STRIKEMASTER Lithium 24V User manual

OWNER’S MANUAL
TOLL-FREE HELPLINE: 1-877-572-7278 |LIGNE DE SECOURS: 905-571-3001
(Monday - Friday / 8am - 4:30pm CST)
LITHIUM ION
BATTERY CHARGER
READ ALL SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATING
24 v

STRIKEMASTER®LITHIUM 24v CHARGING BASE CONTENTS
PRODUCT SPECIFICATIONS ............................................................ 01
QUICK START................................................................................ 02
SAFETY INFORMATION ................................................................... 03
OPERATION .................................................................................. 04
TROUBLE SHOOTING ..................................................................... 05
LIMITED WARRANTY ...................................................................... 06
PRODUCT SPECIFICATIONS
COMPONENTS
• StrikeMaster Lithium 24v Battery Charging Base
• Input: 120V AC 50/60Hz 1.0A
• Output: 24V DC 2.0A
• Weight: 1.48 lbs., (0.67 kg)
01

02
STRIKEMASTER®LITHIUM 24v BATTERY CHARGING BASE
QUICK START
1. Remove Lithium 24v Battery Charging Base from carton (Image 1).
2. Unpack the 24v Battery Charging Base from carton and plug it in. Slide Battery onto
Battery Charging Base using the channels on both sides as a guide. Press down until
you hear it click in place. Leave Battery on Battery Charging Base until
fully charged (Image 2).
NOTE: Battery is not fully charged when first removed from box.
3. When Battery Charging Base indicator shows solid green, your Battery is
fully charged (Image 3). Your StrikeMaster Lithium 24v Battery is ready for use.
Your StrikeMaster Lithium 24v Battery Charging Base has built in “Smart Charging
Technology”. The chart below shows you the correct charging procedure/occurrences
that could be experienced while charging.
4. Your Battery must be charged in a location where the temperature is more than 35°F/2°C,
but less than 100°F/38°C.
REGISTER YOUR PRODUCT ONLINE TO ACTIVATE YOUR WARRANTY
www.strikemaster.com/warranty
IMAGE 3
IMAGE 2
BATTERY IS CHARGING
FULLY CHARGED
BATTERY IS TOO COOL OR
TOO WARM TO CHARGE
(REFER TO OWNERS MANUAL)
DEFECTIVE BATTERY
(REFER TO OWNERS MANUAL)
GREEN (BLINKING)
RED (BLINKING)
GREEN
RED
CHARGING PROCEDURE
for use with strikemaster®
4ah battery(LtV-b) onLy.
IMAGE 1

03
1 IMPORTANT SAFETY INSTRUCTIONS
• SAVE THESE INSTRUCTIONS - DANGER: TO REDUCE
RISK OF FIRE OR ELECTRICAL SHOCK CAREFULLY
OBEY THESE INSTRUCTIONS.
• Confirm the voltage available at each country location
before using the charger.
• The LTV-CB(CA) is meant for use with
110 to 120 VAC only.
• DO NOT allow liquid inside the charger.
• DO NOT try to use the charger for any other purpose
than what is presented in this manual.
• Unplug the charger before cleaning and when there is
no battery pack in the charger.
• Do not try to connect two chargers together.
• Do not use the charger in the circumstances that the
output Polarity does not match the load polarity.
• For indoor use only.
• The charger may under no circumstances be opened.
If the charger is damaged, then the charger may no
longer be used.
• LTV-CB is only to be used with LTV-B.
WARNING
To avoid risk of fire, electrical shock, or electrocution:
• Do not use a damp cloth or detergent on the battery
or battery charger.
• Always remove the battery pack before cleaning,
inspecting, or performing any maintenance on the
tool.
2 SPECIAL RULES FOR CHARGER
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired
operation.
CAUTION
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE
This equipment has been tested and found to comply
with the limits for a Class II digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protec-
tion against harmful interference in a residential instal-
lation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio or television reception, The
reception can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
the receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
3 SYMBOLS ON THE PRODUCT
You can use below symbols on the machine. Please
study them and learn their definitions. Correct
interpretation of these symbols let you operate the tool
better and safer.
Symbol Explanation
Class II
For indoor use only
Before charging, read the instructions
Fuse
Precautions that involve your safety.
4 RECYCLE
The following symbol words and meanings are intended
to explain the levels of risk associated with this product.
Separate collection. You must not discard
with usual household waste. If it is necessary
to replace the machine, or if it is no more
use to you, do not discard it with household
waste. Make this machine available for
separate collection.
Separate collection of used machine and
packaging let you recycle materials and use
them again. Use of the recycled materials
helps prevent environmental pollution and
decreases the requirements for raw materials.
At the end of their useful life, discard batteries
with a precaution for our environment. The
battery contains material that is dangerous to
you and the environment. You must remove
and discard these materials separately at a
location that accepts lithium-ion batteries.

04
5 CALIFORNIA PROPOSITION 65
WARNING
This product contains a chemical known to the state
of California to cause cancer, birth defects or other
reproductive harm. Some dust created by power
sanding, sawing, grinding, drilling, and other con-
struction activities contains chemicals known to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement and other
masonry products;
• Arsenic and chromium from chemically
treated lumber.
Your risk of exposure to these chemicals varies
depending on how often you do this type of work. To
reduce your exposure to these chemicals, work in a
well-ventilated area, and work with approved safety
equipment, such as dust masks that are specially
designed to filter out microscopic particles.
6 EXAMINE THE LTV-CB CHARGING BASE
If the battery pack does not charge correctly:
1. Examine the current of the power outlet with different
machines. Make sure that the outlet works.
2. Examine that the charger contacts are not
short-circuited.
If the charger is not under usual room temperature,
move the charger and battery pack to a location
where the temperature is between 35˚F(2˚C) and
-100˚F(38˚C).
WARNING
If you put the battery pack into the charger in cold
or hot environment, the charger LED light is red.
Remove battery pack and allow temperature to
arrive at recommended charging range.
7 MOUNT THE LTV-CB
CHARGING BASE
1. Locate on wall where to
mount the charger.
2. Use 2 wood screws to attach
the charger on the wood
studs or anchors and screws
to mount to drywall.
3. Drill two paralleled holes
2 3/8” (60 mm) on center.
4. Use wall anchors and screws
to attach the charger to
the drywall. Hardware
not included.
8 OPERATION OF LVT-CB CHARGING BASE
CHARGE PROCEDURE
• Connect the plug of charger to an AC power outlet.
• Insert battery pack onto charger.
This is a diagnostic charger. The Charger LED Light
(3) illuminates in a specified order to show the
current battery status. They are as follows:
CHARGING PROCEDURE (LED INDICATOR)
BATTERY IS CHARGING GREEN
BLINKING
FULLY CHARGED GREEN
BATTERY IS TOO COLD/WARM
(REMOVE BATTERY AND
ALLOW TEMP TO ARRIVE AT
RECOMMENDED RANGE)
RED
DEFECTIVE BATTERY (REMOVE
AND REPLACE WITH A NEW
BATTERY)
RED
BLINKING
NOTE
If you do not use the battery pack and charger for
a long time, please remove the battery from the
charger and unplug from power source.
9 MAINTENANCE
CLEANING THE MACHINE
NOTE
Keep the air vent free of blockage, dust, and
debris. Do not spray, wash or submerge in water.
• Clear the unwanted material out of the air vent with
a vacuum.
• Clean housing and the plastic components with a
dry, soft cloth.
2-3/8 inch (60MM)

05
10 STOW THE MACHINE
Remove the battery pack before you store the charger
and disconnect the charger from power source .
11 TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Charger doesn't
work. Charger shows
defective mode. (LED
flashes Red)
Battery pack
or charger is
defective or
there is a bad
connection
between the
battery pack and
charger.
Try to remove and reinsert the battery pack in the charger.
Try charging a different battery pack.
Unplug the charger and wait until the red LED goes out, then
reconnect the plug to the power supply.
Replace defective battery pack.
Charger doesn't
work. Charger shows
evaluation mode
(LED indicates Red
solid ON).
Battery pack is
either too hot, or
too cold.
Allow the battery pack to reach normal temperature.
Charging will begin when the battery pack returns to
35˚F(2˚C) and -100˚F(38˚C).
COOLING AIR PORT
ELECTRICAL CONTACTS
LED CHARGING
INDICATOR LIGHTS
WALL MOUNTING HOLES
POWER CORD
2-3/8 inch (60MM)

06
2-YEAR LIMITED WARRANTY
CHARGING BASE WARRANTY
StrikeMaster®hereby warranties this product, to the original purchaser with proof of purchase,
for a period of two (2) years against defects in materials, parts or workmanship. Batteries
must be charged in accordance with the owner’s manuals directions and regulations in order
to be valid. StrikeMaster, at its own discretion will repair or replace any and all parts found
to be defective, through normal use, free of charge to the customer. This warranty is valid
only for units which have been used for personal use that have not been hired or rented for
industrial/ commercial use, and that have been maintained in accordance with the instructions
in the owner’s manual supplied with the product from new.
ITEMS NOT COVERED BY WARRANTY
1. Any part that has become inoperative due to misuse, commercial use, abuse, neglect,
accident, improper maintenance, or alteration; or
2.The unit, if it has not been operated and/or maintained in accordance with the owner’s
manual; or
3.Normal wear;
4.Routine maintenance;
5.Normal deterioration of the exterior finish due to use or exposure.
REGISTER YOUR PRODUCT ONLINE TO ACTIVATE YOUR WARRANTY
www.strikemaster.com/warranty
TRANSPORTATION CHARGES
Transportation charges for the movement of any power equipment unit or attachment are the responsibility
of the purchaser. It is the purchaser’s responsibility to pay transportation charges for any part submitted for
replacement under this warranty unless such return is requested in writing by StrikeMaster.

©2020 StrikeMaster, Inc. August 2020
TOLL-FREE HELPLINE: 1-877-572-7278
(Monday - Friday / 8am - 4:30pm CST)
www.strikemaster.com
10395 Yellow Circle Drive • Minnetonka, MN 55343
LIGNE DE SECOURS: 905-571-3001
(Lundi-Vendredi / 8am - 4:30pm CST)
www.strikemaster.com
