PINBALL MACHINE
SERVICE AND OPERATION MANUAL
Games congured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe
UK, Australia).
Stern Pinball machines are assembled in Melrose Park, Illinois, USA; each pinball machine has unique characteristics that make it a one-of-a-kind
American-made product. Each machine will have variations in appearance resulting from differences in the machine’s particular wood parts, individual
silk screened art and mechanical assemblies. Stern Pinball has inspected each game element to insure it meets our quality standards.
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to
certain visual images, including ashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that
can cause “photosensitive epileptic seizures” due to certain visual images, ashing lights or patterns. Symptoms can include light-headedness, altered
vision, eye or face twitching, jerking or shaking of arms or legs, disorientation, confusion, momentary loss of awareness, and loss of consciousness or
convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
1-800-KICKERS - PAR[email protected]
WWW.STERNPINBALL.COM - FACEBOOK.COM/STERNPINBALL
KISS PRO
KISS PRO #500-55H1-01
MANUAL #780-50H1-01
© 2015 KISS Catalog, Ltd. Under License to Epic Rights.

2
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
TABLE OF CONTENTS
1. Setup and Moving .................................. 3
1.1 First-time Setup Instructions................................ 3
1.2 Transporting the Game ........................................ 6
1.3 Maintenance ........................................................ 7
1.4 Maintenance Kits ................................................. 7
1.5 Common Parts ..................................................... 7
2. SPIKE System and Node Guide ............ 8
2.1 SPIKE System Overview ...................................... 8
2.2 Node Bus Cabling ................................................ 8
2.3 System Power ...................................................... 8
2.4 SPIKE Node addresses ........................................ 8
2.5 SPIKE Node Programming................................... 8
2.6 SPIKE System Terminology ................................. 9
2.7 Common SPIKE Node Boards ............................. 9
3. Light, Switch, and Driver Reference... 10
3.1 SPIKE Node Boards ........................................... 10
3.2 Driver Reference ................................................ 11
3.3 Switch Reference ............................................... 12
3.4 Light Reference .................................................. 15
4. Electronic Pinouts and Schematics.... 19
4.1 SPIKE CPU Node 0 ............................................ 19
4.2 Node 1 Cabinet .................................................. 21
4.3 Lower Playeld 48V 8-Driver Pinout Node 8 ..... 22
4.4 Node 9 Mid Playeld 8-Driver 48V Pinout ......... 23
4.5 Node 10 Upper Playeld 8-Driver 48V Pinout .. 24
4.6 Node 11 Upper Playeld 32-Light and Switch
Pinout .......................................................................... 25
4.7 Dual Motor Driver ............................................... 27
4.8 Main Power Supply ............................................ 27
4.9 Trough Opto Transmitter .................................... 27
4.10 Trough Opto Receiver ........................................ 27
4.11 Star Lower Playeld Grid LED ........................... 28
4.12 Star Upper Playeld LED ................................... 28
4.13 Power Distribution Board ................................... 29
4.14 Power Plug Wiring.............................................. 29
5. Parts Reference.................................... 30
5.1 Playeld Rubber Parts ....................................... 30
5.2 Rubber Size Chart .............................................. 30
5.3 Playeld assemblies, Top ................................... 31
5.4 Playeld assemblies, Bottom ............................. 32
5.5 Backbox Parts.................................................... 33
5.6 Speaker Panel Parts .......................................... 33
5.7 Cabinet Parts ..................................................... 34
5.8 Auto Launch Assembly ...................................... 35
5.9 Ball Trough Assembly......................................... 35
5.10 Flipper Assembly, Left ........................................ 36
5.11 Flipper Assembly, Right ..................................... 36
5.12 Sling shot Assemblies ........................................ 37
5.13 Slingshot Flash Assy - 02 .................................. 37
5.14 Slingshot Flash Assy- 04 ................................... 37
5.15 Power Scoop ..................................................... 38
5.16 Up-Post Vuk Assembly ...................................... 38
5.17 Pop Bumper Assembly ...................................... 39
5.18 Right Ramp Pro Assy ......................................... 40
5.19 Amplier Assembly ............................................ 40
5.20 Left Ramp Assy .................................................. 40
5.21 Paul Assembly, Pro ............................................ 40
5.22 Plastic Flash Assy - 05 ....................................... 41
5.23 Plastic Assy - 06 ................................................ 41
5.24 Plastic Assy - 08 ................................................ 41
5.25 Plastic Assy - 09 ................................................ 41
5.26 Plastic Assembly - 10 ........................................ 41
5.27 Plastic Assembly - 11 ........................................ 42
5.28 Ball Guide Assembly - 03................................... 42
5.29 Plastic Flash Assembly - 28 ............................... 42
5.30 Ball Guide Assembly - 04................................... 42
5.31 Gene Head Assy ................................................ 43
5.32 Spinning Disk Assembly .................................... 43
6. Specications ....................................... 44
6.1 Game Dimensions .............................................. 44
7. Warranty................................................ 45
7.1 Warnings, Compliance, and Legal Notices ........ 45
SPIKE PINBALL SOFTWARE UP-
DATE INSTRUCTIONS
1. Obtain game software update le (lename ends
in “.spk”) from www.sternpinball.com or from
authorized Stern distributor.
2. Place game software update le ( “.spk”) in root
directory of a blank FAT32-formatted USB ash
drive
3. Use backbox power switch to turn off game
4. Plug in USB ash drive to CPU board USB con-
nector (CN20 or CN21). Refer to www.sternpin-
ball.com
5. Turn on game
6. The game will automatically begin software
update
7. Select the correct .spk update le from list.
8. Press Enter on the service switches to start
update
9. When the display indicates “Update Complete”,
turn off game
10. Remove USB ash drive from CPU board
11. Turn game on to complete the update and play
pinball!
12. Detailed instructions and troubleshooting tips
are available in the game manual, www.sternpin-
ball.com and authorized Stern distributors.

1. SETUP AND MOVING
2
2
557
7
1
9
8
11
14
15
14
11
8
6
1.1 FIRST-TIME SETUP
INSTRUCTIONS
CAUTION: AT LEAST TWO (2)
PEOPLE ARE REQUIRED TO
MOVE AND MANEUVER THE
GAME. USE PROPER MOVING
EQUIPMENT AND EXTREME
CARE WHILE HANDLING.
STERN PINBALL MACHINES
WEIGH OVER 250LBS BOXED.
TOOLS REQUIRED
• 5/8” Socket Wrench
• Utility Knife
• Snips
• A helper
Your brand new Stern Pinball Machine is
carefully packed for safety and security.
For your safety, exercise caution and use
the correct tools and sufcient help when
setting up your new game.
1. Locate the side labeled “TRUCK
THIS SIDE ONLY”. The bottom of
the game faces this side.
2. Open the top box aps by pulling
hard in an upward motion on each
ap. If the aps are taped, cut the
tape rst, taking care to avoid the
box staples.
3. Remove the four (4) foam piec-
es and two (2) narrow box tubes
which contain the four (4) identical
legs with levelers.
4. DO NOT CUT STRAPPING YET.
Keep backbox secured in the
down position.
5. With the utility knife, carefully cut
down the left and right corners of
the box.
6. Let the face fall forward and
remove the entire side by carefully
cutting the bottom.
7. With the game still in its folded
position, use a ⅝” wrench to loos-
en and remove the 2 leg bolts on
each side of the front cabinet. En-
sure the leg levelers are screwed
all the way in to the legs.
8. Install front legs using the bolts
removed from Step 5. Secure
tightly.
9. Use a helper to carefully set the
game down on the front legs.
10. Set aside the open box.
11. With the ⅝” socket wrench, loosen
and remove the 2 leg bolts on
each side of the rear cabinet, 4
total.
12. Using supports or two people,
prop the rear of the cabinet up.
13. Ensure the rear leg levelers are
screwed all the way into the legs.
14. Install rear legs using the 4 bolts
removed from step 11.
SETUP AND MOVING
3
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01

19
21
17
25
26
27
FIRST-TIME SETUP CONTINUED
15. Cut nylon strapping and remove
protective strap corner guards
16. Locate the factory keys, either on
the shooter rod or taped to the
playeld glass.
17. Using the snips, cut the tie-wrap
securing the keys if required. One
set of keys is for the front coin
door, the other set of keys is for
accessing components in the
backbox
18. Open the front coin door.
19. Reach into the game and remove
the retaining clip at the rear of the
cash box.
20. Remove the cash box lid by sliding
it toward you.
21. Store the backbox keys, if desired,
on the metal hook located in the
coin door.
22. Locate and remove the pinballs,
plumb bob, and backbox bolts
from the cash box.
23. Replace the cash box lid and
retaining clip for future use.
24. Locate the two (2) backbox bolts in
the cash box.
25. Carefully raise backbox to upright
position while ensuring that cables
are not pinched.
26. Use the ⅝” wrench to Install the
two (2) backbox bolts to secure the
backbox as indicated on the back
of the cabinet.
29. Remove the playeld glass by
sliding it toward you and carefully
place it in a safe location.
Remove all playeld shipping
tie downs, shipping blocks, and
packing foam, and follow any
game-specic unpacking instruc-
tions included in the playeld, if
present.
CAUTION: PLAYFIELD GLASS IS MADE FROM HIGH-STRENGTH TEMPERED GLASS.
TEMPERED GLASS IS SENSITIVE TO EXTREME TEMPERATURE SHIFTS AND COR-
NER NICKS, WHICH CAN CAUSE THE GLASS TO FAIL CATASTROPHICALLY. TAKE
CARE TO STORE THE GLASS ON A SOFT, ROOM-TEMPERATURE SURFACE AND
PREVENT THE CORNERS FROM BEING DAMAGED.
27. Reach inside the cabinet and
move and hold the yellow top
molding lock handle to the left.
28. Remove the front top molding and
then release the handle.
4
SETUP AND MOVING
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.

SETUP AND MOVING
5
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
FIRST-TIME SETUP CONTINUED
30. If pinballs were already installed into the lower ball trough,
remove them before lifting the playeld.
31. Raise the playeld and rest it against the backbox.
32. Grasp the lower arch between the ippers, and rmly but
gently pull directly up to raise the playeld 8-12 inches.
33. While holding the playeld up, pull the playeld toward
you until the two playeld supports are over the front
edge of the cabinet.
34. Rest the playeld on the front edge of the cabinet.
35. Visually inspect all cabinet cables and connector termi-
nations; ensure no wires or cables are pinched and that
cable harnesses are not pulled tight.
36. Locate the plumb bob in the parts bag in the cash box
37. Slide plumb bob onto the hanger wire. Note: the vertical
position of the plumb bob affects tilt sensitivity - higher
makes the game more sensitive to tilting.
38. Tighten the Thumb Screw nger-tight.
39. Install the correct number of pinballs. Refer to the decal
on the lock down assembly for the correct number of
pinballs.
LOCATING, LEVELING, AND FINAL SETUP
1. Select a location that is indoors, out of direct sunlight,
and climate controlled. Excessive moisture/humidity can
cause long-term damage to your game.
2. Adjust the front or rear levelers as necessary to position
the playeld level bubble, located on the front right of the
playeld next to the shooter lane, to oat between the two
(2) black lines. This will place the playeld at the recom-
mended 6.5° pitch. Playeld angles greater than 6.5°
can be achieved by turning out the rear leg leveler(s) for
increased difculty and faster gameplay.
3. Use a pinball to roll down the center of the playeld for
side-to-side leveling, or use an external bubble level,
digital level, or smartphone level app.
4. Plug into a grounded outlet and check for proper opera-
tion through DIAGNOSTICS.
5. Check the coin door: With the door closed, insert coins to
verify proper operation.
6. Play game: Check for satisfactory operation and adjust
game volume (push the Red Buttons inside the Coin
Door).
7. If desired, perform any game diagnostics, game adjust-
ments, and pricing settings at this time.

6
SETUP AND MOVING
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
1. SECURE THE BACKBOX
1. Ensure that the pinballs are re-
moved from the playeld, and se-
cure any free-moving mechanisms
that may get damaged in transport
2. Remove the backbox securing
bolts
3. Carefully lower the backbox onto
the side rails. Use a piece of card-
board or suitable padding between
the backbox and the game.
4. Securely strap the back box to the
game
5. The game may be transported with
the legs on. If the legs must be re-
moved, follow the remaining steps.
2. REMOVE THE LEGS AND
STAND UP
6. Remove the legs, rear legs rst.
Use a stool or a friend to support
1.2 TRANSPORTING THE GAME
2
3
4
the rear of the game.
7. Rest the rear of the game on the
ground.
8. Stand the game up on its back.
9. Remove the front two legs.
6
NEVER TRANSPORT THE GAME IN A
MOVING VEHICLE WITH THE BACK-
BOX RAISED! TWO PEOPLE ARE RE-
QUIRED TO REMOVE THE LEGS!
upright position.
CAUTION
10. Secure all loose parts and trans-
8
port with a hand truck in the
9
When transporting the game, such as in the back of a truck or with a hand truck, the
game’s backbox must be secured to prevent damage to the side rails.
TOOLS REQUIRED
• STRAP (500LB OR GREATER)
• A HELPER
• HAND TRUCK

SETUP AND MOVING
7
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
1.3 MAINTENANCE
REGULAR MAINTENANCE - (MONTHLY/500
GAMES)
• Remove the playeld glass
• Enter the software diagnostics menu, start lamp test, then
clean and wax the playeld.
• While cleaning the playeld, identify and repair malfunctioning
lights, loose parts, cracked plastics and worn rubber parts.
• While in diagnostics, enter the switch test (Select the "SW"
Icon, then "TEST" Icon).
• Use a pinball to actuate all switches and verify the correct
switch registers with the switch test.
• The game will play a sound to conrm the switch.
• Lift the playeld and inspect all assemblies for loose parts,
broken wires or excessive wear. Look at the bottom of the
cabinet for any parts that may have worked loose, then nd
the source.
• Check all coin door mechanisms and bill acceptor (if installed)
for proper operation
• Play the game to ensure all coils and features are working
• Check the playeld to ensure it is level and set to the proper
pitch using the bubble level on the right side wood rail.
• Check game audits: Replay % and Ball Time and note abnor-
mal values which can indicate problems.
• Ensure game volume is set appropriately for the location.
• Clean both sides of the playeld glass and reinstall.
• Check and clean pinballs and replace if excessively worn or
scuffed. Dirty pinballs accelerate game wear.
OVERHAUL MAINTENANCE (5000 GAMES)
• Verify latest game software is installed
• Check ippers for excessive wear. Excessive ipper sloppi-
ness (vertical or horizontal) or weakness indicates a ipper
rebuild is required.
• Clean machine inside and out and check leg levelers for free
operation.
• Visual check for loose or broken playeld and cabinet parts
and repair as necessary.
• Electrical check: Plug into grounded outlet and check for
proper operation through DIAGNOSTICS.
• Replace worn or dirty rubbers.
• Replace pinballs.
• Check all playeld switches with a pinball.
• Check all settings (refer to manual for factory settings).
• Check coin door: With door closed, insert coins to verify
proper operation.
• Check for proper adjustment of the plumb bob tilt.
• Play game: Check for satisfactory operation.
COMMON PINBALL TOOLS
• Common nut drivers (¼”, 5/16”, 11/32", ⅜”)
• Phillips screw driver
• Standard Allen wrench/Hex key set
• ⅝” Socket with ratchet
• Adjustable wrench (5/8" & 9/16")
• 6" Torpedo Level (or use a pinball
• Flashlight or headlampv
• Soldering Iron (60w with at tip), lead-free solder
• Wire cutter
• Wire stripper
• Long nose (“needle nose”) pliers
1.4 MAINTENANCE KITS
Description Part Number
KISS Pro Maintenance Kit
• 8 oz pinball playeld wax (Novus # 2) (675-0003-01)
• Standard Pinball (260-5000-00)
• Cleaning Cloth
• All Playeld Rubber Rings
• Spare Fuses
502-6002-H1
KISS Pro Deluxe Maintenance Kit
• All standard kit items, plus:
• Flipper rebuild kits, Left and Right (500-6307-10,-00)
502-6003-H1
KISS Playeld Plastics Kit 803-5000-H1
KISS Playeld Decals Kit 802-5000-H1
KISS Playeld Decals Kit (Germany) 802-5000-H1-GER
KISS Pro Cabinet Decal Left 820-66H1-01
KISS Pro Cabinet Decal Left (Germany) 820-66H1-01G
KISS Pro Cabinet Decal Right 820-66H1-02
KISS Pro Cabinet Decal Right (Germany) 820-66H1-02G
KISS Pro Cabinet Decal Left 820-66H1-03
KISS Pro Cabinet Decal Left (Germany) 820-66H1-03G
KISS Pro Cabinet Decal Right 820-66H1-04
KISS Pro Cabinet Decal Right (Germany) 820-66H1-04G
KISS Pro Cabinet Decal Front 820-66H1-05
KISS Pro Cabinet Decal Front (Germany) 820-66H1-05G
KISS Pro Playeld, Bare 830-5000-H1
KISS Pro Playeld, Bare (Germany) 830-5000-H1G
KISS Pro Translite 830-52H1-01
KISS Pro Translite (Germany) 830-52H1-GER
1.5 COMMON PARTS
Description Part Number
8 oz Pinball Playeld wax (Novus # 2) 675-0003-01
Standard Pinball, 1-1/16 in 260-5000-00
Flipper Rebuild Kit Left (Standard) 500-6307-10
Flipper Base Plate Kit Left 515-6617-01
Flipper Rebuild Kit Right 500-6307-00
Flipper Base Plate Kit Right 515-6617-00

8
SPIKE SYSTEM AND NODE GUIDE
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
2.1 SPIKE SYSTEM OVERVIEW
The SPIKE Pinball system is a rugged, distributed, and em-
bedded platform custom-designed for the rigors of the pinball
machine environment. SPIKE takes advantage of modern tech-
nologies to deliver an immersive pinball experience that supports
modern features, reduces cabling, and increases serviceability
and reliability.
A Stern Pinball machine based on the SPIKE system will have at
least two nodes networked together with the SPIKE node bus,
a custom industrial pinball control bus that is designed around
industry standards and optimized for the pinball environment.
The primary CPU node is networked to one or more input/output
nodes over standard Category 5 UTP (unshielded twisted pair)
ethernet cabling.
There are ve primary types of nodes that are found in the game.
• CPU node (Node 0) - The primary node that controls other
nodes in the system. Contains the primary game software
for the system and provides SPIKE node bus power for other
nodes.
• Cabinet 48V node (Node 1) - Specialized node with specic
inputs and outputs for coin doors, tilt mechanisms, and other
bottom-cabinet devices.
• 48V playeld node - Controls high power devices such
as coils and ashers, and also supports a few switch and
low-power outputs. Powered by the system 48V power
supply.
• Light and switch node - High-density switch and low-power
LED outputs, bus-powered from the node bus. These boards
contain as many 32 switch inputs and light outputs.
• Node extensions - These sub-nodes add additional low-pow-
er input and outputs to a specic Power or I/O node and are
connected with simple serial bus.
2.2 NODE BUS CABLING
The SPIKE node bus utilizes standard Ethernet-style RJ45 8-pin
modular jacks, and off-the-shelf Category 5e or better ethernet
cabling. The node bus is electrically different from Ethernet and
does not not utilize Ethernet or TCP/IP protocols or signaling
standards. SPIKE nodes are not compatible with standard com-
puter networking equipment.
CAUTION: Plugging a SPIKE Node or CPU board into a standard
Ethernet port may damage one or both devices and void your
warranty.
2.3 SYSTEM POWER
The SPIKE System is powered from an 48V DC power supply
bus. Each SPIKE node converts this voltage to lower voltages
required by the node and its specic components. A SPIKE 48V
node typically controls high-power outputs such as game coil
mechanisms and high-brightness LEDs. These powered nodes
are supplied directly with 48V system power. SPIKE standard I/O
nodes are low-power nodes that read switch inputs and output
to standard-brightness LEDs. Standard I/O nodes use the node
bus power, which is supplied by the main CPU node over the
node bus modular jack connectors.
COIN-DOOR SAFETY INTERLOCK
To protect the system and for user safety, power to the playeld
is disabled when the front coin door is opened. 48V system pow-
er and 9V node bus power is disabled to all playeld components
until the switch is closed.
2.4 SPIKE NODE ADDRESSES
Each SPIKE node has a unique address ranging from 0 to 15. Not
all addresses are used in all games. Nodes can be of the same
part number, so the address is specied on the DIP switches on
each node. When replacing a node, be certain that the correct
address is set. Nodes can have 3-position and 4-position DIP
switches. Refer to the appropriate table to set the address for
each type of Node. The correct address for a node can be found
in the SPIKE node reference section of the manual or in the game
diagnostic software. Address 0 is reserved for the backbox CPU
node, where the game software resides. Address 1 is reserved for
the cabinet node, located inside the coin door. These two nodes
do not have DIP switches as their address is not congurable.
Address 1 2 3
8OFF OFF OFF
9OFF OFF ON
10 OFF ON OFF
11 OFF ON ON
12 ON OFF OFF
13 ON OFF ON
14 ON ON OFF
15 ON ON ON
Figure 2.4.1. SPIKE node addresses for nodes with 3-position DIP
switches. Addresses 0-7 are not used by SPIKE nodes with 3-posi-
tion DIP switches.
Address 1 2 3 4
8OFF OFF OFF OFF
9OFF OFF ON OFF
10 OFF ON OFF OFF
11 OFF ON ON OFF
12 ON OFF OFF OFF
13 ON OFF ON OFF
14 ON ON OFF OFF
15 ON ON ON OFF
Figure 2.4.2. SPIKE node addresses for nodes with 4-position DIP
switches. Addresses 0-7 are reserved for xed-function nodes and
do not require conguration.
2.5 SPIKE NODE PROGRAMMING
The SPIKE nodes are smart nodes that have on-board pro-
cessors and run embedded code. The nodes are programmed
2. SPIKE SYSTEM AND NODE GUIDE

SPIKE SYSTEM AND NODE GUIDE
9
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
automatically by the CPU node whenever software updates are
installed to the CPU. When replacing a node, the CPU node will
detect and update the node to the latest software with no user
intervention. Always replace nodes with the power to the game
turned OFF.
2.6 SPIKE SYSTEM TERMINOLOGY
MULTI GENERAL ILLUMINATION LIGHTING
General Illumination Lighting is two or more lights powered by
one control source. These are often a number of LEDs connect-
ed in parallel and the system controls these as one large LED. A
missing LED will not affect these circuits, however a shorted LED
can cause the entire string of LEDs to turn off.
SINGLE LIGHTS
Single lights and LEDs are direct-controlled from SPIKE node
boards. A common power source is grounded by individual
transistors to turn individual LEDs on and off. Groups of LEDs,
usually by node connector, share a common power source, so if
a group of LEDs is out, check the wiring for the power source.
FLASHERS
SPIKE games treat ashers the same as single LEDs that draw
more power. Flashers are controlled from the same circuits that
power regular lights.
DRIVERS
A driver is a circuit that controls a high power-device such as a
coil, magnet, or motor. Each device has a common 48V power
source that is then connected to ground by a dedicated control
transistor. Each driver is protected against shorting, static elec-
tricity, and over-current conditions. Take caution as 48V is always
present on a device even when it is not energized.
OPTOS
Certain types of optical switches (“optos”) require external signal
conditioning. For these optos, they will interface to a SPIKE node
via an opto signal conditioning board. Other optical switches
connect directly to the Spike node board.
System Protections
CAUTION: Unless explicitly directed by an Authorized Stern Re-
pair technician, perform ALL work on your pinball machine with
the power disabled!
INPUT/OUTPUT PROTECTIONS
SPIKE features built-in short-circuit, static electricity, and other
protections to maximize reliability. If an LED, coil or other device
shorts, it will be disabled but will not shut down the entire system
in most circumstances. Groups of LEDs, coils, and switches often
share common power supplies or other circuits, so it is possible
that a bad device will affect the group of related devices and
require removal or repair to x the group. The system diagnostics
will inform the technician of shorted or otherwise malfunctioning
devices whenever possible. While the system is protected against
permanent damage, it is strongly recommended to repair or
replace these bad components as soon as possible to minimize
downtime and maximize game earnings.
FUSES
Nodes that have 48 V power are fused individually. Fuse voltage
ratings are a safety rating and always must be higher than the
circuit the fuse is protecting. Never replace a fuse with a lower
voltage-rated fuse. Fuse current ratings must be replaced with
the same current value. A higher current value fuse could cause
catastrophic failures, and a lower-value fuse will cause premature
fuse failures.
Common fuses
Fuse Rating (Amps) Type Part Number
3/4 A Slow Blow MDL 200-5000-17
3 A Slow Blow MDL 200-5000-08
4 A Slow Blow MDL 200-5000-06
5 A Slow Blow MDL 200-5000-01
7 A Slow Blow MDL 200-5000-03
8 A Slow Blow MDL 200-5000-05
CAUTION: Always replace fuses with the exact current specica-
tions.
2.7 COMMON SPIKE NODE BOARDS
Description Type Part Number
SPIKE CPU Node Node 520-6936-00
SPIKE CPU Node w/ Video Out Support (Back-
ward compatible with -00) Node 520-6936-10
Cabinet Node Node 520-5319-00
48V 8-Driver Node Node 520-6935-00
48V 4-Driver Node Node 520-5329-00
SPIKE 32 Light and Switch Node Node 520-5322-00
Trough Serial Opto Receiver Extension Extension 520-5345-00
SPIKE SYSTEM AND NODE GUIDE CONTINUED

10
LIGHT, SWITCH, AND DRIVER REFERENCE
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
3. LIGHT, SWITCH, AND DRIVER REFERENCE
ID DIP SW1 Address Description Location Part Number
0 n/a SPIKE CPU Node Backbox 520-6936-00
1 n/a Cabinet Node Cabinet 520-5319-00
8OFF-OFF-OFF-OFF Lower Playeld 48V 8-Driver Node Lower playeld 520-6935-00
8a n/a Trough Serial Opto Receiver Extension Lower playeld ball trough 520-5345-01
9OFF-OFF-ON-OFF Mid Playeld 48V 8-Driver Node Mid playeld 520-6935-00
9a n/a Star Grid LED Extension Lower playeld 520-6969-00
10 OFF-ON-OFF-OFF Upper Playeld 48V 8-Driver Node Upper playeld 520-6935-00
10a n/a Star LED Extension Mid playeld 520-6970-00
11 OFF-ON-ON Upper Playeld S/L I/O Node Upper playeld 520-5322-00
3.1 SPIKE NODE BOARDS
755-7512-H1 © 2015 KISS Catalog, Ltd. Under License to Epic Rights.
When replacing node boards,
ensure DIP address switches
are set correctly!
PLAYFIELD REAR
PLAYFIELD FRONT
Node Bus Cable (RJ45)
Serial Data Cable
NODE BOARD ID INSTRUCTION SHEET
BACKBOX
CPU NODE 0
D30D29D28 D13
SDA
RST
GND
SCL
RESET
CN18
LINE
OUT
TxD
NETSTAT
STATUS
RxD
5V 48V
24V
9V
S1
+48V
CN23
11
CN20
POWER
HEADPHONE
CN25
IN
L+ L-
C+ C- R+ R-
CN21
CN7
CN3 CN22
CN4 CN1
CN24
520-6936-00A
SPIKE CPU
11
1
1
BT1
AMPLIFIED AUDIO
OUT
SPIKE NODE BUS
USB
SD CARD
BATTERY
DIP S2
CABINET
CABINET NODE 1
STERN
CN4
CN11
FLIPPER
FLIPPER
CN12
CN14
CN2
CN5
CN8
3A 125V
TIME LAG FUSE
CN13
TO CPU
CN7
CABINET LEFT
CABINET RIGHT
METER 1 METER 2
MENU BUTTONS
CN6
CN3
CN10
CN9
SHAKER MOTOR
DBA
TICKET
COIN DOOR
Pinball
INPUTSLEDS
INPUTS LEDS
POWER
520-5319-00F
Cabinet Node
CN1
1
1
1
1
1
1111
1
1
CN3 CN22
CN3
CN13
CN10 CN2
CN2
CN3
NODE 9
NODE 10a
NODE 9a
NODE 8
NODE 11
CN3
CN9
NODE 0
NODE 10
CN2
CN14
CN14
CN1
CN2
CN14
KISS PRO
ID DIP Address Description Location Part Number
Node 0 n/a SPIKE CPU Node Backbox 520-6936-00
Node 1 n/a Cabinet Node Cabinet 520-5319-00
Node 8 OFF-OFF-OFF-OFF Lower Playeld 48V 8-Driver Node Lower playeld 520-6935-00
Node 9 OFF-OFF-ON-OFF Mid Playeld 48V 8-Driver Node Mid playeld 520-6935-00
Node 10 OFF-ON-OFF-OFF Upper Playeld 48V 8-Driver Node Upper playeld 520-6935-00
Node 11 OFF-ON-ON Mid Right Playeld 32 Lighting and Switch Backbox 520-5322-00
8a n/a Trough Serial Opto Receiver Extension Lower playeld (ball trough) 520-5345-01
9a n/a ASSY Star Grid LED Lower playeld 520-6969-00
10a n/a ASSY Star LED Board Mid playeld 520-6970-00

LIGHT, SWITCH, AND DRIVER REFERENCE
11
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
3.2 DRIVER REFERENCE
Figure 3.2.1. Playeld top component view
color bar
DEEP ROUT
.125
DEEP
.125
ROUT
DEEP
ROUT
DEEP
.062
BOTTOM
TOP
.093 DEEP
.093 DEEP
TOP
BOTTOM
DEEP
.062
.062
DEEP
BOTTOM
TOP
.093 DEEP
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
-20
E
PAHSM
.093 DEEP
TOP
.093 DEEP
TOP
ROUT
.070
CAT
STAR
BUMPER
LITE
BUMPER
DEMON
LITE
BUMPER
SPACE
LITE
BUMPER
LITE
W
W
WW
W
W
W
W
W
W
W
W
W
W
W
W
W
.070 DEEP
S
T
A
R
RED
AMBER
WHITE
GREEN FILTER
WHITE
PURPLE FILTER
WHITE
RED FILTER
WHITE
BLUE FILTER
YELLOW
CLEAR CLEAR CLEAR
WHITE
WHITE
CLEAR
CLEAR
RED
RED
RED
RED
RED
GREEN
GREEN
GREEN
CLEAR
ROCK
AGAIN
WHITE
WHITE
WHITE
WHITE
WHITE
CLEAR
A
CLEAR
CLEAR
YELLOW
ARMY
MILLIONS
WHITE
START
KISS
MILLION TARGETS
JACKPOT
JACKPOT
WHITE
WHITE
WHITE
WHITE
CLEAR
WHITE
DOUBLE
KISS
LITE
SHOT
WHITE
AMBER
BUMPER
WHITE
SUPER
SUPER
YELLOW YELLOW YELLOW YELLOW
WHITE
LITE
TARGETS
ARMY
ORANGE
INSTRUMENT
COLLECT
ORANGE
INSTRUMENT
COLLECT
ORANGE
INSTRUMENT
COLLECT
LITE
L
O
C
K
LITE
L
O
C
K
CLEAR
CLEAR
CLEAR
.062 BOTTOM DEEP
L
O
C
K
-29 -29 -06
-24
-24
NEW
-01
-29
-13
COLOSSAL
R
M
BACK STAGE
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
CLEAR
2X
3X
BONUS
Y
YELLOW
LITE
PASS
ADD A BALL
ORANGE
EXTRA BALL
AMBER
ROCK CITY
CLEAR
KISS ARMY
YELLOW
WHITE WHITE WHITE WHITE
ORANGE ORANGE ORANGE ORANGE
-18
W
W
W W
W
W
W
W
W
INSTRUMENT
COLLECT
MULTIBALL
white
ORANGE
INSTRUMENT
COLLECT
YELLOW
YELLOW
YELLOW
ORANGE
ORANGE
PURPLE
ORANGE
STAR PRO COIL MAP
BD.#10
BD.#9
BD.#8
BD.#11

12
LIGHT, SWITCH, AND DRIVER REFERENCE
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
Figure 3.3.1. Driver reference table.
3.3 SWITCH REFERENCE
Continued on next page...
DRIVER REFERENCE CONTINUED
ID Name Node Con-
nector
Ret.
Pin
Ret. Wire Voltage V+
Pin
V+ Color Location Type Address Part Number
1 Trough 8CN8 5 ORG-GRY 48V 6 GRY-ORG Playeld Coil - 27-1500 8-DR-5 090-5004-ND
2Auto Plunger 8CN6 5 ORG-WHT 48V 6 GRY-ORG Playeld Coil - 23-800 8-DR-4 090-5001-ND
6 Up Left Sling 9CN5 3YEL-BLU 48V 4 GRY-BLK Playeld Coil - 26-1200 9-DR-0 090-5044-ND
7Up Right Sling 9CN7 3YEL-GRY 48V 4 GRY-BLK Playeld Coil - 26-1200 9-DR-1 090-5044-ND
8Shaker Motor 1 CN2 1 BLU 48V 5 RED Cabinet Motor 1-DR-0 041-5029-04
9Left Pop Bumper 9CN6 5 ORG-BLK 48V 6 GRY-BLK Playeld Coil - 26-1200 9-DR-4 090-5044-ND
10 Right Pop Bumper 9CN8 5 ORG-BRN 48V 6 GRY-BLK Playeld Coil - 26-1200 9-DR-5 090-5044-ND
11 Bottom Pop Bumper 9CN10 5 ORG-RED 48V 6 GRY-BLK Playeld Coil - 26-1200 9-DR-6 090-5044-ND
12 Top Pop Bumper 9CN12 5 ORG 48V 6 GRY-BLK Playeld Coil - 26-1200 9-DR-7 090-5044-ND
15 Left Flipper 8CN5 3ORG-YEL 48V 4 GRY-ORG Playeld Coil - 24-850 8-DR-0 090-5083-03-ND
16 Right Flipper 8CN7 3ORG-GRN 48V 4 GRY-ORG Playeld Coil - 24-850 8-DR-1 090-5083-03-ND
17 Left Sling 8CN12 5 ORG-BLU 48V 6 GRY-ORG Playeld Coil - 26-1200 8-DR-7 090-5044-ND
18 Right Sling 8CN10 5 ORG-VIO 48V 6 GRY-ORG Playeld Coil - 26-1200 8-DR-6 090-5044-ND
20 Left Flipper Hold 8CN9 3YEL-ORG 48V 4 GRY-ORG Playeld Coil - 31-3500 8-DR-2 090-5083-03-ND
21 Right Flipper Hold 8CN11 3YEL-GRN 48V 4 GRY-ORG Playeld Coil - 31-3500 8-DR-3 090-5083-03-ND
22 Eject 10 CN5 3YEL-BLK 48V 4 GRY-BRN Playeld Coil - 26-1200 10-DR-0 090-5044-ND
23 Vertical Upkicker 10 CN7 3YEL-BRN 48V 4 GRY-BRN Playeld Coil - 23-800 10-DR-1 090-5001-ND
24 Scoop 10 CN9 3YEL-RED 48V 4 GRY-BRN Playeld Coil - 23-800 10-DR-2 090-5001-ND
29 Motor-Spin Disc 1 10 10a-
CN9
4 BLU-ORG 5V 1 RED Playeld Motor 10-LP-41 511-5190-00
30 Motor-Spin Disc 2 10 10a-
CN9
5 BLU-YEL 5V 1 RED Playeld Motor 10-LP-42 511-5190-00
31 Meter 1 1 CN3 2BLK 12V 1 RED Cabinet Digital Out 1-DR-2 500-9946-00
32 Meter 2 1 CN4 2BLK 12V 1 RED Cabinet Digital Out 1-DR-3 500-9946-00
33 Ticket Dispenser 1 CN11 312V 1 Cabinet Digital Out 1-DR-4
Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground
Wire
Location Type Address Part Number
1 Return Lane L 11 - CN7 3WHT-RED 10 BLK-VIO Playeld Rollover 11-SW-1 500-9935-04
2Return Lane R 11 - CN1 6 TAN-GRN 10 BLK-ORG Playeld Rollover 11-SW-28 500-9935-03
3Left Outlane 11 - CN7 2WHT-BRN 10 BLK-VIO Playeld Rollover 11-SW-0 500-9935-04
4 Right Outlane 11 - CN1 7TAN-BLU 10 BLK-ORG Playeld Rollover 11-SW-29 500-9935-04
5 Left Slingshot 8- CN12 4 GRY-BLU 3BLK-GRN Playeld Leaf 8-SW-7 180-5231-00
6 Right Slingshot 8- CN10 4 GRY-VIO 3BLK-GRN Playeld Leaf 8-SW-6 180-5231-00
10 Flipper Button L 8- CN9 2GRY-BRN 1 BLK-GRN Cabinet Leaf 8-SW-2 500-5160-01
11 Flipper Button R 8- CN11 2GRY-RED 1 BLK-GRN Cabinet Leaf 8-SW-3 500-5160-01
14 Left Orbit 11 - CN7 5 WHT-YEL 10 BLK-VIO Playeld Rollover 11-SW-3 500-9935-04
15 Tournament Start 1 - CN6 9GRY-WHT 5 BLK-WHT Cabinet Micro 1-SW-12 180-5174-00
16 Trough 6 8 8a CN14 - - - - Playeld Opto 8a-SW-9 520-5344-00 tx
520-5345-01 rx
17 Trough 5 8 8a CN14 - - - - Playeld Opto 8a-SW-10 520-5344-00 tx
520-5345-01 rx
18 Trough 4 8 8a CN14 - - - - Playeld Opto 8a-SW-11 520-5344-00 tx
520-5345-01 rx
19 Trough 3 8 8a CN14 - - - - Playeld Opto 8a-SW-12 520-5344-00 tx
520-5345-01 rx
20 Trough 2 8 8a CN14 - - - - Playeld Opto 8a-SW-13 520-5344-00 tx
520-5345-01 rx
21 Trough 1 8 8a CN14 - - - - Playeld Opto 8a-SW-14 520-5344-00 tx
520-5345-01 rx

color bar
DEEP ROUT
.125
DEEP
.125
ROUT
DEEP
ROUT
DEEP
.062
BOTTOM
TOP
.093 DEEP
.093 DEEP
TOP
BOTTOM
DEEP
.062
.062
DEEP
BOTTOM
TOP
.093 DEEP
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
-20
M SHAPE
.093 DEEP
TOP
.093 DEEP
TOP
ROUT
.070
CAT
STAR
BUMPER
LITE
BUMPER
DEMON
LITE
BUMPER
SPACE
LITE
BUMPER
LITE
W
W
WW
W
W
W
W
W
W
W
W
W
W
W
W
W
.070 DEEP
S
T
A
R
RED
AMBER
WHITE
GREEN FILTER
WHITE
PURPLE FILTER
WHITE
RED FILTER
WHITE
BLUE FILTER
YELLOW
CLEAR CLEAR CLEAR
WHITE
WHITE
CLEAR
CLEAR
RED
RED
RED
RED
RED
GREEN
GREEN
GREEN
CLEAR
ROCK
AGAIN
WHITE
WHITE
WHITE
WHITE
WHITE
CLEAR
A
CLEAR
CLEAR
YELLOW
ARMY
MILLIONS
WHITE
START
KISS
MILLION TARGETS
JACKPOT
JACKPOT
WHITE
WHITE
WHITE
WHITE
CLEAR
WHITE
DOUBLE
KISS
LITE
SHOT
WHITE
AMBER
BUMPER
WHITE
SUPER
SUPER
YELLOW YELLOW YELLOW YELLOW
WHITE
LITE
TARGETS
ARMY
ORANGE
INSTRUMENT
COLLECT
ORANGE
INSTRUMENT
COLLECT
ORANGE
INSTRUMENT
COLLECT
LITE
L
O
C
K
LITE
L
O
C
K
CLEAR
CLEAR
CLEAR
.062 BOTTOM DEEP
L
O
C
K
-29 -29 -06
-24
-24
NEW
-01
-29
-13
COLOSSAL
R
M
BACK STAGE
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
CLEAR
2X
3X
BONUS
Y
YELLOW
LITE
PASS
ADD A BALL
ORANGE
EXTRA BALL
AMBER
ROCK CITY
CLEAR
KISS ARMY
YELLOW
WHITE WHITE WHITE WHITE
ORANGE ORANGE ORANGE ORANGE
-18
W
W
W
W
W
W
W
W
W
INSTRUMENT
COLLECT
MULTIBALL
white
ORANGE
INSTRUMENT
COLLECT
YELLOW
YELLOW
YELLOW
ORANGE
ORANGE
PURPLE
ORANGE
STAR PRO SWITCH MAP
BD.#10
BD.#9
BD.#8
BD.#11
LIGHT, SWITCH, AND DRIVER REFERENCE
13
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
Figure 3.3.2. Playeld switch locations (top view).
SWITCH REFERENCE CONTINUED

14
LIGHT, SWITCH, AND DRIVER REFERENCE
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
SWITCH REFERENCE CONTINUED
Continued on next page...
Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground
Wire
Location Type Address Part Number
22 Trough Jam 8 8a CN14 - - - - Playeld Opto 8a-SW-15 520-5344-00 tx
520-5345-01 rx
23 Shooter Lane 8- CN6 4 GRY-WHT 3BLK-GRN Playeld Rollover 8-SW-4 180-5157-01
24 Right Orbit 11 - CN3 9PNK-VIO 10 BLK-RED Playeld Rollover 11-SW-23 500-9935-03
25 (S)TAR Target 11 - CN7 6 WHT-GRN 10 BLK-VIO Playeld Leaf, Target 11-SW-4 515-9783-00-00
26 S(T)AR Target 11 - CN7 7WHT-BLU 10 BLK-VIO Playeld Leaf, Target 11-SW-5 515-9783-00-00
27 ST(A)R Target 11 - CN7 8WHT-VIO 10 BLK-VIO Playeld Leaf, Target 11-SW-6 515-9783-00-00
28 STA(R) Target 11 - CN7 9WHT-GRY 10 BLK-VIO Playeld Leaf, Target 11-SW-7 515-9783-00-00
30 Left Pop Bumper 9- CN6 4 LGN-BLK 3BLK-BRN Playeld Leaf 9-SW-4 180-5232-00
31 Right Pop Bumper 9- CN8 4 LGN-BRN 3BLK-BRN Playeld Leaf 9-SW-5 180-5232-00
32 Bottom Pop Bumper 9- CN10 4 LGN-RED 3BLK-BRN Playeld Leaf 9-SW-6 180-5232-00
33 Top Pop Bumper 9- CN12 4 LGN-ORG 3BLK-BRN Playeld Leaf 9-SW-7 180-5232-00
35 Up Left Sling 9- CN5 2LGN-YEL 1 BLK-BRN Playeld Leaf 9-SW-0 180-5231-00
36 Up Right Sling 9- CN7 2LGN-BLU 1 BLK-BRN Playeld Leaf 9-SW-1 180-5231-00
38 4 Bank (K)ISS 10 - CN6 4 WHT-BRN 3BLK-BLU Playeld Leaf, Target 10-SW-4 515-9783-00-00
39 4 Bank K(I)SS 10 - CN8 4 WHT-RED 3BLK-BLU Playeld Leaf, Target 10-SW-5 515-9783-00-00
40 4 Bank KI(S)S 10 - CN10 4 WHT-ORG 3BLK-BLU Playeld Leaf, Target 10-SW-6 515-9783-00-00
41 4 Bank KIS(S) 10 - CN12 4 WHT-YEL 3BLK-BLU Playeld Leaf, Target 10-SW-7 515-9783-00-00
42 Verticual Upkicker 10 - CN7 2WHT-BLU 1 BLK-BLU Playeld Rollover 10-SW-1 180-5209-00
43 Scoop 10 - CN9 2WHT-VIO 1 BLK-BLU Playeld Rollover 10-SW-2 180-5057-00
44 Left Lock Target 11 - CN5 2LGN-BLK 10 BLK-GRY Playeld Leaf, Target 11-SW-8 515-9785-00-00
45 Right Lock Target 11 - CN5 3LGN-BRN 10 BLK-GRY Playeld Leaf, Target 11-SW-9 515-9785-00-00
46 Left Return Lane (R) 11 - CN7 4 WHT-ORG 10 BLK-VIO Playeld Rollover 11-SW-2 500-9935-04
47 Eject 10 - CN5 2WHT-GRN 1 BLK-BLU Playeld Micro 10-SW-0 180-5186-01
48 Spinner 10 - CN11 1 WHT-GRY 1 BLK-BLU Playeld Micro 10-SW-3 180-5010-04
49 Demon Entrance Opto 11 - CN5 4 LGN-RED 10 BLK-GRY Playeld Opto 11-SW-10 515-0215-00 tx
515-0215-01 rx
56 Right Ramp Exit 11 - CN3 7PNK-GRN 10 BLK-RED Playeld Micro 11-SW-21 180-5087-00
58 (A)RMY Target 11 - CN1 2TAN-BLK 10 BLK-ORG Playeld Leaf, Target 11-SW-24 515-9783-00-00
59 A(R)MY Target 11 - CN1 3TAN-RED 10 BLK-ORG Playeld Leaf, Target 11-SW-25 515-9783-00-00
60 AR(M)Y Target 11 - CN1 4 TAN-ORG 10 BLK-ORG Playeld Leaf, Target 11-SW-26 515-9783-00-00
61 ARM(Y) Target 11 - CN1 5 TAN-YEL 10 BLK-ORG Playeld Leaf, Target 11-SW-27 515-9783-00-00
62 Start Button 1 - CN6 10 GRY 5 BLK-WHT Cabinet Micro 1-SW-11 500-6388-44-
LED
64 Left Ramp Exit 11 - CN3 3PNK-BRN 10 BLK-RED Playeld Micro 11-SW-17 180-5087-00
65 Left Flipper EOS 8- CN5 2GRY-YEL 1 BLK-GRN Playeld Leaf 8-SW-0 180-5149-00
66 Right Flipper EOS 8- CN7 2GRY-GRN 1 BLK-GRN Playeld Leaf 8-SW-1 180-5149-00
67 Left Coin 1 - CN5 9PNK-BRN 3BLK Cabinet Micro 1-SW-16
68 Right Coin 1 - CN5 8PNK-RED 3BLK Cabinet Micro 1-SW-18
69 Center Coin 1 - CN5 7PNK-ORG 3BLK Cabinet Micro 1-SW-17
70 Fourth Coin 1 - CN5 6 - - - Cabinet - 1-SW-19
71 Fifth Coin 1 - CN5 5 - - - Cabinet - 1-SW-20
72 Tilt Pendulum 1 - CN6 7WHT 5 BLK-WHT Cabinet Plumb Bob 1-SW-14
73 Launch Button (Re-
served)
1 - CN7 8PNK-BLU 5 BLK Cabinet Micro 1-SW-2
76 Ticket Notch 1 - CN11 5 - - - Cabinet - 1-SW-8
77 Slam Tilt 1 - CN5 4 LGN-RED 3BLK Cabinet - 1-SW-21
C1 DIP 1 0 - - - - - - CPU Node 0-SW-0 -
C2 DIP 2 0 - - - - - - CPU Node 0-SW-2 -
C3 DIP 3 0 - - - - - - CPU Node 0-SW-3 -
C4 DIP 4 0 - - - - - - CPU Node 0-SW-4 -
C5 DIP 5 0 - - - - - - CPU Node 0-SW-5 -

LIGHT, SWITCH, AND DRIVER REFERENCE
15
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
SWITCH REFERENCE CONTINUED
Continued on next page...
3.4 LIGHT REFERENCE
Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground
Wire
Location Type Address Part Number
C6 DIP 6 0 - - - - - - CPU Node 0-SW-6 -
C7 DIP 7 0 - - - - - - CPU Node 0-SW-7 -
C8 DIP 8 0 - - - - - - CPU Node 0-SW-8 -
C9 Service Select 0 - CN25 1 LGN-GRY 11 BLK-WHT Coin Door 0-SW-9 180-5192-04
C10 Service Plus 0 - CN25 2LGN-VIO 11 BLK-WHT Coin Door 0-SW-10 180-5192-02
C11 Service Minus 0 - CN25 3LGN-BLU 11 BLK-WHT Coin Door 0-SW-11 180-5192-02
C12 Service Back 0 - CN25 4 LGN-BLK 11 BLK-WHT Coin Door 0-SW-12 180-5192-00
C16 Power Interlock Sense 0 - CN7 4 GRY-RED 1 BLK Cabinet Interlock 0-SW-16 180-5136-00
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src.
Wire
Location Type Light
Color
Address Part Number
1 Start Button 1 - CN6 3YEL BRN 1 RED Cabinet Feature White 1-LP-2 112-5033-08
2Tournament Button 1 - CN6 2YEL RED 1 RED Cabinet Feature White 1-LP-3 112-5033-08
6 Left Outlane 11 - CN8 8BRN GRN 2/3 RED Playeld Feature White 11-LP-28 520-5307-00
7Left Return Lane L 11 - CN8 9BRN BLU 2/3 RED Playeld Feature White 11-LP-29 520-5307-00
8Left Return Lane R 11 - CN8 10 BRN VIO 2/3 RED Playeld Feature White 11-LP-30 520-5307-00
9Bonus (K)ISS 9 9a CN14 - - - - Playeld Feature White 9a-LP-39 520-6969-00
10 Bonus K(I)SS 9 9a CN14 - - - - Playeld Feature White 9a-LP-36 520-6969-00
11 Bonus KI(S)S 9 9a CN14 - - - - Playeld Feature White 9a-LP-27 520-6969-00
12 Bonus KIS(S) 9 9a CN14 - - - - Playeld Feature White 9a-LP-30 520-6969-00
13 Bonus (A)RMY 9 9a CN14 - - - - Playeld Feature White 9a-LP-45 520-6969-00
14 Bonus A(R)MY 9 9a CN14 - - - - Playeld Feature White 9a-LP-33 520-6969-00
15 Bonus AR(M)Y 9 9a CN14 - - - - Playeld Feature White 9a-LP-24 520-6969-00
16 Bonus ARM(Y) 9 9a CN14 - - - - Playeld Feature White 9a-LP-21 520-6969-00
17 Bonus Pop Starchild 9 9a CN14 - - - - Playeld Feature White 9a-LP-48 520-6969-00
18 Bonus Pop Spaceman 9 9a CN14 - - - - Playeld Feature White 9a-LP-42 520-6969-00
19 Bonus Pop Demon 9 9a CN14 - - - - Playeld Feature White 9a-LP-18 520-6969-00
20 Bonus Pop Catman 9 9a CN14 - - - - Playeld Feature White 9a-LP-15 520-6969-00
21 Bonus Inst Starchild 9 9a CN14 - - - - Playeld Feature White 9a-LP-54 520-6969-00
22 Bonus Inst Spaceman 9 9a CN14 - - - - Playeld Feature White 9a-LP-51 520-6969-00
23 Bonus Inst Demon 9 9a CN14 - - - - Playeld Feature White 9a-LP-9 520-6969-00
24 Bonus Inst Catman 9 9a CN14 - - - - Playeld Feature White 9a-LP-12 520-6969-00
25 Bonus Starchild 9 9a CN14 - - - - Playeld Feature White 9a-LP-61 520-6969-00
26 Bonus Spaceman 9 9a CN14 - - - - Playeld Feature White 9a-LP-58 520-6969-00
27 Bonus Demon 9 9a CN14 - - - - Playeld Feature White 9a-LP-57 520-6969-00
28 Bonus Catman 9 9a CN14 - - - - Playeld Feature White 9a-LP-56 520-6969-00
29 Bonus 2X 9 9a CN14 - - - - Playeld Feature White 9a-LP-59 520-6969-00
30 Bonus 3X 9 9a CN14 - - - - Playeld Feature White 9a-LP-60 520-6969-00
31 Bonus Colossal 99a 9a-CN3 2ORG RED 4 RED Playeld Feature White 9a-LP-62 520-5307-00
32 Rock Again 9 9a 9a-CN3 3ORG YEL 4 RED Playeld Feature White 9a-LP-63 520-5307-00
33 Right Return Lane 10 10a 10a-CN8 4 BRN YEL 8RED Playeld Feature White 10-LP-61 520-5307-00
34 Right Outlane 10 10a 10a-CN8 5 BRN GRN 8RED Playeld Feature White 10-LP-62 520-5307-00
35 (K)ISS 11 - CN8 4 BRN BLK 2/3 RED Playeld Feature White 11-LP-24 520-5307-00
36 K(I)SS 11 - CN8 5 BRN RED 2/3 RED Playeld Feature White 11-LP-25 520-5307-00
37 KI(S)S 11 - CN8 6 BRN ORG 2/3 RED Playeld Feature White 11-LP-26 520-5307-00
38 KIS(S) 11 - CN8 7BRN YEL 2/3 RED Playeld Feature White 11-LP-27 520-5307-00
39 Extra Ball 11 - CN6 10 ORG BLU 2/3 RED Playeld Feature White 11-LP-22 520-5307-00
40 KISS Army 11 - CN6 11 ORG VIO 2/3 RED Playeld Feature White 11-LP-23 520-5307-00
41 Backstage Pass LT 11 - CN4 10 ORG BLK 2/3 RED Playeld Feature White 11-LP-14 520-5307-00
42 Backstage Pass RT 11 - CN4 11 ORG BRN 2/3 RED Playeld Feature White 11-LP-15 520-5307-00

16
LIGHT, SWITCH, AND DRIVER REFERENCE
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
LIGHT REFERENCE CONTINUED
Continued on next page
color bar
DEEP ROUT
.125
DEEP
.125 ROUT
DEEP
ROUT
DEEP
.062
BOTTOM
TOP
.093 DEEP
.093 DEEP
TOP
BOTTOM
DEEP
.062
.062
DEEP
BOTTOM
TOP
.093 DEEP
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
-20
M SHAPE
.093 DEEP
TOP
.093 DEEP
TOP
ROUT
.070
CAT
STAR
BUMPER
LITE
BUMPER
DEMON
LITE
BUMPER
SPACE
LITE
BUMPER
LITE
W
W
WW
W
W
W
W
W
W
W
W
W
W
W
W
W
.070 DEEP
S
T
A
R
RED
AMBER
WHITE
GREEN FILTER
WHITE
PURPLE FILTER
WHITE
RED FILTER
WHITE
BLUE FILTER
YELLOW
CLEAR CLEAR CLEAR
WHITE
WHITE
CLEAR
CLEAR
RED
RED
RED
RED
RED
GREEN
GREEN
GREEN
CLEAR
ROCK
AGAIN
WHITE
WHITE
WHITE
WHITE
WHITE
CLEAR
A
CLEAR
CLEAR
YELLOW
ARMY
MILLIONS
WHITE
START
KISS
MILLION TARGETS
JACKPOT
JACKPOT
WHITE
WHITE
WHITE
WHITE
CLEAR
WHITE
DOUBLE
KISS
LITE
SHOT
WHITE
AMBER
BUMPER
ARM
Y
WHITE
SUPER
SUPER
YELLOW YELLOW YELLOW YELLOW
WHITE
LITE
TARGETS
ARMY
ORANGE
INSTRUMENT
COLLECT
ORANGE
INSTRUMENT
COLLECT
ORANGE
INSTRUMENT
COLLECT
LITE
L
O
C
K
LITE
L
O
C
K
CLEAR
CLEAR
CLEAR
.062 BOTTOM DEEP
L
O
C
K
-29 -29 -06
-24
-24
NEW
-01
-29
-13
COLOSSAL
R
M
BACK STAGE
.062
DEEP
BOTTOM
.062
DEEP
BOTTOM
CLEAR
2X
3X
BONUS
Y
YELLOW
LITE
PASS
ADD A BALL
ORANGE
EXTRA BALL
AMBER
ROCK CITY
CLEAR
KISS ARMY
YELLOW
WHITE WHITE WHITE WHITE
ORANGE ORANGE ORANGE ORANGE
-18
W
W
W
W
W
W
W
W
W
INSTRUMENT
COLLECT
MULTIBALL
white
ORANGE
INSTRUMENT
COLLECT
YELLOW
YELLOW
YELLOW
ORANGE
ORANGE
PURPLE
ORANGE
BD.#10
BD.#9
BD.#8
BD.#11

LIGHT, SWITCH, AND DRIVER REFERENCE
17
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
LIGHT REFERENCE CONTINUED
Continued on next page
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src.
Wire
Location Type Light
Color
Address Part Number
43 Rock City 10 10a CN14 - - - - Playeld Feature White 10-LP-15 520-6970-00
44 New Track 10 10a CN14 - - - - Playeld Feature White 10-LP-17 520-6970-00
46 BOT Pop bumper-RED 11 - CN4 4 RED YEL 2/3 RED Playeld Feature Red 11-LP-8 520-6971-00
47 BOT Pop bumper-GRN 11 - CN4 5 GRN YEL 2/3 RED Playeld Feature Green 11-LP-9 520-6971-00
48 BOT Pop bumper-BLU 11 - CN4 6 BLU YEL 2/3 RED Playeld Feature Blue 11-LP-10 520-6971-00
49 LT Pop bumper-RED 11 - CN2 4 RED BRN 2/3 RED Playeld Feature Red 11-LP-0 520-6971-00
50 LT Pop bumper-GRN 11 - CN2 5 GRN BRN 2/3 RED Playeld Feature Green 11-LP-1 520-6971-00
51 LT Pop bumper-BLU 11 - CN2 6 BLU BRN 2/3 RED Playeld Feature Blue 11-LP-2 520-6971-00
52 TOP Pop bumper-RED 11 - CN4 7RED GRN 2/3 RED Playeld Feature Red 11-LP-11 520-6971-00
53 TOP Pop bumper-GRN 11 - CN4 8GRN 2/3 RED Playeld Feature Green 11-LP-12 520-6971-00
54 TOP Pop bumper-BLU 11 - CN4 9BLU GRN 2/3 RED Playeld Feature Blue 11-LP-13 520-6971-00
55 RT Pop bumper-RED 11 - CN2 7RED ORG 2/3 RED Playeld Feature Red 11-LP-3 520-6971-00
56 RT Pop bumper-GRN 11 - CN2 8GRN ORG 2/3 RED Playeld Feature Green 11-LP-4 520-6971-00
57 RT Pop bumper-BLU 11 - CN2 9BLU ORG 2/3 RED Playeld Feature Blue 11-LP-5 520-6971-00
58 LT Orbit Arrow-RED 11 - CN6 4 RED GRY 2/3 RED Playeld Feature Red 11-LP-16 520-5333-00
59 LT Orbit Arrow-GRN 11 - CN6 5 GRN GRY 2/3 RED Playeld Feature Green 11-LP-17 520-5333-00
60 LT Orbit Arrow-BLU 11 - CN6 6 BLU GRY 2/3 RED Playeld Feature Blue 11-LP-18 520-5333-00
61 Super Bumpers 11 - CN6 7ORG RED 2/3 RED Playeld Feature White 11-LP-19 520-5307-00
62 Collect Catman Inst 11 - CN6 8ORG YEL 2/3 RED Playeld Feature White 11-LP-20 520-5307-00
64 (S)TAR 9- CN6 1 ORG BLK 2YEL Playeld Feature White 9-LP-0 520-5307-00
65 S(T)AR 9- CN8 1 ORG BRN 2YEL Playeld Feature White 9-LP-1 520-5307-00
66 ST(A)R 9- CN10 1 ORG RED 2YEL Playeld Feature White 9-LP-2 520-5307-00
67 STA(R) 9- CN12 1 ORG YEL 2YEL Playeld Feature White 9-LP-3 520-5307-00
68 Starchild Arrow-RED 10 10a 10a-CN7 7RED BLU 10 RED Playeld Feature Red 10-LP-49 520-5333-00
69 Starchild Arrow-GRN 10 10a 10a-CN7 8GRN BLU 10 RED Playeld Feature Green 10-LP-50 520-5333-00
70 Starchild Arrow-BLU 10 10a 10a-CN7 9BLU 10 RED Playeld Feature Blue 10-LP-51 520-5333-00
71 Starchild 10 10a CN14 - - - - Playeld Feature White 10-LP-21 520-6970-00
72 Collect Starchild Inst 10 10a CN14 - - - - Playeld Feature White 10-LP-23 520-6970-00
73 LT Ramp Arrow-RED 10 10a 10a-CN7 4 RED VIO 10 RED Playeld Feature Red 10-LP-46 520-5333-00
74 LT Ramp Arrow-GRN 10 10a 10a-CN7 5 GRN VIO 10 RED Playeld Feature Green 10-LP-47 520-5333-00
75 LT Ramp Arrow-BLU 10 10a 10a-CN7 6 BLU VIO 10 RED Playeld Feature Blue 10-LP-48 520-5333-00
76 Spaceman 10 10a CN14 - - - - Playeld Feature White 10-LP-19 520-6970-00
77 ARMY 10 10a CN14 - - - - Playeld Feature White 10-LP-20 520-6970-00
78 Collect Spaceman Inst 10 10a CN14 - - - - Playeld Feature White 10-LP-22 520-6970-00
79 Demon Arrow-RED 10 10a 10a-CN7 1 RED GRY 10 RED Playeld Feature Red 10-LP-43 520-5333-00
80 Demon Arrow-GRN 10 10a 10a-CN7 2GRN GRY 10 RED Playeld Feature Green 10-LP-44 520-5333-00
81 Demon Arrow-BLU 10 10a 10a-CN7 3BLU GRY 10 RED Playeld Feature Blue 10-LP-45 520-5333-00
82 LT Lock target 10 10a CN14 - - - - Playeld Feature White 10-LP-29 520-6970-00
83 Demon 10 10a CN14 - - - - Playeld Feature White 10-LP-27 520-6970-00
84 RT Lock target 10 10a CN14 - - - - Playeld Feature White 10-LP-26 520-6970-00
85 (D)EMON 10 10a CN14 - - - - Playeld Feature White 10-LP-30 520-6970-00
86 D(E)MON 10 10a CN14 - - - - Playeld Feature White 10-LP-31 520-6970-00
87 DE(M)ON 10 10a CN14 - - - - Playeld Feature White 10-LP-28 520-6970-00
88 DEM(O)N 10 10a CN14 - - - - Playeld Feature White 10-LP-24 520-6970-00
89 DEMO(N) 10 10a CN14 - - - - Playeld Feature White 10-LP-25 520-6970-00
90 LOCK 10 10a CN14 - - - - Playeld Feature White 10-LP-18 520-6970-00
91 Collect Demon Inst. 10 10a CN14 - - - - Playeld Feature White 10-LP-14 520-6970-00
92 RT Ramp Arrow-RED 10 10a CN14 - - - - Playeld Feature Red 10-LP-32 520-6970-00
93 RT Ramp Arrow-GRN 10 10a CN14 - - - - Playeld Feature Green 10-LP-33 520-6970-00
94 RT Ramp Arrow-BLU 10 10a CN14 - - - - Playeld Feature Blue 10-LP-34 520-6970-00
95 Super Targets 10 10a CN14 - - - - Playeld Feature White 10-LP-16 520-6970-00

18
LIGHT, SWITCH, AND DRIVER REFERENCE
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src.
Wire
Location Type Light
Color
Address Part Number
96 LOVE GUN 10 10a CN14 - - - - Playeld Feature White 10-LP-8 520-6970-00
97 Lite Inst. RT ramp 10 10a CN14 - - - - Playeld Feature White 10-LP-13 520-6970-00
98 RT Orbit Arrow-RED 10 10a 10a-CN6 1 RED WHT 8RED Playeld Feature Red 10-LP-52 520-5333-00
99 RT Orbit Arrow-GRN 10 10a 10a-CN6 2GRN WHT 8RED Playeld Feature Green 10-LP-53 520-5333-00
100 RT Orbit Arrow-BLU 10 10a 10a-CN6 3BLU WHT 8RED Playeld Feature Blue 10-LP-54 520-5333-00
101 RT Orbit Catman 10 10a 10a-CN6 4 ORG GRY 8RED Playeld Feature White 10-LP-55 520-5307-00
102 RT Orbit Spaceman 10 10a 10a-CN6 5 ORG WHT 8RED Playeld Feature White 10-LP-56 520-5307-00
103 RT Orbit Starchild 10 10a CN14 - - - - Playeld Feature White 10-LP-11 520-6970-00
104 RT Orbit Demon 10 10a CN14 - - - - Playeld Feature White 10-LP-10 520-6970-00
105 Catman 10 10a CN14 - - - - Playeld Feature White 10-LP-9 520-6970-00
106 (A)RMY 10 10a CN14 - - - - Playeld Feature White 10-LP-12 520-6970-00
107 A(R)MY 10 10a 10a-CN8 1 BRN BLK 8RED Playeld Feature White 10-LP-58 520-5307-00
108 AR(M)Y 10 10a 10a-CN8 2BRN RED 8RED Playeld Feature White 10-LP-59 520-5307-00
109 ARM(Y) 10 10a 10a-CN8 3BRN ORG 8RED Playeld Feature White 10-LP-60 520-5307-00
113 Sling Flash 10 10a 10a-CN8 6 YEL GRN 8RED Playeld Flash White 10-LP-63 520-6785-00
114 Mid Pd Flash Left 11 - CN8 11 YEL BLK 2/3 RED Playeld Flash White 11-LP-31 520-6785-00
115 Pop ash 11 - CN6 9ORG GRN 2/3 RED Playeld Flash White 11-LP-21 520-6785-00
116 STAR Flash 10 10a 10a-CN4 2YEL BRN 5 RED Playeld Flash White 10-LP-36 520-6785-00
117 Paul Flash 10 10a 10a-CN4 1 YEL RED 5 RED Playeld Flash White 10-LP-35 113-5032-08
118 Left Ramp Flash 10 10a 10a-CN4 3ORG GRN 5 RED Playeld Flash White 10-LP-37 520-6785-00
120 Mid Plfd Flash Rt 11 - CN2 11 YEL VIO 2/3 RED Playeld Flash White 11-LP-7
121 Gene Flash 10 10a 10a-CN4 4 YEL ORG 5 RED Playeld Flash White 10-LP-38 113-5032-08
122 Right Ramp Flash 10 10a 10a-CN6 6 ORG BLU 8RED Playeld Flash White 10-LP-57 520-6785-00
123 Backpanel Flash 1 L 10 - CN6 1 YEL BLK 2YEL Back Pnl Flash White 10-LP-0 520-6785-00
124 Backpanel Flash 2 10 - CN8 1 YEL BRN 2YEL Back Pnl Flash White 10-LP-1 520-6785-00
125 Backpanel Flash 3 10 - CN10 1 YEL RED 2YEL Back Pnl Flash White 10-LP-2 520-6785-00
126 Backpanel Flash 4 R 10 - CN12 1 YEL ORG 2YEL Back Pnl Flash White 10-LP-3 520-6785-00
132 Coin Door GI(x2) 1 - CN5 2YEL 1 YEL
WHT
Coin Door G.I. White 1-LP-1 112-5033-08
133 Pd GI White Lower 8- CN13 1 WHT BLK 3YEL
BLK
Playeld G.I. White 8-LP-4 112-5034-08
134 Pd GI White Mid 9- CN13 1 RED BLK 3YEL
RED
Playeld G.I. Red 9-LP-4 112-5034-08
135 Pd GI White Upper 10 - CN13 1 BLU BLK 3YEL
BLU
Playeld/
Back Pnl
G.I. Blue 10-LP-4 112-5034-08
136 Coin Enable 1
- CN8 6
BLK GRY 2GRY
RED Coin Door
Digital
Out 1-LP-0
LIGHT REFERENCE CONTINUED

D30D29D28 D13
SDA
RST
GND
SCL
RESET
CN18
LINE
OUT
TxD
NETSTAT
STATUS
RxD
5V 48V
24V
9V
S1
+48V
CN23
11
CN20
POWER
HEADPHONE
CN25
IN
L+ L-
C+ C- R+ R-
CN21
CN7
CN3 CN22
CN4 CN1
CN24
520-6936-00A
SPIKE CPU
11
1
1
BT1
AMPLIFIED AUDIO
OUT
SPIKE NODE BUS
USB
SD CARD
BATTERY
DIP S2
Figure 3.4.1. SPIKE CPU Node connector detail.
Figure 3.4.2. Country code DIP switch settings.
Figure 3.4.3. Audio Pinouts
ELECTRONIC PINOUTS AND SCHEMATICS
19
© 2015 KISS Catalog, Ltd.
Under License to Epic Rights. KISS PRO MANUAL #500-55H1-01
ID Type Pin Description Minimum
Impedance
Max
Power
(RMS)
CN18 TRS 3.5mm
Headphone
Jack
Tip Headphone Left 8 Ohms 200mW
Ring Headphone Right 8 Ohms 200mW
Sleeve Audio Ground - -
CN1 .156" 5-pin
Header
1 Speaker Right Ground
(-)
4 Ohms -
2Speaker Right (+) 4 Ohms 20W
3n/c - -
4 Speaker Left Ground
(-)
4 Ohms -
5 Speaker Left (+) 4 Ohms 20W
CN4 .156" 2-pin
Header
1 Woofer Ground (-) 8 Ohms -
2Woofer Out (+) 8 Ohms 40W
CN27 .100" 3-pin
header
1 Line Out Left (+) 600 Ohms -
2Line Out Ground - -
3Line Out Right (-) 600 Ohms -
AUDIO PINOUTS
COUNTRY CODES (DIP S2)
DIP S2
Country 1 234567 8
USA OFF OFF OFF OFF OFF OFF OFF OFF
Austria ON OFF OFF OFF OFF OFF OFF OFF
Australia ON OFF ON ON OFF OFF OFF OFF
Belgium OFF ON OFF OFF OFF OFF OFF OFF
Canada 1 ON ON OFF OFF OFF OFF OFF OFF
Canada 2 OFF ON OFF ON ON OFF OFF OFF
Croatia OFF ON ON OFF ON OFF OFF OFF
Denmark ON OFF OFF ON OFF OFF OFF OFF
Finland ON OFF ON OFF OFF OFF OFF OFF
France OFF ON ON OFF OFF OFF OFF OFF
Germany ON ON ON OFF OFF OFF OFF OFF
Greece ON ON ON ON OFF OFF OFF OFF
Italy OFF OFF OFF ON OFF OFF OFF OFF
Japan ON OFF ON OFF ON OFF OFF OFF
Middle East ON ON ON OFF ON OFF OFF OFF
Netherlands OFF OFF ON OFF OFF OFF OFF OFF
New Zealand OFF OFF OFF OFF ON OFF OFF OFF
Norway OFF ON OFF ON OFF OFF OFF OFF
Portugal ON OFF OFF OFF OFF ON OFF OFF
Russia ON OFF OFF ON ON OFF OFF OFF
S. Africa OFF OFF ON OFF ON OFF OFF OFF
Spain OFF ON OFF OFF ON OFF OFF OFF
Sweden ON ON OFF ON OFF OFF OFF OFF
Switzerland OFF OFF ON ON OFF OFF OFF OFF
Taiwan OFF OFF OFF ON ON OFF OFF OFF
United Kingdom OFF ON ON ON OFF OFF OFF OFF
4. ELECTRONIC PINOUTS AND SCHEMATICS
CONNECTORS
ID Connector Type Description
CN1 5-Pin .156” Header Backbox 2-channel amplied speaker out
CN3 RJ45 SPIKE node bus - to cabinet node N1
CN4 2-Pin .156” Cabinet 1-channel amplied speaker out
CN7 5-Pin .156” Header 48V supply from main power supply
CN18 3.5mm Stereo TRS jack Headphone Jack
CN20 USB USB connector - for software updates,
audit dumps, and expansion modules
CN21 USB USB connector - for software updates,
audit dumps, and expansion modules
CN22 RJ45 SPIKE node bus - to playeld node, N8
CN23 14-Pin .100” Header Dot matrix display connector
CN24 4-Pin .156” Header 5V DC and ground out to the LED display
CN25 12-Pin .100” Header Dedicated switch inputs - service, volume
switches
COMPONENTS
ID Name
S1 Resetv Switch
S2 DIP Switches
SD CARD For system SD card. Note: only to be removed if instructed to by
Stern Service.
BT1 CR232 3V Lithium battery for game clock between power cycles
4.1 SPIKE CPU NODE 0
520-6936-00

20
ELECTRONIC PINOUTS AND SCHEMATICS
KISS PRO MANUAL #500-55H1-01 © 2015 KISS Catalog, Ltd.
Under License to Epic Rights.
SPIKE CPU NODE 0 CONTINUED
Figure 4.1.1. Service switch wiring. Note that the Cabient Node must be present and CN10 and CN12 connected for the Coin Door
Service Switches to function correctly.
COIN DOOR SERVICE SWITCH WIRING
STATUS LEDS
LED ID Name Color Description
48V +48V Supply In Red ON: Main system power is connected, OFF: No 48V system power. Check power supply
connections, cables, and fuses.
24V +24V Audio Power Red ON: Audio power supply is good, OFF: Audio power supply off, call tech support.
9V +9V Node Bus Power Red ON: Node bus power supply is good, OFF: Node bus power supply bad, call tech support.
5V Red ON: Logic power supply is good. OFF: Logic power supply bad, call tech support.
TxD Node bus transmit Red Node bus transmit activity
RxD Node bus receive Red Node bus receive activity
Status System status Red Constant double blink - game software running
Netstat Network status Red Communication bridge activity
DIRECT SWITCH MAPPING (CN25)
The coin-door diagnostic switches are connected directly to the CPU node via the Cabinet Node. Note that both the CPU and
Cabinet nodes are required for diagnostic switch operation.
ID Name Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
C1 DIP 1 - - - - - CPU Node 0-SW-0 -
C2 DIP 2 - - - - - CPU Node 0-SW-2 -
C3 DIP 3 - - - - - CPU Node 0-SW-3 -
C4 DIP 4 - - - - - CPU Node 0-SW-4 -
C5 DIP 5 - - - - - CPU Node 0-SW-5 -
C6 DIP 6 - - - - - CPU Node 0-SW-6 -
C7 DIP 7 - - - - - CPU Node 0-SW-7 -
C8 DIP 8 - - - - - CPU Node 0-SW-8 -
C9 Service Select CN25 1 LGN-GRY 11 BLK-WHT Coin Door 0-SW-9 180-5192-04
C10 Service Plus CN25 2LGN-VIO 11 BLK-WHT Coin Door 0-SW-10 180-5192-02
C11 Service Minus CN25 3LGN-BLU 11 BLK-WHT Coin Door 0-SW-11 180-5192-02
C12 Service Back CN25 4 LGN-BLK 11 BLK-WHT Coin Door 0-SW-12 180-5192-00
C16 Playeld Power Interlock CN7 4 GRY 5 GRY-RED Cabinet Interlock 0-SW-16 180-5136-00
