Stryker 6100 Rugged M1 Manual

6100

Table of Contents
Introduction 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty
Obtaining Parts and Service 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental Warranty Coverage 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Return Authorization 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freight Damage Claims 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Precautions 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Set–Up Procedures 8, 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cot Fastener Installation 10, 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Base Unit
Base Unit Specifications 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Base Component Identification 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Guidelines for Operation 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing Cot Height 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cot Positions 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading the Cot into a Vehicle 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unloading the Cot from a Vehicle 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using Additional Assistance 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Caster Steer Lock 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting the Litter to the Base 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Lock 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Base Head End Retractable Lifting Handles 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Litter
Litter Specifications and Component Identification 24, 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Backrest 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Siderails 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Knee Gatch 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trendelenburg Positioning 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Retractable Lifting Handles 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents
Litter (Continued)
3–Stage I.V. Pole 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transferring the Patient to the Cot 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Restraint Straps 32, 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rolling the Cot 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preventive Maintenance
Cleaning 35, 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preventive Maintenance Schedule 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preventive Maintenance Checklist 38, 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Locking Force Adjustment 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steer Lock Detent Force Adjustment 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steer Lock Detent Force Adjustment 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Base Wear Strip Replacement 42–44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pneumatic Backrest Adjustment 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Record 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Training Record 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Notes

Introduction
1–4
INTRODUCTION
This manual is designed to assist you with the operation and maintenance of the 6100 Series
M1 Ambulance Cot. Read it thoroughly before using the equipment or beginning any maintenance on it.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
The personal safety of the patient or user may be involved. Disregarding this information could result in injury
to the patient or user.
CAUTION
These instructions point out special procedures or precautions that must be followed to avoid damaging the
equipment.
NOTE
This provides special information to make maintenance easier or important instructions clearer.

1–5
Warranty
Limited Warranty:
Stryker Medical Division, a division of Stryker Corporation, warrants to the original purchaser that its products
should be free from defects in material and workmanship for a period of one (1) year after date of delivery.
Stryker’s obligation under this warranty is expressly limited to supplying replacement parts and labor for, or
replacing, at its option, any product which is, in the sole discretion of Stryker, found to be defective. Stryker
warrants to the original purchaser that the frame and welds on its beds will be free from structural defects
for as long as the original purchaser owns the bed. If requested by Stryker, products or parts for which a
warranty claim is made shall be returned prepaid to Stryker’s factory. Any improper use or any alteration or
repair by others in such manner as in Stryker’s judgement affects the product materially and adversely shall
void this warranty. No employee or representative of Stryker is authorized to change this warranty in any way.
Stryker Medical ambulance cots are designed for a 5 year expected life under normal use conditions and ap-
propriate periodic maintenance as described in the maintenance manual for each device.
This statement constitutes Stryker’s entire warranty with respect to the aforesaid equipment. STRYKER
MAKES NO OTHER WARRANTY OR REPRESENTATION, EITHER EXPRESSED OR IMPLIED, EXCEPT
AS SET FORTH HEREIN. THERE IS NO WARRANTY OF MERCHANTABILITY AND THERE ARE NO
WARRANTIES OF FITNESS FOR ANY PARTICULAR PURPOSE. IN NO EVENT SHALL STRYKER BE
LIABLE HEREUNDER FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM OR IN ANY
MANNER RELATED TO SALES OR USE OF ANY SUCH EQUIPMENT.
To Obtain Parts and Service:
Stryker products are supported by a nationwide network of dedicated Stryker Field Service Representatives.
These representatives are factory trained, available locally, and carry a substantial spare parts inventory to
minimize repair time. Simply call your local representative, or call Stryker Customer Service at (800)
327–0770.
Supplemental Warranty Coverage:
Stryker has developed a comprehensive program of extended warranty options designed to keep your equip-
ment operating at peak performance at the same time it eliminates unexpected costs. We recommend that
these programs be activated before the expiration of the new product warranty to eliminate the potential of
additional equipment upgrade charges. Stryker offers the following Supplemental Warranties:
Extended (Parts and Labor)
SAll replacement parts (excluding mattresses and consumable items)
SLabor and travel for all scheduled and unscheduled calls
SAnnual Preventive Maintenance Inspections and repairs
SJCAHO paperwork for preventive maintenance
SPriority Emergency Service
Standard (Labor Only):
SLabor and travel for all scheduled and unscheduled calls
SAnnual Preventive Maintenance Inspections and repairs
SJCAHO paperwork for preventive maintenance
SPriority Emergency Service
Basic (Parts Only):
SAll replacement parts (excluding mattresses and consumable items)
SPriority Emergency Service
Please call your local representative, or call (800) 327–0770 for further information

1–6
Warranty
Return Authorization:
Merchandise cannot be returned without approval from the Stryker Customer Service Department. An autho-
rization number will be provided which must be printed on the returned merchandise. Stryker reserves the
right to charge shipping and restocking fees on returned items.
SPECIAL, MODIFIED, OR DISCONTINUED ITEMS NOT SUBJECT TO RETURN.
Damaged Merchandise:
ICC Regulations require that claims for damaged merchandise must be made with the carrier within fifteen
(15) days of receipt of merchandise. DO NOT ACCEPT DAMAGED SHIPMENTS UNLESS SUCH DAMAGE
IS NOTED ON THE DELIVERY RECEIPT AT THE TIME OF RECEIPT. Upon prompt notification, Stryker
will file a freight claim with the appropriate carrier for damages incurred. Claim will be limited in amount to
the actual replacement cost. In the event that this information is not received by Stryker within the fifteen
(15) day period following the delivery of the merchandise, or the damage was not noted on the delivery receipt
at the time of receipt, the customer will be responsible for payment of the original invoice in full.
Claims for any short shipment must be made within thirty (30) days of invoice.
International Warranty Clause:
This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact
your local Stryker Medical representative for additional information.
Patent Information
Rugged Products are manufactured under the following patents:
United States 5,575,026
5,537,700
Other Patents Pending

Summary of Safety Precautions
1–7
The following is a list of safety precautions that must be observed when operating or servicing this unit. The
precautions are repeated throughout the manual, where applicable. Carefully read this list before using or
servicing the unit.
WARNING
SImproper usage of the Cot can cause injury to the patient or operator. Operate the cot
only as described in this manual.
SAlways use all restraint straps to secure the patient on the cot. An unrestrained patient may fall from the
cot resulting in injury.
SNever leave a patient unattended on the cot or injury could result. Hold the cot securely while a patient
is on the cot.
SThe wheel lock is only intended to help prevent the cot from rolling while unattended. The wheel lock may
not provide sufficient resistance on all surfaces or under loads.
SNever apply the wheel lock while a patient is on the cot. Tipping could occur if the cot is moved while the
wheel lock is applied, resulting in injury to the patient or operator and/or damage to the cot.
SThe caster steer lock knob and the casters must be in the locked position when loading/unloading the cot
from a vehicle or loading tray system and when the cot height is changed or the cot may become unstable
possibly resulting in injury to the patient or operator.
SWhen changing the height of the cot, always verify the base frame is securely locked into position before
releasing your grip on the lift handles
SLoading, unloading and changing the position of the cot requires a minimum of one trained operator. The
operator(s) must be able to lift the total weight of the patient, cot and any other items on the cot. (If addition-
al assistance is needed, refer to the reference chart on page 1–19).
SBe sure the undercarriage has engaged and locked before removing the loading wheels from the patient
compartment floor of the vehicle. An unlocked undercarriage will not support the cot and injury to the pa-
tient and/or operator could result.
SWhen changing the height of the cot, always verify the base frame is securely locked into position before
relaxing your hold on the hand grips.
SDo not allow untrained helpers to assist in the operation of the cot. Untrained technicians/helpers can
cause injury to the patient or themselves.
SDo not modify the Cot. Modifying the cot can cause unpredictable operation resulting
in injury to the patient or operator. Modifying the cot will also void its warranty (see page 1–5).
SImproper maintenance can cause injury or damage to the unit. Maintain the cot as described in this manu-
al. Use only Stryker approved parts and maintenance procedures. Using unapproved parts and proce-
dures could cause unpredictable operation and/or injury and will void the product warranty.
SFailure to properly clean or dispose of contaminated mattress or cot components will increase the risk of
exposure to bloodborne pathogens and may cause injury to the patient or the operator.
CAUTION
SDo not steam clean or ultrasonically clean this unit. Clean the cot as described on page 1–35. Failure
to comply with these instructions may invalidate any/all warranties

Set–Up Procedures
1–8
Unpack the cartons and check all items for proper operation. It is important that the Cot is
working properly before it is put into service. Have a qualified service person use the following list and the
operation instructions to check the cot before it is put into service.
Litter
All fasteners secure
All welds intact, not cracked or broken
No bent or broken components
Perimeter bumpers intact
Roller wheels rotate smoothly, no debris around axles
Backrest operating properly (see page 1–45 for backrest adjustment procedure)
Extension lift handles operating properly (4 total)
Siderails operating properly (optional equipment)
Knee Gatch/Trendelenburg operating properly (optional equipment)
Litter retention pins secure and not bent or broken (4 total)
Litter locks securely to base unit, roller guides not bent or broken
Optional accessories intact and operating properly
Mattress
No rips, cracks or punctures in mattress cover
Mattress attaches to litter properly
Restraint System
Buckle and tensioner systems operating properly
No frayed or torn straps
No loose or torn stitching
Base
All fasteners secure
All welds intact, not cracked or broken
No bent or broken components
Plastic wear strips intact (front/rear leg assemblies)
Load wheels rotate smoothly, no debris around axles
All wheels secure, rolling and swivelling properly, no debris in axles
Caster steer lock system operating properly (see page 1–41 for detent force adjustment procedure)
Wheel locks operating properly (see page 1–40 for pedal locking force adjustment procedure)
Undercarriage loads and unloads properly from the vehicle
Green release lever and button intact and operating properly
Undercarriage is secure and operates properly in all height positions
Red release levers intact and operating properly (both ends)

Set–Up Procedures
1–9
Base (Continued)
Litter locks securely onto base unit; litter release mechanism operating properly
Base retention pin secure and not bent or broken
Extendable lift handles intact and operating properly (optional equipment)
Optional accessories intact and operating properly
Base locks securely into cot fastener system (see ATTENTION below)
The patient compartment of the vehicle in which the Cot will be used must have:
SA smooth rear edge for cot loading.
SA level floor or tray system large enough for the folded cot and cot fastener system.
SStryker Cot Fastener System
–Model 6372 Center Mount, Straight Guides
–Model 6373 Center Mount, DIN Guides
SFloor or tray system loading height between 27.0 inches (68.6 centimeters) and 31.0 inches (78.8 centi-
meters)
When necessary, modify the vehicle to fit the cot. Do not modify the cot.
WARNING
Do not modify the Cot. Modifying the cot can cause unpredictable operation resulting in inju-
ry to the patient or operator. Modifying the cot will also void its warranty (see page 1–5).
ATTENTION
The Model 6100 Ambulance Cot, in combination with the Model 6372 or Model 6373 Cot Fastener Systems,
are designed in accordance to BS EN 1789, Medical Vehicles and their Equipment –Road Ambulances. The
Cot Fastener System must be installed by qualified personnel to be in conformance to this standard. 1/4”
steel backing plates (or the equivalent) are recommended beneath the mounting surface (ambulance floor
or tray system) at all mounting points. Before putting the system into service, test the installation using BS
EN 1789 as a minimum.

Cot Fastener Installation
1–10
The Stryker Model 6372 and 6373 Cot Fastener systems are designed to be compatible only with cots which
conform to the installation specifications listed on page 1–11. Ambulance cots which currently meet these
specifications are:
Stryker
Model 6100 M1 Roll–In System
Ferno–Washington
Model X–2*
WARNING
It is the responsibility of the cot operator to ensure that the cot being used in the Stryker Model 6372 or 6373
Cot Fastener Systems meets the installation specifications listed on page 1–11. Injury may result if a non–
compatible cot is used in the Stryker Model 6372 or 6373 Fastener System.
For more detailed installation and operation instructions for the Stryker Model 6372 and 6373 Cot Fastener
systems, refer to part number 6372–90–11 RuggedtCot Fastener Installation/Operation Instructions.
ATTENTION
The Model 6100 Ambulance Cot, in combination with the Model 6372 or Model 6373 Cot Fastener Systems,
are designed in accordance to BS EN 1789, Medical Vehicles and their Equipment –Road Ambulances. The
Cot Fastener System must be installed by qualified personnel to be in conformance to this standard. 1/4”
steel backing plates (or the equivalent) are recommended beneath the mounting surface (ambulance floor
or tray system) at all mounting points. Before putting the system into service, test the installation using BS
EN 1789 as a minimum.
* Stryker is not responsible for changes in specifications to other manufacturer’s cots.

Cot Fastener Installation
1–11
VIEW 2A
VIEW 2B

Base Unit Specifications
1–12
GENERAL SPECIFICATIONS
6100 Series M1 Base Unit –part number 6100–003–000
Length 77.4 inches (196.6 centimeters)
Width 22.0 inches (55.9 centimeters)
Height!–Position 1
Position 2
Position 3
Position 4
Position 5
Position 6
Position 7
Position 8
14.4 inches (36.6 centimeters)
24.4 inches (62.0 centimeters)
30.0 inches (76.2 centimeters)
34.6 inches (87.9 centimeters)
37.6 inches (95.5 centimeters)
39.3 inches (99.8 centimeters)
13.0 inches (33.0 centimeters)
N/A
Weight@73.5 pounds (33.3 kilograms)
Maximum Weight Capacity 500 pounds (228 kilograms)
Caster Diameter/Width 6 inches/2 inches
(15.2 centimeters/5.1 centimeters
Minimum Operators Required for Loading/Unloading 1
Recommended Cot Fastener Systems Model 6372 Center Mount, Straight Guide
Model 6373 Center Mount DIN Guide
Recommended Floor/Tray Height 27 inches –31 inches
(68.6 centimeters –78.8 centimeters)
!Height measured from bottom of mattress at seat section to ground level.
@Standard base unit is weighed without optional accessories.
Stryker reserves the right to change specifications without notice.
The M1 Roll–In System is designed to conform to BS EN 1865, specifications for stretchers and other patient handling equipment used in
road ambulances and BS EN 1789 medical vehicles and their equipment –road ambulances.

Base Component Identification
1–13
FOOT END
HEAD END
HEAD END

Cot Operation
1–14
Guidelines for Operation
SUse the Cot only as described in this manual.
SRead and understand all labels and instructions on the cot before using the cot.
SDo not adjust, roll or load the cot without advising the patient. Stay with the patient and control the cot
at all times.
SAlways use all the restraint straps and keep the siderails up (optional equipment) when a patient is on the
cot.
SUse properly trained helpers when necessary to control the cot and the patient. Do not allow untrained
helpers to assist in the operation of the cot.

Cot Operation
1–15
CHANGING COT HEIGHT
The Cot has six height positions (see
page 1–16):
SThe highest or “Loading”position,
Sfour intermediate patient transfer positions,
Sa “Folded”position for ambulance transport.
WARNING
The caster steer lock knob and the casters must be in the
locked position when loading/unloading the cot from a ve-
hicle or loading tray system and when the cot height is
changed or the cot may become unstable possibly result-
ing in injury to the patient or operator.
The higher the operator must lift the cot, the more difficult
it becomes to hold the weight. The operator may need
help loading the cot into a vehicle if he/she is too short or
if the patient is too heavy for the operator to lift safely. If
additional assistance is needed, see the reference chart
on page 1–19.
The operator must be able to lift the cot high enough for
the cot’s base frame to unfold completely and lock when
the cot is unloaded. A shorter operator will have to raise
his/her arms higher to enable the base frame to unfold.
If additional assistance is needed, see the reference
chart on page 1–19.
Always verify the base frame is securely locked into posi-
tion before releasing the hand grips.
To change the cot height:
Two operators standing at opposite ends of the cot firmly
grasp the hand grips on the base unit.
Both operators lift the cot until the weight is off the latch-
ing mechanism (approximately 1/4”).
Both operators squeeze and hold the red release handles
and raise or lower the cot to the desired height.
As motion of the cot begins, each operator relaxes his/
her grip on the release handle to stop the cot in the next
available height position.
NOTE
Always communicate with your partner to ensure you
work together to achieve the intended operation.
An operator working alone can lower the cot by releasing
alternating ends of the cot.
FOOT END
HEAD END
Red Release
Handle
Red Release
Handle
Red Release
Handle
Red Release
Handle

1–16
Cot Positions
Position 2 –Intermediate Height Position
Position 4 –Intermediate Height Position
Use for patient transfer.
Position 3 –Intermediate Height Position
Use for patient transfer.
Use for patient transfer.
Position 6 –Loading position –Use for patient
transfer, folding or loading the cot or cot rolling.
Position 1 –Intermediate Height Position
Use for patient transfer.
Position 7 –Folded position –Use for
transporting in an ambulance.
Position 8 –Trendelenburg
Position 5 –Intermediate Height Position
Use for patient transfer.

Cot Operation
1–17
Loading the Cot into a Vehicle
WARNING
The caster steer lock knob and the casters must be in the locked position when loading/unloading the cot from
a vehicle or loading tray system and when changing cot height positions or the cot may become unstable
possibly resulting in injury to the patient or operator.
Loading, unloading and changing the position of the cot requires a minimum of one trained operator. The
operator(s) must be able to lift the total weight of the patient, cot and any other items on the cot. (If additional
assistance is needed, see the reference chart on page 1–19).
The higher the operator must lift the cot, the more difficult it becomes to hold the weight. The operator may
need help loading the cot into a vehicle if he/she is too short or if the patient is too heavy for the operator to
lift safely. If additional assistance is needed, see the reference chart on page 1–19.
The operator must be able to lift the cot high enough for the cot’s base frame to unfold completely and lock
when the cot is unloaded. A shorter operator will have to raise his/her arms higher to enable the base frame
to unfold. If additional assistance is needed, see the reference chart on page 1–19.
Place the cot in the loading position (see page 1–16). Roll the cot to the vehicle or loading tray system until
the cot’s loading wheels are in the vehicle or loading tray system. Guide the cot forward until the cot’s front
legs contact the rear of the vehicle or loading tray system.
At the foot end of the cot, push and hold the green safety release button and squeeze and hold the green
release handle.
Guide the cot into the vehicle or loading tray system (the front legs will fold back) until the rear legs come in
contact with the vehicle or loading tray system. Relax your grip on the green release handle and green button.
Lift the foot end of the cot slightly to take the weight off the rear wheels. Squeeze and hold the red release
handle and guide the cot into the vehicle or loading tray system (the rear legs will fold back) engaging the
cot fastener system.
NOTE
Loose items or debris on the patient compartment floor can interfere with the smooth rolling of the cot and
the operation of the cot fastener. Keep the patient compartment floor clear.

Cot Operation
1–18
Unloading the Cot from a Vehicle
WARNING
The caster steer lock knob and the casters must be in the locked position when loading/unloading the cot from
a vehicle or loading tray system and when changing cot height positions or the cot may become unstable
possibly resulting in injury to the patient or operator.
Loading, unloading and changing the position of the cot requires a minimum of one trained operator. The
operator(s) must be able to lift the total weight of the patient, cot and any other items on the cot. If additional
assistance is needed, see the reference chart on page 1–19.
The higher the operator must lift the cot, the more difficult it becomes to hold the weight. The operator may
need help loading the cot into a vehicle if he/she is too short or if the patient is too heavy for the operator to
lift safely. If additional assistance is needed, see the reference chart on page 1–19.
The operator must be able to lift the cot high enough for the cot’s base frame to unfold completely and lock
when the cot is unloaded. A shorter operator will have to raise his/her arms higher to enable the base frame
to unfold. If additional assistance is needed, see the reference chart on page 1–19.
Always verify the base frame is securely locked into position before removing the loading wheels from the
patient compartment floor of the vehicle or loading tray system. An unlocked base frame will not support the
cot and injury to the patient or operator could result.
Disengage the cot from the cot fastener system.
Grasp the hand grips at the foot end of the cot base frame securely and squeeze and hold the red release
handle. Guide the cot out of the vehicle or loading tray system until the rear legs lower and fully extend.
Release the red release handle when the legs are fully extended.
After verifying the rear legs are securely locked in place, continue to guide the cot out of the vehicle or loading
tray system until the front legs of the cot lower and lock into position. It may be necessary to lift the cot slightly
to allow the legs to fully extend and lock. After verifying the front legs are securely locked in place, pull the
cot away from the ambulance until the loading wheels clear the patient compartment floor.

Cot Operation
1–19
Using Additional Assistance
Operator Operator
Helper
Helper
Changing Levels Rolling
Two
Operators
Two
Helpers
Two
Operators
Four
Helpers
Loading/Unloading
Operator
OperatorHelper
Helper
Operator OperatorHelper
Helper Helper
Helper
Operator
Operator
Helper
Helper
Operator
Operator
Helper
Helper
Helper
Helper
Operator Operator
Helper
Helper Helper
Helper
