Stern Pinball Batman Premium User manual

STERN Pinball Inc.
NOTE:This instruction sheet is a guide for the installation ofthe support for the left metal ramp cover and the ball
deflector above the left outlane. The procedures are intended to be performed by the owner of the product. It is the
responsibility of the owner to make sure everything is installed properly and securely.
COPYRIGHT
Copyright Stern Pinball Inc.2017
All rights reserved. No part ofthis publication
may be reproduced in anyform or by any means
without the prior written permission of
Stern Pinballlnc-
llamp Cover Support & Left Outlane Ball
Deflector Installation Kit
Batman Premium / LE /Super LE
Installation Instructions
Document Number: 755-7616-00
lssue: Rev 1.0
Date: January 31, 2017
Page 1

Installation
Tools Required:
4.
2.
3.
#2 Phillips Head Screwdriver
!/4" Hex Nutdriver OR 1/4" Hex Wrench
1,I/32" Hex Nutdriver OR Wrench for 8-32 nut
Installing the Ball Deflector Bracket
Remove the 8-32 nut & oversize #8 washer on top of the left wire ramp mounting leg and set them asicle. Lift up
on the leg and remove & discard the other oversize #8 washer.
While holding up the mounting leg, place the mounting hole of the deflector bracket onto the threadecl post.
The small tab should hang out over the edge of the -05 plastic and prevent the bracket from rotattng.
Place the mounting leg back into position and reinstall the 8-32 nut and washer. Adjust the ramp position as
necessary to keep the exit loop centered over the return Iane.
Return the playfield to its normal playing position.
DEFLECTOR
BRACKET
ANTI-ROTATION TAB
Page 2

ll, Installing the Ramp Cover Support
L. Place the playfield in a position that is convenient for access to the rear section of the game.
2. Remove the 8-32 nut on top of the electric gate cover and set it aside. Leave the #8 washer in place.
3. Attach the L/4" hex spacer onto the threaded stud that protrudes through the electric gate cover. push up on
the gate magnet to ensure that the magnet is properly seated into its mounting bracket.
NUT (FROM ELECTRTC
GATE ASSEMBLY)
WASHER
HEX SPACER M/F
1t4' X 1-1t2"
Page 3

Remove the two 6-32 x I/4" screws & washers that hold the cat billboard assem bly onto the left metal ramp. Set
the washers aside and discard the screws.
Place the ramp cover support under the cat billboard assembly. Attach both plastic parts to the left metal ramp
with the two 6-32x3/8" screws & washers.
Move the ramp cover support so that the mounting hole sits on the thread of the 1/4" hex spacer. Reinstall the
8-32 hex nut with the additional #8 washer.
6-32 X 3/8" SCRE
RAMP COVER SUPPORT
Bill of Materials
A
5.
6.
Line
1
2
3
4
5
atv
7
2
I
t
L
PA
54s-9971-00
232-s201-O0
254-5063-24
242-5005-00
535-1646-00
Title
RAMP COVER SUPPORT
scREW, 6-32 X 3/8" PPH SEMS
HEX SPACER MlF U4" X 1-112" 8-32 THREAD
#8 WASHER
BALL DEFLECIOR BRACKET
Page 4
