Stryker 3002 User manual

2017/03 C.0 3006-409-006 REV C www.stryker.com
Maintenance Manual
S3®MedSurg Bed
REF
3002
International 230V

www.stryker.com 3006-409-006 REV C 3
Table of Contents
Symbols .................................................................................7
Warning/Caution/Note Definition ............................................................8
Introduction ..............................................................................9
Intended Use – Stryker S3®.............................................................................................................9
Specifications ........................................................................10
Mattress Specifications .................................................................10
Environmental Conditions ................................................................11
Product Illustration .....................................................................12
Contact Information ....................................................................13
Serial Number Location .................................................................13
Safety Tips and Guidelines ..................................................................14
iBed®Awareness Option ................................................................16
Static Discharge Precautions ................................................................ 17
Setup Procedures.........................................................................18
Maintenance Menu Guide ...................................................................19
Maintenance Menu Screen ..............................................................19
Preventive Maintenance ....................................................................25
Checklist ............................................................................25
Grease Points ........................................................................26
Cleaning................................................................................27
Troubleshooting Guide .....................................................................28
iBed® Awareness System Error Codes .........................................................31
Error Handling .......................................................................31
Logged Errors ........................................................................31
Error Messages .......................................................................32
Quick Reference Replacement Parts List .......................................................35
Service Information........................................................................37
Brake Pedal Replacement ...............................................................37
Lift Motor and Capacitor Removal and Replacement ............................................38
Lift Housing Removal and Replacement .....................................................39
Lift Potentiometer Replacement and Adjustment ...............................................41
Lift Potentiometer “Burn-in” Procedure ......................................................42
Lift Motor Isolation Plate Replacement ......................................................43
Lift Motor Coupler Replacement ...........................................................44
Power and Sensor Coil Cord Replacement ...................................................45
Power and Sensor Coil Cord Replacement Illustration ...........................................46
Knee Motor Removal and Replacement .....................................................47
Fowler Motor CAM and CAM Guide Replacement ..............................................48
Limit Setting - Fowler Motor ..............................................................49
Fowler Motor Removal and Replacement ....................................................50
Fowler Motor Drive Isolator and CPR Decoupler Removal and Replacement ..........................51
Fowler Motor Ball Screw Assembly Replacement ..............................................52
Head Motor Brake/Clutch Replacement .....................................................53
Load Cell Replacement .................................................................54

4 3006-409-006 REV C www.stryker.com
Table of Contents
Service Information (Continued)
Load Cell Replacement - Grease Points .....................................................55
Power Supply Replacement ..............................................................56
CPU Board Replacement ................................................................56
Soft Config. Procedures.................................................................57
Optional Smart TV Interface “Burn-In” Procedure ..............................................68
Fowler Potentiometer Replacement ........................................................69
Fowler Potentiometer “Burn-In” Procedure ...................................................69
Head and Foot Siderail Cover Removal......................................................70
Head Siderail Hoop Replacement ..........................................................71
Footboard Module Removal ..............................................................72
Footboard Interface Plug Replacement ......................................................73
Bed Circuit Boards ........................................................................74
CPU Board - 3006-308-900 ..............................................................74
CPU Board - 3006-308-900 (Continued).....................................................75
Software Configuration..................................................................76
Power Supply - 0059-157-000.............................................................77
iBed Enhanced Nurse Call Option, 37-Pin Plugover Board - 3006-303-900 ...........................78
iBed Enhanced Nurse Call Option, Dip-Switch Settings (Default) ...................................78
Head Wall Output Configuration ..............................................................80
Bed Assembly, Standard Bed ................................................................81
Bed Assembly, iBed® Awareness Option........................................................87
Base Assembly, Standard Bed ...............................................................89
Lift Assembly (Head and Foot End) ............................................................98
Lift Assembly ............................................................................99
Motor Isolation Plate Assembly .............................................................. 103
Brake Shaft Assembly, Standard Bed ......................................................... 104
Brake Crank Assembly .................................................................... 105
Brake Bar Assembly ......................................................................106
Swivel Lock Caster Assembly - 3006-200-060...................................................107
Steer Swivel Caster Assembly - 3006-200-065 .................................................. 108
6” Molded Wheel Assembly - 3006-200-142 ....................................................109
Bottom Cover - 3001-200-022 ...............................................................110
Litter Assembly, Standard Components ........................................................111
Litter Assembly, Standard Bed ..............................................................116
Foot Prop Assembly, Standard Length Bed - 3003-034-010 ......................................... 12 3
Litter CPU Cover Assembly - 3006-301-097 .................................................... 12 4
Foot Cover Assembly - 3003-300-042 ......................................................... 12 5
Electrical Litter Assembly, Standard Bed ....................................................... 12 6
Mechanical Litter Assembly ................................................................ 13 3
Moving Frame Assembly................................................................... 13 8
CPR Damper Assembly Option .............................................................. 13 9
Lift Header Assembly - No Load Cells ......................................................... 140
Lift Header Assembly with Load Cells ......................................................... 141

www.stryker.com 3006-409-006 REV C 5
Table of Contents
Assembly Drawings (Continued)
Gatch Motor Assembly - 3006-375-420........................................................ 142
Fowler Drive Assembly ....................................................................143
Fowler Actuator Assembly - 3006-375-705 .....................................................145
Fowler Brake Kit Assembly - 3001-300-775 ..................................................... 146
Fowler Limit Switch Assembly - 3002-343-035 .................................................. 147
Night Light Assembly - 3006-410-020 .........................................................148
Optional Scale/Bed Exit Assembly ........................................................... 150
Optional Litter Assembly, Communication Capability .............................................. 15 2
Optional Litter Assembly, Nurse Call and Communication........................................... 154
Optional Litter Assembly, Nurse Call and Communication........................................... 155
Optional Litter Assembly, HWI with 1 Stryker Port ................................................ 156
Optional Litter Assembly, Nurse Call and 1/4” Port................................................ 158
Optional iBed Enhanced Nurse Call, 37-Pin Plugover Assembly ......................................160
Battery Enclosure Assembly ................................................................162
Head End Siderail Assembly ................................................................163
Head End Siderail Assembly with Optional Cardiac Chair........................................... 17 2
Head End Siderail Assembly with Optional...................................................... 17 3
Gatch/Fowler and Cardiac Chair ............................................................. 17 3
Head End Siderail Assembly with Optional...................................................... 17 4
Nurse Call, Cardiac Chair and Gatch/Fowler .................................................... 17 4
Head End Siderail Assembly with Optional...................................................... 17 5
Nurse Call, Lights, Cardiac Chair and Gatch/Fowler............................................... 175
Head End Siderail Assembly with Optional...................................................... 17 6
Nurse Call, TV/Radio, Lights and Cardiac Chair .................................................. 17 6
Head End Siderail Assembly with Optional...................................................... 17 7
Nurse Call, TV/Radio, Lights and Cardiac Chair .................................................. 17 7
Head End Siderail Assembly with Optional...................................................... 17 8
Nurse Call, Lights, Cardiac Chair and Smart TV ................................................. 178
Head End Siderail Assembly with Optional...................................................... 17 9
Nurse Call, Lights, Cardiac Chair and Smart TV ................................................. 17 9
Head End Siderail Assembly with Optional...................................................... 180
NC, Lights, Gatch/Fowler, Cardiac Chair and Smart TV ............................................ 180
Head End Siderail Assembly, Outer Panel ......................................................182
Head End Siderail Assembly, Inner Panel ...................................................... 183
Siderail Ass’y, iBed® Awareness Option, HE, Left - 3006-400-100 ....................................185
Siderail Ass’y, iBed® Awareness Option, HE, Right - 3006-400-200...................................186
Switch Assembly, iBed® Awareness Option, Head End ............................................ 187
3006-400-120 (Left) / 3006-400-220 (Right) .................................................... 187
Foot End Siderail Assembly ................................................................ 188
Siderail Ass’y, iBed® Awareness Option, FE Left - 3006-400-305 ....................................196
Siderail Ass’y, iBed® Awareness Option, FE, Right - 3006-400-405................................... 197
Switch Assembly, iBed® Awareness Option, Foot End ............................................198
3006-400-315 (Left) / 3006-400-415 (Right) ....................................................198

6 3006-409-006 REV C www.stryker.com
Table of Contents
Optional Pendant Assembly ................................................................199
Footboard Assembly, Standard ..............................................................201
Footboard Pump Rack Assembly ............................................................203
Footboard Module Assembly................................................................204
Footboard Assembly, No Options.............................................................205
Footboard Assembly, Bed Exit Option .........................................................207
Footboard Assembly, Bed Exit/Scale Option ....................................................209
Footboard Assembly, Bed Exit/Zone Control Option ...............................................211
Footboard Assembly, Bed Exit/Scale/Zone Control Option .......................................... 213
Footboard Assembly, iBed® Awareness Option .................................................. 215
Headboard Assembly - 3005-600-100 ......................................................... 217
Optional Accessories ..................................................................... 219
Removable I.V. Pole and Mounting Assembly - 3001-338-010 ........................................220
Removable I.V. Pole Assembly - 3000-300-080 ..................................................221
Two Stage I.V. Pole Assembly - 2035-112-000 ...................................................222
Dual Head End I.V. Pole Assembly - 2035-113-000................................................223
2-Stage I.V. Pole - 2035-112-010 & 2035-113-011 .................................................224
I.V. Pole Latch Assembly - 0785-035-103.......................................................225
Defibrillator Tray Assembly - 3006-120-004 .....................................................226
Upright Oxygen Bottle Holder Assembly - 3006-150-000 ...........................................227
Bed Extender Assembly - 3006-346-020.......................................................228
Bed Extender Mattress - 3000-318-050........................................................230
Traction Socket Extensions.................................................................231
Recycling Passport ......................................................................232
EMC Information.........................................................................238
Warranty ..............................................................................242
Limited Warranty .....................................................................242
To Obtain Parts and Service ............................................................242
Service Contract Coverage .............................................................242
Return Authorization...................................................................243
Damaged Merchandise ................................................................243
International Warranty Clause............................................................243
Assembly Drawings (Continued)

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 7
Symbols
Warning, consult accompanying documentation
Safe Working Load Symbol
Dangerous Voltage Symbol
~
Alternating Current
Direct Current
Protective Earth Terminal
Potential Equalization Symbol
Type B Equipment: equipment providing a particular degree of protection against electric shock,
particularly regarding allowable leakage current and reliability of the protective earth connection.
Class 1 Equipment: equipment in which protection against electric shock does not rely on BASIC
INSULATION only, but which includes an additional safety precaution in that means are provided
for the connection of the EQUIPMENT to the protective earth conductor in the fixed wiring of the
installation in such a way that ACCESSIBLE METAL PARTS cannot become live in the event of a
failure of the BASIC INSULATION.
Mode of Operation: Continuous
IPX4 Protection from liquid splash
Medical Equipment Classified by Underwriters Laboratories Inc. with Respect to Electric Shock, Fire,
Mechanical and Other Specified Hazards Only in Accordance with UL 60601-1, First Edition (2003)
and CAN/CSA C22.2 No. 601.1-M90 with updates 1 and 2 and IEC 60601-1 (1998) with Amendment
1 (1991) and Amendment 2 (1995).
In accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment,
this symbol indicates that the product must not be disposed of as unsorted municipal waste, but
should be collected separately. Refer to your local distributor for return and/or collection systems
available in your country.
Non-ionizing radiation; i.e. RF transmitter (WiFi)

Return To Table of Contents
8 3006-409-006 REV C www.stryker.com
Symbols and Definitions
WARNING/CAUTION/NOTE DEFINITION
The words Warning, Caution and Note carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to the
operator or patient or damage to the equipment or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
Note
This provides special information to make maintenance easier or important instructions clearer.

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 9
Introduction
This manual is designed to assist you with the maintenance of the S3®MedSurg Bed, Model 3002. Read it thoroughly
before using the equipment.
INTENDED USE – STRYKER S3®
The S3®MedSurg Bed, Model 3002 is intended to support and transport patients within the Med/Surg and Critical Care
hospital environments. The S3®MedSurg Bed, Model 3002 is typically used in pre-op, post-op and recovery areas of
hospital facilities. The intended user for this product is both Health Care Providers (HCPs: nurses, nurses’ aides, and
medical doctors) and human patients. Lockout features may limit patient accessible controls. This product is to be
used in combination with a patient sleep surface. The bed has fowler, gatch and lift articulation capabilities that aide
in the adjustment of surface contour, angle, and height. The product offers various options, outlined in the product
operations and maintenance manuals, including but not limited to iBed®awareness, scale, IV pole, defib tray, etc. iBed
awareness allows users to set various bed parameters to monitor bed positioning. Alerts inform users as to patient
movement within a specific zone(s) on a patient surface. The bed may be equipped with an integrated scale intended
to weigh the patient in bed. The scale output is not intended to be used to determine diagnosis or treatment. Both the
iBed Awareness and Chaperone®Bed Exit system provide both visual and audible alerts.
The intended patient population for the S3®MedSurg Bed, Model 3002 is as follows:
• The product should be used with patients upwards of 50 lbs and have a safe working load of 500 lbs.
• The patient must be at least 2 years old
• The patient must be less than 84” without a bed extender OR 96” with a bed extender
Please refer to the operations manual for environmental operation requirements.
The S3®MedSurg Bed, Model 3002 has an expected service life of 10 years under normal use conditions and with
appropriate periodic maintenance as described in the maintenance manual for each device.
The product is not intended to support more than one individual at a time.

Return To Table of Contents
10 3006-409-006 REV C www.stryker.com
Introduction
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the sum of the
patient, mattress, and accessory weight.
500 lbs 227 kg
Bed Weight 570 lbs 259 kg
Scale System Capacity (optional equip-
ment). Loads weighing up to
500 lbs 227 kg
Scale System Accuracy (optional equipment)
± 3 pounds for patients weighing 50 to 100 pounds
± 3% of the total patient weight for patients
weighing 100 to 500 pounds
Overall Length/Width - Standard Bed Siderails Up 93” x 41-1/2” 236,2 cm x 105,41 cm
Siderails Down 93” x 39-1/2” 236,2 cm x 100,3 cm
Patient Sleep Surface - Standard Bed 84” x 35” 213,4 cm x 88,9 cm
Bed Height to Top of Seat Litter - 6” Casters 16” to 30” ±0.5 40,6 cm to 76,2 cm
Litter Platform to Top of
Siderail
Full Up Head End Siderail 15” 38,1 cm
Full Up Foot End Siderail 15 -1/2” 39,37 cm
Space Between Siderails (Full Up) 2-1/4” 5,72 cm
Knee Gatch Angle 0° to 45°
Fowler Angle 0° to 60°
Trendelenburg/Reverse Trendelenburg +12° to -10° ± 1°
Electrical Requirements 230 VAC, 50/60 Hz, 8.0 A
Battery Voltage (1) 9V Nurse Call Option (Alkaline Battery)
MATTRESS SPECIFICATIONS
Thickness 6” 15,2 cm
Width >= 35” >= 88,9 cm
Length >= 84” >= 213,4 cm
ILD 80 lbs 36.3 kg
The above stated mattress specifications assist in ensuring the product conforms to HBSW and IEC
specifications.

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 11
ENVIRONMENTAL CONDITIONS
Environmental Conditions Operation Storage and Transportation
Ambient Temperature
Relative Humidity
(Non-Condensing)
Atmospheric Pressure
Stryker reserves the right to change specifications without notice.
Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
(10 0C)
(40 0C)
50 0F
104 0F
(-30 0C)
(60 0C)
-22 0F
140 0F
30%
75%
10%
95%
700 hPa
1060 hPa
500 hPa
1060 hPa
Introduction

Return To Table of Contents
12 3006-409-006 REV C www.stryker.com
Introduction
Headboard
Brake
Pedal
Siderail Release
Handle
Siderail
Footboard
Caster
Footboard
Control Panel
Patient
Control Panel
Nurse
Control Panel
Steer
Pedal
(not
shown)
PRODUCT ILLUSTRATION

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 13
R
Introduction
CONTACT INFORMATION
Contact Stryker Customer Service or Technical Support at [phone].
Stryker Medical
3800 E. Centre Avenue
Portage, Michigan 49002
USA
Please have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical
Support. Include the serial number in all written communication.
SERIAL NUMBER LOCATION
A
The serial number is located at the head end of the
bed just below the headboard and above the power
cord where it comes out from the frame. Head End of Bed

Return To Table of Contents
14 3006-409-006 REV C www.stryker.com
Before operating the S3®MedSurg Bed, Model 3002, it is important to read and understand all information in this
manual. Carefully read and strictly follow the safety guidelines listed on this page. It is important that all users have
been trained and educated on the inherent hazards associated with the usage of electric beds.
WARNING
• To prevent permanent damage to this unit, the unit must reach room temperature prior to conducting any setup
and/or unit operations.
• Danger: Explosion hazard. Do not use in the presence of flammable anesthetics.
• Always apply the caster brakes when a patient is getting on or off the bed.
• Always keep the caster brakes applied when a patient is on the bed (except during transport). After the brake
pedal is applied, push on the bed to ensure the brakes are locked. Serious injury could result if the bed moves
while a patient is getting in or out of bed.
• Ensure the brakes are completely released prior to moving the unit. Attempting to move the unit with the brakes
actuated could result in injury to the user and/or patient.
• Do not attempt to move the foot end of the bed laterally when the steer pedal is activated. When the steer pedal
is activated, the steer caster at the foot end of the bed cannot swivel. Attempting to move the bed laterally when
the steer pedal is activated may cause injury to the user.
• The Stryker S3®MedSurg Bed, Model 3002 is not intended for use with patients less than two years of age.
• Serious injury can result if caution is not used when operating the unit. Operate the unit only when all persons are
clear of the electrical and mechanical systems.
• To help reduce the number and severity of falls by patients, always leave the bed in the lowest position when the
patient is unattended.
• When attaching equipment to the frame, ensure it will not impede normal frame operation. For example: hooks
on hanging equipment must not actuate control buttons, equipment must not hide the nurse call button, foley bags
must not rest on brake pedal, etc. Use only a Stryker supplied interface cable. Use of any other cable may cause
the bed to function improperly, which may result in patient or user injury.
• The Stryker S3®MedSurg Bed, Model 3002 is equipped with a hospital grade plug for protection against electric
shock hazard. It must be plugged directly into a properly grounded three prong receptacle. Grounding reliability
can be achieved only when a hospital grade receptacle is used.
• When raising the siderails, listen for the “click”. When raising the siderail, the first click will indicate you can return
to the intermediate position, the second click indicates its full up position. Once in position, move siderail from
side to side to ensure it is locked into position. Siderails are not intended to be a patient restraint device. It is the
responsibility of attending medical personnel to determine the degree of restraint and the siderail positioning to
ensure a patient will remain safely in bed.
• The Bed Exit System is intended only to aid in the detection of a patient exiting the unit. It is NOT intended
to replace patient monitoring protocol. The bed exit system signals when a patient is about to exit. Adding or
subtracting objects from the frame after zeroing the weigh system may cause a reduction in the sensitivity of the
bed exit system.
• Before servicing or cleaning the bed, always unplug the bed power cord from the wall socket. When working
under a bed in the high position, always place blocks under the litter frame and apply the brakes to prevent injury
in case the Bed Down switch is accidently pressed.
• To avoid pinching your fingers, place the I.V. pole in the upright position before using the drive handle.
• When using any mattress and/or mattress overlay that increases the overall height greater than 6,” extra caution
and/or operator supervision is required to help reduce the likelihood of a patient fall occurring.
Safety Tips and Guidelines

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 15
To avoid possible injury and to assure proper operation when using model number 2750, 2850, 2920, 2950 or 2981
mattress:
• Confirm proper scale system operation following mattress installation. For best results, secure the therapy mattress
power cord to prevent damage to the cord or interference with the bed frame and the scale system.
• Do not zero bed scales or weigh patient with Percussion, Vibration, Rotation or Turn Assist active. Patient motion
and position resulting from the dynamic therapy mattress may adversely affect scale system performance.
• Do no initialize (“arm”) bed exit with Percussion, Vibration, Rotation or Turn Assist active. The patient motion and
position resulting from the dynamic therapy mattress may adversely affect bed exit system performance.
• When using an XPRT (2950), Position PRO (2920), Impression (2981), ComfortGel (2850) or Symmetric Aire
(2750) mattress, extra caution and/or operator supervision is required to help reduce the likelihood of a patient fall
occurring.
CAUTION
• When large spills occur in the area of the circuit boards, 230 volt cables and motors, immediately unplug the bed
power cord from the wall socket. Remove the patient from the bed and clean up the fluid. Have maintenance
completely check the bed. Fluids can affect the operational capabilities of any electrical product. DO NOT put
the bed back into service until it is completely dry and has been thoroughly tested for safe operation.
• Preventative maintenance should be performed at a minimum of annually to ensure all bed features are functioning
properly. Close attention should be given to safety features including, but not limited to, safety side latching
mechanisms, frayed electrical cords and components, all electrical controls returning to the off or neutral position
when released, caster braking systems, no controls or cabling entangled in bed mechanisms, leakage current
microamps maximum, scale and bed exit systems calibrated properly, and the siderail gas spring not leaking oil.
• Because individual beds may have different options, footboards should not be moved from one bed to another.
Mixing footboards could result in unpredictable bed operation.
• The lockout buttons on the footboard lock the Fowler, Gatch and Bed Up/Down functions and prevent motion of
the bed. It is the responsibility of attending medical personnel to determine whether these functions should be
locked and to use the buttons accordingly.
• The maximum safe working load for each I.V. pole is 40 pounds.
• I.V. Poles should not be used as a bed push/pull device.
• Scale function may be affected by siderail/caster interference. With the litter fully lowered or lowered in Reverse
Trendelenburg, the siderails tucked under the litter in the storage position and the casters turned, there is the
potential for interference between the siderail and the caster. Raise the siderails when lowering the litter to the full
down position to prevent the interference from causing the scale system to weigh inaccurately
• The use of a mattress overlay may reduce the effectiveness of the siderail.
• The cleanliness and integrity of both ground chains must be maintained to minimize static build up and
discharge.
• Do not add or remove weight when the bed exit system is armed.
• There is a possible fire hazard when using half bed length type oxygen administering equipment. Ensure that the
siderails are outside of the tent.
• There is a possible fire hazard when used with oxygen administering equipment of other than the nasal or mask
type. Lock the control at foot of bed when using oxygen administering equipment.
• The weight of the foley bags placed on isolated bag hooks should not exceed five pounds.
• The weight of pumps placed on footboard pump holder should not exceed 45 pounds.
• The safe working load of the defibrillator tray is 40 lbs.
• The safe working load of the oxygen holder is 45 lbs.
• Scale accuracy specifications do not apply for patients under 50 lbs.
Safety Tips and Guidelines
WARNING (CONTINUED)

Return To Table of Contents
16 3006-409-006 REV C www.stryker.com
Safety Tips and Guidelines
IBED®AWARENESS OPTION
In addition to the previous warnings and cautions, all of the following warnings and cautions apply to units equipped
with the iBed® Awareness option.
WARNING
• The optional iBed® Awareness system only indicates the siderail position; it does NOT indicate if the siderail is
locked. It is the caregiver’s responsibility to ensure that the siderails are locked after every move and also before
leaving a patient in the room.
• The optional iBed® Awareness system indicator lights are only an aid to the caregiver, and in no way replace the
caregiver’s responsibility of checking on patients. Caregivers should not rely on the lights to perform their duties.
• Before arming the optional iBed® Awareness system, the nurse must physically verify that siderails are locked.
CAUTION
• If the optional iBed® Awareness system is being used, ensure the bed is in the desirable state (iBed® Awareness
ON and with the light green) before leaving the room.
• If the optional iBed® Awareness system is being used and the iBed® Awareness is alerting, do not turn off iBed®
Awareness as the display information to troubleshoot the bed will get lost.
• If the optional iBed® Awareness system is being used, use of accessories that cover the center and side alert lights
at the footboard are not recommended.

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 17
The electronic circuits in the 3002 S3 Bed are completely protected from static electricity damage only while the bed
is assembled. It is extremely important that all service personnel always use adequate static protection when servicing
the electronic systems of the 3002 S3 Bed. Whenever you are touching wires, you should be using static protection.
Static Protection Equipment
The necessary equipment for proper static protection is:
• 1 static wrist strap; 3M part number 2214 or equivalent,
• 1 grounding plug; 3M part number 61038 or equivalent,
• 1 test lead with a banana plug on one end and an alligator clip on the other; Smith part number N132B699 or
equivalent.
CAUTION
All electronic service parts will be shipped in static shielding bags. Do not open the bags until you have completed steps
2 and 3 of the following procedure. Do not place unprotected circuit boards on the floor. All circuit boards to be returned
to Stryker Medical should be shipped in the static shielding bags the new boards were shipped in.
Static Protection Procedure
1. Unplug the power cord from the wall receptacle.
2. Insert the grounding plug into a properly grounded hospital grade wall receptacle. Plug the banana plug of the
test lead into the receptacle on the grounding plug. Connect the alligator clip on the other end of the test lead to
a ground point on the bed.
3. Place the static control wrist strap on your wrist. Connect the alligator clip at the other end of the wrist strap cord
to a ground point on the bed.
BED
GROUNDING DIAGRAM
Static Discharge Precautions

Return To Table of Contents
18 3006-409-006 REV C www.stryker.com
To prevent permanent damage to this unit, the unit must reach room temperature prior to conducting any setup
and/or unit operations.
It is important that the Stryker S3®MedSurg Bed, Model 3002 is working properly before it is put into service. The
following list will help ensure that each part of the bed is tested.
WARNING
• The Stryker S3®MedSurg Bed, Model 3002 is equipped with a hospital grade plug for protection against electric
shock hazard. It must be plugged directly into a properly grounded three prong receptacle. Grounding reliability
can be achieved only when a hospital grade receptacle is used.
• Use only a Stryker supplied interface cable. Use of any other cable may cause the bed to function improperly
which may result in patient or user injury.
• Ensure there is no patient on the bed during the setup procedure.
1. Plug the bed into a properly grounded, hospital grade wall receptacle and ensure the LED light at the foot
end of the bed comes on.
2. Plug the optional interface cable into the 37 pin connector under the litter frame at the head end of the bed, into
the “Patient Station”, “Head Wall”, “Docker Station”, or equivalent (whichever applies). Test the interface cable to
verify it is functioning properly.
3. Ensure the siderails raise, lower, lock in the up position, lock in the intermediate position when lowered and store
smoothly (see Operations Manual for further details).
4. Ensure that all four casters lock when the brake pedal is engaged ((see Operations Manual for further details).
5. Raise the fowler (head of bed) up to approximately 600. Squeeze the CPR release handle and ensure the back
will drop with minimal effort.
Note
Ensure that the “Brake” LED located on the outside of the head end siderails and on the footboard control panel
blink when the brakes are not engaged.
6. Perform each function on the footboard control panel to ensure that each function is working properly (see
Operations Manual for further details).
7. Perform each function on both head end siderails to ensure that each is working properly (see Operations Manual
for further details).
8. Activate the motion stop system to ensure it is functioning properly; press and hold the BED DOWN key. As the
bed lowers, push up on the motion interrupt pan under the bed and ensure the downward motion stops. Release
the pan and allow the downward motion to continue.
Note
The bed’s upward motion or other functions are not disrupted by the motion stop system.
9. If the bed is equipped with the Nurse Call option, verify it is functioning properly prior to patient use.
Setup Procedures

Return To Table of Contents
www.stryker.com 3006-409-006 REV C 19
MAINTENANCE MENU SCREEN
The Maintenance Menu contains all of the non-regularly accessible features of the product. This menu provides
an interface to the user and/or service personnel in order to provide the ability to control and access maintenance
features.
Maintenance Menu Items
The following are menu items listed in the maintenance menu screen for a fully loaded bed:
1. Calib. Scale (Calibrate Scale)
2. TV Config. (TV Configuration)
3. Scale Info. (Scale Info/Stats)
4. Clear Scale Stats
5. Error Log (View Error Log)
6. Clear Errors (Clear Error Log)
7. Scale Units (Lock Scale Units)
8. About (About Product)
9. Exit Menu (Exit Maintenance)
The following are menu items listed in the maintenance menu screen for a standard bed:
1. TV Config. (TV Configuration)
2. Error Log (View Error Log)
3. Clear Errors (Clear Error Log)
4. About (About Product)
5. Exit Menu (Exit Maintenance)
The following are menu items listed in the maintenance menu screen for an iBed:
1. Calib. Scale (Calibrate Scale)
2. TV Config. (TV Configuration)
3. Scale Info. (Scale Info/Stats)
4. Clear Scale Stats (only if you have scale option)
5. Error Log (View Error Log)
6. Clear Errors (Clear Error Log)
7. Scale Units (Lock Scale Units)
8. About (About Product)
9. Exit Menu (Exit Maintenance)
• Each of the menu items provides the operator with a different function.
• Using the up and down menu buttons, you can scroll though the menu elements.
• To select a menu item, scroll to the desired menu item using the Up and Down menu button. When the desired
feature is highlighted, press the Enter/Check button. Depending on the feature, the display will move into the
sequence for the feature selected.
Load Cell Check (Where applicable: for beds with a minimum of Scale or either kind of Bed Exit)
• This feature automatically checks all four load cells to make sure they are working properly.
• The purpose of this feature is to provide a self diagnostic of the load cells.
• When maintenance is entered, a self-diagnostic feature should run and display results.
• While the procedure is running, the following message is displayed: “Load Cell Check”.
• Any load cell errors will be displayed as a message “Load Cell Error” and then, depending on the error, an HL,
HR, FL or FR will be displayed below the message. (Refer to the Error Handling Section).
• If no errors are present, then the maintenance menu will be displayed and menu items 1-9 above may be
accessed where applicable.
Maintenance Menu Guide

Return To Table of Contents
20 3006-409-006 REV C www.stryker.com
• This feature allows the operator to calibrate the scale system.
• This calibration is used to provide the system with a weight offset that occurs when the product is put into
trend and reverse trend.
• This calibration does not calibrate the load cells; the load cells are pre-calibrated.
To calibrate the scale system:
1. In the Maintenance Menu, select the Calibrate Scale item; then press and hold the Enter/Check button.
2. The display should present the following message:
“Do Not Touch Bed”. The message should be flashing.
3. Use the up and down arrow to select the proper weight (50lbs is the default).
4. Press the “Enter/Check” button when the display shows the proper weight.
5. The display should present the following message:
“Place Weight in Center”.
6. Place the weight in the center of the bed.
7. Press the “Enter/Check” button when completed.
8. The display should present the following message:
“Press Reverse Trend”.
9. Press the reverse trend button.
10. The display should present the following message when the bed is in the proper position:
“Release Button”.
11. Release the button and do not touch the bed. When the button is released, the following message is displayed:
“Do Not Touch Bed”. The message should be flashing.
12. The display should present the following message when the bed is ready to continue:
“Press Trend”.
13. Press the trend button.
14. The display should present the following message when the bed in the proper position:
“Release Button”.
15. Release the button and do not touch the bed. When the button is released the following message is displayed:
“Do Not Touch Bed”. The message should be flashing.
16. The display should present the following message when the bed is ready to continue:
“Save Calibration?”.
17. Press the “Enter/Check” button to save the calibration.
18. The display should present the following message when the bed is ready to continue:
“Save Successful”.
Note:
If an error occurs during the procedure the display will show an error message, “Calibration Error,” for four
seconds.
WARNING
Ensure there is no patient on the bed while the calibration procedure is being performed.
Maintenance Menu (Continued)
Scale Calibration
Maintenance Menu Guide
