StarTech.com RK219WALLV User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: November 13, 2020 6:26 PM
Product Diagram (RK219WALLV)
Component Function
1Cage Nut Holes
• Secures the equipment to the Wall Mount
Bracket.
• 2U of rack mounting space.
2Mounting Holes
• 6 Mounting Holes, secures the Wall Mount
Bracket to a Mounting Surface.
• The Wall Mount Bracket can be mounted
vertically or horizontally.
•
Requirements
For the latest requirements, please visit www.startech.com/RK219WALLV
• (Optional) Cage Nut Tool
• Phillips® Head Screwdriver
• 1U - 2U Equipment
2U 19in Steel Vertical Wall Mount Equipment Rack Bracket
Mounting the Wall Mount Bracket
Notes: Product mounting should be completed by a certied professional as per the
local safety and building code guidelines.
Mounting structures vary, and it’s important to make sure that the type of structure
and mounting hardware used will properly support the mounted equipment. Failure to
do so may result in personal injury and/or equipment damage.
1. Make sure the Mounting Surface is sturdy enough to support the weight of the
Wall Mount Bracket and installed equipment combined, 125.3 lb. (56.7 kg).
2. Test t the Wall Mount Bracket to the Mounting Surface to ensure a proper t
3. Using a Writing Utensil, mark the 6 Mounting Holes.
4. Use the included Wood Screws (for wood surfaces only), to mount the Wall Mount
Bracket to the Mounting Surface.
Installing Equipment
1. Insert the one side of the Cage Nut into the Cage Nut Hole and apply pressure to
the other side of the Cage Nut until it snaps into place.
2. Repeat step 2 to install the second Cage Nut into the Wall Mount Bracket.
Note: If it is too dicult to install the M5 Cage Nuts by hand, use a Cage Nut Tool
(not included) to install the M5 Cage Nuts.
3. Align the Mounting Points on the Equipment with the M5 Cage Nuts on the Wall
Mount Bracket.
Note: The number of Mounting Points may vary depending on the type of
Equipment. The Equipment may have more than Mounting Points and may
require the installation of additional M5 Cage Nuts.
4. Insert the M5 Screws (included) through the Equipment’s Mounting Points and
into the M5 Cage Nuts.
5. Using a Phillips Head Screwdriver (not included), tighten the M5 Screws, being
careful not to over-tighten.
2
1
