Summer Extra Tall & Wide Arch User manual

Extra Tall & Wide Arch Safety Gate
USER MANUAL
Please read the following instructions carefully.
Keep this instruction manual and
save for future reference.
For technical support, contact us at 1-401-671-6551
or www.summerinfant.com/contact
Tools required: Qty. 2-Phillips-head screwdrivers (not included),
measuring tape (not included),
and wrench (included).
For use with children from 6 - 24 months.
Keep small parts away from children.
Adult assembly required.
Fits openings from 28" - 42" wide.

components
Gate Door
Gate Frame Hinge
A
B
Gate Frame Hinge Side
Gate Frame Latch Side
C
DBinding Bolts (6)
I
Base Frame Connector
E
Lower Gate Frame Hinge
Door Stopper
F
G
Small Extension Frame (3)
H
LTension Bolts with Tension Nuts (4)
M
Binding Posts (6)
J
K
Wall Cups (4)
Wall Anchors (4)
N
O
Wall Screws (4)
Wrench
P
Q
Hinge Post
R
Adhesive Mounting Pads (4)
2
hardware
L
x4 x4
M
J
x6 x6
K
NO
P
R
Q
x4 x4
x1
x1
x4
HCD
BA
E
G
F
Children have died or been seriously injured when gates are not securely installed.
• ALWAYS install and use gate as directed using all required parts.
• Install according to manufacturer’s instructions.
• Stop using when a child can climb over or dislodge the gate.
• Use only with the locking/latching mechanism securely engaged.
• To prevent falls, never use at top of stairs without wall mounting cups and door stopper.
• You MUST install wall cups to keep gate in place. Without wall cups, child can push out and escape.
• NEVER use a gate to keep child away from pool.
• NEVER leave child unattended.
• ALWAYS close and lock the gate behind you.
• This product will not necessarily prevent all accidents. Proper adult supervision is required at all times.
• Do not use if any components are missing or damaged.
• Adult assembly required. Exercise care when unpacking and assembling product.
CAUTION: KEEP SMALL PARTS OUT OF CHILD’S REACH.
WARNING
Door Latch
I

3
assembly
1
R
x 2
J
x 2
K
Lower the gate frame hinge
onto the gate door.
Attach with 2 binding bolts
and 2 binding posts.
Attach Lower Gate Frame Hinge using
2 binding bolts and 2 binding posts.
Attach gate door to the Gate
Frame Hinge Side and insert
Hinge Post through openings
in Gate Frame Hinge Side.
2
34
B
G
x 2
J
x 2
K
NOTE:
This is
easier to
do when
using two
Phillips
head
screw-
drivers.

4
56
assembly (cont.)
Slide the gate frame hinge side and door
and the gate frame latch side into the base
frame connector.
Attach using 2 binding
bolts and 2 binding posts.
x 2
J
E
7
x 2
K
NOTE:
The gate will appear
off-center until you add the
tension bolts, mount it into
the door frame and tighten
the bolts according to the
instructions.

gate configurations (choose which best fits your scenario)
5
Measure the width of the opening where you intend to install the gate. Refer to the following
illustrations to determine the correct installation conguration. Baseboard molding may change which
conguration is appropriate.
A B
CD
(28"- 30.25") without extension frames (31.5"- 34.25") with one extension frame
(35.5"- 38.25") with two extension frames (39.5"- 42") with three extension frames
Important: Gate includes a door stop
(part F) which prevents the gate from
swinging open in one direction.
When installing the gate at the TOP OF
STAIRS, be sure that the door stop is
used so the door cannot open over the
stairs.
!
Note: This instruction book illustrates
installation of gate conguration C.
If choosing gate conguration A, skip
ahead to step 2. Otherwise, follow step 1
using the appropriate extension frames
that best t your scenario.
!
F

6
installation
L
x 4
1
!
• If choosing gate conguration A, skip this step.
• If choosing gate conguration B or C, add the desired extension frames to either side of the gate frame.
• If choosing gate conguration D, add all 3 extensions to the gate frame.
Slide tension bolts into
upper and lower holes on
both sides of extension
frames (or into the gate
frame if no extensions are
being used).
2

AB
Checking the gate fit in the door frame
Check distances A & B. The distance
between the gate and the wall should
never exceed 2.75 in.
IMPORTANT
3
7
A. Stand the gate in the center of the
opening. Make sure the bottom of the gate is
completely flush to the floor.
B. Slide tension bolts out until they contact
the door frame or wall on both sides.

Checking the gate fit in the door frame (cont.)
4
5
8
Use the tension nuts to
tighten both of the bottom
tension bolts.
Use the tension nuts to
tighten both of the top
tension bolts.
tighten!
tighten!
tighten!
tighten!
Proceed to Wall Cup Installation section once check is complete.

2
1
wall cup installation
You MUST install wall cups to keep gate in place.
Without wall cups, child can push out and escape.
With a pencil, trace the
entire outline of each
tension bolt directly
onto the wall.
Loosen the lower
and upper
tension nuts and
remove gate.
9
x 4
loosen!
x 2
loosen!
x 2
At the top of the
landing, position the
gate a minimum of
3-6 inches (8-15cm)
away from the top
step.
IMPORTANT
WARNING

3
NOTE: Skip this step if:
- mounting directly into wood,
- if installing at the bottom
of the stairs ONLY
!
x 4
x4
wall cup installation (continued)
1
st
Drill a 7/32''pilot hole
into each of the 4
center marks.
Drill a 7/32'' pilot hole
into each of the 4
center marks.
2
nd
Insert wall anchors
into pilot holes.
Insert wall anchors
into pilot holes.
4
10
O
Place a wall cup
over the center of
each circular
outline on the wall.
Mark drill holes
with a pencil
through the center
of each wall cup.
NOTE: Skip this step if:
- if installing at the bottom
of the stairs ONLY
!

peel!
peel!
2
nd
3
rd
1
st
5
!
wall cup installation (continued)
press!
press!
press!
press!
6
11
x 4
M
x 4
N
Remove backing
from one side of each
adhesive mounting pad.
Align the wall cups so
the center hole is placed
directly over the wall
anchor. Stick the wall
cups to the wall.
Make sure all
wall cups are
facing up.
Attach one pad to the
back of each wall cup.
Remove backing.

x4
x 4
wall cup installation (continued)
7
8
12
P
Screw wall
cups into wall.
x 4
Repeat "installation"
steps on page 7&8.
The 4 tension bolts will
rest within each wall cup.
NOTE:
Screws are ONLY required
for top of stair use.
!

Q
wall cup installation
x 4
13
FINISHED!
Tighten all 4 tension nuts with the
provided wrench.
9
Make sure
when tightening
the bolts the red pin
on the door is not
visible when the
door is closed.
Red pin
If any problems installing,
refer to trouble shooting
on page 16.

confirming the installation
push!
push!
1
st
2
nd
1. Close the gate. Make sure the upper latch is locked securely
and the red pin is not visible when the door is closed.
2. Make sure the gate is installed with the door stopper opposite side of stairs.
3. Push on the gate to check.
4. Door latch is on the stair side.
Push the gate
and frame to
check stability.
Important: Gate includes a door stopper (part F) which prevents the gate from swinging
open in one direction. When installing the gate at the top of stairs, be sure that the door
stopper is on the opposite side from the stairs so if a child was at the top of the stairs they
can not push the door open over the stairs.
!
F
Make sure
the door stopper is
on the opposite
side of the stairs.
3
rd
Red pin
Door latch is on the
stair side.
4
th
14

15
operation
to unlock gate:
1st
2nd
First, slide locking tab back to release. Second, lift gate door up
and then swing out to open.

If the gate does not close properly:
1. Gate is not properly aligned in the door
frame.
Solution: To adjust the gate’s alignment,
loosen all four tension bolts and reposition
gate so that it matches the “correct” image.
Re-tighten tension nuts.
2. Pressure of tension bolts needs
adjusting.
Solution: Loosen or tighten the upper tension
nuts. Ensure the upper latch handle always
remains below the release button. Ensure the
upper latch handle engages securely when the
gate swings closed and that it releases
properly when the release button is pressed.
troubleshooting
maintenance
• Regularly check tension bolts to make sure the gate is securely in place.
• Do not use the gate if any components are damaged or missing.
• Surface-clean with a damp cloth or sponge using mild detergent and warm water.
correct!
incorrect!
Colors and styles may vary.
MADE IN CHINA.
D0000000776 5/20
Summer Infant (USA), Inc.
1275 Park East Drive
Woonsocket, RI 02895 USA
1-401-671-6551
© 2020 Summer Infant (USA), Inc.
We're here to help!
If you have any questions or need assistance,
contact our Consumer Relations Team at
1-401-671-6551 or www.summerinfant.com/contact
Mis-aligned
Gate at top is installed
further back then
the bottom of gate
Aligned in door frame
from top to bottom
#33240-50
