Introduction
2
INTRODUCTION
This manual is designed to assist you with the operation of the Model ASC Stretcher. Read it thoroughly be-
fore using the equipment or beginning any maintenance on it.
SPECIFICATIONS
Maximum Weight Capacity 500 pounds
Overall Stretcher Length 84” (.5”)
Overall Stretcher Width (Siderails Up) 33.5” & 37” (.5”)
Overall Stretcher Width (Siderails Down) 30.25” & 30.75” (.5”)
Minimum / Maximum Bed Height 21.5” / 36” (.5”)
Fowler Angle 0 to 90°( 3°)
Trendelenburg / Reverse Trendelenburg +16 / −16 °( 1°)
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also
describe potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate
injury to the user or patient or damage to the equipment or other property. This includes special care neces-
sary for the safe and effective use of the device and the care necessary to avoid damage to a device that
may occur as a result of use or misuse.
NOTE
This provides special information to make maintenance easier or important instructions clearer.
Return to Table of Contents
Back to Table of Contents

Introduction
3
Before operating this stretcher, it is important to read and understand all information in this manual. Carefully
read and strictly follow the warnings and cautions listed on this page.
WARNING
Always apply the caster brakes when a patient is getting on or off the stretcher. Push on the stretcher to en-
sure the brakes are securely locked. Always engage the brakes unless the stretcher is being moved. Injury
could result if the stretcher moves while a patient is getting on or off the stretcher. If brakes do not hold proper-
ly, refer to your stretcher maintenance manual for a brake adjustment procedure.
When lowering the siderail to the collapsed position, keep extremities of patients and staff away from the side-
rail spindles or injury could occur.
Keep fingers/hands clear of area around Fowler release handle and Fowler frame when lowering. Injury could
result if care is not taken when lowering the Fowler.
If the stretcher is equipped with the optional foot end IV pole, the IV pole must be in the raised position when
the foot extension/defibrillator tray is installed. If the IV pole is not raised, the foot extension will not function
properly and injury could occur.
CAUTION
To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height.
To avoid injury or damage to the equipment, do not allow the siderail to lower on its own.
To avoid damage, the weight of the I.V. bags should not exceed 40 pounds.
To avoid damage while transporting the stretcher, verify the I.V. pole is at a low enough height to allow it to
safely pass through door openings and under light fixtures.
To avoid damage, do not put items weighing more than 30 pounds on the serving tray.
Return to Table of Contents
Back to Table of Contents

Stretcher Operation
4
OPERATING BASE CONTROLS − SIDE CONTROL
Pump pedal (A) to raise the litter.
Depress in the center of pedal (B) to lower
Depress the side of pedal (B) closest to the
Pedal (C) − Brake and Steer functions (foot end)
Pedal (D) − Brake and Steer functions (head end)
both ends of the stretcher together.
foot end of the stretcher to lower the foot end.
Depress the side of pedal (B) closest to the
head end of the stretcher to lower the head end.
D
CA
AB
B
HEAD ENDFOOT END
Return to Table of Contents
Back to Table of Contents

Stretcher Operation
5
RAISING AND LOWERING LITTER HEIGHT − SIDE CONTROL
CAUTION
To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height.
To raise the litter height, pump pedal (A) repeatedly until the desired height is achieved (see illustration on
page 4).
To lower both ends of the litter together, depress the center of pedal (B). To lower only the head end of the
litter, depress the side of pedal (B) closest to the head end. To lower only the foot end of the litter, depress
the side of pedal (B) closest to the foot end (see illustration on page 4).
TRENDELENBURG/REVERSE TRENDELENBURG − SIDE CONTROL
NOTE
Litter height must be raised first in order to achieve a trend. or reverse trend. position.
CAUTION
To avoid damage, remove any equipment that may be in the way before lowering the stretcher.
For Trendelenburg positioning (head down), depress the side of pedal (B) closest to the head end of the
stretcher (see illustration, page 4).
For Reverse Trendelenburg positioning (foot down), depress the side of pedal (B) closest to the foot end.
NOTE
The higher the litter is before pedal (B) is activated, the greater the trend. or reverse trend. angle will be.
(Maximum trend. angle is +16_. Maximum reverse trend. angle is −16_).
Return to Table of Contents
Back to Table of Contents

Stretcher Operation
6
APPLYING THE BRAKE SYSTEM
Brake/Steer
Pedal
Brake/Steer
Pedal
(Optional)
(Optional)
FOOT END HEAD END
BA
NOTE
For user convenience, a brake/steer control pedal is located on both ends of the stretcher.
WARNING
Always apply the caster brakes when a patient is getting on or off the stretcher. Push on the stretcher to en-
sure the brakes are securely locked. Always engage the brakes unless the stretcher is being moved. Injury
could result if the stretcher moves while a patient is getting on or off the stretcher. If brakes do not hold proper-
ly, refer to your stretcher maintenance manual for a brake adjustment procedure.
To engage the brakes on the head end, push fully down on the left side of pedal (A).
To engage the brakes on the foot end, push fully down on the right side of pedal (B).
NOTE
Your stretcher may be equipped with optional side control brake and steer functions in addition to the standard
head and foot end controls. The side control brakes operate the same as the head and foot end versions.
OPERATING THE FIFTH WHEEL
The purpose of the Fifth Wheel is to help guide the stretcher along a straight line during transport and to help
pivot the stretcher around corners.
To engage the fifth wheel, push the proper side of the brake/steer pedal to the full down position.
Return to Table of Contents
Back to Table of Contents

Stretcher Operation
7
OPERATING THE GLIDEAWAYtSIDERAILS
A
B
B
FOOT END
NOTE
Raising and lowering the siderails safely is a two−handed operation. Use one hand to hold and position the
siderail and the other hand to operate the siderail latch.
WARNING
When lowering the siderail to the collapsed position, keep extremities of patients and staff away from the side-
rail spindles or injury could occur.
To raise the siderails: Pull up on the siderail (A) and raise it to the full up position until the latch (B) engages.
To lower the siderails: Pull up on the latch (B) and guide the siderail to the full down position.
NOTE
The latches (B) are colored yellow for easy identification.
The foot end of the siderail top rail can be used as a push/pull handle.
CAUTION
To avoid injury or damage to the equipment, do not allow siderail to lower on its own.
NOTE
There is a dual siderail latch option available with latches on both ends of the stretcher.
Return to Table of Contents
Back to Table of Contents

Stretcher Operation
8
OPERATING THE PNEUMATIC FOWLER
Squeeze either or both of the yellow Fowler handles (A) for pneumatic assist in lifting the Fowler to the desired
height. Remove hand(s) from handle when the desired height is achieved.
The optional drop seat/lift assist Fowler uses the weight of the patient for additional assistance with lifting the
Fowler. It also helps keep the patient from sliding toward the foot end of the stretcher when the Fowler is
raised.
AA
WARNING
Keep hands/fingers clear of the area around the Fowler release handles and the Fowler frame when lowering.
Injury could result if care is not taken when lowering the Fowler.
Return to Table of Contents
Back to Table of Contents

Stretcher Operation
9
OPERATING THE OPTIONAL 2−STAGE PERMANENTLY ATTACHED IV POLE
A
C
BA
C
DETAIL OF I.V. POLE LATCH
NOTE
The 2−stage permanently attached IV pole is an option and may have been installed at either the head, foot
or both ends of the stretcher. The choice was made at the time the stretcher was purchased.
To use the 2−stage permanently attached IV pole:
1. Lift and pivot the pole from the storage position and push down until it is locked into the receptacle.
2. To raise the height of the pole, pull up on the telescoping portion (A) until it locks into place at its fully raised
position.
3. Rotate the IV hangers (B) to desired position and hang the IV bags.
4. To lower the IV pole, turn the latch (C) until section (A) lowers.
CAUTION
To avoid damage, the weight of the IV bags should not exceed 40 pounds.
To avoid damage while transporting the stretcher, verify the IV pole is at a low enough height to allow it to
safely pass through door openings and under light fixtures.
