Stirling IA0978 User manual

Backpack Vacuum Cleaner
Model Number: IA0978
INSTRUCTION MANUAL
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016

02
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Welcome
Congratulations on choosing to buy a Stirling® product.
All products brought to you by Stirling® are manufactured to the highest standards of performance
and safety and, as part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.

AFTER SALES SUPPORT
1300 777 137 03
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Contents
02 Welcome
04 Warranty Details
05 General Information and Safety Instructions
08 Product Overview
09 Getting Started
10 Instructions
15 Other Useful Information
18 FAQ
20 Repair and Refurbished Goods or Parts Notice

04
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Backpack Vacuum Cleaner
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period of 36
months from the date of purchase. Defects that occur within this warranty period, under normal
use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this
warranty are in addition to all rights and remedies in respect of the product that the consumer has
under the Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

AFTER SALES SUPPORT
1300 777 137 05
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
General Information and
Safety Instructions
RETAIN FOR FUTURE USE
Read this manual thoroughly before first use, even if you are familiar with this type of product. The
safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly
adhered to. Please keep this user manual in a safe place along with your purchase receipt and carton
for future reference. If applicable, pass these instructions and packaging on to the next owner of the
appliance. Always follow basic safety precautions and accident prevention measures when using an
electrical product.
This product is intended for indoor domestic use only and not designed for commercial,
trade or outdoor use.
Electrical Safety and Cord Handling
IMPORTANT: Never pull by the cord. To disconnect from the power supply, remove the plug
from the power outlet.
1. Before turning on the Backpack Vacuum Cleaner, ensure the electrical voltage and frequency of
the circuit corresponds to those indicated on the rating label of the product.
2. To protect against fire and electric shock, do not immerse the product, cord set or plug in water
or any other liquids.
3. Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the
cord around sharp edges or corners.
4. Keep cord away from heated surfaces.
5. Do not bend or damage the power cord.
6. Never force the plug into an outlet, or out of an outlet.
7. Always unplug the Backpack Vacuum Cleaner when not in use. The plug must be removed
from the power outlet before cleaning, servicing, maintaining or moving the Backpack Vacuum
Cleaner.
8. To avoid a hazard, do not use the Backpack Vacuum Cleaner if the plug, cord or the Backpack
Vacuum Cleaner itself is damaged. Please contact the After Sales Support line for further
advice.
9. Unless your home is already fitted with a residual current device (safety switch), we recommend
installing an RCD with a rated residual operating current not exceeding 30mA to provide
additional safety protection when using electrical appliances. See your electrician for
professional advice.
10. Do not handle the plug, cord or the Backpack Vacuum Cleaner with wet hands.
11. This Backpack Vacuum Cleaner is equipped with a cord restraint. If the supply cord is damaged
it must be replaced by the manufacturer, it’s service agent or similarly qualified persons in order
to avoid a hazard.
12. Do not use an extension cord unless completely necessary with the Backpack Vacuum Cleaner.
If an extension cord is used, please ensure that it has a rating equal or exceeding the rating of
this product.

06
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
General Information and
Safety Instructions (cont)
Usage Conditions and Restrictions
1. To reduce the risk of electric shock, do not use outdoors or on wet surfaces.
2. Do not use the Backpack Vacuum Cleaner for other than its intended use.
3. The Backpack Vacuum Cleaner is not a toy. Supervise young children to ensure they do not play
with this product.
4. The Backpack Vacuum Cleaner is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience or knowledge, unless they
have been given supervision or instruction concerning use of the product by a person responsible
for their safety.
5. Do not leave the Backpack Vacuum Cleaner unattended when plugged in. Always switch off and
unplug when you are not using the Backpack Vacuum Cleaner.
6. This unit has no user-serviceable parts contained within. Do not attempt to repair, disassemble or
modify the Backpack Vacuum Cleaner.
7. Improper installation or misuse may result in the risk of fire, electric shock or injury to person.
8. The manufacturer is not responsible for any eventual damage caused by improper or faulty use.
9. The use of attachments not sold or recommended by the manufacturer may cause fire, electric
shock or injury.
10. The Backpack Vacuum Cleaner is not intended to be operated by means of an external timer or
any type of separate remote control system.

AFTER SALES SUPPORT
1300 777 137 07
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
General Information and
Safety Instructions (cont)
Handling and Usage
1. Do not use the Backpack Vacuum Cleaner without a dust bag and filters in place.
2. Before you commence using the Backpack Vacuum Cleaner, please remove any large or sharp
objects from the floor in order to prevent the Dust Bag being damaged.
3. Do not put any objects into the air ventilation of the Backpack Vacuum Cleaner or operate when
the air ventilations are blocked. Keep the air ventilation free of anything that may reduce the
airflow.
4. Do not operate the Backpack Vacuum Cleaner near heaters, radiators, cigarette butts etc.
5. Do not pick up materials such as plaster dust, wood shavings or other building materials.
6. Do not use to pick up flammable, combustible or toxic materials such as petrol, chlorine, gasoline
or use where they may be present.
7. Do not attempt to remove blockages with sharp objects as this may cause damage to the
Backpack Vacuum Cleaner.
8. Only use the Backpack Vacuum Cleaner on dry, indoor surfaces.
9. Use extra care when using the Backpack Vacuum Cleaner on stairs.
10. Keep hair, loose clothing, fingers and all parts of body away from the openings or moving parts.
11. To reduce the risk of electrocution, never operate this product with wet hands, submerge in water
or spill liquids into the product.
12. Only use attachments and/or replacement parts recommended by the manufacturer.
13. Do not use the Backpack Vacuum Cleaner on any glowing, burning or smoking particles.
14. Do not use the Backpack Vacuum Cleaner near a open window when raining as this may cause a
electric shock.

08
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
1. Canister Lid
2. Canister Lid Tabs
3. Back Board Panel
4. Shoulder Straps
5. Waist Band with Attachment Storage
6. Flexible Hose
7. Telescopic Tube
8. Blower Port
9. Power Cord
Included (not pictured):
Exhaust Filter, Instruction Manual, Quick Start Guide and Warranty Card.
10. Blower Attachments
11. Crevice Tool
12. Upholstery Tool
13. Dusting Brush
14. Carry Handle
15. Hose Inlet
16. Main Unit
17. Shake-Out Bag
18. Exhaust Grill
19. Exhaust Grill Port
20. 5 x Dust Bags
21. Floor-to-Carpet Selector
22. Floor Head
23. HEPA Filter
3
5
49
6
7
8
10 11 12 13
23
16
17
15
14
19
18
20
22
Parts Details
21

AFTER SALES SUPPORT
1300 777 137 09
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Getting Started
Before First Use
Prior to using your Backpack Vacuum Cleaner, please read all the safety and operating instructions
thoroughly. Please ensure you follow the steps below before using this appliance. We recommend
you keep the original packaging for storing your Backpack Vacuum Cleaner when not in use.
1. Unpack the product but keep all packaging material until you have made sure your new Backpack
Vacuum Cleaner is undamaged and in good working order. Plastic wrapping can be a suffocation
hazard for babies and young children, so ensure all packaging materials are out of their reach.
2. Uncoil the cord and straighten it to remove any kinks. Do not use this product if these parts are
damaged. In case of damage, phone the After Sales Support line.
Assembly
WARNING: To reduce the risk of electric shock, the power cord must be disconnected form
power outlet before removing the Flexible Hose (6), Dust Bag (20), Shake-Out Bag (17), changing
the filters or performing maintenance or troubleshooting procedures.
Attaching the Flexible Hose to the Backpack Vacuum Cleaner and Using the Attachments
The Flexible Hose should be connected to the Backpack Vacuum Cleaner before strapping to your body.
1. To connect the Flexible Hose (6) into the Hose Inlet (15), insert the threaded end of the Flexible Hose
into the Hose Inlet and turn right until it locks into place (Fig. 1). To remove the Flexible Hose, unplug the
Power Cord (9) and then turn the hose left.
2. To remove the Telescopic Tube (7) from the Flexible Hose, hold the Flexible Hose handle and pull the
Telescopic Tube to separate.
3. See page 13 for instructions on inserting the Dust Bag correctly.
4. Step on the Floor-to-Carpet Selector (21) to adjust the height of the brushes. There are two different
heights, one for floors and one for carpets.
5. To remove the Telescopic Tube from the Floor Head (22), simply pull the Telescopic Tube out from the
Floor Head.
6. The Backpack Vacuum Cleaner can be adjusted to suit Left or Right-Handed users. Simply change the
direction of the Canister Lid (1) so that the Hose Inlet is on the same side as the dominant hand when
the Backpack Vacuum Cleaner is on (Fig. 2).
Fig. 1
Right-Handed
Placement
Left-Handed
Placement
Fig. 2

10
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Instructions
The Attachments
2 in 1 Floor Head
Floor Head with metal base and Floor-to-Carpet selector. Adjust the height
of the brushes to suit hard surfaces or carpets. To vacuum carpets the
selector on the left side should be vertical as seen in Fig. 3a. To vacuum hard
surfaces the selector on the right side must be vertical as seen Fig. 3b.
Dusting Brush
The Dusting Brush features soft bristles that helps clean furniture,
windowsills, embedded art and blinds (Fig. 4).
Crevice Tool
With its skinny shape and angled tip the Crevice Tool gets into tight spaces,
corners, crevices, around radiators or vents and between sofa cushions (Fig. 5).
Upholstery Tool
The Upholstery Tool contains a wide head and unique surface that makes
it an excellent tool for removing dust, dirt or unwanted pet hair off sofas,
chairs, mattresses and cushions (Fig. 6).
NOTE: This tool is not a grooming tool and should not be used on animals.
WARNING: Please do not use Upholstery Tool on delicate or woven
fabrics that may tear. Do not use the Upholstery Tool on wooden floors as
this may cause mild scratching.
Blower Attachments
The Blower Attachments can be used to inflate air mattresses and other
inflatable items (Fig. 7). There are 3 different sizes to fit different inflatable
items.
The Waist Band
The Waist Band (5) has been designed to carry accessories by placing
attachments into the loops.
Fig. 5
Fig. 6
Fig. 3a
Fig. 3b
Fig. 4
Fig. 7

AFTER SALES SUPPORT
1300 777 137 11
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Instructions (cont)
Manual Suction Control
Your Backpack Vacuum Cleaner also includes a Manual Variable Suction Control on the Flexible Hose
Handle (6). This manually adjusts the suction power through the hose by adjusting the suction regulator to
the desired position between open and closed (Fig. 8).
Using the Blower Attachment
The Blower Attachments (10) can be used to inflate air mattresses and other inflatable items. The Blower
Attachment features air release holes that are designed to help relieve the air pressure to ensure the
attachments does not blow off when in use.
IMPORTANT: Take caution when using this function to blow up inflatable items. Turn the unit on and
hold the Blower Attachment and air valve while the Vacuum Exhaust is pumping air into the inflatable.
IMPORTANT: Do not use Blower Attachment function on fragile or delicate objects unless they are
secured or held firmly in place as the power is quite strong and may cause damage.
To use the Blower Attachment:
1. Lift up and unlock the Exhaust Grill (18) tab and click out the Exhaust Grill
(Fig. 9).
2. Remove the Exhaust Grill and store in a safe and clean place.
3. To insert the Blower Port (8) into the exhaust outlet, align the lower tabs of
the Blower Port with the slots of the exhaust outlet. Push on the top of the
Blower Port and press until it snaps into place.
4. To attach the Flexible Hose (6) to the Blower Port, align the Flexible Hose and
turn right until it locks. The Flexible Hose is now securely in place (Fig. 10).
5. Choose 1 of the 3 Blower Attachments (Fig. 7) that fit the item that needs
inflating. Connect the attachment to the end of the Flexible Hose.
6. To detach the Flexible Hose turn left and pull out from Blower Port. Fig. 10
Fig. 9
Fig. 8

12
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Power Switch
Instructions (cont)
Using the Backpack Vacuum Cleaner
1. Connect the Flexible Hose (6) and Metal Telescope Tube (7) if desired. Choose the correct accessory as
explained on page 10.
2. Loosen the Shoulder Straps (4) on both sides and correctly position onto your shoulders, securing the
straps into a comfortable position.
3. Fasten the Waist Band (5) around your waist so that the Backpack Vacuum Cleaner rests comfortably
on your hips (Fig .11)
CAUTION: If the Waist Band and both Shoulder Straps are not properly and securely in place, the unit
could fall off your back causing damage or injury.
4. Plug the power plug into an electrical outlet.
5. Turn the unit ON/OFF by pressing the switch located near the base of the unit (Fig. 12).
Fig. 11 Fig. 12

AFTER SALES SUPPORT
1300 777 137 13
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Inserting the Dust Bag
NOTE: Do not use the Backpack Vacuum Cleaner unless the HEPA filter (23), Shake-Out Bag (17) and
Dust Bag (20) are correctly in place.
1. Ensure the Power Cord (9) is disconnected from the power outlet, unplug the Flexible Hose (6) from the
Canister Lid (1) by rotating the Flexible Hose to the left and pulling down.
2. To open the Canister Lid, pull out the bottom of the Canister Lid Tabs (2) on each side of the unit,
release from the Canister Lip Clip and lift the Canister Lid (Fig. 13).
3. Flip the Canister Lid upside down and place your finger beneath the tabs on the Dust Bag holder and
flip upwards to lift the Dust Bag (Fig. 14).
4. Holding the Dust Bag (20) in your hand, slide it carefully through the slots of the Dust Bag Holder and
dispose of the Dust Bag (Fig. 14).
5. Insert a new Dust Bag and ensure the cardboard face of the new bag rests securely in the Dust
Bag Cover guides (Fig. 14).
6. Flip the Dust Bag Holder over, pressing the tab of the Dust Bag Holder until it clicks and locks into
place.
7. Remove the Shake-Out Bag from the Canister Lip and shake out any excess dirt in a large bin or
appropriate area. Ensure the Shake-Out Bag is carefully re-inserted in place (Fig. 15).
8. Put the Canister Lid back on the unit with the Flexible Hose positioned on the right or left, as per
your preference.
9. Lift the Canister Lid Tabs up, hook onto the Canister Lip Clip and click towards the body of the unit to
lock into place.
NOTE: There is no Dust Bag full indicator. Change the Dust Bag when the suction performace has
decreased.
Instructions (cont)
Fig. 13 Fig. 14 Fig. 15
Shake-Out Bag
Canister Lip
Tabs

14
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
NOTE: Most major vacuum retailers and hardware stores should sell extra refill dust bags. When
visiting the store, take one of the dust bags with you for reference. If you are having trouble finding
extra dust bags, please contact our After Sales Support line for assistance.
NOTE: Do not overfill or reuse the Dust Bag. Replace when the bag is full.
NOTE: When replacing the Dust Bag, please do so in an outdoor or open area with sufficient
ventilation.
Instructions (cont)

AFTER SALES SUPPORT
1300 777 137 15
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Cleaning the Shake-Out Bag
1. Remove the Shake-Out Bag (17) from the Backpack Vacuum Cleaner Canister (1).
2. While holding the handle at the bottom of the Shake-Out Bag, shake vigorously in an outdoor area over
a garbage receptacle until there is no more dust.
3. Inspect the Shake-Out Bag regularly for tears or damage. If the Shake-Out Bag is damaged please
contact our After Sales Support line.
4. Re-insert the Shake-Out Bag into the canister.
NOTE: If required you are able to hand wash the Shake-Out Bag in lukewarm water. However it is
essential you allow it to completely dry before reusing. Never insert it back into the Backpack Vacuum
Cleaner if it is still wet.
NOTE: If you wish to enquire about spare parts for your Stirling Backpack Vacuum Cleaner please
contact the After Sales Support line on 1300 777 137.
Cleaning the Backpack Vacuum Cleaner
1. Switch off and unplug the Backpack Vacuum Cleaner at the power outlet.
2. If necessary, remove any hair or large pieces of debris from the Dusting Brush (13) and Floor
Brush.
3. If necessary wash the Attachments (see page 10) in warm water with mild detergent. Ensure
Attachments are completely dry before use or storage.
4. Clean the exterior of the Backpack Vacuum Cleaner using a soft damp cloth and dry thoroughly.
Other Useful Information

16
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Cleaning The HEPA Filter
1. It is recommended to clean the HEPA FILTER (23) at least once every 6 months or when the suction of
your Backpack Vacuum Cleaner begins to decrease.
2. Remove the Shake-Out Bag (17) from the Backpack Vacuum Cleaner Canister. The HEPA Filter is
located underneath the Shake-Out Bag.
3. To remove the HEPA Filter, use your thumbs to press away the tab that is used to lock the HEPA Filter
and lift with another finger to unlock the attachment.
4. Tap the HEPA Filter outside in a well ventilated area on a safe surface to remove any residual dust that
has gathered on the HEPA Filter.
5. You can wash the HEPA Filter by running it under cold water and allowing the water to run out the dirt.
6. Let your HEPA filter dry naturally in a leaning position, until it is completely dry. Afterward, carefully
place it back inside your Backpack Vacuum Cleaner and turn it on to test its functionality.
IMPORTANT: Always ensure the HEPA Filter is completely dry before inserting it back into your
Backpack Vacuum Cleaner.
Storage
• Before packing away the Backpack Vacuum Cleaner for storage, ensure it is clean and dry.
• We recommend storing the Backpack Vacuum Cleaner in its original carton to protect it from
dust, with all the parts and accessories.
• Store the Backpack Vacuum Cleaner in a clean and dry place, out of children’s reach.
• Do not place heavy objects on top during storage.
Other Useful Information (cont)

AFTER SALES SUPPORT
1300 777 137 17
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Other Useful Information (cont)
Responsible Disposal
At the end of its working life, do not throw this product out with your household rubbish. Electrical and
electronic products contain substances that can have a detrimental effect on the environment and human
health if disposed of inappropriately. Observe any local regulations regarding the disposal of electrical
consumer goods and dispose of it appropriately for recycling. Contact your local authorities for advice on
recycling facilities in your area.
Please keep the original packaging carton and materials in a safe place. It will help to prevent any damage
if the product needs to be transported in the future. In the event it is to be disposed of, please recycle all
packaging material where possible.
If you require another copy of this instruction manual please contact [email protected] to obtain an
electronic copy.
AS/NZS 60335.1
AS/NZS 60335.2.2
Specification Table
MODEL: IA0978
COLOUR: Blue
VOLTAGE: 220-240V, 50-60Hz Class II
POWER: 1400W
DIMENSIONS: 49 x 32 x 25.5cm
NET WEIGHT: 5.15kg
WARRANTY: 3 Years
LENGTH OF POWER CORD: 10m
Version No: 1.4
Issue Date: October 29th, 2015

18
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
FAQ
Problem Possible Cause Solution
The Backpack Vacuum
Cleaner will not turn on?
• The Backpack Vacuum
Cleaner is not plugged
into the power outlet
correctly.
• Check that the ON/OFF Power
Switch (Fig .11) located at the
base of the unit is switched
on.
• Remove the power plug (9)
and then reinsert into the
power outlet.
The suction performance
of the Backpack Vacuum
Cleaner is declining?
• The Dust Bag (20) is full.
• The Dust Bag and/or
HEPA Filter (23) are not
correctly installed or
assembled.
• There may be a tear in the
Dust Bag.
• There may be a blockage
in the Telescopic Tube
(7), Flexible Hose (6),
Floor Head (22) or the
accessories (11,12,13).
• The HEPA Filter (23) or
Shake-Out Bag (17) are
dirty.
• Replace the Dust Bag (20).
• Ensure the Dust Bag and/
or HEPA Filter are correctly
inserted. Please see page 13.
• Replace with a new Dust Bag,
and dispose of the damaged
Dust Bag.
• Visually inspect the Telescopic
Tube, Flexible Hose, Floor
Head and accessories for
large items that may have
been sucked in. Do not
use sharp tools to remove
blockages.
• Clean the HEPA Filter or
replace the Shake-Out Bag.
For detailed instructions
please see page 15 and 16.
The Backpack Vacuum
Cleaner makes an
abnormal sound when
switched on?
• There may be blockages
within the Backpack
Vacuum Cleaner.
• Check the Backpack Vacuum
Cleaner (including the
Telescopic Tube & Flexible
Hose) to ensure there are no
blockages.
• Please clear any blockages
that may be found.

AFTER SALES SUPPORT
1300 777 137 19
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Notes

20
AFTER SALES SUPPORT
1300 777 137
[email protected]
MODEL: IA0978 PRODUCT CODE: 52458 03/2016
Backpack Vacuum Cleaner
Repair and Refurbished
Goods or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to be
returned to the Supplier for repair.
Please be aware that if your product is capable of retaining user-generated data (such as
files stored on a computer hard drive, telephone numbers stored on a mobile telephone,
songs stored on a portable media player, games saved on a games console or files stored
on a USB memory stick) during the process of repair, some or all of your stored data may
be lost.
We recommend you save this data elsewhere prior to sending the product for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where
they meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1300 777 137 or write to us at:
UNCLE BILL’S AUSTRALIA PTY LTD
PO Box 6292
Silverwater NSW 1811 Australia
1300 777 137
Opening Hours - 9:00am - 4:30pm (Mon-Fri)
9:00am - 3:00pm (Sat)
