SSCOR S-SCORT VX2 2310 Instructions for use

manuale scor multi-lingue 1-05-2003 21:19 Pagina 1

ENGLISH
FRANÇAIS
ITALIANO
ESPANOL
DEUTSCH
PP 3-13
PP 15-25
PP 27-37
PP 39-49
PP 51-61
manuale scor multi-lingue 1-05-2003 21:19 Pagina 2

3
ENGLISH
OPERATING INSTRUCTIONS
AND
MAINTENANCE MANUAL
S-SCORT ®VX2
Models
2310, 2310B, 2310V, 2310BV
2310-230, 2310B-230, 2310V-230, 2310BV-230
NEW GENERATION S-SCORT SUCTION FOR PREHOSPITAL CARE
30 LPM PERFORMANCE
DC INTERNAL POWER DC VEHICLE POWER
CONTROLLED BATTERY MAINTENANCE
REGULATED POWER TO SPARE
SSCOR, Inc.
11064 Randall St.
Sun Valley, CA 91352
USA
Tel [phone]
Fax [phone]
USA 800 434 5211
www.sscor.com
email: [e-mail]
manuale scor multi-lingue 1-05-2003 21:19 Pagina 3

4
ENGLISH
Table of Contents
S-SCORT VX2
Caution-Notice 4
General Description and Symbols 5
Getting Acquainted- Basic Instructions 6 – 7
General Specifications-Trouble Shooting 8
Warranty-Maintenance 9
Internal Access-Internal Components 10
Retention Bracket Mounting Instructions 9
Statement of Conformity 12
Caution-Notice
S-SCORT VX2
1. Federal law restricts this device to sale, distribution, and use by, or on the order of a physician, emer-
gency medical technician, or other medical practitioner. For use by medical personnel trained in suc-
tioning techniques and in the use of medical suction equipment. To be used only as directed by local
EMS authorities.
2. This manual is restricted to the discussion of the use and maintenance of this device. It does not
attempt to discuss professional techniques in suctioning procedures.
3. Operator should be thoroughly familiar with these operating instructions before this device is used.
4. Use a thumb control on all suction tips, especially when suctioning children and intubated patients.
5. The battery is protected from a deep discharge condition by shutting down after approximately 45
minutes (±10%) running time.
6. Do not use in the presence of flammable agents or anesthetics.
7. The shut-off valve in the canister lid will close down when the canister is full.
8. Install a new canister before testing for vacuum over 300mmHg to minimize the possibility of implo-
sion, which can occur when a canister is aged or damaged.
9. All S-SCORT pumps must be reconnected to the charging source after each use and remain on charge
until needed.
manuale scor multi-lingue 1-05-2003 21:19 Pagina 4

5
ENGLISH
General Description
S-SCORT VX2
S-SCORT is a portable, 12V DC battery operated, suction device for resuscitation emergencies in Pre-
Hospital Care.
CAUTION: S-SCORT suction units are designed for hospital crash cart suction, patient transport and
emergency medical service. They are not designed or intended for use in extended procedures that
require prolonged high vacuum/low airflow applications, as is the case in wound drainage or endo-
scopic use or in any other procedure that produces high vacuum levels within an occluded system for
an extended period of time. Turn the S-SCORT suction unit off when it is not in use.
The unit receives power from its internal 12V DC battery or from the 12V system of the vehicle.
The battery is recharged by an internal, dual mode battery charger which is activated by the AC-DC
converter or direct connection to the vehicle electrical system. The charger monitors the battery,
charges the battery only when necessary, shuts down the unit if battery is low and signals battery con-
dition. A fully charged battery will power the unit for 45 minutes (±10%).
Description of Symbols
S-SCORT VX2
SYMBOL LOCATION MEANING
Control panel Pump is on
Serialized label Type B equipment
Control panel Battery level of charge
Green LED = Full
Green/Yellow LED = High
Yellow led = Half
Yellow/Red LED = Low
Red LED = Bettery depleted
Put back on Charge
Control panel Push On / Push Off
S-SCORT®VX2 Models 2310, 2310B, 2310V, 2310BV, 2310-230, 2310B-230,
2310V-230, 2310BV-230
US Patent Pending
ETL listed, conforms to UL STD 2601-1, IEC 60601-1, EN 60601-1-2
©2003 SSCOR, Inc., S-SCORT, Duet, HI-D and Big Stick are registered trademarks of SSCOR, Inc.
