Steam Australia PEGASO SVD User manual

PEGASO SVD Quick Start Guide
Tel: [phone] E-mail: inf[email protected] Web: www.steamaustralia.com.au
1
PEGASO SVD PEGASO Display PEGASO Hose Controls
_______________________________________________________________________________________________
Preparing the PEGASO
Steam Operation:
1. Plug cable into a wall outlet. NOTE: Do NOT use
multi-outlet power-boards and avoid using low-
quality extension cables.
2. Open water tank
filler cap (i), fill
tank with clean tap
water up to the
line indicator on
the left-side panel
(iv) then close filler
cap. NOTE: Do NOT
use de-mineralised water, do
NOT fill above maximum line
indicator (iv) and do NOT fill
with any chemicals.
3. Turn PEGASO on using the
ON/OFF switch (a), making sure
the “ON” LED (o) lights up and the machine beeps
straight away.
4. Press the ‘Boiler Switch’ button on
the display (c) to start the boiler. After
approx. 10 minutes the digital display
(b) showing the boiler temperature
should show a temperature at or
slightly above 170C and the machine
should be at pressure (p). This means
that the steam function is ready to use.
5. Connect hose into the PEGASO by opening the
protective plastic flap located on the front of the
machine (v) and pushing the plug end of the hose in
with the “doman” imprint on the top side of the
hose until it clicks.
Proceed to “Vacuum Operation” and/or “Detergent
Operation” section if you are planning on using the vacuum
and/or detergent functions together with the steam
functions.
Vacuum Operation:
Locate the vacuum
switch (S) on the
vacuum head unit (iii)
and turn it on.
NOTE: The vacuum
bucket can be cleaned
by detaching the bucket from the vacuum head
through the latch that holds it. Always make sure the
bucket is fitted on properly to ensure that the
contents will not disperse to your surroundings.
Detergent Operation:
1. Open
detergent tank
filler cap (ii), fill
tank with
detergent
2. Remove the
detergent tank
filler cap and
fill with the diluted 101 degreaser solution until it
reaches up to the line indicator on the right-side panel
(vi). NOTE: We recommend using Steam Australia’s
101 degreaser or similar to ensure it does not impact
machine operation and/or cause adverse health
issues.
3. Replace the detergent filler cap (ii) before
operating.
i
ii
iii
iv
v
a
b
c
d
e
S/V HOSE
S/O HOSE
f
g
T
h
k
i
S
ii
iv
p
p
o
vi
INCLUDED
OPTIONAL

PEGASO SVD Quick Start Guide
Tel: [phone] E-mail: inf[email protected] Web: www.steamaustralia.com.au
2
Hose Handle Operations
Steam Function:
1. After approx. 10 minutes, check that the machine
has reached pressure. Ready light will be illuminated
and the digital display shows that the boiler
temperature reaches at or above 170C.
2. If the PEGASO makes a beeping noise and the “Tank
Level” LED (d) flashes, proceed to Step 2 of “Preparing
the PEGASO | Steam Operations” (page 1).
3. For S/V Hose, press and hold the trigger (T) to
activate the steam function. For S/O Hose, toggle the
steam on/off switch (h) to activate an automatic
stream.
4. Adjust the steam level from the knob (e). Turning
clockwise will increase steam level, turning counter-
clockwise will decrease it.
WARNING: Do NOT operate hose with steam nozzle
pointing at persons, animals or electrical machinery
/equipment/outlets/sensors that are sensitive to
water and heat (especially near fire alarm sensors).
Vacuum Function:
1. Plug the S/V Hose into the PEGASO.
2. Press the vacuum button (f)to engage the vacuum
function. The vacuum will turn on and you will feel
suction from the vacuum nozzle.
NOTE: Ensure that you regularly empty out the
contents of the vacuum waste bucket for a smooth
operation and change the HEPA filter located under
the vacuum head inside of the bucket if it is worn out
or too stained.
Detergent Function:
Press and hold the detergent button (g for S/V Hose, k
for S/O Hose) to activate the detergent function.
If the detergent runs low in the PEGASO, the hoses
will stop spraying detergent. This is noticeable when
using the steam function in conjunction with the
detergent function as only the drier steam sprays out
the nozzle when the detergent function is activated.
Proceed to Step 1 –3 of “Preparing the PEGASO |
Detergent Operation” (page 1) if this happens.
Warning Lights
The PEGASO will make a beeping noise and a red LED
light will flash when the water tank’s level is low:
For water tank low level, refer to Step 2 of “Preparing
the PEGASO | Steam Operations” (page 1).
Cleaning the PEGASO
Draining the PEGASO’s boiler once a month ensures
that the machine operates at optimal conditions.
WARNING: Ensure machine has cooled down before
attempting to clean out the boiler by checking that
the machine doesn’t feel warm on the bottom part
and machine is free from any pressure.
You will need:
- A pan or container that can hold at least 5 litres of
water
- A rag
- Flathead screwdriver
- Supplied socket wrench
1. Ensure the machine isn’t plugged into a power
source and the machine doesn’t feel warm (no
pressure present).
2. Locate the brass boiler plug underneath the
PEGASO and position the PEGASO on top of a pan or
container.
3. Using the supplied socket wrench, unscrew the
boiler plug by slowly turning counter-clockwise. You
may need to use a rag to hold the plug as you unscrew
the plug by hand after loosening using the socket
wrench. Let the water drain, then screw the plug back
on and tighten with supplied socket wrench.
d

PEGASO SVD Accessories Guide
Tel: [phone] E-mail: inf[email protected] Web: www.steamaustralia.com.au
3
Floor Tool S/V
Squeegee S/V
KIT0805
Steam/Vac Squeegee
300mm
Spray a stream of steam in a circular
motion onto the glass surface, then
use the rubber squeegee part to
remove water condensation and
clean the surface.
If using in areas with frosty climates,
warm the windows or mirrors by
spraying a high stream of steam for
a slightly prolonged time before
cleaning.
This tool is also available for the
KIT0800/MOD Steam + Vacuum
Hose:
KIT0805 S/V Squeegee 300mm
KIT0804 Floor Brush
300mm
KIT0822 Teflon
Carpet Insert
KIT0824 Rubber Lip
Insert
2 x KIT0801
Extension Tube
S/V 500mm
KIT0800/MOD S/V
Hose 4M
For hard floor surfaces such as:
- Tiles
- Marble
- Most sealed hardwood
- Linoleum & Vinyl
- Carpets
- Non-slip surfaces
First, use high steam pressure to lift
dirt off the floor. Then disengage
the steam and turn on the vacuum
to suck the floor dry.
We recommend using the steam
and vacuum functions separately as
it will perform better this way.
Whenever the vacuum motor is
turned on, the steam boiler loses
some of its power and will take
longer to produce 7.5 bars of
pressure.

PEGASO SVD Accessories Guide
Tel: [phone] E-mail: inf[email protected] Web: www.steamaustralia.com.au
4
Detailing Extension + Small Nylon Brush (Steam Only)
KIT0703 Steam
Lance 100mm
2 x KIT0701 S/O
Extension Tube
500mm
KIT0700 S/O Hose
4M
KIT0816/N Small Brush
w/ nylon bristles
KIT0816/I Small Brush
w/ Stainless Steel
bristles
Optional Accessories:
KIT0816/O Small Brush
w/ Brass bristles
KIT0814/O Big Round
Brush w/ Brass bristles
For detail cleaning in kitchens,
bathrooms and other areas:
- Tile grouts (walls and floors)
- Drains
- Cooktops
- Bathtubs
- Roadside chewing gum removal
For best results, hold brush on angle to
clean sides of the grout line, and then
tilt in other direction to clean the
other side of the grout line.
Optional stainless steel and/or brass
brushes can be fitted onto the
detailing nozzle to scrub off certain
hard-to-remove stains in nooks and
crannies. Stainless steel is particularly
effective on grout and chewing gum
stains.
Be wary that the stainless steel and
brass brushes may scratch certain
surfaces, leaving unwanted scratch
marks. Always test areas in an
inconspicuous spot before proceeding.
This tool is also available for the
KIT0800/MOD Steam + Vacuum hose:
KIT0808/DA/X –S/V lance short
KIT0801 –Extension Tube S/V 500mm
The brushes fits both S/V and S/O
lances.

PEGASO SVD Accessories Guide
Tel: [phone] E-mail: inf[email protected] Web: www.steamaustralia.com.au
5
Car Wash Upholstery Tool (Steam + Vacuum)
KIT0806/CW Car
Wash Upholstery
Tool
KIT0800/CW6M
S/V Hose Car
Wash 6M (short
grip)
The optional KIT0800/CW6M Hose
features a shorter handle grip that gives
an easier access for use in car detailing
jobs. When used in conjunction with the
KIT0806/CW upholstery tool, it is the best
tool combination for cleaning interior
carpets, mats, roof linings and fabric car
seats.
Turn on the vacuum. Squeeze the steam
trigger and vacuum at the same time by
dragging the tool towards you in a
straight line. Let go of the steam trigger
when you are finished with one line and
repeat the previous step by starting on a
new straight line. Best used with the
detergent function.
Triangular Brush (Steam Only)
KIT0709
Triangular Brush
with bristles
KIT0706 Joint for
brushes
2 x KIT0701 S/O
Extension Tube
500mm
KIT0700 S/O
Hose 4M
Microfibre Cloth
For cleaning skirting boards, kitchen
benchtops, underneath kitchen cabinets,
rangehoods, car interior mattresses,
upholstery and other areas.
Begin with low level steam to loosen
bacteria, introduce light to moderate
scrubbing as required, with or without
steam activated.
To steam clean upholstery and other
surfaces, fit brush with cushion and wrap
with a reusable or disposable microfibre
cloth securing with clips on tool. This
creates a superheated steam pocket with
a smooth surface to effectively sanitise a
range or hard and soft surfaces.
Caution: when cushion & microfibre are
used tool will retain heat and moisture.
This tool must be used with caution with
risk of burning. Tools will be hot after use.

PEGASO SVD Accessories Guide
Tel: [phone] E-mail: inf[email protected] Web: www.steamaustralia.com.au
1
Floor Brush (Steam Only)
KIT0707
Rectangle Floor
S/O Brush
KIT0706 Joint for
brushes
2 x KIT0701 S/O
Extension Tube
500mm
KIT0700 S/O
Hose 4M
Microfibre Cloth
For cleaning walls & floors where
abrasion is required. Including tiles &
grout, marble, sealed concrete, linoleum
& vinyl & non slip surfaces. Sanitising soft
surfaces such as carpet, mattresses &
upholstery.
Begin with low level steam to loosen
bacteria, introduce light to moderate
scrubbing as required, with or without
steam activated.
Wrap the rectangle brush with microfibre
cloth to steam clean upholstery and other
surfaces such as mattresses and lounges.
This creates a super-heated steam pocket
as the microfibre wrap retains the heat.
This is excellent for sanitising surfaces and
killing bacteria, dust mites & bed bugs.
Caution: when cushion and microfibre are
used tool will retain heat and moisture.
This combined tool must be used with
caution with risk of burning. Tools will be
hot after use.
Floor Mop Head + Microfibre Mop Pad (Steam Only) (Optional Extras)
KIT0714 Steam Mop
400mm
KITQ706 Microfibre
Mop Pad 400mm
2 x KIT0701 S/O
Extension Tube
500mm
KIT0706 Joint for
brushes
KIT0700 S/O Hose
4M
For cleaning non-carpeted hard-floor
surfaces.
Engage steam flow and move forwards
and backwards quickly over the floor
surface.
Caution: when cushion and microfibre are
used tool will retain heat and moisture.
This combined tool must be used with
caution with risk of burning. Tools will be
hot after use.
