Stryker InTouch FL27 series User manual

2009/04 2131-009-005 REV A www.stryker.com
Operations Manual
InTouch™ Critical Care Bed
InTouch™ Intensivpflegebett
Letto per terapia intensiva InTouch™
InTouch™-bed voor kritieke zorg
Κρεβάτι εντατικής θεραπείας InTouch™
Model/Modell/Modello/Μοντέλο FL27 (2131/2141)
Bedienungsanleitung
Manuale d’uso
Gebruikshandleiding
Εγχειρίδιο λειτουργιών
For parts or technical assistance call:
Ersatzteile oder technische Unterstützung:
Per parti o assistenza tecnica chiamare i seguenti numeri
Voor onderdelen of technische bijstand belt u:
Για εξαρτήματα ή τεχνική βοήθεια καλέστε:
USA/VS/Η.Π.Α.: 1-800-327-0770 (option 2 /opzione 2/ optie 2/επιλογή 2), Canada/Kanada/Καναδάς: 1-888-233-6888
Version 2.2
0086

International Addresses
EASTERN EUROPE
Stryker SA - Export Business
Grand-Rue 90
P.O. Box 1567
1820 Montreux, Switzerland
Phone: [phone]
Fax: [phone]
AUSTRIA
Stryker-Howmedica Osterreich GmbH
Millenium Tower
Handelskai 94-96
120 Wien
Austria
Phone: [phone]
Fax: [phone]
BELGIUM
NV Stryker SA
Ikaros Business Park- Fase III
Ikaroslaan 12
1930 Zaventem, Brussels
Belgium
Phone: [phone]
Fax: [phone]
DENMARK
Stryker Denmark
Filial of Stryker AB
Postbox 772
1532 Copenhagen
Denmark
Phone: [phone]
Fax: [phone]
ENGLAND
Stryker UK Limited
Stryker House
Hambridge Road
Newbury, Berkshire
RG14 5EG, England
Phone: [phone]
Phone: [phone]
Fax: [phone]
POLAND
Stryker Polska Sp. ZO.O
Kolejowa 5/7
01-217 Warsawa
Poland
Phone: [phone]
Fax: [phone]
PORTUGAL
Stryker Portugal Produtos
Medicos, LTDA.
Avenida Marechal Gomes
da Costa, 35
1800-255 Lisboa
Portugal
Phone: [phone]
Fax: [phone]
ROMANIA
Stryker Osteonics Romania S.R.L.
19, Leonida Str.
District 2
7000 Bucharest
Romania
Phone: [phone]
Fax: [phone]
SOUTH AFRICA
Stryker Osteonis PTY. LTD.
3 Susan Street
Strydom Park
Johannesburg, 2194 - South Africa
Mailing Address:
P.O. Box 48039
2129 Roosevelt Park
Johannesburg, South Africa
Phone: [phone]
Fax: [phone]
SPAIN
Stryker Howmedica Iberica S.L.U.
Manual Tovar, 35
28034 Madrid
Spain
Phone: [phone]
Phone: [phone]
Fax: [phone]
SWEDEN
Stryker AB/Scandinavia
Box 50425
SE-204 14 Malmo
Sweden
Phone: [phone]
Fax: [phone]
FINLAND
Stryker AB, Finland
PO 80 Makelankatu 2
00501 Helsinki
Finland
Phone: [phone]
Fax: [phone]
FRANCE
Stryker France SA
ZAC - Avenue de Satolas Green
69330 Pusignan
France
Phone: [phone]
Fax: [phone]
GERMANY
Stryker Howmedica GmbH
Dr. Homer Stryker Platz 1
47228 Duisburg
Germany
Phone: [phone]
Fax: [phone]
GREECE
Stryker Hellas EPE
455 Messogion ave
153 43 Agia Paraskevi
Athens, Greece
Phone: [phone]
Fax: [phone]
ITALY
Stryker Italia SrL
Via Ghisalba 15B
00188 Roma
Italy
Phone: [phone]
Fax: [phone]
MIDDLE EAST / NORTH AFRICA
Stryker Osteonics SA
Twin Towers
11th Floor, Suite 1101 & 1102
P.O. Box 41446
Baniyas Road
Dubai, Deira, UAE
Phone: [phone]
Fax: [phone]
NEDERLANDS
Stryker Nederlands BV
(P.O. Box 13, 4180 BA Waardenburg)
4181 CD Waardenburg
The Nederlands
Phone: [phone]
Fax: [phone]
NORWAY
Stryker Norway
Norsk Fillial
Nedre Vollgate 3
0158 Oslo
Norway
Phone: [phone]
Fax: [phone]
EUROPE HEADQUARTERS
Stryker SA
Cite-Centre, Grand-Rue 90
P.O. Box 1568
1820 Montreux, Switzerland
Phone: [phone]
Fax: [phone]
www.stryker.com

English
www.stryker.com 2131-009-005 REV A 1-1
Table of Contents
Introduction ............................................................................1-4
IntendedUse........................................................................1-4
ProductDescription...................................................................1-4
ProductIllustration....................................................................1-4
Specifications.......................................................................1-5
Specifications(Continued)..............................................................1-6
Warning/Caution/NoteDefinition........................................................1-6
Symbols...............................................................................1-7
SummaryofSafetyPrecautions.............................................................1-8
Optional Zoom®DriveSystem(Model2141Only)............................................1-10
SetupProcedures.......................................................................1-11
OptionalXPRTTherapyMattress........................................................1-12
Optional PositionPRO™ Patient Repositioning Mattress Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Applyingthelinens...............................................................1-13
Optional Zoom®DriveSystem(Model2141Only)............................................1-13
ModesofOperation.....................................................................1-14
PoweringtheBed....................................................................1-14
ModesofOperationwiththeBattery .....................................................1-14
BaseOperationGuide ...................................................................1-15
Brake/Drive/NeutralOperation........................................................1-15
ElectronicMode.................................................................1-15
ManualMode...................................................................1-15
LitterOperationGuide ...................................................................1-16
CPREmergencyRelease..............................................................1-16
LoweringtheFowlerDuringaPowerFailure.............................................1-16
Foley Bag Hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
PatientRestraintLocations.............................................................1-16
NightLightUsage ...................................................................1-16
NurseCallUsage....................................................................1-17
AuxiliaryPowerOutletUsage...........................................................1-17
HeadandFootboardOperation .........................................................1-17
PositioningtheSiderails...............................................................1-18
BedPositioning.....................................................................1-19
SiderailOperationGuide..................................................................1-20
SiderailMotionControlPanel,NurseControl ...............................................1-20
BedPositioningDescriptions ...........................................................1-21
Siderail Brake/Motion Control Panel, Nurse Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-22
OptionalPendantControl..............................................................1-23
FootboardOperationGuide................................................................1-24
ControlPanel.......................................................................1-24
SystemMessageIndicatorLights........................................................1-25
MainMenu:PatientInformation .........................................................1-26
PatientInformation,NewPatient .....................................................1-27
PatientInformation,Configure.......................................................1-27
MainMenu:BedControls .............................................................1-28

English
1-2 2131-009-005 REV A www.stryker.com
Table of Contents
Footboard Operation Guide (Continued)
MainMenu: Scale .................................................................1-29
ZeroButton.....................................................................1-31
WeightHistoryButton.............................................................1-32
ChangeEquipmentButton..........................................................1-33
ChangeWeightButton.............................................................1-34
GainorLossButton ..............................................................1-35
MainMenu: BedExit.................................................................1-37
MainMenu:SupportSurfaces..........................................................1-39
AirMattressOptions..............................................................1-39
XPRT Mattress Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-39
InTouch™integratedwiththeXPRTMattress ...........................................1-39
PositionPRO™MattressSpecifications.................................................1-40
Interaction Between InTouch™andPositionPRO™........................................1-40
Specific PositionPRO™ Functionality on the InTouch™.....................................1-40
TimeSetupButton ...............................................................1-42
SmartTVButton(Optional).........................................................1-42
LanguageButton.................................................................1-42
AdvancedOptions Button..........................................................1-43
HistoryButton...................................................................1-44
NurseControlBacklightButton......................................................1-46
MaintenanceButton ..............................................................1-46
MainMenu: Lockouts................................................................1-47
Main Menu: iBed ...................................................................1-48
iBed,Awareness.................................................................1-48
iBed,ProtocolReminder...........................................................1-49
iBed,ProtocolReminder(Continued)..................................................1-50
iBed,HeadofBed(HOB)History.....................................................1-51
iBed,BedHeightHistory...........................................................1-51
iBed,Calculator .................................................................1-52
iBed,Converter..................................................................1-52
iBed,Translations................................................................1-53
iBed,Documentation..............................................................1-54
iBed,BradenScale...............................................................1-55
iBed,SoundTherapy..............................................................1-56
ZOOM®DriveOperations(Model2141).......................................................1-57
Using the Zoom®Drive(Model2141)......................................................1-57
OptionalBedAccessories.................................................................1-58
BedExtender-FA64234..............................................................1-59
PermanentI.V.Pole-FA64221..........................................................1-60
DualHeadEndPermanentI.V.Pole-FA64202..............................................1-62
Line Management System (Accessory Clip) - FA64210 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-64
MonitorTray-FA64214...............................................................1-66
UprightOxygenBottleHolder-FA64187...................................................1-68
RightFitOxygenBottleHolder-FA64203..................................................1-69

English
www.stryker.com 2131-009-005 REV A 1-3
Table of Contents
Optional Bed Accessories (Continued)
PendantwithMotionControlOnly-FA64209...............................................1-70
PendantwithMotionControl/NurseCall-FA64194...........................................1-71
PendantwithMotionControl/SmartTV-FA64195............................................1-72
Pendant with Motion Control/NC/Smart TV - FA64193 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-73
PendantClip-FA64186...............................................................1-74
TractionSleeve-FA64215throughFA64219................................................1-75
WallSaver-FA64208 ................................................................1-76
X-RayCassetteHolder-FA64205 .......................................................1-77
Cleaning..............................................................................1-78
BedCleaning.......................................................................1-78
MattressCare......................................................................1-78
PreventativeMaintenance.................................................................1-79
Checklist..........................................................................1-79
Warranty .............................................................................1-80
LimitedWarranty....................................................................1-80
ToObtainPartsandService ...........................................................1-80
ServiceContractCoverage ............................................................1-80
ServiceContractPrograms ............................................................1-81
ReturnAuthorization..................................................................1-81
DamagedMerchandise ...............................................................1-81
InternationalWarrantyClause...........................................................1-81
RecyclingPassports.....................................................................1-82

English
1-4 2131-009-005 REV A www.stryker.com
Return To Table of Contents
INTENDED USE
This manual is designed to assist you with the operation of Stryker InTouch™ Critical Care Bed Model FL27 (2131/2141).
Carefully read this manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe
operation of this equipment, it is recommended that methods and procedures be established for educating and training
staff on the safe operation of this bed.
This Operations Manual is an integral part of the bed and should be included if the bed is sold or transferred.
PRODUCT DESCRIPTION
This product is intended to be used as an Intensive Care Unit bed.
PRODUCT ILLUSTRATION
Introduction
Nurse Control
Panel
Casters
ZOOM®Drive Wheel
(Model 2141 only)
(Under base -
not shown)
Siderails
Footboard
Control Panel
Footboard
Nurse Call
Foley Bag
Hooks
CPR Emergency
Release Pedal
Manual
Backup
Siderail
Release
Levers
Brake Control
Panel
Headboard
InTouch™
Screen

English
www.stryker.com 2131-009-005 REV A 1-5
Return To Table of Contents
Introduction
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the
sum of the patient, mattress and accessory
weight.
550 lbs 250 kg
Bed Weight 750 lbs 340.2 kg
Overall Bed Length 90” 228,6 cm
Overall Bed
Width
Siderails Up 42” 106,7 cm
Siderails Down 41” 104,1 cm
Base Under Bed Clearance 5” 12,7 cm
Litter Patient Surface
• Width
• Length
• Length (with Optional Bed Extender)
35”
84”
90”
88,9 cm
213,4 cm
228,6 cm
Seat Section
• Depth 18.5” 47 cm
Foot Section
• Length
• Angle 29”
0° to 50°
73,7 cm
0° to 50°
Fowler Section
• Length
• Width
• Angle
36”
34” to 35”
0° to 70°
91,4 cm
86,4 cm - 88,9 cm
0° to 70°
Gatch Section
• Length
• Width
• Angle
18”
34” to 35”
0° to 15°
45,7 cm
86,4 cm - 88,9 cm
0° to 15°
Cardiac Chair
• Standard Cardiac Chair Position
• Enhanced Cardiac Chair Position Head: 65°, Seat: 17°, Foot: 30°, Trend: 3°
Head: 70°, Seat: 19°, Foot: 47°, Trend: 3°
Fowler Length 36.5” 92,7 cm
Bed Lift
System
Height (high) to top of litter 31” 78,7 cm
Height (low) to top of litter 16” 40,6 cm
Trendelenburg/Reverse Trendelenburg 12°
Bed Lift Time 35 seconds maximum from lowest to highest position
Scale System Capacity 550 lbs 250 kg
Accuracy:
• For weight from 100 lb to 550 lb
• For weight from 100 lb to 550 lb
• For weight under 100 lb
• For weight under 100 lb
+/- 2% when in Trendelenburg or Reverse Trendelenburg
+/- 1% when Flat
+/- 2 lb when in Trendelenburg or Reverse
Trendelenburg
+/- 1 lb when Flat
CPR System Speed to level bed from any position
• Fowler
• Foot
• Seat
15 seconds
60 seconds
30 seconds
Drive System Speed (Optional ZOOM®Drive)
• Forward
• Backwards 3.6 mph
2.5 mph
5.8 km/h
4.0 km/h

English
1-6 2131-009-005 REV A www.stryker.com
Return To Table of Contents
Introduction
SPECIFICATIONS (CONTINUED)
Mattress
Recommended Mattress Size 35” x 84” x 6” 88,9 cm x 213,4 cm x 15,2 cm
Recommended Air Mattress Size 35” x 84” x 6” - 8.5” 88,9 cm x 213,4 cm x
15,2 cm - 21,6 cm
Maximum
Current
Consumption
Without Optional Auxiliary Outlet
(120VAC Only) 4.8 Amps
With Optional Auxiliary Outlet(s)
(120VAC Only) 9.8 Amps
Environmental
Conditions
Storage
• Ambient Temperature
• Relative Humidity
• Atmospheric Pressure
-40°F to 158°F
10 to 100%
500 to 1060 hPa
-40°C to 70°C
Operating
• Ambient Temperature
• Relative Humidity
• Atmospheric Pressure
50°F to 104°F
30 to 75%
700 to 1060 hPa
10°C to 40°C
Electrical
Requirements
All electrical requirements meet CSA
C22.2 No. 601.1, UL 60601-1 and IEC
60601-1.60601-2-38 specifications.
100V~, 50-60Hz, 7.5A - Two 250V, 10A Fuses
120 ± 10% Vac, 50/60Hz - Two 250V, 10A Fuses
120V~, 50-60Hz, 4.0A (9.8A with 120V Optional Auxiliary
Outlet) - Two 250V, 10A Fuses
200V~, 50-60Hz, 3.2A -Two 250V, 6.3A Fuses
220V~, 50-60Hz, 2.9A -Two 250V, 6.3A Fuses
240V~, 50-60Hz, 2.7A -Two 250V, 6.3A Fuses
Battery
12 V, 17.6 Ahr, Sealed Lead-Acid Battery (Part Number QDF9188)
3.0 V 220mAh Lithium Battery, Size 20mm - Varta Int. CR2032
Coin Cell PC Battery Holder, Size 20mm - MDP Int. BA2032
Stryker reserves the right to change specifications without notice.
Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION, and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to
the user or patient or damage to the equipment or other property. This includes special care necessary for the safe
and effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use
or misuse.
Note
This provides special information to make maintenance easier or important instructions clearer.
