Stern Pinball 500-55L5-01 User manual

Games congured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe, UK, Australia).
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to certain visual images, in-
cluding ashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that can cause “photosensitive epileptic seizures”
due to certain visual images, ashing lights or patterns. Symptoms can include lightheadedness, altered vision, eye or face twitching, jerking or shaking of arms or legs,
disorientation, confusion, momentary loss of awareness, and loss of consciousness or convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
1-800-KICKERS - [email protected]
www.sternpinball.com - facebook.com/sternpinball
MANUAL #780-50L5-00
GUARDIANS OF THE GALAXY PRO #500-55L5-01
© MARVEL
Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA. Stern Pinball has inspected each game element to ensure it meets our quality standards.
Each pinball machine has unique characteristics that make it a one-of-a-kind American made product. Each will have variations in appearance resulting from differences
in the machine’s particular wood parts, individual printed art and mechanical assemblies. No playeld is perfectly at and varies depending on the season. Game play will
result in playeld dimpling as the harder steel ball contacts the wood and coating; over time multiple dimples will blend to make them less noticeable. Normal plastic insert
crazing (tiny stress cracks) and ghosting (small cloudy areas around insert edges) are often seen in pinball machines, due to a combination of plastic mold stress, pushing of
inserts into purposely undersized holes, and heating and breaking of inserts’ plastic “skin” when the playeld eld is sanded.
GUARDIANS OF
THE GALAXY
SERVICE AND OPERATION MANUAL
ATTENTION! IMPORTANT WARRANTY INFORMATION
The electronics system, node network architecture, mechanical devices and associated software control systems in this pinball machine are designed to work with genuine
Stern Pinball accessories and devices.
Installation of non-authorized accessories, lamps, LED’s, motors or other devices or modication of electro-mechanical devices may damage the system and will void your
warranty.

2
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
TABLE OF CONTENTS
1. Setup and Moving .................................. 3
1.1 First-Time Setup Instructions ............................... 3
1.2 Adjustments Menu ............................................... 6
1.3 Transporting the Game ........................................ 7
1.4 Maintenance ........................................................ 8
1.5 Maintenance Kits ................................................. 8
1.6 Common Parts ..................................................... 8
2. SPIKE System and Node Guide ............ 9
2.1 SPIKE System Overview ...................................... 9
2.2 Node Bus Cabling ................................................ 9
2.3 System Power ...................................................... 9
2.4 SPIKE Node addresses ........................................ 9
2.5 SPIKE Node Programming................................. 10
2.6 SPIKE System Terminology ............................... 10
2.7 Common SPIKE Node Boards ........................... 10
3. Light, Switch, and Driver Reference... 11
3.1 SPIKE Node Boards ........................................... 11
3.2 Driver Reference ................................................ 12
3.3 Switch Reference ............................................... 14
3.4 Light Reference .................................................. 18
3.5 Motor Reference ................................................ 23
4. Electronic Pinouts and Schematics.... 24
4.1 SPIKE-2 CPU Node 0 ........................................ 24
4.2 Cabinet Node 1 .................................................. 26
4.3 Lower Playeld 48V Driver Pinout Node 8 ......... 27
4.4 Mid Upper Playeld 48V Driver Pinout Node 9 . . 28
4.5 Lower LED Board 8b .......................................... 29
4.6 Right Lower LED Board 8c ................................ 29
4.7 Right Upper LED Board 8d ................................ 30
4.8 Serial Motor Driver Board 8e ............................. 30
4.9 Center Upper LED Board 9a .............................. 31
4.10 Left Upper LED Board 9b .................................. 31
4.11 LED Board 9c ..................................................... 32
4.12 Trough Serial Opto Receiver Extension 8a ........ 32
4.13 Main Power Supply ............................................ 33
4.14 Trough Serial Opto Emitter ................................. 33
4.15 Trough Serial Opto Receiver .............................. 33
4.16 Power Distribution Board ................................... 34
4.17 Power Plug Wiring.............................................. 34
5. Parts Reference.................................... 35
5.1 Playeld Rubber Parts ....................................... 35
5.2 Rubber Size Chart .............................................. 35
5.3 Playeld Assemblies, Top .................................. 36
5.4 Playeld Assemblies, Bottom ............................ 37
5.5 Backbox Parts.................................................... 38
5.6 Speaker Panel Parts .......................................... 38
5.7 Cabinet Parts ..................................................... 39
5.8 Ball Shooter Assembly ....................................... 40
5.9 Auto Launch Assembly ...................................... 40
5.10 Ball Trough Assembly......................................... 41
5.11 Slingshot Assembly............................................ 41
5.12 Flipper Assembly, Left ........................................ 42
5.13 Flipper Assembly, Right ..................................... 42
5.14 Pop Bumper Assembly ...................................... 43
5.15 1-Bank Drop Target Assembly ........................... 44
5.16 Rocket Raccoon Assembly ................................ 44
5.17 Dual Target Assembly ........................................ 44
5.18 Orb Assembly .................................................... 45
5.19 Kicker Assembly ................................................ 45
5.20 Eject VUK ........................................................... 46
5.21 Left Ramp Assembly .......................................... 46
5.22 Right Ramp Assembly ....................................... 46
5.23 Left Ramp Entrance Assembly .......................... 47
5.24 Left Ramp Exit Assembly ................................... 47
5.25 Right Ramp Entrance Assembly ........................ 48
5.26 Right Ramp Exit Assembly ................................ 48
5.27 Ball Guide #2 & Opto ......................................... 49
5.28 Ball Guide #3 & Opto ......................................... 49
5.29 Ball Guide #7 & Opto ......................................... 49
5.30 Ball Guide #8 & Opto ......................................... 49
5.31 Groot Jaw & Bracket .......................................... 50
5.32 Groot Jaw Motor & Switches ............................. 50
5.33 Groot Jaw Lift..................................................... 50
5.34 4-Ball Trough ...................................................... 51
5.35 Back Panel Assembly ........................................ 51
6. Specications ....................................... 52
6.1 Game Dimensions .............................................. 52
6.2 Warranty ............................................................. 53
6.3 Warnings, Compliance, and Legal Notices ........ 53

1. SETUP AND MOVING
2
2
557
7
1
9
8
11
15
11
8
6
14
14
SETUP AND MOVING
3
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
1.1 FIRST-TIME
SETUP INSTRUCTIONS
CAUTION: AT LEAST TWO (2)
PEOPLE ARE REQUIRED TO
MOVE AND MANEUVER THE
GAME. USE PROPER MOVING
EQUIPMENT AND EXTREME
CARE WHILE HANDLING. STERN
PINBALL MACHINES WEIGH
OVER 250LBS BOXED.
TOOLS REQUIRED
• 5/8” Socket Wrench
• Utility Knife
• Snips
• An Assistant
Your brand new Stern Pinball Machine is
carefully packed for safety and security.
For your safety, exercise caution and use
the correct tools and sufcient help when
setting up your new game.
1. Locate the side labeled “TRUCK
THIS SIDE ONLY”. The bottom of
the game faces this side.
2. Open the top box aps by pulling
hard in an upward motion on each
ap. If the aps are taped, cut the
tape rst, taking care to avoid the
box staples.
3. Remove the four (4) foam pieces
and two (2) narrow box tubes
which contain the four (4) identical
legs with levelers.
4. DO NOT CUT STRAPPING YET.
Keep backbox secured in the
down position.
5. With the utility knife, carefully cut
down the left and right corners of
the box.
6. Let the face fall forward and
remove the entire side by carefully
cutting the bottom.
7. With the game still in its folded po-
sition, use a ⅝” wrench to loosen
and remove the 2 leg bolts on each
side of the front cabinet. Ensure
the leg levelers are screwed all the
way into the legs.
8. Install front legs using the bolts
removed from the cabinet. Secure
tightly.
9. Have someone help you carefully
set the game down on the front
legs.
10. Set aside the open box.
11. With a ⅝” socket wrench, loosen
and remove the 2 leg bolts on
each side of the rear cabinet, 4
total.
12. Using supports or two people,
prop the rear of the cabinet up.
13. Ensure the rear leg levelers are
screwed all the way into the legs.
14. Install rear legs using the 4 bolts
removed from step 11.

19
21
17
25
26
27
FIRST-TIME SETUP CONTINUED
27
4
SETUP AND MOVING
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
15. Cut nylon strapping and remove
protective strap corner guards.
16. Locate the factory keys, either on
the shooter rod or taped to the
playeld glass.
17. Using snips, cut the tie-wrap secur-
ing the keys if required. One set of
keys is for the front coin door, the
other set of keys is for accessing
components in the backbox.
18. Open the front coin door.
19. Reach into the game and remove
the retaining clip at the rear of the
cash box.
20. Remove the cash box lid by sliding
it toward you.
21. Store the backbox keys, if desired,
on the metal hook located in the
coin door.
22. Locate and remove the pinballs,
plumb bob, and backbox bolts
from the cash box.
23. Replace the cash box lid and
retaining clip for future use.
24. Locate the two (2) backbox bolts in
the cash box.
25. Carefully raise backbox to upright
position while ensuring that cables
are not pinched.
26. Use the ⅝” wrench to Install the
two (2) backbox bolts to secure the
backbox as indicated on the back
of the cabinet.
27. Reach inside the cabinet and lift
the two latches located on either
side of the coin door.
28. Remove the front top molding.
29. Remove the playeld glass by
sliding it toward you and carefully
place it in a safe location.
Remove all playeld shipping
tie downs, shipping blocks, and
packing foam, and follow any
game-specic unpacking instruc-
tions included in the playeld, if
present.
CAUTION: PLAYFIELD GLASS IS MADE FROM HIGH-STRENGTH TEMPERED
GLASS. TEMPERED GLASS IS SENSITIVE TO EXTREME TEMPERATURE SHIFTS
AND CORNER NICKS, WHICH CAN CAUSE THE GLASS TO FAIL CATASTROPHI-
CALLY. TAKE CARE TO STORE THE GLASS ON A SOFT, ROOM-TEMPERATURE
SURFACE AND PREVENT THE CORNERS FROM BEING DAMAGED.

SETUP AND MOVING
5
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
30. If pinballs were already installed into the lower ball
trough, remove them before lifting the playeld.
31. Grasp the lower arch between the ippers, and rmly
but gently pull directly up to raise the playeld 8 to 12
inches.
32. While holding the playeld up, pull the playeld toward
you until the two playeld supports are over the front
edge of the cabinet.
33. Rest the playeld on the front edge of the cabinet.
34. Raise the playeld and rest it against the backbox.
35. Visually inspect all cabinet cables and connector termi-
nations; ensure no wires or cables are pinched and that
cable harnesses are not pulled tight.
36. Locate the plumb bob in the parts bag in the cash box.
37. Slide plumb bob onto the hanger wire. Note: the vertical
position of the plumb bob affects tilt sensitivity - higher
makes the game more sensitive to tilting.
38. Tighten the thumb screw nger-tight.
39. Install the correct number of pinballs. Refer to the decal
on the lock down assembly for the correct number of
pinballs.
LOCATING, LEVELING, AND FINAL SETUP
1. Select a location that is indoors, out of direct sunlight,
and climate controlled. Excessive moisture/humidity
can cause long-term damage to your game.
2. Adjust the front or rear levelers as necessary to position
the playeld level bubble, located on the front right of
the playeld next to the shooter lane, to oat between
the two (2) black lines. This will place the playeld at the
recommended 6.5° pitch. Playeld angles greater than
6.5° can be achieved by turning out the rear leg level-
er(s) for increased difculty and faster gameplay.
3. Use a pinball to roll down the center of the playeld for
side-to-side leveling, or use an external bubble level,
digital level, or smartphone level app.
4. Plug into a grounded outlet and check for proper opera-
tion through DIAGNOSTICS.
5. Check the coin door: With the door closed, insert coins
to verify proper operation.
6. Play game: Check for satisfactory operation and adjust
game volume (push the Red Buttons inside the Coin
Door).
7. If desired, perform any game diagnostics, game adjust-
ments, and pricing settings at this time.
FIRST-TIME SETUP CONTINUED
SPIKE PINBALL SOFTWARE
UPDATE INSTRUCTIONS
1. Obtain game software update le (lename ends
in “.spk”) from www.sternpinball.com or from
authorized Stern distributor.
2. Place game software update le ( “.spk”) in root
directory of a blank FAT32-formatted USB ash
drive
3. Use backbox power switch to turn off game
4. Plug in USB ash drive to CPU board USB
connector (CN20 or CN21). Refer to www.
sternpinball.com
5. Turn on game
6. The game will automatically begin software
update
7. Select the correct .spk update le from list.
8. Press Enter on the service switches to start
update
9. When the display indicates “Update Complete”,
turn off game
10. Remove USB ash drive from CPU board
11. Turn game on to complete the update and play
pinball!
12. Detailed instructions and troubleshooting tips
are available in the game manual, www.sternpin-
ball.com and authorized Stern distributors.

6
SETUP AND MOVING
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
1.2 ADJUSTMENTS MENU
STANDARD ADJUSTMENTS
Perform the below steps to review the adjustments.
Enter the Service Menu, then enter the Standard Adjustments
Menu.
Press SELECT. Press BACK to exit or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the S.P.I. icon. Press SELECT.
STANDARD ADJUSTMENT #1 appears with the adjustment
name ashing. While the adjustment name is ashing press [<]
[>] to move between adjustments.
To change the adjustment setting press SELECT. While the
adjustment setting is ashing, press [<] [>] repeatedly until
the desired setting appears. Press the SELECT button to
“install” the change. The adjustment comment (bottom line) will
indicate if the factory default setting is selected or will display
INSTALLED if the change is not a factory default setting.
ID Adjustment Name Default Setting
1 REPLAY TYPE AUTO
2REPLAY PERCENTAGE 10%
3REPLAY AWARD CREDIT
4 REPLAY LEVELS 1
5 AUTO REPLAY START 20,000,000
6 DYNAMIC REPLAY START 60,000,000
7REPLAY LEVEL #1 15,000,000
8REPLAY LEVEL #2 30,000,000
9REPLAY LEVEL #3 45,000,000
10 REPLAY LEVEL #4 60,000,000
11 REPLAY BOOST YES
12 SPECIAL LIMIT 1
13 SPECIAL PERCENTAGE 10%
14 SPECIAL AWARD CREDIT
15 FREE GAME LIMIT 5
16 EXTRA BALL LIMIT 5
17 EXTRA BALL PERCENTAGE 25%
18 GAME PRICING USA 11
19 MATCH PERCENTAGE 9%
20 MATCH AWARD CREDIT
21 BALLS PER GAME 3
22 TILT WARNINGS 2
23 CREDIT LIMIT 30
24 ALLOW HIGH SCORES YES
25 HIGH SCORE AWARD CREDIT
26 GRAND CHAMPION AWARDS 1
27 HIGH SCORE #1 AWARDS 1
28 HIGH SCORE #2 AWARDS 0
29 HIGH SCORE #3 AWARDS 0
30 HIGH SCORE #4 AWARDS 0
31 GRAND CHAMPION SCORE 75,000,000
32 HIGH SCORE #1 55,000,000
33 HIGH SCORE #2 40,000,000
ID Adjustment Name Default Setting
34 HIGH SCORE #3 30,000,000
35 HIGH SCORE #4 25,000,000
36 HSTD INITIALS 3 INITIALS
37 HSTD RESET COUNT 2000
38 FREE PLAY NO
39 LANGUAGE ENGLISH
40 PLAYER LANGUAGE SELECT YES
41 CUSTOM MESSAGE ON
42 FLASH LAMP POWER NORMAL
43 COIL PUSLE POWER NORMAL
44 KNOCKER VOLUME NORMAL
45 GAME RESTART YES
46 BILL VALIDATOR NO
47 MUSIC VOLUME 1
48 BALL SAVE TIME 0:05
49 TIMED PLUNGER OFF
50 FLIPPER BALL LAUNCH OFF
51 COINDOOR BALL SAVER NO
52 COMPETITION MODE NO
53 CONSOLATION BALL YES
54 FAST BOOT YES
55 Q24 OPTION COIN METER
56 TICKET DISPENSER NO
57 PLAYER COMPETITION YES
58 TEAM SCORES NO
59 LOCATION ID 0
60 GAME ID 0
61 TIME FORMAT 12-HOUR
62 COIN INPUT DELAY 30
63 LOST BALL RECOVERY YES
64 COIN DOOR DISABLE TILT NO
65 BACKBOX BRIGHTNESS 100%
66 COIN DOOR OPEN B.BOX BRIGHTNESS 10%
FEATURE ADJUSTMENTS
Each table has feature adjustments specic to the
characteristics of that game. To access feature adjustments
enter the Service Menu and then enter the Adjustments Menu.
Press SELECT to access the Service Menu. Press BACK to exit
or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the game icon. Press SELECT.
FEATURE ADJUSTMENT #1 appears with the adjustment name
ashing. With the adjustment name ashing press [<] [>] to
move between adjustments. Feature adjustments are changed
similarly to standard adjustments using the SELECT button
to choose options and the [<] [>] buttons to cycle through
available settings.

SETUP AND MOVING
7
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
1. SECURE THE BACKBOX
1. Ensure that the pinballs are re-
moved from the playeld, and se-
cure any free-moving mechanisms
that may get damaged in transport
2. Remove the backbox securing
bolts
3. Carefully lower the backbox onto
the side rails. Use a piece of card-
board or suitable padding between
the backbox and the game.
4. Securely strap the back box to the
game
5. The game may be transported with
the legs on. If the legs must be re-
moved, follow the remaining steps.
2. REMOVE THE LEGS AND
STAND UP
1.3 TRANSPORTING THE GAME
2
3
4
6. Remove the legs, rear legs rst. Use
a stool or a friend to support the
rear of the game.
7. Rest the rear of the game on the
ground.
6
CAUTION
NEVER TRANSPORT THE GAME
IN A MOVING VEHICLE WITH THE
BACKBOX RAISED! TWO PEOPLE
ARE REQUIRED TO REMOVE THE
LEGS!
10. Secure all loose parts and trans-
port with a hand truck in the
upright position.
8. Stand the game up on its back.
8
9. Remove the front two legs.
9
When transporting the game, such as in the back of a truck or with a hand truck, the
game’s backbox must be secured to prevent damage to the side rails.
TOOLS REQUIRED
• STRAP (500LB OR GREATER)
• AN ASSISTANT
• HAND TRUCK

8
SETUP AND MOVING
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
1.4 MAINTENANCE
REGULAR MAINTENANCE - (MONTHLY/500
GAMES)
• Remove the playeld glass
• Enter the software diagnostics menu, start lamp test, then
clean and wax the playeld.
• While cleaning the playeld, identify and repair malfunction-
ing lights, loose parts, cracked plastics and worn rubber
parts.
• While in diagnostics, enter the switch test (Select the "SW"
Icon, then "TEST" Icon).
• Use a pinball to actuate all switches and verify the correct
switch registers with the switch test.
• The game will play a sound to conrm the switch.
• Lift the playeld and inspect all assemblies for loose parts,
broken wires or excessive wear. Look at the bottom of the
cabinet for any parts that may have worked loose, then nd
the source.
• Check all coin door mechanisms and bill acceptor (if in-
stalled) for proper operation
• Play the game to ensure all coils and features are working
• Check the playeld to ensure it is level and set to the prop-
er pitch using the bubble level on the right side wood rail.
• Check game audits: Replay % and Ball Time and note
abnormal values which can indicate problems.
• Ensure game volume is set appropriately for the location.
• Clean both sides of the playeld glass and reinstall.
• Check and clean pinballs and replace if excessively worn or
scuffed. Dirty pinballs accelerate game wear.
OVERHAUL MAINTENANCE - (5000 GAMES)
• Verify latest game software is installed
• Check ippers for excessive wear. Excessive ipper sloppi-
ness (vertical or horizontal) or weakness indicates a ipper
rebuild is required.
• Clean machine inside and out and check leg levelers for
free operation.
• Visual check for loose or broken playeld and cabinet parts
and repair as necessary.
• Electrical check: Plug into grounded outlet and check for
proper operation through DIAGNOSTICS.
• Replace worn or dirty rubbers.
• Replace pinballs.
• Check all playeld switches with a pinball.
• Check all settings (refer to manual for factory settings).
• Check coin door: With door closed, insert coins to verify
proper operation.
• Check for proper adjustment of the plumb bob tilt.
• Play game: Check for satisfactory operation.
COMMON PINBALL TOOLS
• Common nut drivers (¼”, 5/16”, 11/32", ⅜”)
• Phillips screwdriver
• Standard Allen wrench/Hex key set
• ⅝” Socket with ratchet
• Adjustable wrench (5/8" & 9/16")
• 6" Torpedo Level (or use a pinball
• Flashlight or headlamp
• Soldering Iron (60w with at tip), lead-free solder
• Wire cutter
• Wire stripper
• Long nose (“needle nose”) pliers
1.5 MAINTENANCE KITS
Description Part Number
Guardians of the Galaxy Maintenance Kit
8 oz pinball playeld wax (Novus # 2) (675-0003-01)
Standard Pinball (260-5000-00)
Cleaning Cloth
All Playeld Rubber Rings
Spare Fuses
502-6002-L5
Guardians of the Galaxy Deluxe Maintenance Kit
All standard kit items, plus:
Flipper rebuild kits, Left and Right (500-6307-10,-00)
502-6003-L5
Guardians of the Galaxy Playeld Plastics Kit 803-5000-L5
Guardians of the Galaxy Playeld Decals Kit 802-5000-L5
Guardians of the Galaxy Backbox Decal Left 820-78L5-01
Guardians of the Galaxy Backbox Decal Right 820-78L5-02
Guardians of the Galaxy Cabinet Decal Left 820-78L5-03
Guardians of the Galaxy Cabinet Decal Right 820-78L5-04
Guardians of the Galaxy Cabinet Decal Front 820-78L5-05
Guardians of the Galaxy Playeld, Bare 830-5100-L5
Guardians of the Galaxy Translite 830-52L5-00
1.6 COMMON PARTS
Description Part Number
8 oz Pinball Playeld wax (Novus # 2) 675-0003-01
Standard Pinball, 1-1/16 in 260-5000-00
Flipper Rebuild Kit Left (Standard) 500-6307-10
Flipper Base Plate Kit Left 515-6617-01
Flipper Rebuild Kit Right 500-6307-00
Flipper Base Plate Kit Right 515-6617-00

SPIKE SYSTEM AND NODE GUIDE
9
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
2. SPIKE SYSTEM AND NODE GUIDE
2.1 SPIKE SYSTEM OVERVIEW
The SPIKE Pinball system is a rugged, distributed, and em-
bedded platform custom-designed for the rigors of the pinball
machine environment. SPIKE takes advantage of modern tech-
nologies to deliver an immersive pinball experience that supports
modern features, reduces cabling, and increases serviceability
and reliability.
A Stern Pinball machine based on the SPIKE system will have at
least two nodes networked together with the SPIKE node bus,
a custom industrial pinball control bus that is designed around
industry standards and optimized for the pinball environment.
The primary CPU node is networked to one or more input/output
nodes over standard Category 5 UTP (unshielded twisted pair)
ethernet cabling.
There are ve primary types of nodes that are found in the game.
• CPU node (Node 0) - The primary node that controls other
nodes in the system. Contains the primary game software
for the system and provides SPIKE node bus power for other
nodes.
• Cabinet 48V node (Node 1) - Specialized node with specic
inputs and outputs for coin doors, tilt mechanisms, and other
bottom-cabinet devices.
• 48V playeld node - Controls high power devices such
as coils and ashers, and also supports a few switch and
low-power outputs. Powered by the system 48V power sup-
ply.
• Light and switch node - High-density switch and low-power
LED outputs, bus-powered from the node bus. These boards
contain as many 32 switch inputs and light outputs.
• Node extensions - These sub-nodes add additional low-pow-
er input and outputs to a specic Power or I/O node and are
connected with simple serial bus.
2.2 NODE BUS CABLING
The SPIKE node bus utilizes standard Ethernet-style RJ45 8-pin
modular jacks, and off-the-shelf Category 5e or better ethernet
cabling. The node bus is electrically different from Ethernet and
does not utilize Ethernet or TCP/IP protocols or signaling stan-
dards. SPIKE nodes are not compatible with standard computer
networking equipment.
CAUTION: Plugging a SPIKE Node or CPU board into a standard
Ethernet port may damage one or both devices and void your
warranty.
2.3 SYSTEM POWER
The SPIKE System is powered from an 48V DC power supply
bus. Each SPIKE node converts this voltage to lower voltages
required by the node and its specic components. A SPIKE 48V
node typically controls high-power outputs such as game coil
mechanisms and high-brightness LEDs. These powered nodes
are supplied directly with 48V system power. SPIKE standard I/O
nodes are low-power nodes that read switch inputs and output to
standard-brightness LEDs. Standard I/O nodes use the node bus
power, which is supplied by the main CPU node over the node
bus modular jack connectors.
2.4 SPIKE NODE ADDRESSES
Each SPIKE node has a unique address ranging from 0 to 15. Not
all addresses are used in all games. Nodes can be of the same
part number, so the address is specied on the DIP switches on
each node. When replacing a node, be certain that the correct
address is set. Nodes can have 3-position and 4-position DIP
switches. Refer to the appropriate table to set the address for
each type of Node. The correct address for a node can be found
in the SPIKE node reference section of the manual or in the game
diagnostic software. Address 0 is reserved for the backbox CPU
node, where the game software resides. Address 1 is reserved for
the cabinet node, located inside the coin door. These two nodes
do not have DIP switches as their address is not congurable.
Address 1 2 3
8OFF OFF OFF
9OFF OFF ON
10 OFF ON OFF
11 OFF ON ON
12 ON OFF OFF
13 ON OFF ON
14 ON ON OFF
15 ON ON ON
SPIKE node addresses for nodes with 3-position DIP switches.
Addresses 0-7 are not used by SPIKE nodes with 3-position DIP
switches.
Address 1 2 3 4
8OFF OFF OFF OFF
9OFF OFF ON OFF
10 OFF ON OFF OFF
11 OFF ON ON OFF
12 ON OFF OFF OFF
13 ON OFF ON OFF
14 ON ON OFF OFF
15 ON ON ON OFF
SPIKE node addresses for nodes with 4-position DIP switches.
Addresses 0-7 are reserved for xed-function nodes and do not
require conguration.

10
SPIKE SYSTEM AND NODE GUIDE
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
SPIKE SYSTEM AND NODE GUIDE CONTINUED
2.5 SPIKE NODE PROGRAMMING
The SPIKE nodes are smart nodes that have on-board pro-
cessors and run embedded code. The nodes are programmed
automatically by the CPU node whenever software updates are
installed to the CPU. When replacing a node, the CPU node will
detect and update the node to the latest software with no user
intervention. Always replace nodes with the power to the game
turned OFF.
2.6 SPIKE SYSTEM TERMINOLOGY
MULTI GENERAL ILLUMINATION LIGHTING
General Illumination Lighting is two or more lights powered by
one control source. These are often a number of LEDs connect-
ed in parallel and the system controls these as one large LED. A
missing LED will not affect these circuits, however a shorted LED
can cause the entire string of LEDs to turn off.
SINGLE LIGHTS
Single lights and LEDs are direct-controlled from SPIKE node
boards. A common power source is grounded by individual
transistors to turn individual LEDs on and off. Groups of LEDs,
usually by node connector, share a common power source, so if
a group of LEDs is out, check the wiring for the power source.
FLASHERS
SPIKE games treat ashers the same as single LEDs that draw
more power. Flashers are controlled from the same circuits that
power regular lights.
DRIVERS
A driver is a circuit that controls a high power-device such as a
coil, magnet, or motor. Each device has a common 48V power
source that is then connected to ground by a dedicated control
transistor. Each driver is protected against shorting, static elec-
tricity, and over-current conditions. Take caution as 48V is always
present on a device even when it is not energized.
OPTOS
Certain types of optical switches (“optos”) require external signal
conditioning. For these optos, they will interface to a SPIKE node
via an opto signal conditioning board. Other optical switches
connect directly to the Spike node board.
System Protections
CAUTION: Unless explicitly directed by an Authorized Stern Re-
pair technician, perform ALL work on your pinball machine with
the power disabled!
INPUT/OUTPUT PROTECTIONS
SPIKE features built-in short-circuit, static electricity, and other
protections to maximize reliability. If an LED, coil or other device
shorts, it will be disabled but will not shut down the entire system
in most circumstances. Groups of LEDs, coils, and switches often
share common power supplies or other circuits, so it is possible
that a bad device will affect the group of related devices and
require removal or repair to x the group. The system diagnostics
will inform the technician of shorted or otherwise malfunctioning
devices whenever possible. While the system is protected against
permanent damage, it is strongly recommended to repair or
replace these bad components as soon as possible to minimize
downtime and maximize game earnings.
2.7 COMMON SPIKE NODE BOARDS
Description Type Part Number
SPIKE CPU Node Node 509-1003-01
Cabinet Node Node 520-6967-72
Playeld 48V Core-Driver Node Node 520-7017-72
Trough Serial Opto Receiver Extension Extension 520-7001-00

LIGHT, SWITCH, AND DRIVER REFERENCE
11
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
3. LIGHT, SWITCH, AND DRIVER REFERENCE
3.1 SPIKE NODE BOARDS
CABINET
CABINET NODE 1
BACKBOX
CPU NODE 0
CN11
CN13
CN5
CN4
CN22
CN4
CN2
CN1
CN1
CN3
CN1
CN2
CN3
CN1
CN2
CN2
CN5 CN1
CN3
CN1
CN1
CN2
755-7512-L5
When replacing node boards,
ensure DIP address switches
are set correctly!
PLAYFIELD REAR
PLAYFIELD FRONT
Node Bus Cable (RJ45)
604-5004-08-XX
Serial Data Cable
036-8054-XX
NODE BOARD ID INSTRUCTION SHEET
NODE 0
NODE 8c
NODE 8a
NODE 8
NODE 9a
NODE 9c
NODE 8e
NODE 8b
NODE 9
NODE 9b
NODE 8d
ID DIP Address Description Location Part Number
Node 0 n/a SPIKE 2 CPU Node Backbox 509-1003-01
Node 1 n/a Cabinet Node Cabinet 520-6967-72
Node 8 OFF-OFF-OFF-OFF Playeld 48V Core-Driver Node Lower Playeld 520-7017-72
8a n/a Trough Serial Opto Receiver Extension Playeld 520-7001-00
8b n/a Lamp Board Playeld 520-7062-00
8c n/a Lamp Board Playeld 520-7061-00
8d n/a Lamp Board Playeld 520-7059-00
8e n/a Serial Motor Driver Board Playeld 520-6996-00
Node 9 OFF-OFF-ON-OFF Playeld 48V Core-Driver Node Playeld 520-7017-72
9a n/a Lamp Board Playeld 520-7057-00
9b n/a Lamp Board Playeld 520-7058-00
9c n/a Lamp Board Playeld 520-7060-00
PRO
ID DIP Address Description Location Part Number
Node 0 n/a SPIKE 2 CPU Node Backbox 509-1003-01
Node 1 n/a Cabinet Node Cabinet 520-6967-72
Node 8 OFF-OFF-OFF-OFF Playeld 48V Core-Driver Node Lower Playeld 520-7017-72
8a n/a Trough Serial Opto Receiver Extension Playeld 520-7001-00
8b n/a Lower LED Board Playeld 520-7062-00
8c n/a Right Lower LED Board Playeld 520-7061-00
8d n/a Right Upper LED Board Playeld 520-7059-00
8e n/a Serial Motor Driver board Playeld 520-6996-00
Node 9 OFF-OFF-ON-OFF Playeld 48V Core-Driver Node Playeld 520-7017-72
9a n/a Center Upper LED Board Playeld 520-7057-00
9b n/a Left Upper LED Board Playeld 520-7058-00
9c n/a LED Board Playeld 520-7060-00

12
SPIKE SYSTEM AND NODE GUIDE
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
3.2 DRIVER REFERENCE
ID Name Node Connector Ret.
Pin
Ret. Wire Voltage V+
Pin
V+ Color Location Type Address Part Number
1 Trough 8CN8 7ORG GRY 48V 1-4 GRY ORG Playeld Coil - 27-1500 8-DR-1 090-5004-ND
2Auto Plunger 8CN8 9ORG WHT 48V 1-4 GRY ORG Playeld Coil - 23-800 8-DR-4 090-5001-ND
3Left Flipper 8CN8 6 ORG YEL 48V 1-4 GRY ORG Playeld Coil - 23-1100 8-DR-5 090-5030-ND
4 Right Flipper 8CN8 5 ORG GRN 48V 1-4 GRY ORG Playeld Coil - 23-1100 8-DR-0 090-5030-ND
5 Left Slingshot 8CN8 11 ORG BLU 48V 1-4 GRY ORG Playeld Coil - 26-1200 8-DR-3 090-5044-ND
6 Right Slingshot 8CN8 10 ORG VIO 48V 1-4 GRY ORG Playeld Coil - 26-1200 8-DR-2 090-5044-ND
7Shaker Motor 1 CN2 1 BLU 48V 5 RED Cabinet Motor 1-DR-0 041-5029-04
8
9Right Scoop 8CN7 2YEL BRN 48V 1 GRY ORG Playeld Coil - 26-1200 8-DR-8 090-5044-ND
10 Center Drop Target-Down 8CN7 4 YEL RED 48V 1 GRY ORG Playeld Coil - 32-1800 8-DR-7 090-5031-00-ND
11 Center Drop Target-Up 8CN7 3YEL BLK 48V 1 GRY ORG Playeld Coil - 25-1240 8-DR-6 090-5034-ND
12
13 Left Pop Bumper 9CN8 10 ORG BLK 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-2 090-5044-ND
14 Right Pop Bumper 9CN8 11 ORG BRN 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-3 090-5044-ND
15 Bottom Pop Bumper 9CN8 9ORG RED 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-4 090-5044-ND
16
17 Orbit Control Gates-L/R 9CN8 5 BLU YEL 48V 1-4 GRY BRN Playeld Coil - 32-1250 9-DR-0 511-7510-02 RT
090-5060-01-ND LT
18
19
20 Groot-Trough Eject 9CN8 7YEL ORG 48V 1-4 GRY BRN Playeld Coil - 23-800 9-DR-1 090-5001-ND
21 Top Magnet 9CN7 3BRN BLK 48V 1 GRY BRN Playeld Coil - 22-650 9-DR-6 511-5065-ND
22
23
24 Kickback 9CN7 2YEL VIO 48V 1 GRY BRN Playeld Coil - 23-800 9-DR-8 090-5001-ND
25
26
27
28
29
30
31
32
33 Coin Meter 1 CN3 2BLK 12V 1 RED Cabinet Digital Out 1-DR-2 500-9946-00
34 Ticket Meter 1 CN4 2BLK 12V 1 RED Cabinet Digital Out 1-DR-3 500-9946-00
35 Ticket Dispenser 1 CN11 312V 1 Cabinet Digital Out 1-DR-4

SPIKE SYSTEM AND NODE GUIDE
13
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
Figure 3.2.1. Playeld driver locations (top view).
DRIVER REFERENCE CONTINUED

14
SPIKE SYSTEM AND NODE GUIDE
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
3.3 SWITCH REFERENCE
Continued on next page...
ID Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
1 Left Outlane 8- CN11 4 LGN RED 11-12 BLK ORG Playeld Rollover 8-SW-17 500-9935-04
2Left Return Lane-Left 8- CN11 5 LGN ORG 11-12 BLK ORG Playeld Rollover 8-SW-18 500-9935-04
3Left Return Lane-Right 8- CN11 8LGN VIO 11-12 BLK ORG Playeld Rollover 8-SW-21 500-9935-04
4
5 Right Return Lane 8- CN11 6 LGN YEL 11-12 BLK ORG Playeld Rollover 8-SW-19 500-9935-03
6 Right Outlane 8- CN11 7LGN BLU 11-12 BLK ORG Playeld Rollover 8-SW-20 500-9935-04
7Left Slingshot 8- CN10 4 GRY BLU 8BLK GRN Playeld Leaf 8-SW-30 180-5231-00
8Right Slingshot 8- CN10 3GRY VIO 8BLK GRN Playeld Leaf 8-SW-29 180-5231-00
9Left Flipper Button 8- CN9 4 GRY BRN 7BLK GRN Cabinet Leaf 8-SW-25 180-5160-01
10 Right Flipper Button 8- CN9 3GRY RED 7BLK GRN Cabinet Leaf 8-SW-24 180-5160-01
11 Left Flipper EOS 8- CN10 6 GRY YEL 9BLK GRN Playeld Leaf 8-SW-16 180-5149-00
12 Right Flipper EOS 8- CN10 5 GRY GRN 9BLK GRN Playeld Leaf 8-SW-31 180-5149-00
13
14
15 Trough 6 8 8a CN14 - -Playeld Opto 8-SW-32 520-5344-00 tx
520-7001-00 rx
16 Trough 5 8 8a CN14 - -Playeld Opto 8-SW-33 520-5344-00 tx
520-7001-00 rx
17 Trough 4 8 8a CN14 - -Playeld Opto 8-SW-34 520-5344-00 tx
520-7001-00 rx
18 Trough 3 8 8a CN14 - -Playeld Opto 8-SW-35 520-5344-00 tx
520-7001-00 rx
19 Trough 2 8 8a CN14 - -Playeld Opto 8-SW-36 520-5344-00 tx
520-7001-00 rx
20 Trough 1 8 8a CN14 - -Playeld Opto 8-SW-37 520-5344-00 tx
520-7001-00 rx
21 Trough Jam 8 8a CN14 - -Playeld Opto 8-SW-38 520-5344-00 tx
520-7001-00 rx
22 Shooter Lane 8- CN10 2GRY WHT 7BLK GRN Playeld Micro 8-SW-28 180-5157-01
23
24
25
26
27
28 Left Lane 9- CN11 2TAN BLK 11/12 BLK BLU Playeld Rollover 9-SW-26 500-9935-04
29 Left Lane Target 9- CN11 3TAN RED 11/12 BLK BLU Playeld Leaf, Target 9-SW-27 515-9783-00-00
30 Guardians Target-Top 9- CN11 7TAN BLU 11/12 BLK BLU Playeld Leaf, Target 9-SW-20 511-9979-00
31 Guardians Target-Bottom 9- CN11 8TAN VIO 11/12 BLK BLU Playeld Leaf, Target 9-SW-21 511-9979-00
32
33
34
35 Left Orbit 9- CN12 2WHT BRN 10 BLK VIO Playeld Rollover 9-SW-8 500-9935-04
36 Kickback Opto 9- CN11 10 TAN WHT 11/12 BLK BLU Playeld Opto 9-SW-23 515-0215-00 tx
515-0215-01 rx
37 Left Ramp Exit 9- CN12 6 WHT GRN 10 BLK VIO Playeld Opto 9-SW-12 515-0215-00 tx
515-0215-01 rx
38
39 Groot Target-Left 9- CN12 4 WHT ORG 10 BLK VIO Playeld Leaf, Target 9-SW-10 515-9785-00-00
40 Groot Target-Right 9- CN12 5 WHT YEL 10 BLK VIO Playeld Leaf, Target 9-SW-11 515-9785-00-00
41 Groot Opto 9- CN13 2PNK BLK 10 BLK GRY Playeld Opto 9-SW-0 515-0215-00 tx
515-0215-01 rx
42 Groot Trough 1 9- CN13 3PNK BRN 10 BLK GRY Playeld Opto 9-SW-1 520-7064-00 rx
520-7065-00 tx

SPIKE SYSTEM AND NODE GUIDE
15
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
SWITCH REFERENCE CONTINUED
Continued on next page...
ID Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
43 Groot Trough 2 9- CN13 4 PNK RED 10 BLK GRY Playeld Opto 9-SW-2 520-7064-00 rx
520-7065-00 tx
44 Groot Trough 3 9- CN13 5 PNK ORG 10 BLK GRY Playeld Opto 9-SW-3 520-7064-00 rx
520-7065-00 tx
45 Groot Trough 4 9- CN13 6 PNK YEL 10 BLK GRY Playeld Opto 9-SW-4 520-7064-00 rx
520-7065-00 tx
46 Groot Motor Away 9- CN13 7PNK GRN 10 BLK GRY Playeld Micro 9-SW-5 180-5119-02
47 Groot Motor Home 9- CN13 8PNK BLU 10 BLK GRY Playeld Micro 9-SW-6 180-5119-02
48
49 Center Drop Target 8- CN12 3WHT RED 10 BLK RED Playeld Opto 8-SW-9 520-5252-01
50 Orb Standup Target 8- CN12 6 WHT GRN 10 BLK RED Playeld Leaf, Target 8-SW-12 515-9783-00-00
51
52
53
54
55 Right Orbit 9- CN12 3WHT RED 10 BLK VIO Playeld Rollover 9-SW-9 500-9935-03
56 Right Ramp Exit 9- CN12 7WHT BLU 10 BLK VIO Playeld Opto 9-SW-13 515-0215-00 tx
515-0215-01 rx
57
58 Left Pop Bumper 9- CN10 2GRY BLK 7/8/9 BLK YEL Playeld Leaf 9-SW-28 180-5232-00
59 Right Pop Bumper 9- CN10 3GRY BRN 7/8/9 BLK YEL Playeld Leaf 9-SW-29 180-5232-00
60 Bottom Pop Bumper 9- CN10 4 GRY RED 7/8/9 BLK YEL Playeld Leaf 9-SW-30 180-5232-00
61
62 Top Lane-Left 9- CN10 5 GRY ORG 7/8/9 BLK YEL Playeld Rollover 9-SW-31 500-9935-04
63 Top Lane-Right 9- CN10 6 GRY YEL 7/8/9 BLK YEL Playeld Rollover 9-SW-16 500-9935-04
64
65 Hadron Enforcer Target 1 9- CN11 4 TAN ORG 11/12 BLK BLU Playeld Leaf, Target 9-SW-17 515-9785-00-00
66 Hadron Enforcer Target 2 9- CN11 5 TAN YEL 11/12 BLK BLU Playeld Leaf, Target 9-SW-18 515-9785-00-00
67 Hadron Enforcer Target 3 9- CN11 6 TAN GRN 11/12 BLK BLU Playeld Leaf, Target 9-SW-19 515-9785-00-00
68 Hadron Enforcer Target 4 8- CN12 8WHT VIO 10 BLK RED Playeld Leaf, Target 8-SW-14 515-9785-00-00
69 Hadron Enforcer Target 5 8- CN12 9WHT GRY 10 BLK RED Playeld Leaf, Target 8-SW-15 515-9785-00-00
70
71 Right Scoop 8- CN12 2WHT BRN 10 BLK RED Playeld Micro 8-SW-8 180-5209-00
72
73
74
75
76
77
78
79
80 Lockdown Button 1 - CN7 8TAN WHT 5 BLK WHT Cabinet Leaf 1-SW-2 180-5218-00
81
82
83
84 Start Button 1 - CN6 10 GRY 5 BLK WHT Cabinet Micro 1-SW-11 180-5174-00
85 Tournament Start Button 1 - CN6 9GRY WHT 5 BLK WHT Cabinet Micro 1-SW-12 180-5174-00
86
87
88
89
90 Left Coin 1 - CN5 9PNK BRN 3BLK Cabinet Micro 1-SW-16

16
SPIKE SYSTEM AND NODE GUIDE
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
SWITCH REFERENCE CONTINUED
Continued on next page...
Figure 3.3.1. Playeld switch locations (top view).

SPIKE SYSTEM AND NODE GUIDE
17
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
SWITCH REFERENCE CONTINUED
ID Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
91 Right Coin 1 - CN5 7PNK ORG 3BLK Cabinet Micro 1-SW-18
92 Center Coin 1 - CN5 8PNK RED 3BLK Cabinet Micro 1-SW-17
93 Fourth Coin 1 - CN5 6 -Cabinet - 1-SW-19
94 Fifth Coin 1 - CN5 5 -Cabinet - 1-SW-20
95 Tilt Pendulum 1 - CN6 7WHT 5 BLK WHT Cabinet Plumb Bob 1-SW-14 516-0007-00
96 Sixth Coin 1 - CN9 5 -Cabinet - 1-SW-21
97 Ticket Notch 1 - CN11 5 -Cabinet - 1-SW-8
98 Slam Tilt 1 - CN5 4 LGN RED 3BLK Cabinet - 1-SW-22
99
100
C1 DIP 1 0 - - - -CPU Node 0-SW-0 -
C10 Service Plus 0 - CN25 3LGN VIO 6 BLK Coin Door 0-SW-9 180-5192-02
C11 Service Minus 0 - CN25 2LGN BLU 6 BLK Coin Door 0-SW-10 180-5192-02
C12 Service Back 0 - CN25 1 LGN BLK 6 BLK Coin Door 0-SW-11 180-5192-00
C24 DC Sense 0 - CN7 4 GRY RED 1 BLK - 0-SW-23 -
C17 Headphone Detect 0 - - - - - - Coin Door 0-SW-16 -
C18 Headphone Kit Cable
Detect
0 - CN3 5 BLK 4 BLK CPU Node 0-SW-17 -
C19 Volume Encoder 1 0 - CN3 6 WHT 1 DRAIN CPU Node 0-SW-18 -
C20 Volume Encoder 2 0 - CN3 7GRN 1 DRAIN CPU Node 0-SW-19 -
C2 DIP 2 0 - - - -CPU Node 0-SW-1 -
C3 DIP 3 0 - - - -CPU Node 0-SW-2 -
C4 DIP 4 0 - - - -CPU Node 0-SW-3 -
C5 DIP 5 0 - - - -CPU Node 0-SW-4 -
C6 DIP 6 0 - - - -CPU Node 0-SW-5 -
C7 DIP 7 0 - - - -CPU Node 0-SW-6 -
C8 DIP 8 0 - - - -CPU Node 0-SW-7 -
C9 Service Select 0 - CN25 4 LGN GRY 6 BLK Coin Door 0-SW-8 180-5192-04

18
SPIKE SYSTEM AND NODE GUIDE
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
3.4 LIGHT REFERENCE
Continued on next page...
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src. Wire Location Type Light
Color
Address Part Number
1 Coin Enable 1 - CN8 6 BLK GRY 2GRY RED Coin Door Digital Out 1-LP-0
2Start Button 1 - CN6 3YEL BRN 1 RED Cabinet Feature White 1-LP-2 112-5033-08
3Tournament Start 1 - CN6 2YEL RED 1 RED Cabinet Feature White 1-LP-3 112-5033-08
4 Lockdown Button-RED 1 - CN7 2RED WHT 1 RED Cabinet Feature RGB 1-LP-5 520-5333-00
5 Lockdown Button-GRN 1 - CN7 3GRN WHT 1 RED Cabinet Feature RGB 1-LP-4 520-5333-00
6 Lockdown Button-BLU 1 - CN7 4 BLU WHT 1 RED Cabinet Feature RGB 1-LP-7 520-5333-00
7
8
9
10
11 Left Outlane 9 c CN3 6 BLU GRY 1 RED Playeld Feature White 9-LP-51 520-5307-00
12 Left Return Lane-Left 9 c CN3 5 BLU VIO 1 RED Playeld Feature White 9-LP-52 520-5307-00
13 Left Return Lane-Right 9 c CN3 4 BLU GRN 1 RED Playeld Feature White 9-LP-53 520-5307-00
14 Antiquities Shop 8b - LED13 - - - Playeld Feature White 8-LP-20 520-7062-00
15 Pod Chase 8b - LED14 - - - Playeld Feature White 8-LP-21 520-7062-00
16 Sanctuary 8b - LED16 - - - Playeld Feature White 8-LP-23 520-7062-00
17 Yaka Arrow 8b - LED9 - - - Playeld Feature White 8-LP-16 520-7062-00
18 Sibling Rivalry 8b - LED12 - - - Playeld Feature White 8-LP-19 520-7062-00
19 Escape Kyln 8b - LED11 - - - Playeld Feature White 8-LP-18 520-7062-00
20 Knowhere 8b - LED10 - - - Playeld Feature White 8-LP-17 520-7062-00
21 Quills Quest 8b - LED8 - - - Playeld Feature White 8-LP-15 520-7062-00
22 Immolation Initiative 8b - LED15 - - - Playeld Feature White 8-LP-22 520-7062-00
23 Orb Multiball-Bottom 8b - LED2 - - - Playeld Feature White 8-LP-9 520-7062-00
24 Save Xandar 8b - LED3 - - - Playeld Feature White 8-LP-10 520-7062-00
25 Groot Multiball-Bottom 8b - LED6 - - - Playeld Feature White 8-LP-13 520-7062-00
26 Shoot Again (x2) 8b CN4 4 ORG YEL 1 RED Playeld Feature White 8-LP-11 520-5307-00
27 Right Return Lane 8 c CN3 2GRN VIO 1 RED Playeld Feature White 8-LP-24 520-5307-00
28 Right Outlane 8 c CN3 3GRN GRY 1 RED Playeld Feature White 8-LP-31 520-5307-00
29
30
31
32
33
34
35 Left Lane Arrow-RED 9 c - LED9 - - - Playeld Feature RGB 9-LP-57 520-7060-00
36 Left Lane Arrow-GRN 9 c - LED9 - - - Playeld Feature RGB 9-LP-58 520-7060-00
37 Left Lane Arrow-BLU 9 c - LED9 - - - Playeld Feature RGB 9-LP-59 520-7060-00
38 Left Lane X 9 c - LED13 - - - Playeld Feature White 9-LP-63 520-7060-00
39 Left Lane Rectangle 9 c - LED14 - - - Playeld Feature White 9-LP-56 520-7060-00
40
41 Guardians-Left 9b - LED4 - - - Playeld Feature White 9-LP-37 520-7058-00
42 Guardians-Center 9b - LED5 - - - Playeld Feature White 9-LP-38 520-7058-00
43 Guardians-Right 9b - LED6 - - - Playeld Feature White 9-LP-39 520-7058-00
44
45
46
47
48
49
50 Left Orbit Arrow-RED 9b - LED2 - - - Playeld Feature RGB 9-LP-33 520-7058-00
51 Left Orbit Arrow-GRN 9b - LED2 - - - Playeld Feature RGB 9-LP-34 520-7058-00

SPIKE SYSTEM AND NODE GUIDE
19
© MARVEL GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01
MARVEL.COM
LIGHT REFERENCE CONTINUED
Continued on next page...
Figure 3.4.1. Playeld light locations (top view).

20
SPIKE SYSTEM AND NODE GUIDE
GUARDIANS OF THE GALAXY PRO MANUAL 500-55L5-01 © MARVEL
MARVEL.COM
LIGHT REFERENCE CONTINUED
Continued on next page...
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src. Wire Location Type Light
Color
Address Part Number
52 Left Orbit Arrow-BLU 9b - LED2 - - - Playeld Feature RGB 9-LP-35 520-7058-00
53 Left Orbit X 9b - LED3 - - - Playeld Feature White 9-LP-36 520-7058-00
54 Left Orbit Rectangle 9b - LED1 - - - Playeld Feature White 9-LP-32 520-7058-00
55
56 Rocket Arrow-RED 9b - LED10 - - - Playeld Feature RGB 9-LP-43 520-7058-00
57 Rocket Arrow-GRN 9b - LED10 - - - Playeld Feature RGB 9-LP-44 520-7058-00
58 Rocket Arrow-BLU 9b - LED10 - - - Playeld Feature RGB 9-LP-45 520-7058-00
59 Rocket X 9b - LED9 - - - Playeld Feature White 9-LP-42 520-7058-00
60 Rocket Rectangle 9b - LED7 - - - Playeld Feature White 9-LP-40 520-7058-00
61 Rocket Multiball 9b - LED12 - - - Playeld Feature White 9-LP-47 520-7058-00
62
63 Left Ramp Arrow-RED 9 a - LED11 - - - Playeld Feature RGB 9-LP-21 520-7057-00
64 Left Ramp Arrow-GRN 9 a - LED11 - - - Playeld Feature RGB 9-LP-22 520-7057-00
65 Left Ramp Arrow-BLU 9 a - LED11 - - - Playeld Feature RGB 9-LP-23 520-7057-00
66 Left Ramp X 9 a - LED13 - - - Playeld Feature White 9-LP-24 520-7057-00
67 Left Ramp Rectangle 9 a - LED14 - - - Playeld Feature White 9-LP-25 520-7057-00
68
69 Groot Target-Left 9 a - LED12 - - - Playeld Feature White 9-LP-20 520-7057-00
70 Groot Target-Right 9 a - LED1 - - - Playeld Feature White 9-LP-8 520-7057-00
71 Groot Multiball 9 a - LED9 - - - Playeld Feature White 9-LP-16 520-7057-00
72 Groot Arrow-RED 9 a - LED10 - - - Playeld Feature RGB 9-LP-17 520-7057-00
73 Groot Arrow-GRN 9 a - LED10 - - - Playeld Feature RGB 9-LP-18 520-7057-00
74 Groot Arrow-BLU 9 a - LED10 - - - Playeld Feature RGB 9-LP-19 520-7057-00
75 Groot X 9 a - LED20 - - - Playeld Feature White 9-LP-31 520-7057-00
76 Groot Rectangle 9 a - LED19 - - - Playeld Feature White 9-LP-30 520-7057-00
77
78
79
80
81 Lock 1 9 a - LED15 - - - Playeld Feature White 9-LP-26 520-7057-00
82 Lock 2 9 a - LED16 - - - Playeld Feature White 9-LP-27 520-7057-00
83 Lock 3 9 a - LED17 - - - Playeld Feature White 9-LP-28 520-7057-00
84 Lock 4 9 a - LED18 - - - Playeld Feature White 9-LP-29 520-7057-00
85
86 Orb Arrow-RED 8d - LED10 - - - Playeld Feature RGB 8-LP-45 520-7059-00
87 Orb Arrow-GRN 8d - LED10 - - - Playeld Feature RGB 8-LP-46 520-7059-00
88 Orb Arrow-BLU 8d - LED10 - - - Playeld Feature RGB 8-LP-47 520-7059-00
89 Orb X 8d - LED14 - - - Playeld Feature White 8-LP-51 520-7059-00
90 Orb Rectangle 8d - LED12 - - - Playeld Feature White 8-LP-49 520-7059-00
91 Orb Multiball 8d - LED11 - - - Playeld Feature White 8-LP-48 520-7059-00
92
93 Right Ramp Arrow-RED 8d - LED9 - - - Playeld Feature RGB 8-LP-42 520-7059-00
94 Right Ramp Arrow-GRN 8d - LED9 - - - Playeld Feature RGB 8-LP-43 520-7059-00
95 Right Ramp Arrow-BLU 8d - LED9 - - - Playeld Feature RGB 8-LP-44 520-7059-00
96 Right Ramp X 8d - LED15 - - - Playeld Feature White 8-LP-52 520-7059-00
97 Right Ramp Rectangle 8d - LED13 - - - Playeld Feature White 8-LP-50 520-7059-00
98
99 Right Orbit Arrow-RED 8d - LED6 - - - Playeld Feature RGB 8-LP-37 520-7059-00
100 Right Orbit Arrow-GRN 8d - LED6 - - - Playeld Feature RGB 8-LP-38 520-7059-00
101 Right Orbit Arrow-BLU 8d - LED6 - - - Playeld Feature RGB 8-LP-39 520-7059-00
102 Right Orbit X 8d - LED1 - - - Playeld Feature White 8-LP-32 520-7059-00
