THANK YOU FOR YOUR PURCHASE!
QUESTION? PROBLEM? CONTACT STELPRO CUSTOMER SERVICE.
WWW.STELPRO.COM
CONT[email protected]
1-866-766-6020
THIS UNIT
COMPLIES WITH
CSA STANDARDS

2INSASSO0518
Before installing and using this product, you must read and
understand these instructions and keep them for future refer-
ence. If the installer and the user do not follow these instruc-
tions, the manufacturer cannot be held liable in any way and
the warranty will be null and void.
The following instructions must be adhered to in order to
avoid personal injuries or property damages, serious injuries
and potentially fatal electric shocks.
If the installer or the user modies the unit, they will be held
responsible for any damage resulting from this modication,
and the CSA certication could be void.
INTENDED USE
For indoor installation only.
Make sure the unit is appropriate for the intended use (if
needed, refer to the product catalog or a representative).
RECOMMENDED HEATING CAPACITY: 1,25 W per ft3
(0.03 m3). This corresponds to 10 W per ft2(0.09 m²) based on
a standard ceiling height of 8 ft (2.44 m). The recommended
capacity is usually sucient for normal heating needs. Please
note that the insulation quality of walls and windows are some
of the factors that inuence heat losses, which modify the
required capacity to heat a room. If needed, speak with a spe-
cialist (industrial and commercial buildings) who will be able to
calculate these heat losses and optimize the required capacity
or consult the “Calculation Tools/Heating Calculator” section
of the °STELPRO Design website.
If the unit capacity is insucient for the size of the room, it
will be in operation continuously, and may become defective
earlier and turn yellow.
POSITION
Do not install the unit where objects or pieces of furniture
could be heat damaged.
Respect the following distances and positions: This unit must
be installed at least 6 in. (15 cm) from any adjacent surfaces
and at least 6 in. (15 cm) from the oor. Make sure objects
or pieces of furniture such as, but not limited to, blankets,
towels, beds, laundry baskets, clothing, papers, etc. do not
come into contact with the unit, and keep them at least 36 in.
(90 cm) from the unit. Some materials are more heat-sensitive
than others, so make sure those near the unit can withstand
heat. Do not install on a wall behind a door.
This unit has hot and arcing or sparking parts inside. It is not
designed to be used or stored in wet areas or areas contain-
ing ammable liquids, combustible materials or corrosive,
abrasive, chemical, explosive and ammable substances such
as, but not limited to, paint, gasoline, chlorine, sawdust and
cleaning products.
RISK OF FIRE, ELECTRIC SHOCK,
BODILY INJURY AND DAMAGE
This product must be installed by a qualied person and con-
nected by a certied electrician, according to the electrical
and building codes eective in your region.
Protect the heating unit with the appropriate circuit breaker or
fuse, in accordance with the nameplate.
Make sure the line voltage (volts) is consistent with that indi-
cated on the unit’s nameplate.
This unit must be grounded.
Switch o the power at the circuit breaker or fuse before
installing, repairing and cleaning the unit.
This unit must not come into contact with a water source
and must be protected from splashes (e.g., splashes from a
sink or shower). Do not use it if any part has been immersed.
Moreover, do not turn it on or o when standing in water or if
your hands are wet.
When starting up the unit for the rst time or after a long pe-
riod, it is normal that it produces some temporary odours.
Because this unit is hot when in use, it may pose risks even
in normal operation. Therefore, be careful and responsible
when using it. To avoid burns, do not let bare skin touch hot
surfaces. The unit must cool down for few minutes since it will
stay warm for some time after shut down.
Do not insert or allow foreign objects to enter any air vent as
this may cause electric shocks, res or damages to the unit.
MAINTENANCE
Some areas are dustier than others. Thus, it is the user’s res-
ponsibility to evaluate if the unit must be cleaned based on
the amount of dirt accumulated on and inside air vents. Ac-
cumulated dirt can lead to a component malfunction or give a
yellowish colour to the unit. Failure to install and maintain the
unit in accordance with these instructions poses a re hasard.
Thermal protection activation indicates that the unit has been
subjected to abnormal operating conditions. If the thermal
protection remains activated it is recommended that a quali-
ed electrician or a certied repair centre examine the unit
in order to make sure it is not damaged. (Refer to the limited
warranty.)
If the unit is damaged or defective, discontinue use, cut o
power supply at circuit breaker or fuse and have it repaired at
a certied repair centre. (Refer to the limited warranty.)
IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS

3INSASSO0518
2 Mounting screws
for the front panel
Knob for the timer
(ASSO…T2TW)
WHAT IS IN THE BOX
INSTALLING THE FAN HEATER
TO ENSURE A SAFE AND EASY INSTALLATION, TAKE A FEW MINUTES TO READ THIS INSTALLATION GUIDE.
SONOMA
Wall fan heater
SONOMA HORIZON
Wall fan heater
2 caps Self-adhering spacer
Knob for the mechanical
thermostat
(ASSO… T2W)
Knob for the mechanical
thermostat
(ASSOH… T2W)
CONTROL AND COMPATIBILITY
You can control your Sonoma fan heater in multiple ways:
ASSO(H) ... WCW ASSO(H) ... T2W ASSO ... T2TW
With a Maestro thermostat or any other
compatible wall thermostat that:
• Has a fan heater mode
• Can handle the fan heater’s power
(see the product nameplate)
With its integrated mechanical
thermostat
With its integrated mechanical
thermostat and timer
TOOLS REQUIRED
2 Screws (1-1/2") with a 1/4" (6.5 mm) diameter
head minimum, suitable for securing the back box
directly to a stud.
Tool to cut drywall or gypsum board
Level
Phillips screwdriver
Wire stripper
Wire clamp
Tape measure
Stud nder
Flat screwdriver

4INSASSO0518
A
WARNING: This product must be installed by a certied electrician according to the electrical and building codes
eective in your region.
Install your fan heater in an unobstructed location at least
6 in. o the ground.
TIP: You can access the fan heater’s controls more easily
if you install it 12 in. o the ground.
ATTENTION: To avoid any risk of overheating, leave
a clearance of at least 36 in. in front of the fan heater
and 6 in. on either side of it.
No objects or furniture such as, but not limited to,
blankets, towels, a bed, a laundry basket, clothing,
papers, etc., should come into contact with fan heater.
Keep these items at least 36 in. away from it.
It is not designed to be used or stored in wet areas
or areas containing ammable liquids, combustible
materials or corrosive, abrasive, chemical, explosive
and ammable substances such as, but not limited
to, paint, gasoline, chlorine, sawdust and cleaning
products.
Make sure that objects or furniture near the heater can
withstand the heat it gives o.
Do not install the heater on a wall behind a door.
If a piece of furniture is nearby, make sure the fan heater will
not impede the opening of its drawers or doors.
To recess your fan heater in a wall, consider the following:
• Check the construction of your wall. There should be
at least 4 in. from the outside of your nishing and the
inside of your wall. A 2 × 4 wood stud construction with
a 1/2 in. thick nishing are considered compliant [A].
• Avoid installing in an exterior wall as this decreases the
wall’s insulation.
• Consider the location of the studs in your wall. One side
of the heater must be xed to a stud.
• Consider the location of pipes, electrical wires or other
components that may be present inside the wall and
damaged during installation.
1WHERE TO INSTALL YOUR FAN HEATER
DRY WALL
2 × 4 STUD
TOP VIEW
6" MIN.
6" MIN.
36" MIN.
4"
MIN.

5INSASSO0518
ON OFF
1. Locate the studs and any other
structures that might be inside
the wall.
2. Measure the space required
according to the diagrams
shown beside.
3. Make an opening according
to the direction of the desired
installation.
4. Pull the power cable out of the
wall. You will need at least 6 in.
of cable inside the junction
box to connect the unit’s wires
easily.
VERTICAL INSTALLATION HORIZONTAL INSTALLATION
3PREPARING THE
SURFACE FOR
INSTALLATION
10"
7 5/8"
7 1/2" MIN. 7 1/2" MIN.
10"
7 5/8"
To protect yourself from the risk of electric shock, turn o the
power to the lead wires from the electrical panel.
2CUTTING THE POWER SUPPLY

INSASSO0518
6
2
1
4
B
A3
F
D
D
C C
E
*
1. Pivot the fan heater’s front panel toward the top of
the unit [1] and slide it up. Remove the front panel
completely [2] and place it on a clean surface where
it won’t be damaged.
Note: The HORIZON front panel rest on the mecha-
nical housing of the unit. Pull it up and put aside.
4. Perforate one of
the six pre-cut
holes. Choose the
hole according
to the power
cable’s position in
the wall and the
available space.
4PREPARING THE FAN HEATER
ATTENTION : Be sure to push in the right
hole by placing the back box in the correct
direction. The notches will be positioned
at the bottom [C], or at the right [D].
6. Attach the self-adhering spacer [F] to one of the four spe-
cially identied spots on the external side of the back box
that will rest against the stud.
2. Remove the two screws. Keep the screws with the
front panel.
3.
Lift the top [3] of the mechanical housing [A] and
slide it [4] to remove it from the back box [B].
5. Place the wire clamp [E] in the hole. Insert the power cable
through the wire clamp and secure it.
*wire clamp not included

INSASSO0518
7
A
A
A
TOP VIEW
1. Insert the fan heater’s back box in
the opening you’ve made in the wall,
making sure it is level.
5ATTACHING THE BACK BOX TO THE WALL
6SELECTING THE POWER
2. According to your
installation, screw*
the box to the wall
stud using two
mounting holes [A].
NOTE: If the wall nishing is not
installed yet, make sure you position
the box at the correct depth so that
it rests on the surface once work is
complete.
For 1/2 inch thick nishing, you can
fold the side tabs and install directly
on the stud. For other thicknesses,
align the stud with the corresponding
perforated marks.
WALL FINISHING
SIDE VIEW
*Screws not included
1. The heater is provided with a jumper that allows installer to pick a
wattage onsite without any tool. To reduce the full factory wired wattage
output by half, remove the pull-out jumper [A] located on the side of the
mechanical box.

8INSASSO0518
A
C
B
L1
L1
L2/N
L2/N
GND
JUMPER JUMPER
GND
A
B
CONNECTION DIAGRAM
*ASSO(H).....T2TW*ASSO(H).....T2W
MOTORMOTOR
DOUBLE POLE
INTEGRATED
THERMOSTAT*
THERMAL
FUSE
THERMAL
FUSE
THERMAL
PROTECTION
THERMAL
PROTECTION
ELEMENT ELEMENT
ELEMENT ELEMENT
TIMER*
DOUBLE POLE
INTEGRATED
THERMOSTAT*
1. If needed, strip the power cable wires with a wire stripper.
2. Connect the fan heater and power supply wires with the
supplied connection caps [A] according to the connection
diagram. Tighten caps on the wires to make sure the
connections are secure.
3. Connect the grounding wire rmly with the green screw
[B] provided at the back of the back box. The grounding
screw can be moved to position [C], if required.
4. Store all the wires in the back box.
7CONNECTING THE WIRING
8ATTACHING THE MECHANICAL HOUSING TO THE BACK BOX
1. Put the mechanical housing
[A] in the back box by
inserting it into the bottom
notches [B] provided for this
purpose.
2. Pivot the mechanical housing
toward the wall. Be careful
not to trap the wires or caps.
3. Secure with the screws set
aside in step 4.2.
ELECTRICAL DIAGRAM OF THE DEVICE ELECTRICAL DIAGRAM OF THE DEVICE
Warning: Use copper or aluminium wires only. Use
supply wires suitable for 194 °F.

9INSASSO0518
A
ON OFF
D
DE
B
BOTTOM VIEW
C
E
9ATTACHING THE FRONT PANEL
1. Press the top of the front panel
against the wall, keeping it
slightly tilted [A] and centered
with respect to the mechanical
housing.
2. Carefully slide the front panel
down until the hooks behind the
front panel [B] are engaged and
then pivot it toward the wall.
3. Check that the screw [C] at
the bottom of the unit is inser-
ted in the front panel’s slot.
Tighten the screw to secure
the front panel.
Restore power to the fan heater and make sure the fan heater works
by raising the temperature until the unit starts to heat. See section
Controling the fan heater, p. 10, to get the most out of your unit.
10 TURNING THE POWER BACK ON
WARNING: You must set the wall thermostat to fan heater mode as soon as you restore power. If the thermostat
stays in baseboard mode, the fan heater will run intermittently and may overheat.
1a. Place the front panel and tighten the screws to
secure it.
4. According to your model, install the timer [D]
and mechanical thermostat [E] control knobs.

10 INSASSO0518
USING AND MAINTAINING THE FAN HEATER
CONTROLING THE FAN HEATER
According on your model, see the table below for how to control your fan heater.
ASSO ... WCW With a compatible wall thermostat to adjust the room’s temperature
setpoint ---
ASSO ... T2W
With its integrated mechanical thermostat
• The temperature setpoint is controlled with the knob with settings from 1 to
5, where 1 represents the minimum amount of heating and 5, the maximum.
ASSO ... T2TW
With its integrated mechanical thermostat and timer
• The temperature setpoint is controlled with the knob with settings from 1 to
5, where 1 represents the minimum amount of heating and 5, the maximum.
• The timer knob lets your fan heater run continuously at maximum heating
mode for a set period (0 to 30 minutes). Ideal for use when taking a shower.
ASSOH ... WCW With a compatible wall thermostat to adjust the room’s temperature
setpoint ---
ASSOH ... T2W
With its integrated mechanical thermostat
• The temperature setpoint is controlled with the knob with settings from 1 to
5, where 1 represents the minimum amount of heating and 5, the maximum.
WARNING: Before using your fan heater, make sure that it has been installed by a certied electrician in accor-
dance with the electrical and building codes in your area.
Do not operate without front panel.
MAINTAINING THE FAN HEATER
FOR THE WARRANTY TO BE VALID, THE FAN HEATER’S AIR INLET AND OUTLET MUST BE CLEANED REGULARLY.
WARNING: Cut o the power at the breaker or fuse
before cleaning the unit. High voltage and the risk
of electric shock are present in the unit even if the
thermostat is set to o. Therefore, you can receive an
electrical shock as long as the unit is under power.
Over time, cigarette smoke may cause the outlet grill to yel-
low. The best way to prevent yellowing is to clean the unit
regularly.
Dust the front panel with a soft cloth and clean it with a damp
cloth only. If you use cleaning products, they could cause the
heater to yellow.
If the unit is installed in a very dusty location, use the dust
brush of a vacuum cleaner to remove dust and other foreign
objects.
When maintaining the product, never use:
• A brush or metal scrubbing pad
• Chlorine
• Abrasive cleaning products
• Hydrochloric acid-based products such as bleach
• Any other cleaning products that bear the following
symbols:

INSASSO0518
11
TROUBLESHOOTING THE FAN HEATER
The following table outlines the most common issues and alerts you could
experience with your fan heater.
If your problem is not listed in the table below or the proposed solution
does not solve the problem, turn the power o and contact our customer
service team.
WWW.STELPRO.COM
CONT[email protected]
1-866-766-6020
PROBLEM/ALERT POSSIBLE CAUSE AND SOLUTION
The fan heater is not
operational after installation.
• Make sure the temperature setpoint is not too low.
• Check whether the fan heater’s wiring is correctly connected. See Connecting the wiring, page 8.
• Make sure that the circuit breaker corresponding to the heating system in the electrical panel is
closed (ON).
• If the problem persists, the thermostat may be defective. Contact STELPRO Customer Service.
The breaker goes o
when the fan heater starts.
• Check whether the fan heater’s wiring is correctly connected. See Connecting the wiring, page 8.
• Make sure the voltage supplied is adequate (see the nameplate).
• Make sure the circuit breaker or fuse is adequate for the requested power.
The temperature setpoint
is never reached.
• Make sure the voltage supplied is adequate (see the nameplate).
• Make sure the unit is powerful enough for the size of the room.
• The fan heater is overheating, and the thermal protection has been triggered. Make sure the unit’s
air inlet and air outlet are not obstructed. Once the cause of overheating is eliminated, the unit will
resume operating after a few minutes.
• If a wall thermostat controls the fan heater, make sure it isn’t defective.
• If none of the solutions above work, one or more of the heating elements may be defective. Contact
STELPRO Customer Service.
The fan heater is operating
continuously.
• Check whether the timer is at zero.
• Make sure the unit is powerful enough for the size of the room.
• If the fan heater never stops, the thermostat or timer may be defective. Contact STELPRO Customer
Service.
The ambient temperature
is too high.
• Make sure the temperature setpoint is adequate.
• If the problem persists, the thermostat may be defective. Contact STELPRO Customer Service.
Heating is not operational.
• The fan heater is overheating, and the thermal protection has been triggered. Make sure the unit’s
air inlet and air outlet are not obstructed. Once the cause of overheating is eliminated, the unit will
resume operating after a few minutes.
• Make sure the temperature setpoint is not too low.
• Check whether the fan heater’s wiring is correctly connected (see Connecting the wiring, page 8)
and choose the desired power (as needed).
• If the problem persists, the thermostat or one of the heating elements may be defective. Contact
STELPRO Customer Service.
Heating stops, but the fan
continues to run.
• The fan heater is overheating, and the thermal protection has been triggered. Make sure the unit’s
air inlet and air outlet are not obstructed. Once the cause of overheating is eliminated, the unit will
resume operating after a few minutes.
• Make sure the air inlet and air outlet are not obstructed. Clean them, if necessary (see Maintaining
the fan heater, page 10), then turn the fan heater back on.
• If the problem persists, it is possible an internal component is defective. Contact STELPRO
Customer Service.
With a wall thermostat: the
fan heater turns on and o
frequently.
• Make sure the wall thermostat is in fan mode.

INSASSO0518
12
STELPRO DESIGN INC.
Saint-Bruno-de-Montarville, Québec, Canada, J3V 6L7
This limited warranty is oered by STELPRO Design inc.
(“STELPRO”) and applies to the following product made by
STELPRO: ASSO/ASSOH model. Please read this limited
warranty carefully. Subject to the terms of this warranty,
STELPRO warrants its products and their components against
defects in workmanship and/or materials for the following
periods from the date of purchase: 5 years. This warranty ap-
plies only to the origi nal purchaser; it is non-transferable and
cannot be extended.
CLAIM PROCEDURE
If at any time during the warranty period the unit becomes
defective, you must cut o the power supply at the main elec-
trical panel and contact 1) your installer or distributor, 2) your
service center or 3) STELPRO’s customer service department.
In all cases, you must have a copy of the invoice and provide
the information written on the product nameplate. STEL-
PRO reserves the right to examine or to ask one of its repre-
sentatives to examine the product itself or any part of it before
honoring the warranty. STELPRO reserves the right to replace
the entire unit, refund its purchase price or repair a defective
part. Please note that repairs made within the warranty period
must be authorized in advance in writing by STELPRO and
carried out by persons authorized by STELPRO.
Before returning a product to STELPRO, you must have a
STELPRO authorization number (RMA). To obtain it, call the
customer service department at: 1-800-363-3414 (electricians
and distributors - French), 1-800-343-1022 (electricians and
distributors - English), or 1-866-766-6020 (consumers). The
authorization number must be clearly written on the parcel or
it will be refused.
CONDITIONS, EXCLUSIONS
AND DISCLAIMER OF LIABILITY
This warranty is exclusive and in lieu of all other representa-
tions and warranties (except of title), expressed or implied,
and STELPRO expressly disclaims and excludes any implied
warranty of merchantability or implied warranty of tness for a
particular purpose.
STELPRO’s liability with respect to products is limited as pro-
vided above. STELPRO shall not be subject to any other ob-
ligations or liabilities whatsoever, whether based on contract,
tort or other theories of law, with respect to goods or services
furnished by it, or any undertakings, acts or omissions relating
thereto. Without limiting the generality of the foregoing, STEL-
PRO expressly disclaims any liability for property or personal
injury damages, penalties, special or punitive damages, dam-
ages for lost prots, loss of use of equipment, cost of capital,
cost of substitute products, facilities or services, shutdowns,
slowdowns, or for other types of economic loss or for claims
of a dealer’s customers or any third party for such damages.
STELPRO specically disclaims all consequential, incidental
and contingent damages whatsoever.
This warranty does not cover any damages or failures result-
ing from: 1) a faulty installation or improper storage; 2) an abu-
sive or abnormal use, lack of maintenance, improper main-
tenance (other than that prescribed by STELPRO) or a use
other than that for which the unit was designed; 3) a natural
disaster or an event out of STELPRO’s control, including, but
not limited to, hurricanes, tornadoes, earthquakes, terrorist
attacks, wars, overvoltage, ooding, water damages, etc. This
warranty does not cover any accidental or intentional losses
or damages nor does it cover damages caused by negligence
of the user or owner of the product. Moreover, it does not
cover the cost of disconnection, transport, and installation.
The warranty is limited to the repair or the replacement of the
unit or the refund of its purchase price, at the discretion of
STELPRO. Any parts replaced or repaired within the war-
ranty period with the written authorization of STELPRO will be
warranted for the remainder of the original warranty period.
This warranty will be considered null and void and STELPRO
will have the right to refuse any claims if products have been
altered without the written authorization of STELPRO and
if the nameplate numbers have been removed or modied.
This warranty does not cover scratches, dents, corrosion or
discoloration caused by excessive heat, chemical cleaning
products and abrasive agents. It does not cover any damage
that occurred during the shipping.
Some states and provinces do not allow the exclusion or
limitation of incidental or consequential damages and some of
them do not allow limitations on how long an implied warranty
lasts, so these exclusions or limitations may not apply to you.
This warranty gives you specic legal rights and you may have
other rights which vary from state to state or from province to
province.
STELPRO LIMITED WARRANTY
