Stern Pinball AC/DC User manual

AC/DC
SERVICE AND OPERATION MANUAL
Games congured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe UK, Australia).
Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA; each pinball machine has unique characteristics that make it a one-of-a-kind American-made
product. Each machine will have variations in appearance resulting from differences in the machine’s particular wood parts, individual silk screened art and mechanical
assemblies. Stern Pinball has inspected each game element to ensure it meets our quality standards.
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to certain visual images, in-
cluding ashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that can cause “photosensitive epileptic seizures”
due to certain visual images, ashing lights or patterns. Symptoms can include lightheadedness, altered vision, eye or face twitching, jerking or shaking of arms or legs,
disorientation, confusion, momentary loss of awareness, and loss of consciousness or convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
1-800-KICKERS - [email protected]
www.sternpinball.com - facebook.com/sternpinball
MANUAL #780-50C8-00
AC/DC LUCI #500-55C8-01
The AC/DC mark and logo are owned by LEIDSEPLEIN PRESSE B.V. Used by Stern Pinball, Inc. with permission, all rights reserved.

2
AC/DC LUCI MANUAL 500-55C8-01
TABLE OF CONTENTS
1. Setup and Moving .................................. 3
1.1 First-Time Setup Instructions ............................... 3
1.2 Adjustments Menu ............................................... 6
1.3 Transporting the Game ...................................... 10
1.4 Maintenance ...................................................... 11
1.5 Maintenance Kits ............................................... 11
1.6 Common Parts ................................................... 11
1.7 Updating Game Code for the S.A.M. System .... 12
1.8 Fuses and Cabinet Switches ............................. 13
1.9 Service Switch & CPU DIP Switch Settings ....... 14
1.10 Diagnostic Aids .................................................. 15
1.11 CPU DIP Switch Settings ................................... 15
1.12 Switch Locations................................................ 17
1.13 Lamp Locations ................................................. 19
1.14 Coil Locations .................................................... 23
2. Service Menu System .......................... 25
2.1 Service Menu Introduction ................................. 25
2.2 Service Menu Icon Tree...................................... 26
2.3 Problem/Solution Table ...................................... 28
2.4 Diagnostics Menu .............................................. 29
3. PartsIdentication&Location ........... 37
3.1 Backbox Parts.................................................... 37
3.2 Speaker Panel Parts .......................................... 37
3.3 Cabinet Parts ..................................................... 38
3.4 Playeld Top - Main Assem. & Switches ............ 39
3.5 Playeld Bottom - Main Assem. and Switches . . 40
3.6 Playeld - Rubber Parts ..................................... 41
3.7 Rubber Size Chart .............................................. 41
4. Major Assemblies................................. 42
4.1 Ball Shooter Assembly ....................................... 42
4.2 Auto Launch Assembly ...................................... 42
4.3 Flipper Assembly, Left ........................................ 43
4.4 Flipper Assembly, Right ..................................... 43
4.5 Pop Bumper Assembly ...................................... 44
4.6 Slingshot Assembly............................................ 45
4.7 4-Ball Trough Assembly ..................................... 45
4.8 Cannon Motor & Switch ..................................... 46
4.9 AC/DC Cannon .................................................. 46
4.10 Front Molding Assembly - Premium/LE ............. 47
4.11 LED Board Assembly ......................................... 47
4.12 Top Button Switch Assembly ............................. 47
4.13 Vertical Up-Kicker .............................................. 48
4.14 Magnet Core ...................................................... 48
4.15 Left Ramp Assembly - Premium/LE ................... 49
4.16 Right Ramp Assembly - Premium/LE ................ 49
4.17 Detonator Assembly - Premium ......................... 50
4.18 Detonator Assembly - Coil/Plunger ................... 50
4.19 Electric Ball Gate............................................... 51
4.20 3-Bank Drop Target Assembly ........................... 51
4.21 5-Bank Drop Target Assembly ........................... 52
4.22 Pivoting Bell Assembly - Premium ..................... 52
4.23 Bell & Block Assembly - Premium ..................... 53
4.24 Plunger Assembly .............................................. 53
4.25 Kicker Arm Assembly - Premium ....................... 53
4.26 Mini Playeld Fastening Items - Top .................. 54
4.27 Mini Playeld Fastening Items - Bottom ............ 55
4.28 Lower Mini Playeld ........................................... 56
4.29 Rocking Band Assembly .................................... 57
4.30 Malcolm Assembly ............................................. 58
4.31 Angus Assembly ................................................ 58
4.32 Brian Assembly .................................................. 58
4.33 Cliff Assembly .................................................... 58
4.34 Back Panel Assembly ........................................ 59
5. Schematics,Wiring&PCBs ................ 60
5.1 Backbox Wiring .................................................. 60
5.2 Playeld Wiring .................................................. 62
5.3 Cabinet and Coin Door Wiring ........................... 67
5.4 Printed Circuit Boards ........................................ 70
6. Specications ..................................... 116
6.1 Game Dimensions ............................................ 116
6.2 Warranty ........................................................... 117
6.3 Warnings, Compliance, and Legal Notices ...... 117

1. SETUP AND MOVING
2
2
557
7
1
9
8
11
14
15
14
11
8
6
SETUP AND MOVING
3
AC/DC LUCI MANUAL 500-55C8-01
1.1 FIRST-TIME
SETUP INSTRUCTIONS
CAUTION: AT LEAST TWO (2)
PEOPLE ARE REQUIRED TO
MOVE AND MANEUVER THE
GAME. USE PROPER MOVING
EQUIPMENT AND EXTREME
CARE WHILE HANDLING. STERN
PINBALL MACHINES WEIGH
OVER 250LBS BOXED.
TOOLS REQUIRED
• 5/8” Socket Wrench
• Utility Knife
• Snips
• An Assistant
Your brand new Stern Pinball Machine is
carefully packed for safety and security.
For your safety, exercise caution and use
the correct tools and sufcient help when
setting up your new game.
1. Locate the side labeled “TRUCK
THIS SIDE ONLY”. The bottom of
the game faces this side.
2. Open the top box aps by pulling
hard in an upward motion on each
ap. If the aps are taped, cut the
tape rst, taking care to avoid the
box staples.
3. Remove the four (4) foam pieces
and two (2) narrow box tubes
which contain the four (4) identical
legs with levelers.
4. DO NOT CUT STRAPPING YET.
Keep backbox secured in the
down position.
5. With the utility knife, carefully cut
down the left and right corners of
the box.
6. Let the face fall forward and
remove the entire side by carefully
cutting the bottom.
7. With the game still in its folded po-
sition, use a ⅝” wrench to loosen
and remove the 2 leg bolts on each
side of the front cabinet. Ensure
the leg levelers are screwed all the
way into the legs.
8. Install front legs using the bolts
removed from the cabinet. Secure
tightly.
9. Have someone help you carefully set
the game down on the front legs.
10. Set aside the open box.
11. With a ⅝” socket wrench, loosen
and remove the 2 leg bolts on
each side of the rear cabinet, 4
total.
12. Using supports or two people,
prop the rear of the cabinet up.
13. Ensure the rear leg levelers are
screwed all the way into the legs.
14. Install rear legs using the 4 bolts
removed from step 11.

19
21
17
25
26
FIRST-TIME SETUP CONTINUED
4
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
15. Cut nylon strapping and remove
protective strap corner guards.
16. Locate the factory keys, either on
the shooter rod or taped to the
playeld glass.
17. Using snips, cut the tie-wrap secur-
ing the keys if required. One set of
keys is for the front coin door, the
other set of keys is for accessing
components in the backbox.
18. Open the front coin door.
19. Reach into the game and remove
the retaining clip at the rear of the
cash box.
20. Remove the cash box lid by sliding
it toward you.
21. Store the backbox keys, if desired,
on the metal hook located in the
coin door.
22. Locate and remove the pinballs,
plumb bob, and backbox bolts
from the cash box.
23. Replace the cash box lid and
retaining clip for future use.
24. Locate the two (2) backbox bolts in
the cash box.
25. Carefully raise backbox to upright
position while ensuring that cables
are not pinched.
26. Use the ⅝” wrench to Install the
two (2) backbox bolts to secure the
backbox as indicated on the back
of the cabinet.
27. Reach inside the cabinet and hold
and move the yellow top molding
lock handle to the left.
28. Remove the front top molding.
29. Remove the playeld glass by
sliding it toward you and carefully
place it in a safe location.
Remove all playeld shipping
tie downs, shipping blocks, and
packing foam, and follow any
game-specic unpacking instruc-
tions included in the playeld, if
present.
CAUTION: PLAYFIELD GLASS IS MADE FROM HIGH-STRENGTH TEMPERED
GLASS. TEMPERED GLASS IS SENSITIVE TO EXTREME TEMPERATURE SHIFTS
AND CORNER NICKS, WHICH CAN CAUSE THE GLASS TO FAIL CATASTROPHI-
CALLY. TAKE CARE TO STORE THE GLASS ON A SOFT, ROOM-TEMPERATURE
SURFACE AND PREVENT THE CORNERS FROM BEING DAMAGED.
27

SETUP AND MOVING
5
AC/DC LUCI MANUAL 500-55C8-01
30. If pinballs were already installed into the lower ball
trough, remove them before lifting the playeld.
31. Grasp the lower arch between the ippers, and rmly
but gently pull directly up to raise the playeld 8 to 12
inches.
32. While holding the playeld up, pull the playeld toward
you until the two playeld supports are over the front
edge of the cabinet.
33. Rest the playeld on the front edge of the cabinet.
34. Raise the playeld and rest it against the backbox.
35. Visually inspect all cabinet cables and connector termi-
nations; ensure no wires or cables are pinched and that
cable harnesses are not pulled tight.
36. Locate the plumb bob in the parts bag in the cash box.
37. Slide plumb bob onto the hanger wire. Note: the vertical
position of the plumb bob affects tilt sensitivity - higher
makes the game more sensitive to tilting.
38. Tighten the thumb screw nger-tight.
39. Install the correct number of pinballs. Refer to the decal
on the lock down assembly for the correct number of
pinballs.
LOCATING, LEVELING, AND FINAL SETUP
1. Select a location that is indoors, out of direct sunlight,
and climate controlled. Excessive moisture/humidity
can cause long-term damage to your game.
2. Adjust the front or rear levelers as necessary to position
the playeld level bubble, located on the front right of
the playeld next to the shooter lane, to oat between
the two (2) black lines. This will place the playeld at the
recommended 6.5° pitch. Playeld angles greater than
6.5° can be achieved by turning out the rear leg level-
er(s) for increased difculty and faster gameplay.
3. Use a pinball to roll down the center of the playeld for
side-to-side leveling, or use an external bubble level,
digital level, or smartphone level app.
4. Plug into a grounded outlet and check for proper opera-
tion through DIAGNOSTICS.
5. Check the coin door: With the door closed, insert coins
to verify proper operation.
6. Play game: Check for satisfactory operation and adjust
game volume (push the Red Buttons inside the Coin
Door).
7. If desired, perform any game diagnostics, game adjust-
ments, and pricing settings at this time.
FIRST-TIME SETUP CONTINUED

6
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
1.2 ADJUSTMENTS MENU
STANDARD ADJUSTMENTS
Perform the below steps to review the adjustments.
Enter the Service Menu, then enter the Standard Adjustments
Menu.
Press SELECT. Press BACK to exit or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the S.P.I. icon. Press SELECT.
STANDARD ADJUSTMENT #1 appears with the adjustment
name ashing. While the adjustment name is ashing press [<]
[>] to move between adjustments.
To change the adjustment setting press SELECT. While the ad-
justment setting is ashing, press [<] [>] repeatedly until the de-
sired setting appears. Press the SELECT button to “install” the
change. The adjustment comment (bottom line) will indicate if
the factory default setting is selected or will display INSTALLED
if the change is not a factory default setting.
ID Adjustment Name Default Setting
1 REPLAY TYPE AUTO
2REPLAY PERCENTAGE 10%
3REPLAY AWARD CREDIT
4 REPLAY LEVELS 1
5 AUTO REPLAY START 20,000,000
6 DYNAMIC REPLAY START 60,000,000
7 REPLAY LEVEL #1 15,000,000
8 REPLAY LEVEL #2 30,000,000
9 REPLAY LEVEL #3 45,000,000
10 REPLAY LEVEL #4 60,000,000
11 REPLAY BOOST YES
12 SPECIAL LIMIT 1
13 SPECIAL PERCENTAGE 10%
14 SPECIAL AWARD CREDIT
15 FREE GAME LIMIT 5
16 EXTRA BALL LIMIT 5
17 EXTRA BALL PERCENTAGE 25%
18 GAME PRICING USA 11
19 MATCH PERCENTAGE 9%
20 MATCH AWARD CREDIT
21 BALLS PER GAME 3
22 TILT WARNINGS 2
23 CREDIT LIMIT 30
24 ALLOW HIGH SCORES YES
25 HIGH SCORE AWARD CREDIT
26 GRAND CHAMPION AWARDS 1
27 HIGH SCORE #1 AWARDS 1
28 HIGH SCORE #2 AWARDS 0
29 HIGH SCORE #3 AWARDS 0
30 HIGH SCORE #4 AWARDS 0
31 GRAND CHAMPION SCORE 75,000,000
32 HIGH SCORE #1 55,000,000
33 HIGH SCORE #2 40,000,000
ID Adjustment Name Default Setting
34 HIGH SCORE #3 30,000,000
35 HIGH SCORE #4 25,000,000
36 HSTD INITIALS 3 INITIALS
37 HSTD RESET COUNT 2000
38 FREE PLAY NO
39 LANGUAGE ENGLISH
40 PLAYER LANGUAGE SELECT YES
41 CUSTOM MESSAGE ON
42 FLASH LAMP POWER NORMAL
43 COIL PUSLE POWER NORMAL
44 KNOCKER VOLUME NORMAL
45 GAME RESTART YES
46 BILL VALIDATOR NO
47 MUSIC VOLUME 1
48 BALL SAVE TIME 0:05
49 TIMED PLUNGER OFF
50 FLIPPER BALL LAUNCH OFF
51 COINDOOR BALL SAVER NO
52 COMPETITION MODE NO
53 CONSOLATION BALL YES
54 FAST BOOT YES
55 Q24 OPTION COIN METER
56 TICKET DISPENSER NO
57 PLAYER COMPETITION YES
58 TEAM SCORES NO
59 LOCATION ID 0
60 GAME ID 0
61 TIME FORMAT 12-HOUR
62 COIN INPUT DELAY 30
63 LOST BALL RECOVERY YES
64 COIN DOOR DISABLE TILT NO

SETUP AND MOVING
7
AC/DC LUCI MANUAL 500-55C8-01
FEATURE ADJUSTMENTS
Each table has feature adjustments specic to the character-
istics of that game. To access feature adjustments enter the
Service Menu and then enter the Adjustments Menu.
Press SELECT to access the Service Menu. Press BACK to exit
or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the game icon. Press SELECT.
FEATURE ADJUSTMENT #1 appears with the adjustment name
ashing. With the adjustment name ashing press [<] [>] to
move between adjustments. Feature adjustments are changed
similarly to standard adjustments using the SELECT button to
choose options and the [<] [>] buttons to cycle through avail-
able settings.

8
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
USA & INTERNATIONAL (NON-EURO)
STANDARD PRICING SELECT TABLE
*

SETUP AND MOVING
9
AC/DC LUCI MANUAL 500-55C8-01
EURO SUMMARY & INTERNATIONAL (EURO)
STANDARD PRICING SELECT TABLE
CPU/SOUND PCB
DIP SWITCH SW1
SETTING
COUNTRY
SETTING
OPTION(S)
COIN MECHANISMS (SWITCHES)PRICING SCHEME
Number of Plays (Credits) for Price Amount Shown
See "AppendixJ" for Coin Cards Examples& Info!
Requires SPI
C O INS T H R U . . . SLO T : Coin Card(s)
LEFTCENTERRIGHT4THPart Number
Pos. Default Highlighted EUR// EUROPEAN UNION EUROS // [ ]
ON SEEBE L O W Euro 1 1/0.50 755-5401-01-
Y
OFF S E T T I N G S Euro 2
1/0.50 2/1.00 3/1.505/2.00755-5401-02-
Y
Euro 1-12 are alternate settings for
countries using the Euro. Euro 3 1/0.503/1.00755-5401-03-
Y
Euro 4 1/0.50 2/1.00 3/1.506/2.00755-5401-04-
Y
=Factory Default
= Not Shown on Coin
Card
Euro 5 optional 1/0.50 3/1.00 4/1.507/2.00755-5401-05-
Y
Euro 6 2/0.50755-5401-06-
Y
Euro 7 1/1.00 2/2.003/3.005/4.00755-5401-07-
Y
Euro 8 optional1/1.003/2.00755-5401-08-
Y
Euro 9 1/1.002/1.503/2.00755-5401-09-
Y
Euro 10 1/1.003/2.007/3.00755-5401-10-
Y
Euro 11 1/1.004/2.00755-5401-11-
Y
Euro 12 2/1.004/2.006/3.009/4.00755-5401-12-
Y
For a differentEuro Pricing Scheme (other than Factory Default listed below), scroll through Standard Adjustment 18:
Euro 1-12 or CUSTOM*for new setting (reference above Euro 1-12 Summary). Keep the Country Dip Switch Setting the same as listed below.
Pos. Default Highlighted EUR// EUROPEAN UNION EUROS // [ ]
ON AUSTRIA755-5401-09-
Y
OFF Euro 9
Pos. Default Highlighted
ON BELGIUM755-5401-01-
Y
OFF Euro 1
Pos. Default Highlighted
ON FINLAND755-5401-08-
Y
OFF Euro 8
Pos. Default Highlighted
ON FRANCE755-5401-10-
Y
OFF Euro 10
Pos. Default Highlighted
ON GERMANY 1 1/0.50755-5401-01-
Y
OFF GERMANY 2
1/0.50 2/1.00 3/1.505/2.00755-5401-02-
Y
GERMANY 3 1/0.50 2/1.00 3/1.506/2.00755-5401-04-
Y
Pos. Default Highlighted
ON GREECE 3/2.00755-5401-08-
Y
OFF Euro 8
Pos. Default Highlighted
ON ITALY 1 1/0.50755-5401-01-
Y
OFF ITALY 2 1/1.003/2.00755-5401-08-
Y
Pos. Default Highlighted
ON NETHERLANDS 755-5401-03-
Y
OFF Euro 3
Pos. Default Highlighted
ON PORTUGAL 755-5401-01-
Y
OFF
Pos. Default Highlighted
ON SPAIN755-5401-08-
Y
OFF Euro 8
=Factory Default =Not Shown on Coin Card
HIGHLIGHTED
HIGHLIGHTED
HIGHLIGHTED
HIGHLIGHTED

10
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
1. SECURE THE BACKBOX
1. Ensure that the pinballs are re-
moved from the playeld, and se-
cure any free-moving mechanisms
that may get damaged in transport
2. Remove the backbox securing
bolts
3. Carefully lower the backbox onto
the side rails. Use a piece of card-
board or suitable padding between
the backbox and the game.
4. Securely strap the back box to the
game
5. The game may be transported with
the legs on. If the legs must be re-
moved, follow the remaining steps.
2. REMOVE THE LEGS AND
STAND UP
1.3 TRANSPORTING THE GAME
2
3
4
6. Remove the legs, rear legs rst. Use
a stool or a friend to support the
rear of the game.
7. Rest the rear of the game on the
ground.
6
CAUTION
NEVER TRANSPORT THE GAME
IN A MOVING VEHICLE WITH THE
BACKBOX RAISED! TWO PEOPLE
ARE REQUIRED TO REMOVE THE
LEGS!
10. Secure all loose parts and trans-
port with a hand truck in the
upright position.
8. Stand the game up on its back.
8
9. Remove the front two legs.
9
When transporting the game, such as in the back of a truck or with a hand truck, the
game’s backbox must be secured to prevent damage to the side rails.
TOOLS REQUIRED
• STRAP (500LB OR GREATER)
• AN ASSISTANT
• HAND TRUCK

SETUP AND MOVING
11
AC/DC LUCI MANUAL 500-55C8-01
1.4 MAINTENANCE
REGULAR MAINTENANCE - (MONTHLY/500
GAMES)
• Remove the playeld glass
• Enter the software diagnostics menu, start lamp test, then
clean and wax the playeld.
◊ While cleaning the playeld, identify and repair malfunctioning
lights, loose parts, cracked plastics and worn rubber parts.
• While in diagnostics, enter the switch test (Select the "SW"
Icon, then "TEST" Icon).
◊ Use a pinball to actuate all switches and verify the correct
switch registers with the switch test.
◊ The game will play a sound to conrm the switch.
• Lift the playeld and inspect all assemblies for loose parts,
broken wires or excessive wear. Look at the bottom of the
cabinet for any parts that may have worked loose, then nd
the source.
• Check all coin door mechanisms and bill acceptor (if installed)
for proper operation
• Play the game to ensure all coils and features are working
• Check the playeld to ensure it is level and set to the proper
pitch using the bubble level on the right side wood rail.
• Check game audits: Replay % and Ball Time and note abnor-
mal values which can indicate problems.
• Ensure game volume is set appropriately for the location.
• Clean both sides of the playeld glass and reinstall.
• Check and clean pinballs and replace if excessively worn or
scuffed. Dirty pinballs accelerate game wear.
OVERHAUL MAINTENANCE (5000 GAMES)
• Verify latest game software is installed
• Check ippers for excessive wear. Excessive ipper sloppi-
ness (vertical or horizontal) or weakness indicates a ipper
rebuild is required.
• Clean machine inside and out and check leg levelers for free
operation.
• Visual check for loose or broken playeld and cabinet parts
and repair as necessary.
• Electrical check: Plug into grounded outlet and check for
proper operation through DIAGNOSTICS.
• Replace worn or dirty rubbers.
• Replace pinballs.
• Check all playeld switches with a pinball.
• Check all settings (refer to manual for factory settings).
• Check coin door: With door closed, insert coins to verify
proper operation.
• Check for proper adjustment of the plumb bob tilt.
• Play game: Check for satisfactory operation.
COMMON PINBALL TOOLS
• Common nut drivers (¼”, 5/16”, 11/32", ⅜”)
• Phillips screwdriver
• Standard Allen wrench/Hex key set
• ⅝” Socket with ratchet
• Adjustable wrench (5/8" & 9/16")
• 6" Torpedo Level (or use a pinball
• Flashlight or headlamp
• Soldering Iron (60w with at tip), lead-free solder
• Wire cutter
• Wire stripper
• Long nose (“needle nose”) pliers
1.5 MAINTENANCE KITS
Description Part Number
AC/DC Luci Maintenance Kit
8 oz pinball playeld wax (Novus # 2) (675-0003-01)
Standard Pinball (260-5000-00)
Cleaning Cloth
All Playeld Rubber Rings
Spare Fuses
502-6002-C7
AC/DC Luci Deluxe Maintenance Kit
All standard kit items, plus:
Flipper rebuild kits, Left and Right (500-6307-10,-00)
502-6003-C7
AC/DC Luci Playeld Plastics Set 830-6125-XX
AC/DC Luci Playeld Decals Set 820-7000-XX
820-8353-XX
AC/DC Luci Backbox Decal Left 820-66C8-01
AC/DC Luci Backbox Decal Right 820-66C8-02
AC/DC Luci Cabinet Decal Left 820-66C8-03
AC/DC Luci Cabinet Decal Right 820-66C8-04
AC/DC Luci Cabinet Decal Front 820-66C8-05
AC/DC Luci Playeld, Unpopulated 830-5100-M7
AC/DC Luci Playeld, Populated 505-6004-C8
AC/DC Luci Mini Playeld, Unpopulated 830-71C8-00
AC/DC Luci Mini Playeld, Populated 500-5022-C8
AC/DC Luci Translite 830-52C8-00
Pinballs (4) 260-5000-00
1.6 COMMON PARTS
Description Part Number
8 oz Pinball Playeld wax (Novus # 2) 675-0003-01
Standard Pinball, 1-1/16 in 260-5000-00
Flipper Rebuild Kit Left 500-6307-10
Flipper Base Plate Kit Left 515-6617-01
Flipper Rebuild Kit Right 500-6307-00
Flipper Base Plate Kit Right 515-6617-00

12
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
1.7 UPDATING GAME CODE FOR THE S.A.M. SYSTEM
Game code is subject to change. Update this game with the latest code downloaded from our website, from another game, or order
from your local distributor.
Upon powering up, the display will describe the version of code installed in your game. When directed to do so (via Service Bulletin or
website announcment) you will need to update your code with the boot ash EPROM installed, here’s how:
STEP 1
Open the backbox and locate the 8-position DIP switch (SW1 on
the CPI/Sound board)
STEP 2
Switch DIP switch #8 to ‘ON’ (Boot ash EPROM must be in-
stalled)
STEP 3
Press the white reset button (S1 RESET on the CPU/Sound
board) or power cycle the game OFF/ON (ON/OFF switch is
located on the outside of the cabinet bottom, front right).
STEP 4
Using the 4-button service switch set (inside the coin door):
4A: Press [SELECT] to begin.
4B: With the “UPDT” icon highlighted, press [SELECT].
4C: Insert the memory stick (with the latest les) into the USB
port.
4D: If more than one le is present on the memory stick, press [<]
or [>] to locate your le. Press [SELECT] to update.
4E: Follow on-screen prompts.
GreenButton
Press to escape
back (or exit)
RedButtons
Press to move <Left, Right>.
Press to - Decrease or +
Increase values or to change
settings.
CPU/SOUND BOARD (S.A.M. SYSTEM)

SETUP AND MOVING
13
AC/DC LUCI MANUAL 500-55C8-01
1.8 FUSES AND CABINET SWITCHES
FOR PROPER OPERATION OF THIS PIN-
BALL GAME, <4> PINBALLS MUST BE
INSTALLED IN THE 4-BALL TROUGH!

14
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
1.9 SERVICE SWITCH & CPU DIP SWITCH SETTINGS
SERVICE SWITCH X4 SET OVERVIEW
The fours buttons (inside the coin door) have dual functions
depending on if you have entered the Service Menu or not.
Open the coin door to access the service switch X4 set.
FUNCTIONS IN GAME OR ATTRACT MODE
FUNCTIONS IN THE SERVICE MENU
GreenButton
Press for
Service
Credit(s).
RedButtons
Press for Volume
Adjustment
- for less (quieter)
+ for more (louder)
BlackButton
Press for
Service Menu
entry.
GreenButton
Press to Escape
Back (or Exit).
RedButtons
Press to move
< Left , Right >
Press to - Decrease
or + Increase
values or to change
settings.
BlackButton
Press to Enter
Select (or
‘OK’).
EXAMPLE
To enter the Service Menu, then enter the Switch Test Menu via
the Diagnostics Menu, perform the below steps.
STEP 1
Press [Select].
STEP 2
With the “DIAG” icon hightlighted, press [Select].
STEP 3
With the “SW” icon highlighted, press [Select].
STEP 4
With the “TEST” icon highlighted, press [Select].
Press any switch. If wired correctly, the information in the display
will match the information in the Switch Matrix.
Press [<] or [>] to move left or right through the menus.
Press [Back] to get back a menu, exit, or escape at any time.

SETUP AND MOVING
15
AC/DC LUCI MANUAL 500-55C8-01
1.10 DIAGNOSTIC AIDS
1.11 CPU DIP SWITCH SETTINGS
This audible/visual alert display is shown when the 50V/20V power is
disabled (by opening the coin door). Pull out the interlock switch only while
in the service menu for coil, switch, or play testing when the coin door is
required to stay open for service button use! Pulling out the power interlock
switch or pressing the ‘escape’ green [BACK] button will remove the alert
display. Initial display presentation is accompanied by 3 audible tones (the
bright display warning will go dim after approximately 30 seconds).
This alert display is shown momentarily during game mode or powering up
to alert the operator of a device malfunction (device or mechanism doesn’t
energize or is energized repeatedly). OPERATOR ALERT! works by moni-
toring any switch activated device that has the potential to trap a ball when
disabled (e.g. in the shooter lane, scoop, or eject holes, etc.). This alert
can also appear if a switch associated with a device (e.g. ball trough, auto
plunger, etc.) is stuck closed (caused by a switch jam or stuck ball); the
game will activate the device a predetermined number of times and if the problem is still detected, this device or switch will be
noted in Switch Alerts and/or Technical Alerts.
Upon entering the service menu, if an asterisk “ * ” is displayed after the
words “SERVICE MENU”, the game has detected possible fualty devices,
switched, and/or missing pinballs. Press either of the red buttons (short-
cut to the technical alerts menu) or continue into the service menu (press
the black button again), select the “DIAG” icon and “TECH” icon or the
technical alerts information.

16
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
180-5119-02
Below P/F
SW.
180-5119-02
below playfield
SW.
180-5119-02
below playfield
SW. SW. SW. SW. SW.
500- 227-0
below playfield
SW.
500- 227-0
below playfield
SW.
180-5054-00
2 per Asm.
SW.
180-5054-00
2 per Asm.
SW.
500- 227-0
below playfield
SW.
500- 227-0
below playfield
SW. SW. SW.
NOT
USED
()
4-BALL
TROUGH
#4 (L) TROUGH
#3
()
4-BALL TROUGH
#2
()
4-BALL TROUGH
#1 (R)
()
VUK OPTO TROUGH
JAM
()
STACK OPTO SHOOTER
LANE LEFT
OUTLANE
LEFT
RETURN
LANE
LEFT
SLING-
SHOT
RIGHT
SLING-
SHOT
RIGHT
RETURN
LANE RIGHT
OUTLANE LEFT
BUMPER RIGHT
BUMPER BOTTOM
BUMPER
SW.
WHT-BRN
J6-P9
IC-U22A
-5 -
below playfield
SW.
01
Q1
GRN-BRN
J1-P1
DRIVE
CPU/
Sound
Board WHT-RED
J6-P8
IC-U22B
02
-5 -
below playfield
SW.
Q2
GRN-RED
J1-P3
DRIVE
Q3
GRN-ORG
J1-P4
DRIVE
Q4
GRN-YEL
J1-P5
DRIVE
WHT-ORG
J6-P7
IC-U22C
03
WHT-YEL
J6-P6
IC-U22D
04
WHT-GRN
J6-P5
IC-U16A
05
WHT-BLU
J6-P3
IC-U16B
06
WHT-VIO
J6-P2
IC-U16C
07
WHT-GRY
J6-P1
IC-U16D
08
TAN-BLK
J12-P9
IC-U36A
09
TAN-RED
J12-P8
IC-U B36
10
TAN-ORG
J12-P7
IC-U C36
11
TAN-YEL
J12-P6
IC-U D36
12
TAN-GRN
J12-P4
IC-U40A
13
TAN-BLU
J12-P3
IC-U B40
14
TAN-VIO
J12-P2
IC-U C40
15
TAN-WHT
J12-P1
IC-U D40
16
-5 -
below playfield
SW.
-5 -
below playfield
SW.
-5 -
below playfield
SW.
180-520 -00
below playfield
SW.
180-520-00
above playfield
SW.
180-520-00
below playfield
SW.
180-520-00
below playfield
SW.
--
below playfield
SW.
--
below playfield
SW.
--
below playfield
SW.
180-5087-00
e playfield
SW.
ENTER
180-5087-00
playfield
SW.
TOURNA-
MENT
START
180-51 -00
In Cabinet
CABINET
SW.
START
BUTTON
SW.
#1 #2 #3 #4 #5 #6 #7 #8 #9 #10 #11 #12 #13 #14 #15 #16
180-5174-00
In Cabinet
RETURN
180-5119-02
below playfield
RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN
« D.O.T.S. »
01 02 03 04
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » CABINET
NOT USED « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. »
L
180-5087-00
playfield 180-5208-00
below playfield 180-5208-00
below playfield 180-52 -00
below playfield 500- 227-0
below playfield 500-22 -0
below playfield -5 7-
playfield --
below playfield -7-00
above playfield -7-00
above playfield 180-5
-0 above
playfield
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » 500-22 -0
below playfield
SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW.
180-0000-00
a / b playfield 180-0000-00
a / b playfield
NOT
USED
180-0000-00
a / b playfield
NOT
USED
180-0000-00
a / b playfield 180-508-00
playfield
NOT
USED
180-0000-00
a / b playfield
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. »
« D.O.T.S. »
SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW.
# 49 # 50 # 51 # 52 # 53 # 54 # 55 # 56 # 57 # 58 # 59 # 60 # 61 # 62 # 63 # 64
SW. D-17
502-5032-00
Optional Kit
SW. D-18
180-0000-00
a/b playfield
SW. D-19 SW. D-20 SW. D-21 SW. D-22
180-5192-02
Coin Door
SW. D-23
180-5192-00
Coin Door
SW. D-24
TILT
PENDULUM
(PLUMB BOB)SLAM
TILT TICKET
NOTCH NOT
USED
X
BACK
(GREEN
BUTTON)
MINUS
(< / – RED
BUTTON)
XPLUS
(+ / > RED
BUTTON)
XSELECT
(BLACK
BUTTON)
X
PNK-BRN
J2-P2
LEFT
COIN
SLOT
180-5204-00
Coin Door
SW. D-1
-RED
J2-P3
PNK
CENTER
COIN
SLOT
180-5204-00
Coin Door
SW. D-2
-ORG
J2-P4
PNK -YEL
J2-P6
PNK -GRN
J2-P7
PNK -BLU
J2-P8
PNK -VIO
J2-P9
PNK -GRY
J2-P10
PNK GRY-BRN
J3-P1 -RED
J3-P2
GRY -ORG
J3-P4
GRY -YEL
J3-P5
GRY -GRN
J3-P6
GRY -BLU
J3-P7
GRY -VIO
J3-P8
GRY -BLK
J3-P9
GRY
RIGHT
COIN
SLOT
180-5204-00
Coin Door
SW. D-3
FOURTH
COIN
SLOT
180-5204-00
Coin Door
SW. D-4
FIFTH
COIN
SLOT
180-0000-00
a/b playfield
SW. D-5
NOT
USED
180-0000-00
a/b playfield
SW. D-6
NOT
USED
180-5160-01
Cabinet Side
SW. D-7
NOT
USED
180-5160-01
Cabinet Side
SW. D-8
L. (EFT)
FLIPPER
BUTTON
500-890-01
Cabinet Side
SW. D-9
LEFT
FLIPPER
E.O.S.
180-5149-00
Flipper Asm.
SW. D-10
R. (IGHT)
FLIPPER
BUTTON
Cabinet Side
SW. D-11
RIGHT
FLIPPER
E.O.S.
180-5149-00
Flipper Asm.
SW. D-12 SW. D-13
NOT
USED
SW. D-14 SW. D-15 SW. D-16
180-5192-04
Coin Door 180-5192-02
Coin Door
180-5119-02
Below P/F
NOT USED
LGN-BRN
J13-P1 -RED
J13-P3
LGN -ORG
J13-P4
LGN -YEL
J13-P5
LGN -BLK
J13-P6
LGN -BLU
J13-P7
LGN -VIO
J13-P8
LGN GRY
J13-P9
LGN-
TRANS. / REC.
TX
RX 515-0173-00
515-0174-00
TRANS. / REC.
TX
RX 515-0173-00
515-0174-00
NOT USED NOT USED NOT USED NOT USED IF USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED
NOT USED
OPTIONAL IF USED NOT USED NOT USED NOT USED NOT USED NOT USED
# 17 # 19 # 20 # 21 # 22 # 23 # 24 # 25 # 26 # 27 # 28 # 29 # 30 # 31 # 32
# 18
# 33 # 34 # 35 # 36 # 38 # 39 # 40 # 41 # 42 # 43 # 44 # 45 # 46 # 47 # 48
# 37
SWITCH MATRIX GRID [ #1 – #64 ] {Switch Locations : next page}
« D.O.T.S. »
GROUND
(BLK)
J2-P1/11
& J3-P10
GROUND
(BLK)
J13-P10
IC-U2 IC-U2
IC-41
IC-41
IC-U4
IC-U4
IC-41
IC-41 IC-41
IC-41 IC-41
IC-41 IC-41
IC-41 IC-41
IC-41 IC-41IC-41 IC-41
IC-41
IC-U2IC-U2 IC-U2IC-U2 IC-U2
IC-U2 IC-U2
IC-U2 IC-U2
IC-U2 IC-U2IC-U2 IC-U2IC-U2 IC-U4
IC-U4 IC-U4
IC-U4 IC-U4
IC-U4 IC-U4
IC-U4 IC-U4IC-U4 IC-U4
IC-U4 IC-U4
IC-U4
Dedicated Switches [ #D-1 – #D-32 ] {Dedicated Switch Locations : next page}
CPU/SND
Board
CPU/SND
Board
180-5015-04
below playfield 180-5015-04
below playfield 180-5015-04
below playfield
DIP
SWITCH
POSITION
ON / OFF
#1
DIP
SWITCH
POSITION
ON / OFF
#2
DIP
SWITCH
POSITION
ON / OFF
#3
DIP
SWITCH
POSITION
ON / OFF
#4
DIP
SWITCH
POSITION
ON / OFF
#5
DIP
SWITCH
POSITION
ON / OFF
#6
DIP
SWITCH
POSITION
ON / OFF
#7
DIP
SWITCH
POSITION
ON / OFF
#8
CPU/SOUND BD. SW1 DIP SWITCH (located between Connectors J3/J13)
SW. D-25 SW. D-26 SW. D-27 SW. D-28 SW. D-29 SW. D-30 SW. D-31 SW. D-32
« FOR MORE ABOUT DIODE ON TERMINAL STRIPS « D.O.T.S. », SEE SECTION 5, CHAPTER 2, PAGES 102 – 103. »
BLK
Black YEL
Yellow
WHT
White
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
Brown
Blue
BLU GRY
Gray LGN
Light Grn. PNK
Pink TAN
Tan
Wire Color Abbreviations used: BLK
Black GRY
Gray LGN
Light Grn. PNK
Pink TAN
Tan WHT
White YEL
Yellow
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
BrownBlue
BLU
A C AC CC
TOP LANE
CANNON
HOME
520-5292-00
below playfield
CANNON
MARK
180-5119-02
below playfield 180-5218-00
In Cabinet
FIRE
BUTTON
CABINET
NOT
USED
NOT
USED NOT
USED NOT
USED
- -0
BELL
180-52 7-00
below playfield
TOP LANE CANNON
R.
ENTER
-7-
below playfield
RIGHT
TOP LANE
above playfield
BELL
OPTO
--
above playfield
LOWER P.F.
KICKER
OPTO
500-6775-01
below playfield
LOWER P.F.
S/U TARGET
(LEFT)
180-5207-00
below playfield
LOWER P.F.
S/U TARGET
(CENTER)
180-5207-00
below playfield 180-5207-00
below playfield
LOWER P.F.
S/U TARGET
(RIGHT)
LOWER P.F.
LOOP (L.)
500-6227-04
below playfield
LOWER P.F.
LOOP (R.)
500-6227-03
below playfield
U.L.
FLIPPER
BUTTON
U.R
.
FLIPPER
BUTTON
-90-0
Cabinet Side -90-0
Cabinet Side
180-5157-01
below playfield
180-5207-00 2

SETUP AND MOVING
17
AC/DC LUCI MANUAL 500-55C8-01
1.12 SWITCH LOCATIONS
Switch Menu: Switch, Active, Single, & Service

18
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
BLK
Black YEL
Yellow
WHT
White
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
Brown
Blue
BLU GRY
Gray
Wire Color Abbreviations used: BLK
Black GRY
Gray WHT
White YEL
Yellow
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
BrownBlue
BLU
#1
LED #2
LED #3
LED #4
LED #5
LED #6
LED #7
LED
« D.O.T.S. » 20-5324-01« D.O.T.S. » 20-5324-01« D.O.T.S. » 20-5324-01« D.O.T.S. » 20-5324-01
#8
LED
#9
LED # 10
LED # 11
LED # 12
LED # 13
LED # 14 # 15
« D.O.T.S. »« D.O.T.S. » 20-5324-0120-5324-01« D.O.T.S. » 20-5324-01« D.O.T.S. » 20-530 -00« D.O.T.S. » 20-530 -00
# 16
# 17 # 18
LED # 19
LED # 20
LED # 21
LED # 22
LED # 23
« D.O.T.S. » 20-5324-0 « D.O.T.S. » 20-5324-0 « D.O.T.S. » 20-530 -00« D.O.T.S. » 20-530 -00« D.O.T.S. » 20-530 -00
# 24
LED
.N. . RRO
H . NO E
# 25
LED # 26
LED # 27
LED # 28
LED # 29
LED # 30
LED # 31
LED
« D.O.T.S. » 20-530-00« D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 32
LED
# 33
LED # 34
LED # 35
LED # 36
LED # 37
LED # 38
LED # 39
LED
« D.O.T.S. » 20-5324-04« D.O.T.S. » 20-5324-04« D.O.T.S. » 20-5324-04« D.O.T.S. » 20-5324-04« D.O.T.S. » 20-530 -00« D.O.T.S. » 20-530 -00« D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 40
LED
# 41
LED # 42
LED # 43
LED # 44
LED
NNON
OER
# 45
LED
NNON
OLLE
# 46
LED
NNON
H O
# 47
LED
RO K
N
« D.O.T.S. » 20-530 -00« D.O.T.S. » 20-530 -00« D.O.T.S. » 20-530-00« D.O.T.S. » 20-530 -00« D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 48
LED
OUR
ULB LL
# 49
LED
UER
OBO
# 50
LED
U ER
LOO
# 51
LED # 52
LED # 53
LED # 54
LED # 55
#555 Clear
« D.O.T.S. »
« D.O.T.S. » 20-5324-03« D.O.T.S. » 20-5324-03« D.O.T.S. » 112-5033-08
# 56
#555 Clear
# 57
LED # 58
LED # 59 # 60
LED
# 61
LED
# 62
LED
# 63
LED # 64
LED
# 65
LED # 66
LED # 67
LED # 68
LED # 69
LED # 71
LED
LE HERE
BEROK
# 72
LED
# 73
#555 Clear # 74 # 75 # 76 # 77 # 78
NOT
USED
# 79
#555 Clear
NOT
USED
# 80
#555 Clear
LAMP MATRIX GRID [ #1 – #80 ] {Lamp Locations : next page}
I/O
Power
Driver Board
LED
[ C. = CENTER][L. = LEFT][R. = RIGHT ]
20-5324-03
LED LED
U ER
LNE
LBU
UL B LL
NOT
USED NOT
USED
NOT
USED
NOT
USED
« D.O.T.S. » 20-503 -00
« D.O.T.S. » 20-5324-0
LE
OU L NE
LE
RE URN L NE
R H
RE URNL NE
« D.O.T.S. » 20-5324-01« D.O.T.S. » 20-5324-01
R H
OU LNE
« D.O.T.S. » 20-5324-01
3X
.N. . .N. . .N. .
LED
L. R
NUL.
L.R
NUR.
LOERL.
L.LOORRO
« D.O.T.S. » 20-5324-0
« D.O.T.S. » 20-5324-0
LOER L .
R. LOO RRO
RO KRO KR O K R O K
R N
EXR B LL
R. R
NU
EL
.N. .
# 70
« D.O.T.S. » 20-5324-02
« D.O.T.S. » 20-5324-02« D.O.T.S. » 20-5324-02« D.O.T.S. » 20-5324-02« D.O.T.S. » 20-5324-02
OR HO E
BOUORO K
20-5324-02
R
HNE
20-5324-02
BK N
BL K
20-5324-02
20-5324-02
20-5324-0220-5324-0220-5324-02
HELL N B
LEOBE
START
BUTTON
« D.O.T.S. » 112-5024-0
OURN EN
RBU ON
« D.O.T.S. » 112-5024-0
HUN ER RU K
HELL
BELL
HOLELO
RO E
ROKNROLL
R N
H H O
HELL
OU HOOKE
LL N H LON
« D.O.T.S. » 20-5333-00
RE BU ON
RE
RIGHT
BUMPER BOTTOM
BUMPER
LEFT
BUMPER
« D.O.T.S. » 112-5033-08
« D.O.T.S. » 112-5033-08
« D.O.T.S. » 112-5033-08
« D.O.T.S. » 20-5333-00« D.O.T.S. » 20-5333-00
RE BU ON
REEN
RE BU ON
BLUE
JUKEBOX
HORN R.
JUKEBOX
HORN L.
« D.O.T.S. » 112-5034-02« D.O.T.S. » 112-5034-02
J
UL B LL UER
RE
« D.O.T.S. » 20-5324-01
NOT
USED NOT
USED NOT
USED NOT
USED NOT
USED NOT
USED
NOT
USED
NOT
USED NOT
USED NOT
USED NOT
USED
NOT
USED NOT
USED NOT
USED
J5

SETUP AND MOVING
19
AC/DC LUCI MANUAL 500-55C8-01
1.13 LAMP LOCATIONS
Lamp Menu: One, All, Row, Column, & Ordered
AC-DC PREMIUM SINGLE LED MAP

20
SETUP AND MOVING
AC/DC LUCI MANUAL 500-55C8-01
LAMPNUMBER LAMPNAME CONNECTORNUMBERON
DRIVERBD.520-5331-00
81 FACE LEFT EYE CN17
82 FACE RIGHT EYE CN16
84 FACE MOUTH CN1
85 L. LOOP ARROW (BOT.) CN12
86 L. RAMP ARROW CN18
87 BELL ARROW (BOT.) CN8
88 R. RAMP ARROW CN11
89 R. LOOP ARROW (BOT.) CN13
90 L. LOOP ARROW (TOP.) CN14
91 BELL ARROW (TOP.) CN3
92 RIGHT LOOP ARROW (MID.) CN7
93 LEFT TOP LANE CN9
94 CENTER TOP LANE CN4
95 RIGHT TOP LANE CN19
96 TUNES - N - STUFF CN5
