stop.
• Observe gauge (located above the vacuum
regulator). The vacuum reading should rise to -
300mmHg from zero in 3 seconds. It should max
out at approximately >= -525mmHg. Lower lev-
els of negative pressure will be observed at alti-
tude.
2. Press the on/off switch on the control panel to
stop the vacuum pump.
5
4
3
1
2

SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
6
Clearing The Airway Is Our #1 Priority
Operating Instructions (Continued)
3
Remove the discharged batteries from the 12xD Cell battery holder and dispose of the batteries ac-
cording to local / regional / national requirements for the disposal of alkaline batteries. Install 12 new fresh
D Cell alkaline batteries into the 12xD Cell battery holder - being careful to assemble the batteries in the
correct orientation as indicated on the battery holder. When the battery holder is loaded with 12 new D
Cell alkaline batteries, set the 12xD Cell battery holder back into the chassis. The battery holder only fits
in one orientation. Re-connect the Molex on the battery holder to the wiring harness. Turn the device on
to verify the batteries are correctly installed and the battery holder is connected to the wiring harness. Ob-
serve the battery voltage indicator on the control panel. The green LED should be lit indicating the batter-
ies have a high level of charge.
Running the device using the #80665 DC power cord (Available for purchase on shop.sscor.com)
Connect the DC power cord to the 12V DC cigarette lighter receptacle in the vehicle. Connect the DC
power cord to the suction unit by securely attaching the charging plug into the receptacle. If the suction
unit is operated while it is hooked up to the vehicle it will utilize the vehicle power and save its own battery
for emergency use. The DC power cord will not charge the 12xD Cell batteries when connected to the
suction device.
CAUTION: The #80529 power adapter will not charge the 12xD Cell batteries when connected to the suc-
tion device. If the 80529 power adapter is connected to the SSCOR DCell Suction device and the battery
voltage indicator shows a red LED, the output from the power adapter is not sufficient to power the
SSCOR DCell Suction device. The device is running from its internal batteries. The 80529 power adapter
may be purchased at shop.sscor.com.
4
Do not store batteries in the SSCOR DCell Suction device if it is not expected to be used for
several months.
WARNING:
To avoid risk of shock, this equipment must only be connected to a supply mains with
protective earth.
The 80529 Power Adapter is for Indoor Use Only.
WARNING:
Periodic checking or replacement of “D” Cell Alkaline batteries is required.
If for any reason poor battery quality is suspected, perform a battery test as described below.
BATTERY TEST:
Turn the SSCOR DCell Suction device on and run the unit for 30 seconds. Occlude the patient port
of the canister and observe the negative pressure gauge. The negative pressure gauge should rise
above 300mmHg in 3 seconds and reach 525mmHg. Observe the battery condition indicator
LED . If it lights red, it is time to install 12 fresh D Cell batteries into the SSCOR DCell Suction
battery holder. Dispose of the batteries according to local /regional / national requirements for the
disposal of electronic waste.

SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
7
Clearing The Airway Is Our #1 Priority
Trouble Shooting
Problem Possible Cause Corrective Action
Does not function when
switch is on (DC Power) Battery discharge Replace Batteries
Molex connections disconnected Lift battery cover and check to see
Molex connections are secure
Defective PC Board Replace PC Board
Fuse Blown Replace Fuse
Red LED Low battery capacity Replace Batteries
Battery condition indicator
lights not lit Defective PC Board Replace PC Board
No suction when pump is
running Vacuum line is disconnected Re-connect vacuum line
Canister Defective Replace canister
Canister lid loose Tighten canister lid
Catheter thumb vent is open Occlude thumb vent
Defective pump(s) Replace pump(s)

SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
8
Clearing The Airway Is Our #1 Priority
General Specifications
Characteristics Specifications
Size 12”H x 9”W x 11”D
30.48cm H x 22.86cm W x 27.94 cm D
Weight 9.5 LBS. / 4.3Kg
Vacuum Pump 12V DC
Exceeds 525mmHg.
Clinical Airflow >=30 LPM with 12 fully charged D Cell alkaline batteries at
full capacity
Variable Regulator Controls negative pressure
Battery 12 x D Cell alkaline batteries
12 x D Cell battery holder
part number: 040-00001
Wiring Harness Uses (1) 2A 250V slow acting fuse
UL Listed and CSA Certified Type (1¼ x ¼)
Collection Canister 1200cc/ml SSCOR Part #48041
Patient Tubing Vinyl tubing 9/32” ID, 72”L SSCOR Part #43200
Suction Tip HI-D® “Big Stick®“ Large Bore Suction Tip with thumb control.
SSCOR Part #44241
Operating Temperature Range: 0 °C (+32 °F) – +40 °C (+104 °F)
Operating Relative Humidity: 0 - 93% (non condensing)
Operating Atmospheric Pressure: 10.2 Psi (70 kPA) – 15.4 Psi (106 kPA)
Operating Altitude: <2000m
Storage & Transport Temperature: -40 °C (-40 °F ) – +50 °C (+122 °F)
Storage & Transport Relative Humidity: 0 - 95% (non condensing)
Storage & Transport Atmospheric Pressure: 7.3 Psi (50 kPA) – 15.4 Psi (106 kPA)
Environmental Conditions

SSCOR DCell Suction– Model DM10-001
Rev. D (02/17)
9
Clearing The Airway Is Our #1 Priority
Maintenance
Preventive Care
Observe the following maintenance routine to ensure readiness at any time:
1. Do not store batteries in the SSCOR DCell Suction device if it is not expected to be used for several
months.
2. Test the SSCOR aspirator at regular intervals; See page 6.
3. Make sure the SSCOR aspirator is always clean and ready for use.
4. The canister contains a float valve to prevent fluids from reaching the vacuum pump, however, if the
procedure produced an excessive quantity of fluids, check the vacuum line (#) for evidence of moisture. If
the vacuum line between the device and canister is moist, it is possible that fluids have reached the vac-
uum pumps. See Disinfection Instructions below.
5. For technical assistance, call [phone] or international [phone].
Note: No part requires lubrication and lubricants should not beused.
Sanitation
As soon as possible after use, the single use disposable canister, patient tubing and catheter should be
discarded according to local / regional / national requirements for the disposal of hazardous waste mate-
rials. Clean using a mild detergent and if necessary disinfect with a mild disinfectant such as 10 to 1
bleach and rinse using clear water to remove any residue.
Do not reuse any single use disposable parts; do not submerge the device into any liquid, this will void
the warranty and cause the device to malfunction.
Disinfection
Use personal protective equipment such as gloves, a smock, and face and eye protection when handling
units that are suspected to be contaminated.
Caution: Disconnect the unit from any power source prior to cleaning the unit. When cleaning the
interior of the chassis, disconnect the battery from the PC Board to prevent damaging the PC Board.
Part Cleaning & Disinfecting
Collection Canister SSCOR #48041. Disposable item, re-use not permitted.
Use new canister for each patient.
Patient Tubing
(Type BF Applied Part) SSCOR #43200. Disposable item, re-use not permitted.
Use new patient tubing for each patient.
HI-D® Stick
(Type BF Applied Part) SSCOR #44241. Disposable item, re-use not permitted.
Use new HI-D Stick for each patient.
Vacuum Pump SSCOR #90207. Wipe with damp cloth or disinfectant wipe.
Sterilization not permitted. Vacuum pump should be replaced if
contaminated.
PC Board SSCOR #050-00001. Sterilization not permitted. PC Board should be
replaced if contaminated.
Plastic Chassis Wipe with damp cloth or disinfectant wipe. Sterilization not permitted.

SSCOR DCell Suction – Model DM10-001
Rev. D (02/17)
10
Clearing The Airway Is Our #1 Priority
Internal Access
DO NOT ATTEMPT TO SERVICE THIS EQUIPMENT
IF YOU ARE NOT A BIOMEDICAL TECHNICIAN.
NO MODIFICATION OF THE EQUIPMENT IS ALLOWED.
UNAUTHORIZED SERVICE ATTEMPTS, OPENING OR TAMPERING
WITH THE COMPONENTS OF THE SSCOR DCELL SUCTION™ CAN DAMAGE
OR DISABLE THE DEVICE, AND WILL VOID THE WARRANTY
WARNING
To open the device, first remove
the 5 screws around the perimeter
of the back chassis. Next, remove
the two screws holding the D-Ring
of the carry handle on each side of
the device. The device will then
open. To close the device, replace
the screws and tighten. Make sure
all pneumatic and wiring connec-
tions are secure before closing the
chassis.
A
1
2
3
4
5 1 2
B
C
D
(A) PC BOARD-ELECTRICAL CIRCUITS
Do not attempt to service the PC Board. Return to
SSCOR for service
(B) Regulator
Do not attempt to service the regulator. Return to
SSCOR for service
(C) Vacuum Pumps
Do not attempt to service the vacuum pumps. Re-
turn to SSCOR for service
(D) Battery Holder
Do not attempt to service the battery holder. Return
to SSCOR for service
