Sun Power PERFORMANCE P6-COM-S-BF User manual

Engineered for
Performance
• Smaller cells stay cooler when
shaded, extending panel life3
• An advanced encapsulant
minimizes degradation from
environmental exposure
• Conductive adhesive defends
against daily temperature
swings
• Redundant cell connections
create flexible paths for
continuous electricity flow
PERFORMANCE 6COM
| 485–510
Framed
Glass-Glass
Making the conventional, exceptional
Shingled Cell Bifacial Commercial
The SunPower Performance P6-COM-S-BF panel is
engineered to meet the unique needs of solar power
plants. Bifacial power generation and G12 (210mm)
cell technology combine to maximise power density,
while its framed glass/glass construction offers
greater durability for extended panel life.
Backed by an comprehensive warranty and an estimated 35-year useful
life,1SunPower Performance panels wrap conventional front contact cells
with 35 years of materials, engineering and manufacturing expertise to
mitigate the reliability challenges of Conventional Panel design.
Durability that Translates to More Energy
Engineered to stand up to environmental stresses such as shading, daily
temperature swings and high humidity, the SunPower Performance P6
COM is a high power panel uniquely suited for power plant EPCs and
developers looking to maximize energy production.
A Track Record of Innovation Leadership
SunPower Performance panels represent the most deployed shingled
cell panel in the industry—innovation protected by a growing portfolio
of patents worldwide.2
6+ GW
Deployed
60+
Countries
90+
Patents
A Better Product. A Better Warranty.
SunPower Performance panel is backed by the SunPower Performance
COM panel warranty providing 25-year product and power coverage.
• Year 1 Minimum Warranted Power Output 98.0%
• Maximum Annual Degradation 0.45%
• Year 25 Warranted Power Output 87.2%
POWER RANGE: 485–510 W
sunpower.maxeon.com

Mechanical Data
Impact Resistance 25 mm diameter hail at 23 m/s
Solar Cells Monocrystalline PERC
Glass 2.0mm, Heat Strengthened Glass
Junction Box IP-68, 3 bypass diodes
Connector Zerun Z4S or Stäubli Evo2
Weight 29.6 kg
Max. Load Wind: 2400 Pa, 245 kg/m² front & back
Snow: 5400 Pa, 550 kg/m² front
Frame Anodized Aluminum Alloy
Electrical Data
Bifaciality (φPmax) 70% +/–10%
Maximum System Voltage 1500 V IEC
Temperature −40°C to +85°C
Maximum Series Fuse 25 A
Power Temp. Coef. –0.34% / ° C
Voltage Temp. Coef. –0.26% / ° C
Current Temp. Coef. 0.05% / ° C
Tests And Certifications
Standard Tests IEC 61215, IEC 61730 Rated to 1500 V
Fire Rating Class C (IEC 61730)
Quality Certs ISO 9001:2015, ISO 14001:2015
EHS Compliance ISO 45001-2018, Recycling Scheme
Ammonia Test IEC 62716
Dust and Sand IEC 60068-2-68
Salt Spray Test IEC 61701 (maximum severity)
LeTID Test TUV 2fg 2689/04.19 (LeTID Detection)
PID Test IEC 62804
35 mm
1092 mm
2185 mm
35 mm
B
FRAME PROFILE
(A) Cable lengths:
(-) 1200 mm +/-15 mm
(+) 300 mm +/-15 mm
(B) Long Side: 30 mm
Short Side: 16 mm
1 Performance panels expected useful life of 35 years. Source: “SunPower P-
Series Technology Technical Review,” Leidos Independent Engineer Report.
2016.
2 Osborne. "SunPower supplying P-Series modules to a 125MW NextEra
project." PV-Tech.org. March 2017.
3 SunPower Performance Series – Thermal Performance, Z.Campeau 2016.
4 Measured at Standard Test Conditions (STC): irradiance of 1000 W/m², AM
1.5, and cell temperature 25° C.
5 The additional gain from the back side compared to the power of the front
side at the standard test condition. It depends on mounting (structure, height,
tilt angle etc.) and albedo of the ground.
Designed in the U.S.A.
Assembled in China
Specifications included in this datasheet are subject to change without notice.
© 2022 Maxeon Solar Technologies, Ltd. All Rights Reserved. View warranty,
patent and trademark information at maxeon.com/legal.
544513 REV
A
/ A4_EN
Publication Date: May 2022
PERFORMANCE 6COM
POWER: 485–510 W
sunpower.maxeon.com
Electrical Data, Front STC Characteristics 4
SPR-P6-510-COM-
S-BF
SPR-P6-505-COM-
S-BF
SPR-P6-500-COM-
S-BF
SPR-P6-495-COM-
S-BF
SPR-P6-490-COM-
S-BF
SPR-P6-485-COM-
S-BF
Nominal Power (Pnom) 510 W 505 W 500 W 495 W 490 W 485 W
Power Tolerance +3/0% +3/0% +3/0% +3/0% +3/0% +3/0%
Efficiency 21.4% 21.2% 21.0% 20.7% 20.5% 20.3%
Rated Voltage (Vmpp) 36.7 V 36.4 V 36.2 V 36.0 V 35.7 V 35.4 V
Rated Current (Impp) 13.92 A 13.88 A 13.82 A 13.77 A 13.73 A 13.71 A
Open-Circuit Voltage (Voc)
(+/−3%) 43.4 V 43.3 V 43.2 V 43.1 V 43.0 V 42.9 V
Short-Circuit Current (Isc)
(+/−3%) 14.82 A 14.76 A 14.71 A 14.65 A 14.59 A 14.56 A
Bifacial Gain 5
Pmax with 5% Bifacial Gain 536 W 530 W 525 W 520 W 515 W 509 W
Isc with 5% Bifacial Gain 15.56 A 15.50 A 15.44 A 15.38 A 15.32 A 15.29 A
Pmax with 10% Bifacial Gain 561 W 556 W 550 W 545 W 539 W 534 W
Isc with 10% Bifacial Gain 16.30 A 16.24 A 16.18 A 16.12 A 16.05 A 16.02 A
Pmax with 20% Bifacial Gain 612 W 606 W 600 W 594 W 588 W 582 W
Isc with 20% Bifacial Gain 17.78 A 17.72 A 17.65 A 17.58 A 17.51 A 17.47 A
Please read the safety and installation instructions.
Visit www.sunpower.maxeon.com/int/PVInstallGuideIEC
Paper version can be requested through [e-mail]

Maxeon Solar Technologies, Ltd. | www.sunpower.maxeon.com
Document#: 544362 REV A
© 2022 Maxeon Solar Technologies, Ltd. All Rights Reserved. View warranty, patent and trademark information at maxeon.com/legal.
