StarTech.com FPWTLTB1 User manual

Manual Revision: 05/21/2019
User Manual
For the latest information and specications visit
www.startech.com/FPWTLTB1
TV Wall Mount | Heavy-Duty | Tilt
Actual product may vary from photos
SKU#: FPWTLTB1

1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Use of Trademarks, Registered Trademarks, and other
Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and
other protected names and/or symbols of third-party companies not related in
any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service
by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com
hereby acknowledges that all trademarks, registered trademarks, service marks,
and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.

2
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Safety Statements
Safety Measures
• Product installation and/or mounting should be completed by a certied
professional as per the local safety and building code guidelines.
• Cables (including power and charging cables) should be placed and routed
to avoid creating electric, tripping or safety hazards.
Mesures de sécurité
• L’installation et/ou le montage du produit doit être réalisé par un
professionnel certié et dans le respect des normes locales et du code de
construction local.
• Les câbles (y compris les câbles d’alimentation et de chargement) doivent
être placés et acheminés de façon à éviter tout risque électrique, de chute ou
de sécurité
安全対策
• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に
従い、有資格の専門業者が行うようにしてください。
• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し
を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう
にしてください。
Misure di sicurezza
• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un
tecnico professionale certicato che conosca le linee guida locali sulle norme
edilizie e sulla sicurezza.
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati
e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o
pericoli per la sicurezza.
Säkerhetsåtgärder
• Installation och/eller montering får endast göras av behöriga yrkespersoner
och enligt gällande lokala förordningar för säkerhet och byggnormer.
• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så
sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.
For the State of California
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov

3
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Warning Statements
• Make sure to assemble this product according to the instructions. Failure to
do so might result in personal injury or property damage.
• Make sure that the weight of the TV doesn’t exceed the weight capacity
of this product. If you exceed the weight capacity, you might experience
personal injury or damage to the equipment. This product can support the
following weight: Up to 75 kg (165 lb.).
• Never operate this product if parts are missing or damaged.
• The wall mount is designed to be installed on a wood stud, solid concrete,
or cinder block wall. The wall structure should also be capable of supporting
at least four times the weight of the mounted equipment. The mounting
hardware included with this product may not be adequate for installation on
certain wall structures. Failure to comply with these warnings may result in
personal injury or damage to the equipment.
• The mounting hardware included with this product might not be adequate
for some wall structures. If you lack the necessary expertise to attach this
product to the wall structure that you’re using, contact a construction
professional to install the wall mount or to provide specic mounting
instructions for your wall structure.
Dichiarazioni di avvertenza
• Assemblare il prodotto rispettando le istruzioni. Il mancato rispetto delle
istruzioni potrebbe causare danni a persone o proprietà.
• Vericare che il peso del monitor non superi la capacità di supporto del
prodotto. In caso di superamento della capacità di supporto potrebbero
vericarsi danni a persone o apparecchiature. Il prodotto è in grado di
supportare i seguenti pesi: 75 kg.
• Non utilizzare il prodotto in presenza di parti mancanti o danneggiate.
• Le caratteristiche dei muri sono variabili ed è importante vericare che
la struttura muraria e l’hardware di montaggio in uso siano in grado di
supportare adeguatamente le apparecchiature montate. Il mancato rispetto
delle istruzioni potrebbe causare danni a persone o proprietà. La struttura
muraria deve essere in grado di supportare un peso almeno quattro volte
superiore a quello dell’apparecchiatura montata.
• L’hardware di montaggio incluso con il prodotto potrebbe non essere
adeguato ad alcune strutture murarie. Se l’utente non dispone delle
competenze necessarie per agganciare il prodotto alla struttura muraria
in uso, dovrà contattare un professionista edile per installare il supporto a
parete o ottenere istruzioni di montaggio per la struttura muraria in uso.

4
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Avertissements
• Assemblez ce produit conformément aux instructions. Si vous ne respectez
pas ces instructions, vous risquez de vous blesser ou d’endommager
l’équipement.
• Vériez que le poids du moniteur ne dépasse pas la capacité pondérale du
produit. Si vous dépassez la capacité pondérale, vous risquez des blessures
corporelles ou des dommages matériels. Ce produit peut supporter de 75 kg.
• N’utilisez pas ce produit si des pièces sont endommagées ou manquantes.
• Les structures des murs varient. Vous devez impérativement vérier que
le type de mur et le matériel de xation que vous utilisez permettent de
soutenir correctement l’équipement. Dans le cas contraire, vous risquez des
blessures corporelles ou des dommages matériels. La structure du mur doit
pouvoir supporter au moins quatre fois le poids de l’équipement monté.
• Le matériel de xation inclus avec ce produit n’est pas forcément approprié
pour toutes les structures de murs. Si vous ne disposez pas des compétences
nécessaires pour installer ce produit au mur, contactez un professionnel
an qu’il installe le support mural ou qu’il vous fournisse les instructions de
montage spéciques à votre structure de mur.
Warnhinweise
• Montieren Sie dieses Produkt gemäß den Anweisungen. Anderenfalls kann
dies zu Verletzungen von Personen oder Schäden an Eigentum führen.
• Das Gewicht des Monitors darf die zulässige Traglast des Produkts nicht
übersteigen. Wenn die Traglast überschritten wird, kann dies zu Verletzungen
von Personen oder Schäden an Geräten führen. Dieses Produkt ist für
folgendes Gewicht geeignet: 75 kg.
• Das Produkt darf nicht bedient werden, wenn Teile fehlen oder beschädigt
sind.
• Wandstrukturen unterscheiden sich, und es muss sichergestellt werden,
dass die Wand und das verwendete Montagematerial das montierte Gerät
halten kann. Anderenfalls kann dies zu Verletzungen von Personen und/oder
Schäden an Geräten führen. Die Wand muss mindestens das Vierfache des
Gewichts des montierten Geräts halten können.
• Das mitgelieferte Montagematerial ist möglicherweise nicht für jede Wand
geeignet. Wenn Ihnen die nötigen Fachkenntnisse zum Anbringen dieses
Produkts an einer Wand fehlen, lassen Sie einen Fachmann den Wandhalter
anbringen, oder lassen Sie sich von einem Fachmann Montageanweisungen
für Ihre Wand erteilen.

5
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Waarschuwingen
• Zorg dat dit product volgens de instructies in elkaar wordt gezet. Indien dit
niet goed gebeurt kan lichamelijk letsel of materiële schade ontstaan.
• Zorg dat het gewicht van het scherm de maximale capaciteit van dit product
niet overschrijdt. Als u de gewichtscapaciteit overschrijdt, kan persoonlijk
letsel of schade aan de apparatuur ontstaan. Dit product ondersteunt het
volgende gewicht: 75 kg.
• Gebruik dit product nooit als er onderdelen ontbreken of beschadigd zijn.
• Omdat wanden verschillen, is het belangrijk dat u ervoor zorgt dat het type
wandstructuur en de montagemiddelen die u gebruikt de gemonteerde
apparatuur goed ondersteunen. Indien u dit niet doet kan lichamelijk
letsel en/of schade aan de apparatuur ontstaan. De wandstructuur moet
voldoende zijn om ten minste vier keer het gewicht van de gemonteerde
apparatuur te ondersteunen.
• De bij dit product geleverde montagemiddelen kunnen niet geschikt zijn
voor sommige wandstructuren. Als u onvoldoende kennis hebt om dit
product aan de door u gebruikte wandstructuur te bevestigen, neem dan
contact op met een bouwkundige om de steun aan de muur te installeren of
specieke montage-instructies voor uw wandstructuur te geven.
Varningsmeddelanden
• Se till att du monterar produkten i enlighet med instruktionerna. Om du inte
gör det kan skada på person eller egendom uppstå.
• Se till att skärmens vikt inte överstiger produktens viktkapacitet. Om
viktkapaciteten överstigs kan skada på person eller utrustning uppstå. Denna
produkt har stöd för följande vikter: 75kg.
• Använd aldrig produkten om delar saknas eller är skadade.
• Eftersom väggstrukturer varierar är det viktigt att kontrollera att
väggstrukturen och monteringsutrustningen som du använder klarar av
den monterade utrustningen. Om du inte gör det kan skada på person och/
eller utrustning uppstå. Väggstrukturen ska kunna klara av minst fyra gånger
vikten av den monterade utrustningen.
• Monteringsutrustningen som medföljer produkten kanske inte är lämplig
för vissa väggstrukturer. Om du saknar nödvändiga kunskaper för att
fästa denna produkt på väggstrukturen som du använder, kontakta en
professionell konstruktör för att installera väggmonteringen eller för att ge
specika monteringsinstruktioner för din väggstruktur.

6
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Mensagens de aviso
• Certique-se de que monta este produto de acordo com as instruções.
O incumprimento pode resultar em ferimentos pessoais ou danos de
propriedade.
• Certique-se de que o peso do monitor não excede a capacidade de peso
deste produto. Se exceder a capacidade de peso, pode sofrer ferimentos
pessoais ou danos no equipamento. Este produto pode suportar o seguinte
peso: 75 kg.
• Nunca opere este produto se faltarem peças ou estas estiverem danicadas.
• As estruturas de parede variam e é importante certicar-se de que o tipo de
estrutura de parede e hardware de montagem que está a usar irá suportar
devidamente o equipamento montado. O incumprimento pode resultar
em ferimentos pessoais e/ou danos no equipamento. A estrutura de parede
deve ser capaz de suportar pelo menos quatro vezes o peso do equipamento
montado.
• O hardware de montagem incluído com este produto pode não ser
adequado para algumas estruturas de parede. Se não tiver o conhecimento
necessário para xar este produto à estrutura de parede que está a usar,
contacte um prossional de construção para fazer a instalação em parede ou
para fornecer instruções de montagem especícas para a sua estrutura de
parede.
Advertencias de uso
• Asegúrese de ensamblar este producto según las instrucciones. De lo
contrario, pueden producirse lesiones personales o daños en la propiedad.
• Asegúrese de que el peso del monitor no exceda la capacidad de carga de
este producto. Si se excede dicha capacidad se podrían producirse lesiones
personales o daños al equipo. Este producto tiene la siguiente capacidad de
carga: 75 kilogramos.
• Nunca opere o ponga en funcionamiento este producto si faltan piezas o hay
daños en las mismas.
• Las estructuras de las paredes pueden variar y, por tanto, es importante
determinar con certeza que el tipo de estructura de la pared y el hardware
de montaje que se va a utilizar puedan soportar debidamente el equipo. De
lo contrario, se pueden producir lesiones personales o daños en el mismo. La
estructura de la pared debe ser capaz de soportar al menos cuatro veces el
peso del componente instalado.
• El hardware de montaje incluido con este producto puede no ser adecuado
para algunas estructuras de pared. Si no tiene la experiencia suciente para
jar este producto a la estructura de la pared correspondiente, póngase en

7
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
contacto con un profesional de la construcción para instalar el soporte de
pared o para que le proporcione las instrucciones especícas de montaje
para su estructura de pared.
注意
• 必ず取扱説明書に従って本製品の組み立てを行って下さい。
• 最初に取扱説明書を最後まで読み、本製品の組み立て方をすべて理解し
てから組み立て作業を始めて下さい。
• 本製品は、室内での使用を想定しています。戸外では使用しないで下さ
い。
• 本製品は、二人がかりでの組み立てを想定しています。手助けなしに単独
で組み立てと設置を行わないで下さい。
• モニタの重量が本製品の最大積載重量を超えないようにして下さい。最
大積載重量をオーバーした場合、怪我をする恐れや器物破損の恐れがあ
ります。モニタアームの耐荷重：2-8kg.キーボードトレイの耐荷重：2.5
kg.
• 壁面の構造は建物によって異なります。壁面の構造や使用する取り付け
金具が設置する装置を適切に支えられるかどうか、必ず確認してくださ
い。この注意を怠ると、怪我をする恐れや器物破損の恐れがあります。設
置する装置の少なくとも4倍の重量に耐えられる壁面構造が必要となり
ます。
• 壁面の構造によっては、本製品に付属の取り付け金具では十分な強度が
得られないことがあります。ご使用の壁面に適切に設置できるか判断し
かねる場合は、内装工事の専門業者にお問い合わせの上、本製品の壁面
設置を依頼するか、特定の壁面に適した設置方法について助言を受けて
ください。
• 反動注意！本製品には、リフト機構が組み込まれており、積載した装置を取
り外すと反動で急激に上昇する可能性があります。装置を取り外す前に、
本製品を最も高い位置に移動させて下さい。この操作を怠ると怪我をす
る恐れや器物破損の恐れがあります。

8
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Table of Contents
Safety Statements..................................................................................2
Warning Statements..............................................................................3
Product Diagram....................................................................................9
Product Information..............................................................................10
Package Contents...................................................................................10
Requirements .........................................................................................15
Installing the Tilt Adjustment Knobs ..................................................15
Installing the Bubble Level...................................................................17
Mounting the Wall Bracket ...................................................................17
Attaching the Vertical Brackets (Flush Mounting)............................19
Recessed Mounting.................................................................................................................................. 21
Spacer Combination ..............................................................................23
Mounting the TV ....................................................................................24
Adjusting the Tilt ...................................................................................25
Removing the TV....................................................................................26

9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Diagram
Number Part
1Bubble Level (1)
2Wall Bracket (1)
3Vertical Brackets (2)
4Release Straps (2)
1
2
33
4 4

10
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Information
Package Contents
Wall Bracket
Qty: One
Vertical Brackets
Qty: Two

11
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Tilt Adjustment Knobs
Qty: Two
Bubble Level
Qty: One
M5x14 mm Screws
Qty: Four
M6x14 mm Screws
Qty: Four

12
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
M6x30 mm Screws
Qty: Four
M8x50 mm Screws
Qty: Four
M8x30 mm screw
Qty: Four
Rectangular Washers
Qty: Four

13
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Small Spacers
Qty: Eight
Large Spacers
Qty: Eight
Wall Screws
Qty: Six
Concrete Anchors
Qty: Six

14
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Round Washers
Qty: Six
Requirements
For the latest requirements, please visit www.startech.com/
FPWTLTB1.
• A Display or TV, compatible with the VESA mounting hole
patterns
• A Phillips Head Screwdriver
Installing the Tilt Adjustment Knobs
1. On the Vertical Bracket, remove the top nut located on the
side of the Vertical Bracket. Once removed the nuts can be
discarded.

15
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Removing Nut

16
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
2. Replace the nut with one of the Tilt Adjustment Knobs.
Tilt Adjustment Knob
3. Repeat steps 1 - 2 to install the second Tilt Adjustment
Knob on the other Vertical Bracket.

17
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installing the Bubble Level
• Insert the Bubble Level into the impression on the center on
the top of the Wall Bracket.
Installing the Bubble Level
Mounting the Wall Bracket
Notes: StarTech.com is not responsible for any damages
related to the installation of this product.
The Wall Mount can accommodate up to 100” TV with a
max weight of 165lbs (75kg), when installed properly.
1. Position the Wall Bracket on the wall, in the desire position.
2. Using the Bubble Level (included), adjust the Wall Bracket
until the bubble inside the Bubble Level is centered
between the two hash marks.
Proper Use of Bubble Level

18
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
3. The TV Wall Mount can be mounted using the Mounting
Hardware included.
Attaching the Vertical Brackets
(Flush Mounting)
To accommodate dierent TV designs, the TV Wall Mount
comes with ve sets of screws of dierent lengths and
diameters, washers with two hole sizes, and two sizes of
spacers.
1. Determine the depth and diameter of the mounting holes
located on the back of the TV.
2. Once you determine the correct depth and diameter of the
hardware needed.
Note: The Spacers can be used if the included screws are
too long for the TV Mounting Holes.
3. Align one of the Vertical Brackets (with the Adjustment
Knob facing outward) with the Mounting Holes of the back
of the TV.
4. Place the Rectangular Washers over the Screw Holes on
the Vertical Bracket.

19
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
5. Insert the either the M5x14 mm or M6x14 mm Screws
(depending on the hardware requirement), through the
Rectangular Washers, Vertical Brackets, and into the TV.
Securing the Vertical Bracket
