STAMOS S-CUTTER 40 UK User manual

S-CUTTER 40 UK
USER MANUAL
expondo.de

2 3
Rev. 05.03.2021 Rev. 05.03.2021
EN
The operation manual must be reviewed.
The product must be recycled.
Satises requirements of applicable safety
standards.
Use full body protective clothes.
Attention! Wear protective gloves.
Safety goggles must be worn
Protective footwear must be worn.
Attention! Hot surface may cause burns.
Attention! Risk of re or explosion.
Attention! Harmful fumes, danger of poisoning.
Gases and vapours may be hazardous to health.
Welding gases and vapours are released during
welding. Inhaling these substances may be
hazardous to health.
Use a welding mask with appropriate lter
shading.
CAUTION! Harmful welding arc radiation.
The original operation manual is in German. Other
language versions are translations from German.
TECHNICAL SPECIFICATIONS
Product name PLASMA CUTTER
Model S-CUTTER 40 UK
Rated voltage 230V~
Frequenzy 50Hz
Cooling Fan
Cutting current 14 A – 40 A
Rated operation cycle 60 %
Safety class IP IP 21
Weight 22 kg
Compressor: Oil-free
Operating pressure: 4 – 5 bar
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
USER MANUAL associated with quality improvements. Taking into account
technological progress and noise reduction opportunities,
the device was designed to reduce noise emission risk to
the minimum.
BEFORE TURNING THE DEVICE ON, READ THE
INSTRUCTION MANUAL THOROUGHLY AND
OBSERVE THE FOLLOWING GUIDELINES:
Familiarize yourself with the instruction manual and the
device. For your own safety and the one of third parties,
observe the safety instructions and the guidelines specied
in the manual. People under 18, as well as those who are
unfamiliar with the instruction manual are not
allowed to operate the device. The device may only be used
in accordance with its purpose.
NOTE
• Ensure your own safety and the one of third parties
by reading and following the instructions of the
device.
• Only qualied persons can be allowed to use,
operate and repair the device.
• While the device is in use, keep third parties,
particularly minors, away from the place of use.
CUTTING MAY CAUSE FIRE OR AN EXPLOSION
A plasma beam ejects incandescent metal particles or
sparkles. Hot metal particles, sparks, heated elements or
hot equipment may cause re. Therefore, it is necessary
to closely examine the work place surrounding sand to
make sure if it is suitable as a working area before using
the device.
• Remove all ammable materials within 12 m radius
from the burner.
• If that is not possible, the ammable materials are to
be covered with an appropriate covering.
• It is forbidden to cut in places where ammable
materials may be ignited.
• Use means of protection against stream of sparks
and incandescent metal particles.
• Keep in mind that sparks or hot metal splinters may
penetrate through gaps or openings.
• Pay close attention to the electric arc and make sure
a re extinguisher is at hand.
• Keep in mind that cutting close to a ceiling, on the
oor or between partitioned space may cause a re
on the other, not visible side.
DO NOT WELD NEAR TANKS OR BARRELS WITH
FLAMMABLE SUBSTANCES.
The power cable is to be plugged into the nearest socket
and arranged in a practical and safe manner. Avoid careless
arrangement of the cable in the room on untested oor,
which may cause an electric shock or re.
• Do not use the plasma cutter to defrost frozen pipes.
• Do not cut with plasma near ammable materials/
containers. Flammable materials or containers are to
be removed or thoroughly emptied.
• Do not cut with plasma in an atmosphere containing
ammable particles or vapours of explosive
materials.
• Do not plasma-cut pressurized tanks, pressure
system pipes or pressurized containers.
• It is forbidden to plasma-cut containers with
ammable materials.
• During plasma-cutting, it is required to wear clean,
oil-free protective clothes, e.g.: leather gloves, thick
shirt, high boots and protective hood.
GENERAL DESCRIPTION
The user manual is designed to aid safe and troublefree
use. The product is designed and manufactured in
accordance with strict technical guidelines, using state of
the art technologies and components and in compliance
with the most stringent quality standards. To extend the
shelf life of the device and to ensure trouble free operation,
use it and perform maintenance tasks in accordance with
this user manual. The technical data and specications in
this user manual are current. The manufacturer reserves the
right to make changes
EN
• The plasma cutting station is to be located away
from ammable surfaces.
• Before starting plasma-cutting, get rid of ammable
or explosive objects, such as propane-butane
lighters or matches.
• Observe safety and OHS regulations applicable
to welding work and ensure the work station is
equipped with an appropriate re extinguisher.
The ame and the working circuit are energized if
the electric power supply is activated. The input and
internal circuit of the device are also energized if the
electric power supply is activated.
ELECTRIC SHOCK IS HAZARDOUS FOR LIFE AND
HEALTH
• Do not touch energized elements.
• Wear dry, insulated gloves without any holes, as well
as suitable protective clothes.
• Put insulation mats or other insulation coatings
on the oor, which should be suciently large to
prevent the body from touching the workpiece or
the oor.
• Do not touch the electric arc if it touches the
workpiece or the oor.
• Before operating, cleaning or replacing the electrode,
disconnect the electrical power supply.
• Before the installation or maintenance, disconnect
the power supply.
• Ensure that the grounding cable is properly
grounded and the pin is properly connected to
a grounded socket.
• Always inspect carefully the grounding.
• Before connecting the input, select an appropriate
grounding.
• Inspect regularly the power if they are damage or
if they present lack of insulation. A damaged cable
must be replaced immediately. Cables must be
replaced if any damage is found. Improper repair of
the insulation may cause death or injury.
• Turn the device o when it is not used.
• Replace the cable if you notice any signs or abrasion
or local damage.
• Do not coil the cable around your body.
• The welded workpiece is to be properly grounded.
• Use only equipment in good condition.
• Any damaged elements of the device are to be
repaired or replaced.
• During work at elevated heights, use safety harness.
• All the elements of equipment and safety should be
located in one place.
• It is forbidden to deactivate the safety system.
• Use only pistols listed in the instruction manual.
• When activating the release, keep the pistol tip and
the arc as far as possible from your body.
• Attach the working cable to an appropriate metal
contact of the welded workpiece (not to an element
which may fall o) or to the work table as close to the
welder as seems appropriate.
• The working clamp is to be insulated, unless it
is connected to the workpiece, in order to avoid
contact with metal.
After disconnecting the supply cable, the device may
still contain SIGNIFICANT VOLTAGE.
After turning the device o and disconnecting the power
cable, check the voltage on the input capacitor and ensure
the voltage value is zero, otherwise do not touch any
element of the device.
The capacitors are to be inspected in accordance with the
guidelines in the operation section of this manual.
ELECTRIC SHOCK may be lethal.
Unsecured elements of the rectier may explode at the
moment of turning on the power supply. When using the
rectier, always use a protective mask and working clothes
with long sleeves.
EXPLODING PARTS OF THE DEVICE may cause injury.
Metal splinters during welding constitute a health hazard.
SPLINTERS AND SPARKS MAY CAUSE INJURIES.
• Always wear a protective mask with side shield.
• Always wear appropriate protective clothes in order
to protect your body.
• Always wear earplugs or other hearing protection
in order to prevent the splinters from entering your
ears.
• During welding, the electric arc generates signicant
amount of visible and invisible radiation (UV and IR
radiation) which may damage eyesight and skin
ELECTRIC ARC RADIATION may damage eyesight and
skin.
• Always use face protection (helmet or shield) and eye
protection with glass with appropriate tint, acting as
lter and protecting the eyes during cutting.
• Safety standards propose tint no. 9 (no. 8 at
minimum) for every current intensity below 300 A.
A lower shield tint may be used if the arc covers the
workpiece.
• Always use permitted safety goggles with side shield
under the helmet or another protection.
• Use workplace shields in order to protect other
people against blinding light or splinters. Warn
bystanders not to look at the electric arc.
• Use protective clothes made of non-ammable
and non-conductive material (leather, thick wool or
cotton) and appropriate working footwear.
THERMAL PROTECTION
The thermal protection system is activated when the device
exceeds the activation time. It causes the device to switch
o. The status indicator on the front panel glows. The fan
works until the device is cooled. After cooling the device to
the operational temperature, it can be restarted.
DUTY CYCLE
The duty cycle is the percentage of the operating time
(measured in minutes) of a 10-minute period in which
the machine is used continuously in normal temperature
conditions. If the values of the duty cycle are exceeded, this
will trigger the overheat protection function, which stops
the machine until it is cooled down to normal operating
temperature. Repeated situations of exceeding the duty
cycle values may lead to serious damage of the machine.

4 5
Rev. 05.03.2021 Rev. 05.03.2021
CONNECTION DIAGRAM S-CUTTER 40 UK
EN
1. supply connection
2. workpiece
3. ground cable connector
4. plasma cutting clamp
S-CUTTER 40 UK
1. ON/OFF SWITCH.
2. LED display = it displays the current value of the
current intensity.
3. OVERLOAD / FAULT LED INDICATOR:
a. If the machine has malfunctioned and cannot
be operated
b. If the cutting device has exceeded the standard
working time the protection mode is initiated
STARTING WITH THE OPERATION
A. UNPACKING
Unpack all the items which are in the box and make sure
that you have received all items which are listed on the
packing list.
B. WORK ENVIRONMENT
Make sure that the work area is well ventilated. The unit
is cooled by an axial fan that provides an air ow for the
electronics through the rear panel.
(Note! The housing must be installed in order to ensure
that the vent holes are closer to the front of the machine).
Leave at least 15 cm at the front and 15 cm at both sides for
cleaning. If the machine is operated without the adequate
cooling, the length of the duty cycle will be greatly reduced.
C. CABLE CONNECTIONS
Each unit is equipped with a main power cable, which is
responsible for providing current and voltage to the device.
If the device is connected to power, which exceeds the
required voltage, or if the wrong phase is set, it may lead
to severe damage to the unit. This is not covered by the
warranty for the equipment and the user will be responsible
for such situations.
D. TORCH CONNECTIONS
Connect the torch to the inverter by connecting the air
tube that is attached at the end of the torch to the torch
connector on the front part of the machine. Ensure that the
connection is secure by tightening it slightly with a spanner.
However you should not make it too tight.
PISTOL ASSEMBLY
1
2
4
3
12
3
4
5
6
87
and the machine will stop functioning. This
means that the machine is now being cooled
in order to be able to restore temperature
control again after the device has overheated.
Therefore the machine is stopped. During this
process, the red warning light on the front
panel lights up. In this case it is not necessary
to remove the power plug from the socket.
The ventilation system may be left on in order
to enhance the cooling of the machine. When
the red light goes dark, this means that the
temperature is now down to the normal level
and the unit can be put back into operation.
4. TEST GAZ / 2T / 4T (2T – press this button on the
burner to start the metal welding/cutting process,
release this button to end this process. 4T – press
this button on the burner to start the metal welding/
cutting process, releasing this button does not end
this process. Press and release this button again to
end the metal welding/cutting process).
5. CUTING CURRENT ADJUSTING KNOB.
6. GROUNDING CABLE CONNECTION.
7. Power supply connection to the plasma torch cable.
8. Compressed air connection to the plasma torch
cable.
3
4
5
2
1
EN
A. ASSEMBLING THE PISTOL
Put the pistol the protective cap facing up and turn the cap
away from the gun. (The protective cap holds the tip, the
ceramic swirl ring and the electrode together). Remove the
cap, the ceramic swirl ring and the electrode. Assemble the
electrode, the ceramic swirl ring and the tip back together.
Replace worn parts if necessary. Put the protective cap on
the head of the pistol and screw it on with your hand until
it is snug. If any resistance is present during this process,
check the thread and the arrangement of the items before
resuming work.
NOTE
In case of some pistols with no reversible electrodes it is
necessary to tighten the electrode further by using a pair
of pliers in order to ensure a reliable electrical connection.
INSTRUCTION FOR USE
A. THE BEGINNING
Turn the power switch to „ON“. Press the pistol switch (air
will ow out from the pistol).
B. WEEKLY ACTIVITIES
Verify the proper operation of the air ow. Blow o or suck
in dust or dirt from the entire machine, including the air
lter.
MAINTENANCE
Check the pistol for wear damage, cracks or exposed wire
sections. Replace or repair any such defects before using
the device. A heavily worn pistol tip/nozzle contributes to
the reduction of speed, voltage drops and crooked cuts.
An indication of a worn pistol tip/nozzle is an elongated or
oversized nozzle opening.
TRANSPORTATION AND STORAGE
Shaking, crashing and turning upside down of the device
should be prevented when transporting it. Store it in
a properly ventilated place with dry air and without any
corrosive gas.
CLEANING AND MAINTENANCE
• Disconnect the device from the electricity when
cleaning the equipment.
• Use cleaner without corrosive substances to clean
the surface.
• Dry all parts well before the device is used again.
• Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
REGULAR CONTROL OF THE DEVICE
Check regularly whether the device is damaged. If it should
be damaged, please stop using it immediately and contact
your customer service to solve the problem. What to do in
case of a problem? Please contact your customer service
and prepare the following information:
• Invoice number and serial number (the latter is to be
found on the technical plate on the device).
• If relevant, take a picture of the damaged, broken or
defective part.
• It will be easier for your customer service clerk to
determine the source of the problem if you give
a detailed and precise description of the matter.
The more detailed your information, the better the
customer service will be able to solve your problem
rapidly and eciently!
CAUTION: Never open the device without the authorization
of your customer service. This can lead to a loss of warranty!
UK

6 7
Rev. 05.03.2021 Rev. 05.03.2021
NOTES NOTES

8Rev. 05.03.2021
expondo.de
Hersteller an Verbraucher
Sehr geehrte Damen und Herren,
gebrauchte Elektro – und Elektronikgeräte dürfen gemäß europäischer Vorgaben [1] nicht zum unsortierten Siedlungsabfall
gegeben werden, sondern müssen getrennt erfasst werden. Das Symbol der Abfalltonne auf Rädern weist auf die Notwendigkeit
der getrennten Sammlung hin. Helfen auch Sie mit beim Umweltschutz. Sorgen Sie dafür, dieses Gerät, wenn Sie es nicht mehr
weiter nutzen wollen, in die hierfür vorgesehenen Systeme der Getrenntsammlung zu geben.
In Deutschland sind Sie gesetzlich [2] verpichtet, ein Altgerät einer vom unsortierten Siedlungsabfall getrennten Erfassung
zuzuführen. Die öffentlich – rechtlichen Entsorgungsträger (Kommunen) haben hierzu Sammelstellen eingerichtet, an denen
Altgeräte aus privaten Haushalten ihres Gebietes für Sie kostenfrei entgegengenommen werden. Möglicherweise holen die
rechtlichen Entsorgungsträger die Altgeräte auch bei den privaten Haushalten ab.
Bitte informieren Sie sich über Ihren lokalen Abfallkalender oder bei Ihrer Stadt – oder Gemeindeverwaltung über die in Ihrem
Gebiet zur Verfügung stehenden Möglichkeiten der Rückgabe oder Sammlung von Altgeräten.
[1] RICHTLINIE 2002/96/EG DES EUROPÄISCHEN PARLAMENTS UND DES RATES
ÜBER ELEKTRO – UND ELEKTRONIK – ALTGERÄTE
[2] Gesetz über das Inverkehrbringen, die Rücknahme und die umweltverträgliche Entsorgung
von Elektro – und Elektronikgeräten (Elektro – und Elektronikgerätegesetz – ElektroG).
Umwelt – und Entsorgungshinweise
For the disposal of the device please consider and act according to the national and local rules and regulations.
CONTACT
expondo Polska sp. z o.o. sp. k.
ul. Nowy Kisielin-Innowacyjna 7
66-002 Zielona Góra | Poland, EU
e-mail: [e-mail]
