StarTech.com SAT3520U2R User manual

SATA Hard Drive Enclosure
3.5” Black USB2.0 to Dual SATA
Hard Drive Enclosure with RAID
SAT3520U2R
Instruction Manual

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company
in question. Regardless of any direct acknowledgement elsewhere in the body of
this document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

i
Table of Contents
Introduction..................................................................... 1
Packaging Contents.....................................................................1
System Requirements .................................................................1
Front View....................................................................................2
Rear View ....................................................................................2
Installation....................................................................... 3
Hardware Installation...................................................................3
Driver Installation.........................................................................7
How to Use ...................................................................... 7
Operating Modes.........................................................................7
Using the RIB Clean Utility ..........................................................8
Specifications.................................................................. 9
Technical Support........................................................... 10
Warranty Information...................................................... 10

1
Introduction
This Dual SATA External RAID Hard Drive Enclosure offers a practical
external RAID solution, allowing you to install two Serial ATA hard
drives for connection to a host computer through high speed USB
2.0. Delivering easy to use, yet versatile external RAID storage, the
enclosure can select JBOD, Striping (RAID 0), Spanning (non RAID),
and Mirror (RAID 1) modes.
Packaging Contents
1 x SAT3520U2R drive enclosure•
1 x USB cable•
1 x Screw kit with screw driver•
1 x Power Adapter•
1 x Software CD•
1 x Instruction Manual•
System Requirements
USB enabled computer system•
Microsoft• ®Windows®2000/XP/Vista/7,
or Apple®Mac OS®X, or Linux®

2
Power•
Rebuild•
HDD1 Access•
HDD2 Access•
HDD1 Error•
HDD2 Error•
Air Vent
USB
connector
Power
switch
Power
connector
Front View
Rear View

3
Installation
WARNING: Hard drives require careful handling, especially when
being transported. If you are not careful with your hard disk, lost data
may result. Always handle your hard drive and storage device with
caution.
Hardware Installation
Mode Selection1.
Remove the cover of the enclosure by unfastening and removing1.
the screws on the bottom of the unit (bottom side is closest to
the USB 2.0 and DC/IN ports). Insert the screwdriver into the
remaining screw hole, and press outward.
With the cover removed, the DIP switches used for mode2.
selection are exposed. Please note that the DIP switch numbers
are denoted on the switch casing.
To configure SAT3520U2R for RAID, use the following DIP switch3.
selections. Once completed, please leave the enclosure open,
for hard drive installation:

4
DIP Switch Hard Drive Mode Max Volume Size
Single/JBOD Above 2TB
Single/JBOD Under 2TB
Spanning Above 2TB
Spanning Under 2TB
RAID 0 (Stripe) Above 2TB
RAID 0 (Stripe) Under 2TB
RAID 1 (Mirror) Above 2TB
RAID 1 (Mirror) Under 2TB
Hard Drive Installation2.
WARNING! If you are installing drives to be used in RAID 1 (Mirroring)
Mode with a drive that already contains data, that drive must always be
installed first.
NOTE: If you are configuring SAT3520U2R for RAID applications
(Mirroring Mode, Striping Mode or Spanning Mode), the installed hard
drives must be identical in brand, size and model number.

5
Unfasten the two screws on either1.
side of the internal drive holder
case, and pull backward to release
and remove the drive tray from the
enclosure.
Non-RAID (Single Mode) or RAID 0 Configurations:
Insert both hard drives into the drive1.
tray, and secure them with screws
(provided). Insert the drive tray (with
both drives installed) back into the
enclosure.
Push the drive tray forward in the2.
enclosure, securing the connection. Once
the tray is firmly connected, fasten the
screws on the holder. Replace the top panel
of the enclosure, and fasten the screws at the
bottom.
RAID 1 Mirror Mode
Insert the primary (containing data to1.
be mirrored) drive into the drive tray,
and fasten it to the tray with the screws
provided.

6
Insert the drive tray back into the enclosure,2.
ensuring the tray is secured using the
connectors.
Once secure, power on the enclosure.3.
SAT3520U2R will recognize the drive as the master drive, and4.
prepare it for mirroring. Once complete, the error light indicator of the
second drive will illuminate (denoted as HDD2 Error).
When this occurs, power off the enclosure, and remove the drive tray5.
from the enclosure.
Insert the second drive (containing no data)6.
into the drive tray, and fasten it to the tray
with the screws provided.
Secure the drive tray to the enclosure connections, and fasten the7.
tray to the enclosure using the screws removed earlier.
Place the cover back on the enclosure, and replace the screws8.
removed earlier.
Power on the enclosure.9.
SAT3520U2R will indicate that the Rebuild function is under way10.
(the corresponding light will display activity), as the data from Drive
1 is mirrored onto Drive 2, and RAID 1 is configured on the drives.
NOTE: that the Mirroring process may take several minutes to several
hours, depending on the amount of data being mirrored.
WARNING! Please do NOT power off the enclosure, until the HDD2
Error LED is no longer illuminated.

7
Driver Installation
Windows 2000/XP/Vista/7, Mac OS X, Linux
No driver installation is required for these operating systems, as
this drive enclosure is natively supported, so the drivers are already
installed.
How to Use
Operating Modes
Single Mode (Non-RAID)
In Single Mode, the installed drives will appear individually as two
independent drives. This function can be used if only one hard drive is
installed, or two different brands or capacities of drive are being used.
RAID 0 - Spanning Mode
In Spanning Mode, two hard drives will appear as a single, large drive.
Spanning is an array that is written sequentially across two drives.
RAID 0 - Striping Mode
Striping combines multiple hard drives into a single large disk array.
The data is split evenly across both drives simultaneously. Read/write
performance is increased as a result, but failure of any one disk will
make the entire array unusable.

8
RAID 1 - Mirroring Mode
To operate in Mirroring Mode, two identical hard drives (capacity, brand
and model number) must be used. This mode creates an extra copy (or
mirrored set) of the data from drive one on the second drive. Mirroring
Mode provides data redundancy that is useful in the event that the
primary hard drive fails, allowing an instant replacement of damaged
data with the second set.
NOTE: If RAID 1 mode is in effect, and you wish to change to single
or RAID 0 modes, please use the RIB Clean utility to clean the drives
partition table, located on the StarTech.com website, in the Downloads
section. For more information, please see the section titled Using the
RIB Clean Utility.
Using the RIB Clean Utility
If you wish to switch from RAID 1 - Mirroring Mode to another
operating mode, the RIB Clean Utility must be used to prepare partition
information.
To use the RIB Clean Utility:
Download the utility from the StarTech.com website (Downloads1.
section), and save it to the local computer.
Double-click on the RIBClean icon to launch the Utility.2.
Once the main Utility screen loads, click on Scan Disk.3.
Once Disk Scanning is complete, click on Clean RIB. Once4.
complete, click on Exit.

9
Specications
Bus Interface USB 2.0
Connectors USB type B
DIN power connector
LEDs
Power, Rebuild, HHD1 Access,
HDD2 Access, HDD1 Error,
HDD2 Error
Chipset Oxford OXU931DS
Maximum Data Transfer Rate 480Mb/s
Hard Drive Support 3.5” SATA 1.5/3.0 Gbps up to
2TB in capacity
Power Adapter 5V/12V, 2A/2A
Compatible Operating
Systems
Windows 2000/XP/Vista/7, Mac
OS X, Linux

10
Technical Support
StarTech.com’s lifetime technical support is an integral part of our
commitment to provide industry-leading solutions. If you ever need
help with your product, visit www.startech.com/support and access
our comprehensive selection of online tools, documentation, and
downloads.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in
materials and workmanship for the periods noted, following the initial
date of purchase. During this period, the products may be returned
for repair, or replacement with equivalent products at our discretion.
The warranty covers parts and labor costs only. StarTech.com does
not warrant its products from defects or damages arising from misuse,
abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA
LLP (or their officers, directors, employees or agents) for any damages
(whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising
out of or related to the use of the product exceed the actual price paid
for the product. Some states do not allow the exclusion or limitation of
incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-find easy” since 1985,
providing high quality solutions to a diverse IT and A/V customer
base that spans many channels, including government, education
and industrial facilities to name just a few. We offer an unmatched
selection of computer parts, cables, A/V products, KVM and Server
Management solutions, serving a worldwide market through our
locations in the United States, Canada, the United Kingdom and
Taiwan.
Visit www.startech.com today for complete information about all
our products and to access exclusive interactive tools such as the
Cable Finder, Parts Finder and the KVM Reference Guide.
