ENGLISH
5
5
INDEX
1. Part List ................................................................... 17
2. Spares...................................................................... 17
3. Use limitations........................................................ 17
4. Characteristics........................................................ 18
5. Specications ......................................................... 18
6. User instructions.................................................... 19
6.1. Adjusting the mask to user .......................................... 19
6.2. Adjusting protection angle ........................................... 19
6.3. Adjusting sensibility ..................................................... 20
6.4. Adjusting wait time....................................................... 20
6.5. Setting grinding........................................................... .20
7. Maintenance............................................................ 20
7.1. Cleaning and storage .................................................. 20
7.2. Replacing protective lenses......................................... 20
7.3. Replacing exterior protection....................................... 20
7.4. Replacing interior protection........................................ 20
7.5. Replacing harness...................................................... .20
7.6.Replacinglter............................................................. 21
7.7. Guarantee................................................................... .21
8. Inspection................................................................ 21
9. Declaration of conformity...................................... 22
1. PART LIST Fig.1
1. Filter holder.
2. Protective inner lens.
3. Fixed/automaticlter.
4. Control of degree of protection.
5. Frame fastening screw.
6. Protective outer lens.
7. Textile band of sweat.
8. Harness height adjustment band.
9. Angle adjustment plate in working position.
10.Attemming adjustment of the harness perimeter band.
11. Retaining bolt for adjustment plate # 9.
12. Screws for attaching the harness to the helmet.
13.Mounting the locking nut of the harness to the hull.
14.Casco.
15. Setting the sensitivity to dark.
16. Set standby to clear.
17. Right clip.
18. Left clip.
19. Shade regulating potentiometer
20.Casco
21. Rightclip(AS-X/AS-XP)
22. LeftClip(AS-X/AS-XP)
23. Resetbutton(self-diagnostics-safetyADF(AS-XL)
24. Filterattachmentholes(AS-XL)
25. Filterattachmentbar(AS-XL)
26. Filterretentionstraps(AS-XL)
27. ReplaceableBatteryHousing(AS-XL)
28. BatteryIndicator(AS-XL)
29. CompleteClipsSet(AS-XL)
Protect this manual and have it available to the
user.
Read and understand completely this manual
before using this product.
External
Protector
Protector
Interno Harness Filter
FIG 6. 2. 8. 3.
AS-XP 4020.48 4020.47 4020.19 4020.31
AS-X 4020.8 4020.13 4020.19 4020.18
AS-XL 4020.29 4020.30 4020.42 4020.27
AS-R 4020.8 4020.57 4020.55 4020.53
AS-1D 4020.58 4020.59 4020.60 4020.61
GS-0 - 8110.1220 8110.1221 8110.1219
2. SPARES
Do not use any solder equipment without prior
training.
Do not use equipment if you are not prepared
for its use. Before each use, inspect the
equipment as explained in this manual to
insure that equipment is in perfect state.
Do not make any modications to equipment
other than mentioned in this manual. Do not
use replacement part other than mentioned in
this manual.
3. USE LIMITATIONS
Do not work under possible sever impact conditions. This
equipment is designed to protect under normal welding conditions.
Do not work out of the margins of this equipments design.
This equipment does not protect against corrosive liquids
or in an explosive atmosphere.
Do not work out of the margins of this equipments design.
Using this equipment with temperatures lower than -5ºC
orhigherthan55ºCe󰀨ectslterdesignandcouldcause
permanent damage to the eyes and even loss of vision.
This equipment must be used for overhead welding and
laser cutting and welding.
This equipment is not designed to work in wet conditions
or in water. Do not submerge in liquid.
Do not work out of the margins of this equipments design.
The use of this equipment in any other type of activity that
requires a level of protection higher than 13 could cause
permanent damage to the eyes and even a loss of vision.
This equipment is not designed to be used with laser cutting
or any other work that requires a grade greater than 13.
Do not use this equipment in extensive overhead soldering.
Dangerous burns could be received if there is a possibility
of droppings from molten metal. Do not use dissolvent on
thelterorhelmet.

ENGLISH
6
6
4. CHARACTERISTICS
The mask “stayer welding” are composed by four main
parts:
1. Helmet sell STAYER EN 175 F (Fig nº 14).
2. Automaticdarkeninglter4/9-13STAYER
1/3/2/2/379(Fig nº 3).
3. Front cover lens STAYER 1 F (Fig nº 6).
4. Back cover lens STAYER 1 S (Fig nº 2)
Explanation of helmet sell STAYER EN 175 F
STAYER=manufacturer code, EN 175= number of testing
standard,F=symbolforlowenergyimpact(45m/s).
Explanationofautomaticdarkeninglter4/9-13STAYER
1/3/2/2/379.
Explanation: 4 = light state, 9-13 = dark states, STAYER
= manufacturer code, 1 = optical class, 3 = di󰀨usion of
light class, 2 = homogeneity class, 2 = angle dependence
class, 379 = number of testing standard.
Explanation of cover lens STAYER 1 F and STAYER 1 S.
Explanation: STAYER=manufacturer code, 1 = optical class,
F=symbolforlowenergyimpact(45m/s)orS=increased
robustness).
Warning!
Automatic darkening lters shall only be used in
conjunction with a suitable backing ocular.
Warning!
If the symbols F and B are not common to both the ocular
and the frame then it is the lower level which shall be
assigned to the complete eye-protector.
Warning!
Materials which may come into contact with wearer’s skin
could cause allergic reactions to susceptible individuals.
Warning!
Scratched or damaged oculars should be replaced.
Warning!
Eye-protectors against high speed particles worn over
standard ophthalmic spectacles may transmit impacts,
thus creating a hazard to the wearer.
Note
If protection against high speed particles at extremes of
temperature is required then the selected eye-protector
should be marked with the letter T immediately after the
impact letter. If the impact letter is not followed by the
letter T then the eye protector shall only be used against
high speed particles at room temperature.
INTRODUCTION
The product “welding maskAS-X /AS-R /AS-XP /AS-
XL” includes 2 photo sensors implanted at eye level in the
automaticdarkening lter.This lter darkens orlightens
automatically depending on the level of light induced.
The lter is transparent before soldering that the way
that the user can observe clearly the surface of the work
area.Whenthesolderarcenergizes,thelterwilldarken
immediately.Whenthearcisnished,thelterwillbecome
transparent once again.
Thetimethatistakesfortheltertogofromtransparent
to dark is extremely fast: 0.00004 seconds.
Filter protection is adjustable in a way that the user can select
thelevelofprotectionbetweendegrees9to13(EN379).
The lter gives the user complete and permanent
protection from inferred and ultraviolet radiation even in
transparent mode.
Thelterhasaspecialpositionforgrinding.Inthisposition
thelterdoesn´tdarkwiththesparksofananglegrinder.
The level of protection against radiations IR/UV is
permanently set at 13 degrees.
Thelterincludes2supercialremovabletransparenthigh
weight molecular polymer protectors which are resistant
to particle sticking, and excessive use.
The unit is power via integrated solar cells in a way that
the user does not have to change batteries or turn on nor
o󰀨theunit.
The GS-0 welding mask includes a permanent dark crystal
lterDIN11.
5. SPECIFICATIONS
GS-0
Filter dimensions ....................................110 x 80 x 3 mm
Vision area..................................................... 97 x 73 mm
Degreeofprotection,clearstate/darkstate................ 11
Degree of protection, dark state ................................... 11
Protection against inferred and ultraviolet .................... 11
Interval between clear to dark ................................. 0 sec
Internal between dark to clear ................................. 0 sec
Operating Temperature.......................................-5 -55 ºC
Weight .............................................................500 grams
AS-1D
Filter dimensions ......................................... 110 x 90 mm
Vision area..................................................... 98 x 35 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Protection against inferred and ultraviolet ....................15
Interval between clear to dark ...................... 1/20000sec
Internal between dark to clear ........................ 0.2-0.8 sec
Sensibility........................................................Automático
Operating Temperature.......................................-5 -55 ºC
Weight .............................................................440 grams
Guarantee............................................................. 2 years

ENGLISH
7
7
AS-R
Filter dimensions ....................................110 x 90 x 8 mm
Vision area..................................................... 92 x 35 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Protection against inferred and ultraviolet ....................15
Interval between clear to dark ..................... 1/20.000sec
Internal between dark to clear .............................. 0.4 sec
Sensibility.............................................................. manual
Power supply....................................................solar cells
Operating Temperature.......................................-5 -55 ºC
Weight .............................................................500 grams
Guarantee............................................................. 2 years
AS-X
Filter dimensions ....................................110 x 90 x 9 mm
Vision area..................................................... 92 x 42 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Degree of protection at max dark state ........................13
Protection against inferred and ultraviolet ....................16
Interval between clear to dark ...................... 1/25000sec
Internal between dark to clear ........................ 0.2/0.8sec
Filter battery................................................Mod. CR2032
Sensibility.............................................................. manual
Power supply....................................................solar cells
Operating Temperature.......................................-5 -55 ºC
Weight .............................................................500 grams
Guarantee............................................................. 2 years
AS-XP
Filter dimensions ....................................110 x 90 x 9 mm
Vision area..................................................... 92 x 42 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Degree of protection for grinding....................................2
Protection against inferred and ultraviolet ....................16
Interval between clear to dark ...................... 1/25000sec
Internal between dark to clear ........................ 0.2/0.8sec
Sensibility.............................................................. manual
Power supply....................................................solar cells
Operating Temperature.......................................-5 -55 ºC
Weight .............................................................500 grams
Guarantee............................................................. 2 years
AS-XL
Filter dimensions ....................................110 x 90 x 9 mm
Vision area..................................................... 92 x 42 mm
Degree of protection, clear state ....................................4
Degreeofprotection,darkstate............................5/9-9/13
Protection against inferred and ultraviolet ....................16
Interval between clear to dark ...................... 1/25000sec
Internal between dark to clear ........................ 0.2/0.8sec
Sensibility.............................................................. manual
Power supply....................................................solar cells
Operating Temperature.......................................-5 -55 ºC
Weight .............................................................440 grams
Guarantee............................................................. 2 years
30 40 60 70 100 125 150 175 200 225 250 300 350 400 450 500 600
9 10 11 12
1211
10
9
10 11 12
13
13
13
1211
10
10 11 12
913
13
1211
109
9 10 11 12 13
1312
11
109
NOTE – The tern “heavy materials” applies to steel, alloy steel, copper and its alloys, etc..
Micro plasma
Arc welding
Plasma
Jet cutting
Finish-to-air arc
MIG with light
Alloys
MIG with heavy
Metals
TIG
MAG
Process
30 40 60 70 100 125 150 175 200 225 250 300 350 400 450 500 600
Current intensity (A)
Recommended use of different degrees of protection to EN 169 arc welding
Coated electrodes

ENGLISH
8
8
6. USER INSTUCTIONS
6.1. Adjusting the mask to the user.
Inthe modelsAS-X /AS-XP/AS-1D.Adjustments may
varydotodi󰀨erentsizesofusershead.Tocorrectlyadjust
the equipment to individual users, follow the proceeding
instructions.
1. Adjust the height of the head: Adjust the upper band
ofthe harness (8),adjustthe length ofthe band so
that it sits on the head in a way that the eyes are at the
heightofthelterwiththemaskperpendiculartothe
horizon and the harness is parallel to the horizon.
2. Adjustment of the perimeter to the head: Adjust the
adjustmentknob(10)bypushingandturninguntilthe
harness sits comfortably without too much slack or too
much pressure.
3. Adjust the angle of vision: Loosen screws (13),
Liftandturntheworkangleadjustmentdeck(9)ina
way that the upper part of the mask is in its working
position (stopper of the harness resting in the stopper
ofthedeck(9))anangleof10ºto15ºtowardsthe
face of the user.
6.2. Adjusting protection angle
Adjustknob(4)usingthefollowingtablebasedinUNEEN
379:2004/A1:2010.
These tables are valid for mid class work conditions where
the distance between the operators eyes and the base of
the molten metal is approximately 50 cm and the middle
brightness is around 100 lx.
TheAS-XL model has a range selector with three positions:
1. Shade range DIN 5-9.
2. Shade range DIN 9-13.
3. Grinding without shadow.
Select according to welding type. Generally, work in the
range 9-13 except for low intensity work such as low
intensityTIGorsoftamewelding.
Grinding mode: in this mode the lter does not darken
avoid losing vision when used as a protector against
sparks projections.
In the AS-XL model: Set knob 4 according to the following
table based on UNE EN 379: 2009-07.
These tables are valid for average working conditions,
where the distance from the observer’s eye to the molten
metal bath is approximately 50 cm and the average
illumination is about 100 lx.
The use of a degree of protection higher does
not necessarily proportion more protection
and obligates the user to close in on the
radiant source and breath harmful fumes.
It’s possible to use lters with one more
degree of protection when working in open
air where there is a strong natural illumination.
6.3. Adjusting sensibility (AS-1D/AS-X/AS-XP/AS-XL)
This regulation, labeled “SENSIVITY” (nº 15) calibrates
theminimumlightintensityneededfordarkeningthelter.
Adjustment is continuous form minimum to maximum
butthree standardposition (min, mediumand max)are
explained.
1. Min.(LO)Usedwhenisusedclosetoanotherwelders
arcs. The purpose is to avoid not desired darkening
ofthelterwhenotherweldershaveestablishedtheir
welding arc. Complementary to this use case is the
situation of high amperage welding.
2. Medium.Thisis thestandard and initiallyrecommended
position for medium amperages and / or sunlight
conditions.
3. Max.(HI)Foruseincoveredandaloneweldingwith
no interference with another welder’s arcs.
Complementary is the situation of low amperage
welding in no sunlight presence. Staring to sunlight
canredarkeningwhenlterisatmaximumsensibility.
It is recommended to start adjustment at mid position
adjusting until the adequate adjustment is obtained.
6.4 Adjusting wait time (AS-1D/AS-X/AS-XP/AS-XL)
Thisregulationisnamed“DELAY”(nº16)andsetsthetime
elapsed between the end of welding arc and the return to
clearstate ofthe weldinglter.Two limituse casesare
described, Min and Max positions.
1. Max. For using at high amperage welding with very
bright welding pool. In this case is desirable a slight
cool of pool before enable eye to see.
2. Min. In low amperage, quick cooled, situations were
immediate control is desired.
Initial position recommended is central one.
It is recommended to start adjustment at mid position
adjusting until the adequate adjustment is obtained.
6.5. Setting grinding
Youcanadjustyourmask(AS-X/AS-R/AS-XP/AS-XL)
as work either welding or grinding.
1. ToenablethemaskgrindingAS-X/AS-R/AS-XP/
AS-XL just put the controller in position 17 GRIND.
TousetheGS-0maskingrindingoperations,liftthexed
lteruntilitstops.
Never leave the knob 17 in the grinding position.
Risk of glare if welded.

ENGLISH
9
9
7. MAINTENANCE
7.1. Cleaning and Storage
Clean the equipment using a soft cloth, a medium soap
and lukewarm water. Do not use solvents.
Cleantheautomaticlterwithacloththatdoesnoloose
bers.Donotprojectspraysinequipmentnorsubmerge.
Store equipment in a place that has a medium temperature
and is clean and dry without any dust.
Sincetheinnerpartoftheouterltercanbegetdirtwith
the welding smoke is recommended to be dismantled and
cleaned regularly.
7.2. Replacing the protective lenses
Theautomatic lter3 hastwo protectivelens toprotect
theotherlensfromsmokeyingparticlesandarcspatter
during the welding process.
Use only original lters supplied by distributor.
7.3. Replacing the exterior protection (AS-X/AS-R/AS-
XP)
Toremovetheprotectivelter:
1. Pressdownwardstheapsofthebuttons21-22, on
both sides of the transparent screen.
2. Pull protector 6 while holding clips 21-22 to release
the clear shield.
7.4. Replacing the interior protection
1. Remove the interior protector 2withindexngerinthe
groovesuppliedatuppersideoflter.
2. Place the interior protector 2by slightly bending in a
way so that it can be inserted into the four highlighted
corners.
3. Removetheprotectivelmfromthesurface.
7.5. Replacing the harness
If the harness 8is broken or does not adjust correctly,
proceed with its replacement.
Only use original harness that is supplied by
an o󰀩cial distributor.
Extract the harness by loosening knobs and nuts (13) and
separate the screws (12).
Replace with new harness using the screws (12) and nuts
(13) respecting the insertion of the angular adjustment
dock (9).
7.6. Replacing the lter (AS-1C/AS-0/AS-XL)
Whenthelterhasbeenusedmorethantwoyears,itis
necessarytochangetheautomaticlter.
Only use original lter that is supplied by an
o󰀩cial distributor.
Changing the inner protector
Simply start the guard or its retaining clip to remove and
replace the guard .
1. Loosen and remove potentiometer knob 4.
2. Release the adjustment potentiometer by loosening
and removing the outer nut.
3. Release the protective frame 1 by loosening and
removing the screws 5
4. Removetheoldlterandpresentthenewoneonthe
hull.
5. To assemble the mask, follow these instructions starting
from 4 to 1.
6. FixthelterbyplacingframeNo.1,tighteningscrews#
5, setting potentiometer and pressing knob # 4.
7.7. Guarantee
Guarantee card
Included in the documentation that accompanies this
equipment,youshouldndthewarrantycard.
You should ll out the card completely and return to
vendor with a copy of purchasing receipt or invoice and
you should receive a receipt.
Note: If you cannot nd the warranty card within the
documentation, you must ask for it through your
supplier.
Conditions of warranty
As with professional equipment, there is established a
warranty period of one year from the date of purchase.
The warranty will expire immediately if the Customer
Attention department in the Central O󰀩ce does not
receive the warranty card within one month of the date of
purchase.
The warranty will also expire if this equipment is used in
an inappropriate manner or accessories are used that are
notappropriatetothespecicationsofthemanufacturer.
The warranty is limited only to manufacturing defects and
expire if pieces have been removed or manipulated or
repaired other than the manufacturer.
STAYER repair of defective parts or replacement is
granted only after being analyzed by its technicians.
All costs of shipping and disassembly will be considered
to part of the purchaser.
To make it easier for technicians, a list of defects that
where found during use should be supplied.

ENGLISH
10
10
8. INSPECTION
Before each use, mandatorily inspect the equipment. Do
not use the equipment if it does not comply with any of the
following circumstances. Any component not valid should
be replaced immediately.
The harness to the head is clean, complete and adjusts
perfectly to the head.
The helmet is clean, complete and does not present any
type of crack.
The lters should be complete with no embedded
projection chips or cracks, including the protection lenses.
Thelter mustcover completely isslot inaway theno
type of light passes through.
The photo sensors must be visible under any circumstance
and not covered by any particles.
The lter should not be used if it has exceeded its
expiration date. Verify that 2 years have not passed
fromthetraceabilitycode.Checktherstfourcharacters
(startingfromtheleft)inthecodemarkedoninteriorpart
oftheautomaticdarkeninglter.Firsttwoaretheyearand
second ones are the week.
Make sure that the automatic lter doesn’t fails and
darkens immediately after the welding arc appears. If not,
reject it from using and contact your dealer immediately.
Don’t test directly with a welding arc for security.
Recommended procedure is:
1. Touse a cigarette lighter for testing automatic lter.
Onlywiththesparkstheltermustimmediatelydarken
in any position of the sensitivity control 15.
2. To face the welding mask against the direct sun light
andverifythatlterdarkens.Increaserstsensitivity
control 15 between medium and high.
Always test before use!
Sensorsoftheautomaticdarkeningltershouldbekept
clean and unobscured.
9. DECLARATION OF CONFORMITY CE
The undersigned:
STAYER IBÉRICA, S.A.
Address:
Sierra de Cazorla 7
Área empresarial Andalucía Sector 1
28320Pinto(Madrid)SPAIN
Tel:+34916918630/Fax:+34916918631
CERTIFY THAT
Individual protection equipment:
Type: Welding Mask with automatic lter.
Is in compliance with the provisions of annex II of Directive
89/686/ECC(Edition1989-12)andstandards:
DIN EN 166:2002-04 for protective oculars.
DIN EN 175:1997-08 for helmet sell.
DINEN379:2009-07forautomaticweldinglter.
Notiedbodynameandaddress:
DIN CERTCO Gesellschaft fuer onformitaetsbewertung
mbH Alboinstrasse 56 - 12103 Berlin.
Notiedbodynumber0196.
January, 2017
Signed: Ramiro de la Fuente Muela
Manager Director

www.grupostayer.com
Área Empresarial Andalucía - Sector 1
C/ Sierra de Cazorla, 7
28320 - Pinto (Madrid) SPAIN
Email: [e-mail]
Email: [e-mail]
