Stairville DMX Joker V2 512 Box User manual

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • [email protected] DocID: 551859_04.10.2022
Safety instructions
Intended use
This device is intended to control lighting devices and eects via computer using
appropriate software. Any other use or use under other operating conditions is con-
sidered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are
not within reach of babies and young children. Choking hazard! Ensure
that children do not detach any small parts from the product. They could
swallow the pieces and choke!
Quick Start Guide
This quick start guide contains important information on the safe operation of the
product. Read and follow the safety advice and instructions given. Retain the quick
start guide for future reference. If you pass the product on to others please include
this quick start guide.
Where to use the product
Never use the product
• in direct sunlight
• in conditions of extreme temperature or humidity
• in extremely dusty or dirty areas
• at locations where the unit can become wet
• near magnetic elds
General handling
• To prevent damage, never use force when handling the product.
• Never immerse the product in water. Just wipe it with a clean dry cloth. Do not
use liquid cleaners such as benzene, thinners or ammable cleaning agents.
Features
• Interface for Stairville DMX Joker and DMX Joker V2
• 512 channels
• Ideal for the mobile DJ, the ambitious light designer and small clubs
• Good introduction to PC-based control of intelligent light
• Easy operation via software with large functionality
• Clear and logical user interface
• Quick access to all relevant functions
• Labelling of the stored scenes and programmes
• Playback via the live board
• Cross fade time between scenes
• Default start scene when turning on
• 16-bit ne channel management
• Control via infrared remote control (item no. 551967, not supplied)
Connection
EN
1 Input socket for the mains cable (USB-C)
2 Screw terminal block
DMX Joker V2 512 Box
USB DEVICE
DMX
DMX
USB
COMPUTER
USB 5V
1: TRIG A
2: TRIG B
3: TRIG C
4: 5V
5: 12V IN
6: GND
ö #

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • [email protected] DocID: 551859_04.10.2022
EN
For the transport and protective packaging, environmentally friendly materials
have been chosen that can be supplied to normal recycling. Ensure that plastic
bags, packaging, etc. are properly disposed of. Do not just dispose of these ma-
terials with your normal household waste, but make sure that they are collected
for recycling. Please follow the notes and markings on the packaging.
This product is subject to the European Waste Electrical and Electronic Equip-
ment Directive (WEEE) in its currently valid version. Do not dispose of your old
device with your normal household waste. Dispose of this product through an
approved waste disposal rm or through your local waste facility. Comply with
the rules and regulations that apply in your country. If in doubt, consult your
local waste disposal facility.
MX Joker V2 512 Box
Hardware Features
DMX output 512 (PC), 512 (Stand Alone)
Inputs and outputs USB-C, Mini-USB 2.0, 1 × XLR chassis socket, 3-pin (optional 5-pin),
screw terminal block (6 pins)
Max. connected interfaces (USB) 12 via USB = max. 12 DMX
DMX modes DMX In/Out, DMX Record, DMX Trigger
Zone (Stand Alone) 1, play 1 scene/sequence at a time
Memory Internal memory
Memory step capacity 200 ~ 2000 (200 KB)
Infrared (scenes, play, pause, dimmer, speed) yes (optional remote control, not supplied)
Stand Alone options 16-bit ne channel management
Cross fade time between scenes,
Default start scene when turning on
Trigger 3 triggers, contact on external screw terminal block
(On, On/O, Release, Restart, Scene, commands and function controls, priority)
Infrared receiver (remote control not supplied)
Infrared options: selection 15 scenes, speed, dimmer, pause, stop, next
Operating voltage USB-C 5 V / 0.2 A
Screw terminal block 5 - 18 V / 0.2 A
Dimensions (W × H × D) 50 mm × 37.5 mm × 50 mm
Housing Aluminium, brushed
Weight 850 g
Ambient conditions Temperature range 0 °C…40 °C
Relative humidity 20 %…80 % (non-condensing)
Software Features
DMX Joker V2 yes, up to 64 x 512 DMX outputs
DMX Joker yes, up to 64 x 512 DMX outputs
DMX Joker Pro yes, no audio and video timeline synchronisation
STUDIO DMX 3D viewer in real time (full mode)
ArtNet output from PC 1 x 512 DMX outputs per connected device
System compatibility Windows®, iOS®, Linux®
System requirements Smartphone/Tablet Android® 5 (or higher) / iOS® 10 (or higher)
1 GHz CPU, 1 GB RAM, 60 MB disk
screen resolution 1280 × 800
WIFI 802.11 b/g/n
System requirements PC Windows®, Mac OS®, Linux® (32 or 64 bit)
2 GHz CPU (2 cores), 8 GB RAM, 2 GB RAM graphic card (only for 3D)
600 MB disk, screen resolution 1920 × 1080
1 × USB port (device), 1 × Ethernet connector (for ArtNet and sACN)
