Quick start guide for
Altrix™Precision Temperature Management System
Setup
Fill the reservoir
The removable reservoir is translucent for you
to see the water levels.
1. Fillthereservoirwithvelitersofsterile
distilledwater.Donotllpastthelllineto
avoidwateroverow.
2. If you remove the reservoir from the
controllertollitwithsteriledistilledwater,
replaceitbygentlyloweringthereservoir
backintoposition.Makesurethatitissecure.
Power on
1. Plugthepowercordintoawalloutlet.
2. TaptheStand-bybuttontostarttheproduct.
A
•Always use sterile distilled water or water that has been
passedthroughalterlessthanorequalto0.22microns
withthisproduct.
•Alwaysllthereservoirwithroomtemperaturesterile
distilled water to reduce the risk of burn.
•Donotoverllthereservoirtoavoidtheriskofwater
spillageandfall.
Caution
!
Quick start guide for
Altrix™Precision Temperature Management System

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 2A
Connecting thermal transfer devices
Therearetwoconnectortypesfor
Stryker’sthermaltransferdevices:
Clik-Titeandcolderstyle.
Pre-filling the thermal transfer devices
1. Openalloftheclampsontheconnectorhoseandthermal
transfer device.
2. Makesurethatthecontrolleris
powered.
3. TaptheManualmodebutton.
4. TapConrm.
5. Selectawatertemperaturethat
alignswithyourtargetpatient
temperature.Allowthewaterto
owfromthecontrollerintothe
thermal transfer device until full.
6. TapConrm.
Connecting patient
temperature probe
•AlignthereddotontheReusable
AdapterCable(B)tothecontroller
(A) probeportAorB.
•Connecttheplug(C)tothepatient
temperatureprobe.
Selecting primary probe
1. TaptheSettingsbutton.
2. TapSelectProbetodisplaythe
SelectPrimaryProbe(ProbeAor
ProbeB)screen
Note:Primaryprobewilldefault
to Probe A.
3. TapConrm.
Connecting patient
temperature output cable
Thisfeatureallowstheoperatorto
viewthetemperatureontheAltrix
systemandonaseparatedevice.
•Insertthereusablepatient
temperatureoutputcableintothe
patienttemperatureoutputport,
located in between the Probe A and
ProbeBports.
AlwaysuseStrykeraccessories.Failuretocomplywiththese
instructions may invalidate any or all warranties and may
negativelyaffecttheproductsEMCperformance.Thisalso
protectstheproductfromcardiacdebrillation.
Patient
temperature
ptrobe
Reusable
adaptercable
Probeport
(AorB)
Colder
style
Clik-Tite
Caution
!
Caution
!Alwayspre-llthethermaltransferdevicewithsteriledistilled
waterbeforeyouapplyittothepatient.Thisistoreducetherisk
ofpressureinjuries.

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 3A
Initiation of therapy
Selecting a therapy mode
Youcanselectfromoneofthesethreemodes:
•Automatic(therapy)
•Manual(therapy)
•Monitor(non-therapy)
Automatic therapy
InAutomaticmode,thetherapycoolsorwarmsthepatienttoaselected
patienttargettemperature.Theproductcontinuallymeasuresthe
patienttemperatureandautomaticallyadjuststhewatertemperature
untiltheselectedpatienttargettemperatureisachieved.
Cooling
Warming
SelectAutomatictherapy
modeandconrm
PressEdit
SelectTargetTemperature
andconrm
SelectTargetTemperature
andconrm
SelectMax,Med,Min
andconrm
SelectMax,Med,Minor
Customandconrm
Quick start guide for
Altrix Precision Temperature Management System

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 4A
Manual therapy
InManualmode,theproductcontrolsthewatertemperatureonly.A
temperatureprobeisnotrequiredwhenoperatinginmanualmode.
Display the patient data graph
Todisplaythepatientdatagraph,tapthegraphicon.
Thepatientdatagraphstoresthefollowingvariables:
•Primarypatienttemperaturereading(A)
•Intermediatetargettemperature(B)
•Watertemperature(C)
•Powerlevel(D)
Pause therapy
•Topausetherapy,pressandholdthePauseTherapy
button for two seconds.
•Toresumetherapy,pressandholdthePauseTherapy
button for two seconds.
Stop therapy
•PressandholdtheStand-bybuttonfortwoseconds.
•Unplugtheproductfromthewalloutlet.
•Opentheclampsforapproximately10minutestoallow
the water to drain back into the controller.
•Closeclampstostopthewaterowanddetach
wrapsfromhoses.
A
B
C
D
Select Manual therapy mode
and conrm
Select desired water
temperature

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 5A
Product functions
Icon Name Function
Stand-by Pressandholdthebuttonfortwosecondstostoptherapyorpoweroff
Therapypaused Pressandholdthebuttonfortwosecondstopauseorresumetherapy
Viewtemperature SelecttemperaturedegreeinCelsiusorFahrenheit
Lock / unlock screen Pressandholdthebuttonfortwosecondstolockorunlockthegraphical
user interface
Audiopaused Pauseorresumetheaudibleindicatorwhenanalarmisactive.Silenceseach
alarmforveortenminutesdependingonthealarmcondition.Thisbutton
breathes¹toindicatethatitisinapausedstate.
Automatictherapymode Coolsorwarmsthepatienttoaselectedpatienttargettemperature
Manualtherapymode Coolsorwarmsthewatertoaselectedwatertargettemperature
Monitoronlymode Displaysthecurrentpatienttemperature(notherapy)
Thegraphicaluserinterfaceshownisforreference
only.Theimageshowswhereyouwillseetheiconsand
buttons illuminate when they are active. At no time
will you see all of these icons at the same time.
Quick start guide for
Altrix Precision Temperature Management System

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 6A
Icon Name Function
Increase Increasesthewaterorpatienttemperatureby0.1°forcoolingorwarming
temperature
Note:Pressandholdtheincreasebuttontomovethetemperatureupfaster.
Decrease Decreasesthewaterorpatienttemperatureby0.1°forcoolingorwarming
temperature
Note:Pressandholdthedecreasebuttontomovethetemperaturedown
Back Returnstothepreviousscreenorcancelanoperation
Editsettings,Exit,orCancel Editcurrentsettings,exit,orcancel.
Conrmselection Acceptstheselectedsettings
NextorMore Changestothenextscreen,option,orsetting
Pageindicators(mayalso
appearvertical)
Indicatesthatthereismorethanonepageassociatedwiththescreentopic
forthepagethatiscurrentlydisplayed
Settings Displaysthesummaryofthecurrent,visual/audible,language,orprimary
probesettings
Graph Graphicaldisplayoftheselecteditemssuchaspatienttemperature,target
temperature,watertemperature,andpowerlevel
Help Displayscontextualhelpscreensfortherapies,navigation,buttons,
and alarm screens
¹Breathe:Thebrightnessofthebuttonoriconwillgotoalowlightandthenincreasetoabrightlight.Thiscyclerepeats.
Product functions
(continued)

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 7A
Icon Function
Watertemperatureontarget,
solidgreenwhenactive,doesnot
breathe
Patienttemperatureontarget
PatientprobeAport,stabilized
PatientprobeBport,stabilized
Externaldevice,patientprobeA
Externaldevice,patientprobeB
Stand-by
Icon Function
Waterowdetected,ports1,2,or3
areactive,solidgreenwhenactive,
does not breathe
Coolingtherapy
Warmingtherapy
Currenttherapyduration
Total duration
Visual and audible tests
Targetpatientorwater
temperature
|
Product functions
(continued)
Quick start guide for
Altrix Precision Temperature Management System

8001-069-002 Rev B.2Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 8A
Alarms
Icon Name Alarm
priority Message Therapy
interrupted Check
Watertemperature
deviation
Medium Watertemperatureis±0.8°C(1.4°F)
outsideoftargettemperature
No Temporaryconditionuponstartup,additionfthermaltransferdevice,or
addition of water
No water Medium No water Yes Check for leaks
Add a minimum of 2 liters of sterile distilled water
Nowaterow Medium Noowdetected Yes Checkforleaksandobstructionsatconnections,hoses,andthermal
transfer devices
Checkwaterowon
anyport
Medium Reducedowdetected No TapConrm,ifthewaterportwasremovedintentionallyCheckforleaks
andobstructionsatconnections,hoses,andthermaltransferdevices
Power loss Medium Notapplicable Yes Checkpowercordconnection
Checkpatientprobe
(AorB)
Medium Abnormalchangeinpatient
temperature
Yes Checkprobecondition,location,andconnections
Probeoradapter
malfunction(AorB)
Medium Notemperaturesignaldetected Yes Checkprobeoradaptercablecondition,location,andconnections
Adaptercable
disconnected(AorB)
Medium Adaptercablenotdetected Yes Reinserttheadaptercable.Ifdamaged,replacetheadaptercable
Patienttemperature
deviation
Medium Patienttemperatureis±0.5°C(0.9°
F)outsideoftargettemperature
No Checkpatientcondition,placementofthermaltransferdevices,andall
connections
Normothermia
deviation
Low Patienttemperatureisoutsideof
36.0°C(96.8°F)to38.0°C(100.4°F)
No Checkpatientcondition,placementofthermaltransferdevices,andall
connections
Therapypause Medium Therapyiscurrentlypaused Yes Toresume,pressandholdtheplay/pausefor2seconds
Batterylow Low Batteryislow No Maintenanceisrecommended.Ifbatteryisnotreplaced,theproductmay
notfunctiononthenextstartup.
Patienttemperature
output(AorB)
Low Patienttemperatureoutputis
inaccurateontheexternaldevice,
oroutsidesupportedrange
No Checkoutputadaptercableconnection.TapConrmtoreactivatethe
outputport.
Removefromuse
(RFU)
Medium Thesystemhaspoweredoffdueto
a malfunction
Yes Removetheproductfromuseimmediately.Notifytheappropriate
personnel.
Ifanyofthealarmconditionspersist,callmaintenance.
Ifthepageindicatorsappearonthealarmscreen,therearemultipleactivealarms.Onlythehighestalarmisdisplayed.

8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 9A
Quick start guide for
Altrix Precision Temperature Management System
Disinfecting
Disinfect the internal water circuit and hoses every 14 days
UsetheBruCleanTbCdisinfectanttabletsbyBrulin(EPAregistration
number71847-2-106)beforerstuse,atleastevery14days,andbefore
storage.BruCleanTbChasbeenvalidatedforinternalwatercircuit
disinfection.Makesurethatyoufollowthedisinfectantmanufacturer’s
guidelinestoavoidtheriskofinjury.Failuretofollowthedisinfectant’s
instructions may void your warranty.
Caution
!• Alwaysusesteriledistilledwaterorwaterthathasbeenpassed
throughalterlessthanorequalto0.22micronswiththisproduct.
• Do not disinfect the internal water system with a thermal transfer
device attached as this may cause a leak.
• Donotusebleachoranyothercleaningordisinfectantagentsfor
internalcircuits.Thiscouldresultindamagetotheproduct.Only
useapproveddisinfectanttablets.
• Alwaysdraintheproductbeforedisinfectingtheinternalwater
circuit.Failuretodraintheproductmayreducetheeffectiveness
ofthedisinfectionprocess.
Tools required:
•2gallons(11.4L)ofsteriledistilledwaterorwaterthathasbeenpassed
throughalterlessthanorequalto0.22microns
•Personalprotectionequipment(PPE)asrecommendedbythedisinfectant
manufacturer’sinstructions
•Soft,lintfreecloth(2ormore)
•2BruCleanTbC13.1gtablets(ActiveingredientNaDCCsolutionppm=
1874mg/L)
Note:BruCleanTbCisablendof48%sodiumdichloroisocyanturateand
AdipicAcidwitha5%sodiumdodecylbenzenesulphonatesurfactant.
•Servicetooladapterhose(8001-999-017)forColderstyleconnectorhoses
•Floor drain
SeeProductillustrationonpage10ofthemanualforclaricationofproduct
componentnamesandlocations.
Draining the internal water circuit and hoses for disinfection
1. Unplugthepowercordfromthewalloutlet.
2. Placethecontrolleroveraoordrain.
Note:Forbestresults,theoordrainshouldbewithinreachofawalloutlettopoweronthecontroller.
3. Todrainthecontroller,pulluponthecontrollerdrainplug(A)toopenthe
drain(Figure24).Leavethedrainopen. Figure 24
Note: Disinfection
oftheAltrix
internal water
system was
validatedusing
M. mucogenicum.

8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 10A
Draining the internal water circuit and hoses for disinfection (cont.)
Figure 25 Figure 27 Figure 28
Figure 26
4. Connectahosetoeachport(Figure25).
5. Closetheconnectorendsofallthreehoses:
a. IfyouhaveColderstyleconnectorhoses,attachtheservicetool
adapterhose(8001-999-017)(Figure26).Completethisforallthree
hoses.
b. IfyouhaveClik-Titehoses,makesurethattheconnectorendsare
connectedandclosed(A),andclampsareopen(B).Completethisforall
threehoses(Figure27).
6. Tofullydrainthehoses,raiseallthehoses(Figure28)abovethe
connectionportsonthecontroller.
Note:Forbestperformance,hangthehosestokeepthemraised.Donot
lowerthehosesuntilyouhavecompletedthedisinfectionandrinsing
process.
7. Allow the controller and hoses to drain for a minimum of two minutes.
8. Pushdownonthedrainplugtoclosethedrain.
1. UsepersonalprotectionequipmentasrecommendedbytheBruCleanTbC
disinfectantmanufacturer’sinstructionsforuse.
2. Put2BruCleanTbCtabletsintothereservoir.
3. Usingappropriatemeasuringequipment,lltheemptyreservoirwith1
gallon(3.8L)ofsterile-distilledwater.
Note: Alwaysallowthedisinfectanttabletstocompletelydissolve
beforestartingthe20minutedisinfectioncycle.
4. Place the reservoir into the controller.
5. Disconnectthebottomhosefromthebottomrightport(Figure29).
6. Connect the bottom hose end to the hydraulic connector in the lid of the
reservoir(Figure30).
7. Plugthepowercordintoawalloutlet.
Figure 29 Figure 30
Disinfecting the internal water circuit and hoses

8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 11A
Quick start guide for
Altrix Precision Temperature Management System
8. Press andholdtheStand-bybutton.
9. Tap theManualmodeicon.
10. TapConrm.
11. Setthewatertargettemperatureto25.0°C(77.0°F).
12. TapConrm.
13. Runthecontrollerfor20minutes.
14. After20minutes,turnthecontrolleroffbypressingandholdingthe
Stand-bybuttonfortwoseconds.
15. Unplugthepowercordfromthewalloutlet.
16. Placethecontrolleroveraoordrain.
17. Removethereservoir.Pullforwardatanangle,andliftoutthe
reservoir.
18. Removethebottomhoseendfromthehydraulicconnectoradapterin
thereservoirlidbypushingdownonthecollar.
19. Emptywaterfromthereservoir,disposeofthewater
perhospitalprotocol.
20. Pulluponthecontrollerdrainplug(Figure31)
toopenthedrain.
21. Makesurethatall3hosesremainraisedabovetheconnectionports
fordraining.
22. Allow the controller and hoses to drain for a minimum of two minutes.
23. Pushdownonthecontrollerdrainplugtoclosethedrain.
24. Whenthecontrollerandhosesaredrained,continuetoRinsingthe
internal water circuit and hoses.
Disinfecting the internal water circuit and hoses (cont.)
Figure 31

8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 12A
1. Usingappropriatemeasuringequipment,lltheemptyreservoirwith
1gallons(3.8L)ofsterile-distilledwater.
2. Place the reservoir into the controller.
3. Connect the bottom hose end to the hydraulic connector in the lid of
thereservoir(Figure32).
4. Plugthepowercordintoawalloutlet.
5. PressandholdtheStand-bybutton.
6. TaptheManualmodeicon.
7. TapConrm.
8. Selectthewatertargettemperatureof25.0°C(77.0°F).
9. TapConrm.
10. Allowthecontrollertorunfor5minutes.
Note:Thetimerwillrunonthemain
display,followthecurrenttherapydurationtimer.
11. After5minutes,turnthecontrolleroffbypressingandholdingthe
Stand-bybuttonfortwoseconds.
12. Unplugthepowercordfromthewalloutlet.
13. Placethecontrolleroveraoordrain.
14. Removethereservoir.Pullforwardatanangle,andliftoutthereservoir.
15. Removethebottomhoseendfromthehydraulicconnectoradapterin
thereservoirlidbypushingdownonthecollar.
16. Emptywaterfromthereservoir,disposeofthewaterperhospital
protocol.
17. Pulluponthecontrollerdrainplugtoopenthedrain.
18. Makesurethatall3hosesremainraisedabovetheconnectionports
fordraining.
19. Allowthecontrollerandhosestodrainforaminimumoftwominutes.
20. Pushdownonthecontrollerdrainplugtoclosethedrain.
21. Wipetheinsideandoutsideofthereservoirandreservoirlid,withadry,
soft,lintfreecloth.
22. Place the reservoir into the controller.
23. Disconnectandstoretheservicetooladapterhosesfromallthreeofthe
hoses.(Ifapplicable,whenusedwithcolderstylehoses.)
24. Storethepowercord,cables,andhoses.
Rinsing the internal water circuit and hoses
Figure 32
