Operating instructions
Additional languages www.stahl-ex.com
EN
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009

2Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Contents
1 General Information ............................................................................................3
1.1 Manufacturer .......................................................................................................3
1.2 Information regarding the operating instructions .................................................3
1.3 Conformity with standards and regulations .........................................................3
2 Explanation of the symbols .................................................................................3
2.1 Symbols in these operating instructions .............................................................3
2.2 Warning notes .....................................................................................................4
2.3 Symbols on the device ........................................................................................4
3 Safety notes ........................................................................................................4
3.1 Operating instructions storage ............................................................................4
3.2 Safe use ..............................................................................................................5
3.3 Intended Use .......................................................................................................5
3.4 Modifications and alterations ..............................................................................5
4 Function and device design ................................................................................5
4.1 Function ..............................................................................................................5
4.2 Device design .....................................................................................................6
5 Technical data .....................................................................................................6
6 Engineering .........................................................................................................9
6.1 Mains operation ..................................................................................................9
6.2 Emergency light blocking ..................................................................................10
7 Transport and storage .......................................................................................11
7.1 General .............................................................................................................11
7.2 Batteries ............................................................................................................11
8 Mounting and installation ..................................................................................12
8.1 Dimensions / fastening dimensions ..................................................................12
8.2 Mounting / dismounting, operating position ......................................................13
8.3 Installation .........................................................................................................16
9 Commissioning .................................................................................................21
10 Operation ..........................................................................................................22
10.1 Operation ..........................................................................................................22
10.2 Indications .........................................................................................................24
10.3 Troubleshooting ................................................................................................25
11 Maintenance and repair ....................................................................................26
11.1 Maintenance .....................................................................................................26
11.2 Cleaning ............................................................................................................29
11.3 Returning the device .........................................................................................29
12 Disposal ............................................................................................................30
13 Accessories and Spare parts ...........................................................................30

226311 / 600960300010
2015-06-24·BA00·III·en·01
General Information
3
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
1 General Information
1.1 Manufacturer
1.2 Information regarding the operating instructions
ID-No.: 226311 / 600960300010
Publication Code: 2015-06-24·BA00·III·en·01
The original instructions are the English edition.
They are legally binding in all legal affairs.
1.3 Conformity with standards and regulations
See certificates and EC Declaration of Conformity: www.stahl-ex.com.
The device has IECEx approval. See IECEx homepage: http://iecex.iec.ch/
Further national certificates can be downloaded via the following link:
http://www.r-stahl.com/downloads/certificates.html.
2 Explanation of the symbols
2.1 Symbols in these operating instructions
R. STAHL Schaltgeräte GmbH
Business Unit Lighting & Signalling
Nordstr. 10
99427 Weimar
Germany
R. STAHL Schaltgeräte GmbH
Am Bahnhof 30
74638 Waldenburg
Germany
Phone:
Fax:
Internet:
E-mail:
[phone]
[phone]
www.stahl-ex.com
[email protected]
Phone:
Fax:
Internet:
E-mail:
[phone]
[phone]
www.stahl-ex.com
[email protected]
Symbol Meaning
Tips and recommendations on the use of the device
General danger
Danger due to explosive atmosphere
Danger due to energised parts

Safety notes
4226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
2.2 Warning notes
Warning notes must be observed under all circumstances, in order to minimize the risk
due to construction and operation. The warning notes have the following structure:
• Signalling word: DANGER, WARNING, CAUTION, NOTICE
• Type and source of danger/damage
• Consequences of danger
• Taking countermeasures to avoid the danger/damage
2.3 Symbols on the device
3 Safety notes
3.1 Operating instructions storage
• Read the operating instructions carefully and store them at the mounting location of
the device.
• Observe applicable documents and operating instructions of the devices to be
connected.
DANGER
Danger to persons
Non-compliance with the instruction results in severe or fatal injuries to
persons.
WARNING
Danger to persons
Non-compliance with the instruction can result in severe or fatal injuries to
persons.
CAUTION
Danger to persons
Non-compliance with the instruction can result in light injuries to persons.
NOTICE
Avoiding material damage
Non-compliance with the instruction can result in material damage to the device and / or
its environment.
Symbol Meaning
05594E00
CE marking according to the currently applicable directive.
02198E00
According to marking, device approved for hazardous areas.

226311 / 600960300010
2015-06-24·BA00·III·en·01
Function and device design
5
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
3.2 Safe use
• Read and observe the safety notes in these operating instructions!
• Observe characteristic values and rated operating conditions on the rating and data
plates!
• Observe additional information plates on the device!
• Use the device in accordance with its intended and approved purpose only!
• We cannot be held liable for damage caused by incorrect or unauthorized use or by
non-compliance with these operating instructions.
• Before installation and commissioning, make sure that the device is not damaged!
• Work on the device (installation, maintenance, overhaul, repair) may only be carried
out by appropriately authorized and trained personnel.
3.3 Intended Use
The light fitting 6009 is equipment
• for lighting areas, work spaces and objects
• for emergency lighting in case of power failure.
• can be used indoors and outdoors
• for stationary mounting
• for use in Zones 1, 21, 2, 22 and in the safe area
3.4 Modifications and alterations
4 Function and device design
4.1 Function
• for lighting areas, work spaces and objects
• for emergency lighting in case of power failure.
• switching off the equipment by means of a central lock (standard version) when the
luminaire is opened
• Weekly functional test, permanently integrated
• Yearly continuous operation test, can be deactivated and activated
DANGER
Explosion hazard due to modifications and alterations to the device!
Non-compliance results in severe or fatal injuries.
• Do not modify or alter the device. No liability or warranty for damage
resulting from modifications and alterations.
DANGER
Explosion hazard due to improper use!
Non-compliance results in severe or fatal injuries.
• Use the device only according to the operating conditions described in
these operating instructions.

Technical data
6226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
4.2 Device design
5 Technical data
16385E00
1 - Lamp holder 6 - Luminaire enclosure
2 - Ballast 7 - Reflector plate
3 - Luminaire trough 8 - Battery
4 - Cable gland 9 - Battery enclosure
5 - Connection terminal
Explosion Protection
Global (IECEx)
Gas and dust
Ex d e mb IIC T4 Gb or Ex db eb mb IIC T4
Ex tb IIIC T80 °C Db or Ex tb IIIC T80 °C
Europe (ATEX)
Gas and dust
E II 2 G Ex d e mb IIC T4 Gb or Ex db eb mb IIC T4
E II 2 D Ex tb IIIC T80°C Db or Ex tb IIIC T80 °C
Certifications and certificates
Certificates IECEx, ATEX
123
4567
8
9

226311 / 600960300010
2015-06-24·BA00·III·en·01
Technical data
7
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Technical Data
Electrical data
Rated voltage Standard:
• 220 ... 240 V ± 10%, 50 / 60 Hz (Lamps acc. IEC60081)
Optional:
• 110 ... 127 V ± 10%, 50 / 60 Hz (Lamps acc. IEC60081)
• 120V ± 10%, 50 / 60 Hz (Lamps acc. ANSI IEC C78.81)
Rated insulation
voltage
320 V
Disconnection of the
light
When opening the light
Switch with safety lock; when opening the central lock, all poles of the voltage
supply to the ballast are disconnected; contacts of the switching element are
NC contacts, they can only switched on again when the lamp cover and the
central locking system are closed.
In case of a lamp fault, the electronic ballast disconnects the defective lamp
from the power supply.
Luminous characteristics
Lamps 2x 18 W; 2x 36 W (acc. to IEC60081)
2x 17W; 2x 32W (acc. to ANSI IEC C78.81)
Measures for light
guidance
Standard: wide beam, internal reflector of the light fittings is painted in white
colour.
Colour: signal white RAL 9003; lateral glare reduction in the luminaire trough.
Ambient conditions
Ambient temperature
Mechanical data
Degree of protection IP66 / IP67 (IP64 when using the breather 8162) IEC 60598
Protection class I (with internal PE connection)
Material
Enclosure
Enclosure Polyester resin, glass fibre-reinforced
Colour colour grey, similar to RAL 7035
Translucent cover Polycarbonate
Gasket Silicone foam gasket in the lamp cover
Luminaire locking Central locking which can be opened/closed using a socket key M8 / wrench
size 13, hinged lamp cover
- 30 ... + 50 °C
- 20 ... + 50 °C with Breathing Glands 8162
- 5 ... + 40 °C operationable

Technical data
8226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Mounting / Installation
Cable glands
Connection
Through wiring
Assembly
Emergency light electronics
Emergency light
mode
In the emergency light mode, only one lamp is used, which results in reduced
light output
Emergency light
service time
Technical Data
Standard luminaire
Plastic: 2 x M25 x 1.5 cable entries 8161 and
2 x M25 x 1.5 stopping plugs 8290 (enclosed)
Metal: 2 x metal plates M20 x 1.5 connected by means of PE for metal
cable entries
Attention: cable entries must be ordered separately
Special: max. 4 drilled holes for M20, M25, NPSM ½’’
max. 2 drilled holes for NPT ¾’’
Metal cable glands: M20 x 1.5, M25 x 1.5; earthing of the metal
cable entries by means of metal plates
Standard: Spring clamp terminals
6-pole: L1, L2, L3, L', N, PE
Clamping range: 1 x 0.75 ... 4 mm2 (solid / finely stranded)
(2 free clamping units per pole available)
Special: Terminal block with covering
6-pole: L1, L2, L3, L', N, PE
Clamping range:
2 x 1.5 ... 6 mm2 (solid);
2 x 1.5 ... 4 mm2 (finely and extra finely stranded)
Through wiring Standard luminaire Luminaires are equipped with internal
through wiring. Ingoing and outgoing leads can be connected
to the opposite sides.
Terminals: see techn. data
Wiring cross section: 2.5 mm2 for max. 16 A.
without Optional
On the connection side, there are 2 bores M25 x 1.5 for cable
entries for ingoing and outgoing wiring of the connection line
(ingoing and outgoing leads on one side).
For outdoor mounting a breather is recommended
Standard luminaire
Standard: 2 x M8 insert nuts in the enclosure
Special: Mounting grooves in the enclosure for use of fastening and
ceiling rails for variable luminaire mounting (variable mounting
distances for luminaires 17 W, 18 W: 320 ... 480 mm,
32 W, 36 W: 670 ... 930 mm)
Battery
capacity
Emergency light
service time
Emergency lighting power
17 W; 18 W 32 W; 36 W
7 Ah 1.5 h 100 % 60 %
3.0 h 60 % 30 %

226311 / 600960300010
2015-06-24·BA00·III·en·01
Engineering
9
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
6 Engineering
6.1 Mains operation
6.1.1 Stand-by operation
• The light fitting is switched off
6.1.2 Continuous operation
• The light fitting is switched on
Switchover voltage from mains to battery operation for U < 0.74 x UN
from battery to mains operation for U > 0.80 x UN
Battery set
Version Gas-tight NiCd battery
Operating voltage 6 V
Capacity 7 Ah
Replacing the battery
set
When opening the battery enclosure, the connection between the battery set
and the emergency light electronics is disconnected.
The battery set can be replaced after disconnecting the plug-in contacts.
16397E00
16398E00
Technical Data
PE
N
L1
L´ PE N L1 L2 L3
PE
N
L1
L´ PE N L1 L2 L3

Engineering
10 226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
6.1.3 Normal lighting operation
• The light fitting is operated by normal lighting
6.2 Emergency light blocking
A remote switch for emergency light blocking can be connected to terminals 9 and 10 of
the emergency light electronics.
6.2.1 Connection version remote switch
The remote switch is directly connected to the emergency light electronics 6043/7.
The following connection versions are possible:
Point-to-point connection
16399E00
16400E00
Remote switch is closed Remote switch is opened
Power supply
operation
Switching on the lamps depend-
ing on operation mode
Switching on the lamps
depending on operation mode
Power failure Emergency light function No emergency light function
16402E00
PE
N
L1
L´ PE N L1 L2 L3
14
13
12
11
10
9
8
F
LED green
LED grün
LED red
LED rot
mit Brücke ohne Brücke
with jumper without jumper
3 h 1,5 h
BAT-
BAT+
Fernschalter
Remote switch
Fernschalter
Remote switch
Remote switch
6043/7.. 6043/7.. 6043/7.. 6043/7..
x1
x1 x1
x1

226311 / 600960300010
2015-06-24·BA00·III·en·01
Transport and storage
11
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Linear connection
7 Transport and storage
7.1 General
• Transport and store the device only in the original packaging.
• Store the device in a dry place (no condensation) and vibration-free.
• Do not drop the device.
7.2 Batteries
• Do not transport together with other materials!
• Handle with care!
• Store protected from fire, sources of dust, harmful gases and liquids!
• Store in a dry and cool location!
16401E00
NOTICE
The following conductor specifications must be observed during connection.
Point-to-point connection Linear connection
maximum conductor length
x 1 500 m 100 m
x 2 50 m
x 3 500 m
maximum number of light
fittings
50 30
minimum cable
cross-section
1.5 mm21.5 mm2
NOTE
Risk of deep battery discharge due to exceeded storage!
Non-compliance can result in material damage!
• The battery should be charged within 26 weeks from date of production by means
of operating the luminaire.
Remote switch
6043/7..
6043/7..
6043/7..
6043/7..
x2
x2
x2
x1
x3

Mounting and installation
12 226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Recommendation:
• Store battery at an ambient temperature of + 5 °C to + 25 °C and a relative humidity
of 65 ± 5 %. The storage period is reduced of up to one month if stored outside this
temperature range..
8 Mounting and installation
8.1 Dimensions / fastening dimensions
DANGER
Explosion hazard due to incorrect installation of the device!
Non-compliance results in severe or fatal injuries.
• Carry out installation strictly according to the instructions and national
safety and accident prevention regulations to maintain the explosion
protection.
• Select and install the electrical device so that explosion protection is not
affected due to external influences, i.e. pressure conditions, chemical,
mechanical, thermal and electric impact such as vibration, humidity and
corrosion (see IEC/EN 60079-14).
• The device must only be installed by trained qualified personnel who is
familiar with the relevant standards.
Dimensional Drawings (All Dimensions in mm [inches]) - Subject to Alterations
16127E00
EXLUX 6009
M25 x 1,5
183,5 [7,22]
125
L3
L2
L1
L3
L2
[4,92]
M25 x 1,5
Dimensions Luminaire
17/18 W 32/36 W
L1 857 [33.74] 1467 [57.76]
L2 1) 400 [15.75] 800 [31.50]
L3 2) 320 ... 480
[12.60 ... 18.90]
670 ... 930
[26.38 ... 36.61]
1) fixed mounting distance
2) variable mounting distance

226311 / 600960300010
2015-06-24·BA00·III·en·01
Mounting and installation
13
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
8.2 Mounting / dismounting, operating position
Suspension at fixed mounting points
WARNING
Danger due to electrostatic discharge!
Explosion protection is impaired!
Do not install within arm's reach!
Ensure that no electrostatic charging may occur.
For example:
• due to accidental friction,
• by cleaning with a dry cloth,
• with particle streams.
The luminaire is suitable for wall and ceiling mounting.
Wall mounting must be performed with the central lock directed downwards.
Outdoors, the mounting position with light emission upwards is not allowed.
For outdoor use, we recommend to install a 8162/1 breather from
R. STAHL Schaltgeräte GmbH.
The breather guarantees compliance with degree of protection IP64 in all
mounting positions.
WARNING
Danger due to inadmissible heating.
Explosion protection is impaired!
External heat sources and/or direct sunlight may effect the temperature class
and the maximum permissible surface temperature.
Early failure of equipment.
• The maximum ambient temperature must not be exceeded by external
heat sources.
16324E00
max. screw-in depth 10 mm
L2
Version L2 [mm]
17/18 W 400
32/36 W 800

Mounting and installation
14 226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Suspension at movable mounting parts
Pole mounting
Pole mounting using pipe clamps
16325E00 16326E00
Mounting bracket Top rail
Lateral mounting pockets for variable points of suspension.
When mounting the luminaire using top rails, ensure that the mounting
surface is flat. Otherwise, the enclosure might be mounted in a
warped/twisted way. The result is leakage of the luminaire and difficulties in
replacing the translucent cover.
16327E00
L
L4
L
L
L4
L
Version L4 [mm] L [mm]
17/18 W 320 80
32/36 W 670 130

226311 / 600960300010
2015-06-24·BA00·III·en·01
Mounting and installation
15
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Wall bracket mounting
16328E00
Version L4 [mm] L [mm]
17/18 W 320 80
32/36 W 670 130
For pipe clamp mounting, use the solution of R. STAHL Schaltgeräte GmbH
with integrated mounting rail providing reliable and stable four-point fixing!
In case of point suspension using pipe clamps,
R. STAHL Schaltgeräte GmbH does not guarantee the strength and
tightness of the luminaire!
15515E00
15517E00
Version L4 [mm] L [mm]
17/18 W 320 80
32/36 W 670 130
L
L
L4
L
L
L4
1
0
x
1
5
°

Mounting and installation
16 226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Continuous row mounting
R. STAHL Schaltgeräte GmbH - rail profile for continuous row mounting of
linear fluorescent luminaires EXLUX
It facilitates row mounting and installation of the luminaires.
The rail profile can also be used as cable duct.
Always use mounting rails to adjust the luminaires to the hole pattern of the rail profile.
8.3 Installation
8.3.1 Opening and Closing of the Enclosure
06250E00 06033E00
1: Rail profile
2: Luminaire
16334E00
DANGER
Risk of electric shock!
Risk of fatal injuries!
• Luminaires without switch must not be opened when they are supplied
with power (see information plate on the lock)!
Recommendation
Opening and closing of the luminaire by using a socket wrench from
R. STAHL Schaltgeräte GmbH.
15448E00
15451E00
15436E00
2
1
800 mm / 31.50 " (32 W / 36 W)
400 mm / 15.74 " (17 W / 18 W)
200 mm / 7.87 " 320 ... 480 12,60 ... 18,90 "mm / (17 W / 18 W)
670 ... 930 26,38 ... 36,61 " 32 36mm / ( W / W)
165°
170
90°

226311 / 600960300010
2015-06-24·BA00·III·en·01
Mounting and installation
17
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
• Remove the closing cap of the central lock.
• Turn the central lock using a socket wrench M8, wrench size 13, by 90° to the left as
far as it will go.
• Swivel down the translucent cover.
• Proceed in reverse order to close.
• The seal of the translucent cover must lie correctly on the sealing edge.
• Push the closing cap onto the central lock opening (dust protection).
Note:
• Version without switch: Disconnect the luminaire from the power supply and secure it
against being switched on again.
• Version with switch: The luminaire is positively disconnected from the power supply by
actuating the central lock.
• In open end position and with translucent cover swivelled down, a restart lock-out
device prevents the central lock from being actuated.
Please do not use force!
When the translucent cover is closed, the central lock is released.
Opening and closing the reflector plate
Opening and closing the battery enclosure
15512E00
1 Open the reflector plate by
pressing the safety latch.
2 Swivel down the reflector plate.
• When closing, flip up the
reflector plate and snap it into
place.
16404E00
16405E00
12
1
2
1
2

Mounting and installation
18 226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Opening
• Loosen the screws (1) (cross head H2).
• Open the battery cover (2).
Closing
• Close the battery cover (2).
• Tighten the screws (1) (cross head H2) firmly (2 Nm).
8.3.2 Electrical connections
Electrical connection
Observe the maximum clamping possibility of the connecting terminals
(see chapter "Technical data").
For optional screw-type terminals, two conductors per clamping unit can be clamped
(ingoing and outgoing wiring).
Note:
• Clamping must be carried out precisely!
• Do not clamp any part of the conductor insulation!
• Do not interchange the conductors!
• Observe the technical regulations when connecting the conductor!
• Clamp the conductor firmly.
• The terminal cover of optional screw-type terminals does not have to be removed to
clamp the conductor!
• The phase L1 must be directly connected to the grid which functions as charging
phase for the battery!
• Optional screw-type terminals: Firmly tighten screws (tightening torque 2 Nm,
for unused clamping units 0.7 Nm)!
NOTICE
Danger due to wrong connection.
Malfunction
• Phases L and L1 must be connected in phase.

226311 / 600960300010
2015-06-24·BA00·III·en·01
Mounting and installation
19
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Connection terminals
Through wiring
Battery connection
Standard:Spring clamp
terminals up to 4 mm2Optional: Screw-type terminals
up to 4 mm2 finely and
extra finely stranded,
and 6 mm2 solid
Stripping length:
10 ... 11 mm
Stripping length:
10 ... 11 mm
16333E00
16408E00
NOTE
Through wiring with 2.5 mm 2 cross-section for max. 16 A.
The connection to the battery is interrupted.
Before commissioning, connect the battery.
CAUTION
Danger deep battery discharge!
The battery can no longer be charged!
• If the luminaire is not connected to the power supply for more than 4
weeks the battery must be disconnected.
L1
NL'
L2 L3
L‘ = switched phase
L1 = charging phase
L2, L3 = phase
N = neutral conductor
PE = protective conductor

Mounting and installation
20 226311 / 600960300010
2015-06-24·BA00·III·en·01
Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
• Disconnect the conductor from the terminal (I).
• Connect the conductor to terminal 8 of the emergency light electronics.
• Tighten the screw of the terminal with 1.2 Nm.
8.3.3 Cable Entries
The standard luminaire is delivered with 3 lead-in holes, 2 cable glands and
2 stopping plug.
Please observe the tightening torque for luminaires with installed cable glands and
stopping plugs from R. STAHL Schaltgeräte GmbH.
Luminaires with approved cable glands and stopping plugs; not supplied by
R. STAHL Schaltgeräte GmbH
16407E00
Tightening torque
Connection thread Pressure screw
Cable gland 8161
M20 x 1.5 2.3 Nm 1.5 Nm
M25 x 1.5 3.0 Nm 2.0 Nm
Stopping plugs 8290
M20 x 1.5 1.0 Nm
M25 x 1.5 1.5 Nm
WARNING
Cable glands and stopping plugs which are not approved.
Explosion protection is impaired!
• Only use separately certified cable glands and stopping plugs.
I
