Stryker 5050 User manual

2017/05 A.1 5050-109-001 REV A www.stryker.com
Operations Manual
Stretcher Chair
5050
5051

sample text

www.stryker.com 5050-109-001 REV A
Symbols
Operating instructions
General warning
Caution
No pushing
Catalogue number
Serial number
For US Patents see www.stryker.com/patents
CE mark
EC REP
Manufacturer
Safe working load
Type B applied part

sample text

www.stryker.com 5050-109-001 REV A 1
Table of Contents
Warning/Caution/Note Definition ..................................................................................................................3
Summary of safety precautions....................................................................................................................4
Pinch points .......................................................................................................................................5
Introduction..............................................................................................................................................6
Product description..............................................................................................................................6
Indications for use...............................................................................................................................6
Expected service life............................................................................................................................6
Contraindications ................................................................................................................................6
Specifications.....................................................................................................................................6
Product illustration (Model 5050)............................................................................................................8
Contact information .............................................................................................................................8
Serial number location .........................................................................................................................9
Date of manufacture............................................................................................................................9
Operation .............................................................................................................................................. 10
Applying and releasing the brakes ........................................................................................................ 10
Raising or lowering the litter................................................................................................................. 10
Positioning the product in Trendelenburg................................................................................................ 11
Positioning the product in Reverse Trendelenburg.................................................................................... 11
Raising or lowering the siderails ........................................................................................................... 12
Raising and lowering the Fowler backrest (Model 5050) ............................................................................ 12
Raising and lowering the Fowler backrest (Model 5051) ............................................................................ 13
Adjusting the footrest ......................................................................................................................... 14
Positioning the foot section in dependent (chair) mode.............................................................................. 14
Positioning the foot section in independent mode ..................................................................................... 15
Positioning the push bar ..................................................................................................................... 15
Removing and installing the mattress..................................................................................................... 16
Positioning the enhanced clearance headpiece ....................................................................................... 16
Accessories ........................................................................................................................................... 17
Hanging devices from the surgery accessory rail ..................................................................................... 17
Positioning the adjustable arm board (Model 5051) .................................................................................. 17
Positioning the wrist rest ..................................................................................................................... 17
Installing the drape support and air delivery system .................................................................................. 18
Attaching and positioning the removable IV pole ...................................................................................... 19
Attaching the tethered IV pole.............................................................................................................. 20
Locating the patient restraint strap tie-ins ............................................................................................... 21
Cleaning................................................................................................................................................ 23
Cleaning the product.......................................................................................................................... 23
Cleaning the mattress ........................................................................................................................ 23
Remove iodine.................................................................................................................................. 24
Special instructions ........................................................................................................................... 24
Disinfecting............................................................................................................................................ 25
Disinfecting the product...................................................................................................................... 25
Disinfecting the mattress .................................................................................................................... 25

2 5050-109-001 REV A www.stryker.com
Table of Contents
Preventive maintenance ........................................................................................................................... 27

www.stryker.com 5050-109-001 REV A 3
Warning/Caution/Note Definition
The words WARNING,CAUTION, and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the
user or patient or damage to the product or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
Note: Provides special information to make maintenance easier or important instructions clearer.

4 5050-109-001 REV A www.stryker.com
Summary of safety precautions
Carefully read and strictly follow the warnings and cautions listed on this page. Service only by qualified personnel.
WARNING
• Always apply the brakes when a patient is getting on the product or off the product or when the product is not
moving. Injury could result if the product moves while a patient is getting on the product or off the product.
• Always place, remove, or transfer the patient from the center (seat) section of the product unless the product is in
the full chair position. Product instability or tip may occur.
• Always put the product in the chair position with the siderails up and latched when you leave a patient unattended
on the product. Do not leave the product in the horizontal (flat) position to avoid a patient fall.
• Do not sit on either end of the product. The product may tip.
• Always keep the product in the chair position when not in use.
• Always lock the siderails in the full up position when you transport a patient.
• Do not allow the siderails to lower on their own.
• Always keep the patient’s limbs away from the siderail spindles when you lower the siderail.
• Always keep hands and fingers clear of the Fowler backrest release handles and the Fowler backrest frame when
you lower the Fowler backrest.
• Always use caution when you raise a pneumatic Fowler backrest while a patient is on the product. Use proper lifting
techniques and get assistance, if necessary.
• Hold the foot rest firmly while repositioning it to prevent it from falling to the lowest position and causing injury or
equipment damage.
• Do not stand on the footrest. Tipping may occur which could result in patient or use injury.
• Always support the patient’s head when you position the headpiece or the Fowler backrest. Patient injury may occur.
• Do not reach between the side of the head extension and the articulating headpiece to pull the release handles.
Operator injury may occur.
• Always keep fingers away from jointed areas when you adjust the headpiece. Operator injury may occur.
• Always use caution when you attach restraint straps. Patient or operator injury may occur. Physical restraints, even
if secured, may result in serious harm to patients and operators, including entanglement, entrapment, physical injury,
or death.
• Always attach restraint straps or devices only at the identified attachment points of the product. Failure to do so
may result in patient or operator injury. Do not attach restraint straps to the siderail.
• Always refer to the applicable state and federal restrictions and regulations and the appropriate facility protocols
before you use any restraint strap or device.
• Do not clean, service, or perform maintenance while the product is in use.
• Do not immerse the mattress in cleaning or disinfectant solutions. Excess moisture could cause product
malfunction that results in product damage or patient injury.
• Do not allow fluid to pool on the mattress. Fluids can cause corrosion of components and may cause the safety and
performance of this product to become unpredictable.
• Always inspect mattress covers for tears, punctures, excessive wear, and misaligned zippers every time you clean
the covers. Remove and replace a damaged mattress immediately to prevent cross-contamination.
• Do not steam clean, pressure wash, hose off, or ultrasonically clean mattresses. These methods of cleaning may
void this product’s warranty.
• Always disinfect the mattress between patients. Failure to do so could result in cross-contamination and infection.

www.stryker.com 5050-109-001 REV A 5
Summary of safety precautions
CAUTION
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in
this manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable
operation resulting in injury to patient or operator. Modifying the product also voids its warranty.
• Always remove any devices that may be in the way before you raise or lower the litter.
• Do not raise the product (hydraulics on base) with a patient lift under the product.
• Always support the foot section while you position the foot section to make sure that the footrest does not fall.
Patient or operator injury or device damage may occur.
• The maximum PSI level for the drape support/oxygen tubing is 20 PSI (1.38 Bars/140 KPA).
• Do not use the IV pole as a push/pull device. Product damage may occur.
• Do not hang IV bags that exceed 40 lb (18 kg) on the IV pole.
• Always make sure that the IV pole is at a low height to pass through door openings when you transport a patient.
• Some cleaning agents are corrosive in nature and may cause damage to the product if you use them improperly. If
you do not properly rinse and dry the product, a corrosive residue may be left on the surface of the product that
could cause premature corrosion of critical components. Failure to follow these cleaning instructions may void your
warranty.
Pinch points

6 5050-109-001 REV A www.stryker.com
Introduction
This manual assists you with the operation or maintenance of your Stryker product. Read this manual before operating
or maintaining this product. Set methods and procedures to educate and train your staff on the safe operation or
maintenance of this product.
CAUTION
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in
this manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable
operation resulting in injury to patient or operator. Modifying the product also voids its warranty.
Notes
• This manual is a permanent part of the product and should remain with the product even if the product is sold.
• Stryker continually seeks advancements in product design and quality. This manual contains the most current
product information available at the time of printing. There may be minor discrepancies between your product and
this manual. If you have any questions, contact Stryker Customer Service or Technical Support at 1-800-327-0770.
Product description
The Stryker Model 5050 and Model 5051 Eye Stretcher Chair is a wheeled stretcher that consists of a platform mounted
on a wheeled frame to transport patients in a substantially horizontal position within the interior of a healthcare facility by
healthcare professionals or trained representatives of the healthcare facility. The Stretcher Chair can be positioned as a
chair or in a horizontal position. It offers siderails, supports for fluid infusion devices, and various options and
accessories that assist with the support and positioning of the patient and transport of the patient.
Indications for use
The Stretcher Chair is for use in all acute care hospitals and medical outpatient services. The Stretcher Chair may be
used for minor procedures and short-term stay, typical of existing stretcher applications, including outpatient clinical
evaluation, treatment, minor procedure, and outpatient recovery. It is for use with all patients, including those mildly to
critically ill.
Expected service life
The Eye Stretcher Chair has a 10 year expected service life under normal use conditions and with appropriate periodic
maintenance.
Contraindications
None known.
Specifications
Safe working load
Note: Safe working load indicates the sum of the
patient, mattress and accessory weight.
400 lb 181 kg
Overall length 76 in. 193 cm

www.stryker.com 5050-109-001 REV A 7
Introduction
Specifications (Continued)
Overall width/litter 30 in. / 27.5 in. 76 cm / 70 cm
Height
High 33.5 in. 85 cm
Low 22 in. 55.5 cm
Litter positioning
Backrest 0° to 90°
Leg 0° to 80°
Trendelenburg/Reverse
Trendelenburg
±18°
Patient surface 24 in. x 74 in. 61 cm x 188 cm
Siderails ±45°
Standard 10 in. x 31 in. 25 cm x 79 cm
Caster diameter/width 6 in. 15 cm
Stryker reserves the right to change specifications without notice.

8 5050-109-001 REV A www.stryker.com
Introduction
Product illustration (Model 5050)
A
B
C
D
E
F
G
H
I
K
L
M
J
A Armrest H Gatch
BBase hood storage area IHead piece, enhanced clearance
CBrake/steer pedal JPump pedal
DBumper K Siderail
E Casters L Siderail locking latch
F Footrest M Uni-lower pedal
GFowler backrest, pneumatic
Contact information
Contact Stryker Customer Service or Technical Support at: 1-800-327-0770.
Stryker Medical
3800 E. Centre Avenue

www.stryker.com 5050-109-001 REV A 9
Introduction
Contact information (Continued)
Portage, MI 49002
USA
To view your operations or maintenance manual online, see https://techweb.stryker.com/.
Have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical
Support. Include the serial number in all written communication.
Serial number location
A
Date of manufacture
The year of manufacture is the first 2 digits of the serial number.

10 5050-109-001 REV A www.stryker.com
Operation
Applying and releasing the brakes
WARNING
Always apply the brakes when a patient is getting on the product or off the product or when the product is not moving.
Injury could result if the product moves while a patient is getting on the product or off the product.
To apply the brakes, push down on the brake (red) side of the brake/steer pedal. Push on the product to make sure that
the brakes work.
To release the brakes, push down on the steer (green) side of the brake/steer pedal.
Raising or lowering the litter
WARNING
• Always place, remove, or transfer the patient from the center (seat) section of the product unless the product is in
the full chair position. Product instability or tip may occur.
• Always put the product in the chair position with the siderails up and latched when you leave a patient unattended
on the product. Do not leave the product in the horizontal (flat) position to avoid a patient fall.
• Do not sit on either end of the product. The product may tip.
• Always keep the product in the chair position when not in use.
CAUTION
• Always remove any devices that may be in the way before you raise or lower the litter.
• Do not raise the product (hydraulics on base) with a patient lift under the product.
To raise the litter, pump the pump pedal (A) repeatedly until you achieve the desired height (Figure 1 on page 11).
To lower the entire litter, press on both pedal (B) and pedal (C) at the same time.
To lower the head end of the litter, depress pedal (B).
To lower the foot end of the litter, depress pedal (C).

www.stryker.com 5050-109-001 REV A 11
Operation
Raising or lowering the litter (Continued)
A
A
B
C
C
B
Figure 1: Raising or lowering the litter
Positioning the product in Trendelenburg
CAUTION
• Always remove any devices that may be in the way before you raise or lower the litter.
• Do not raise the product (hydraulics on base) with a patient lift under the product.
To position the product in the Trendelenburg position (head down):
1. Raise the litter (Raising or lowering the litter on page 10).
Note: The higher the litter is before putting the product in Trendelenburg position, the greater the Trendelenburg
angle will be.
2. Push down on pedal (B) (Figure 1 on page 11) until you reach the desired position.
To lower the product from Trendelenburg position, push down on both pedals (B and C) at the same time until the
litter is flat.
Positioning the product in Reverse Trendelenburg
CAUTION
• Always remove any devices that may be in the way before you raise or lower the litter.
• Do not raise the product (hydraulics on base) with a patient lift under the product.

12 5050-109-001 REV A www.stryker.com
Operation
Positioning the product in Reverse Trendelenburg (Continued)
To position the product in the Reverse Trendelenburg position (foot down):
1. Raise the litter (Raising or lowering the litter on page 10).
2. Push down on pedal (C) (Figure 1 on page 11) until you reach the desired position.
To lower the product from Reverse Trendelenburg position, push down on both pedals (B and C) at the same time.
Raising or lowering the siderails
WARNING
• Always lock the siderails in the full up position when you transport a patient.
• Do not allow the siderails to lower on their own.
• Always keep the patient’s limbs away from the siderail spindles when you lower the siderail.
To raise the siderails, pull out on the locking latch. Raise the siderail to the full up position (Product illustration (Model
5050) on page 8). Pull on the siderail to make sure that the siderail is latched.
To lower the siderails, pull out on the locking latch. Lower the siderail to the full down position.
Note: The siderail will be tucked beneath the litter when you lower the siderail to the full down position.
Raising and lowering the Fowler backrest (Model 5050)
WARNING
• Always keep hands and fingers clear of the Fowler backrest release handles and the Fowler backrest frame when
you lower the Fowler backrest.
• Always use caution when you raise a pneumatic Fowler backrest while a patient is on the product. Use proper lifting
techniques and get assistance, if necessary.
To raise the Fowler backrest, squeeze the red handle (A) toward the Fowler backrest frame, not toward the push bar (B).
Raise the Fowler backrest to the desired position (between 0 degrees and 90 degrees) (Figure 2 on page 13).
To lower the Fowler backrest, squeeze the red handle (A) toward the Fowler backrest frame, not toward the push bar
(B). Push the Fowler backrest down to the desired position (between 0 degrees and 90 degrees).

www.stryker.com 5050-109-001 REV A 13
Operation
Raising and lowering the Fowler backrest (Model 5050) (Continued)
A
B
Figure 2: Fowler backrest
Raising and lowering the Fowler backrest (Model 5051)
WARNING
• Always keep hands and fingers clear of the Fowler backrest release handles and the Fowler backrest frame when
you lower the Fowler.
• Always use caution when you raise a pneumatic Fowler backrest while a patient is on the product. Use proper lifting
techniques and get assistance, if necessary.
To raise the Fowler backrest, squeeze the red handle (A) toward the Fowler backrest frame. Raise the Fowler backrest
to the desired position (between 0 degrees and 90 degrees) (Figure 3 on page 13).
To lower the Fowler backrest, squeeze the red handle (A) toward the Fowler backrest frame. Push the Fowler backrest
down to the desired position (between 0 degrees and 90 degrees).
A
A
Figure 3: Fowler backrest

14 5050-109-001 REV A www.stryker.com
Operation
Adjusting the footrest
WARNING
• Hold the foot rest firmly while repositioning it to prevent it from falling to the lowest position and causing injury or
equipment damage.
• Do not stand on the footrest. Tipping may occur which could result in patient or use injury.
Note: The leg section must be down in order to adjust the foot rest. The foot rest must be rotated halfway up to the leg
section in order to adjust the height.
To raise the footrest:
Rotate the foot rest halfway up, then slide it toward the butt section until you reach the desired height. While pulling the
foot rest out toward you, rotate it down to a horizontal position. The foot rest will drop into the next lower position.
To lower the footrest:
While grasping the foot rest firmly, rotate it up and push back on it. When it clears its latch, it will drop down. Rotate the
foot rest down to a horizontal position.
Positioning the foot section in dependent (chair) mode
CAUTION
Always support the foot section while you position the foot section to make sure that the footrest does not fall. Patient or
operator injury or device damage may occur.
To put the foot section in dependent (chair) mode, rotate the red handle (A), located on both sides of the foot section,
toward the head end of the product (Figure 4 on page 14).
A
Figure 4: Position of red handle in dependent (chair) mode

www.stryker.com 5050-109-001 REV A 15
Operation
Positioning the foot section in dependent (chair) mode (Continued)
Note: In dependent (chair) mode, the foot section articulates with the Fowler backrest when the product moves from the
sitting position to the supine position.
Positioning the foot section in independent mode
CAUTION
Always support the foot section while you position the foot section to make sure that the footrest does not fall. Patient or
operator injury or device damage may occur.
To put the foot section in independent mode, rotate the red handle (A), located on both sides of the foot section, toward
the foot end of the product (Figure 4 on page 14).
To reposition the foot section, hold the foot end and pull the red handle (A) toward you. Lift or lower the foot section to
the desired position and lock the red handle in place.
To reset the foot section to the dependent (chair) mode, support the foot section and rotate the red handle (A) toward
the head end of the product. Lift or lower the foot section until the foot section locks in place. Raise and lower the
Fowler backrest and make sure that the foot section moves with the Fowler backrest.
Note: In independent mode, the foot section articulates to any position independent of the Fowler backrest.
Positioning the push bar
To lower the push bar, support the push bar and pull the red release knob (A) (Figure 5 on page 15). Swing the push bar
into the full down position until it latches.
To raise the push bar, support the push bar and pull the red release knob (A). Swing the push bar into the full up
position it latches.
A
Figure 5: Red release knob

16 5050-109-001 REV A www.stryker.com
Operation
Removing and installing the mattress
To remove the mattress, from the head end of the product, pull on the head end of the mattress to pull the mattress
away from the Velcro on the Fowler backrest and midsection. Continue to pull the mattress toward the head end of the
product to release the mattress from the foot section sliding tabs.
Note: The foot section sliding tabs keep the foot section of the mattress close to the litter surface during articulation.
To install the mattress, slide the pockets on the foot end back over the sliding tabs. Place the mattress on the rest of the
litter surface. Press firmly on the Fowler backrest and midsection to secure the Velcro strips.
Positioning the enhanced clearance headpiece
WARNING
• Always support the patient’s head when you position the headpiece or the Fowler backrest. Patient injury may occur.
• Do not reach between the side of the head extension and the articulating headpiece to pull the release handles.
Operator injury may occur.
• Always keep fingers away from jointed areas when you adjust the headpiece. Operator injury may occur.
To adjust the articulating headpiece:
1. Squeeze right handle (A) under the head section to release the latch. Rotate the headpiece on axis “A” (head)
(Figure 6 on page 16).
A
B
Figure 6: Positioning the articulating headpiece
2. Squeeze left handle (B) under the head section to release the latch. Rotate the head section on axis “B” (neck).
Note: For ease of use, release only one latch at a time.
