Sundance Spas Hamilton User manual

Owner's manual
P.N.:6530-607E Rev. A 780™ Series
Hamilton™Chelsee®Bristol™Hanover™Montclair™Dover™

Attention New Spa Owner!
Congratulations on the purchase of your new Sundance®780 Series spa! The
following is a list of automated functions and maintenance recommendations
for your new spa. Automated functions have been listed below in an attempt to
suppress any operational concerns you may have during startup and the rst 24
hours of ownership! Maintenance recommendations are listed in an attempt to
stress their importance in protecting your new spa. Spa operation and function
are subject to change without notice.
Automated Operations
Your new hot tub is equipped with an automated “clean-up” cycle that clears all
plumbing lines daily to promote maximum water sanitation. Each day at 12:00 PM
(noon), each pump will activate and run for one minute. If either pump has just
nished a 20 minute time out, it will not automatically activate for the clean-up cycle.
Note: Turning off the corresponding jets pump that is running can deactivate
the feature.
Maintain Healthy Spa Water
Always maintain your hot tub’s water chemistry within the following parameters:
with CLEARRAY® without CLEARRAY
pH 7.4-7.6 7.4-7.6
Free chlorine no less than 1.0 ppm 3.0-4.0 ppm
Free Bromine no less than 2.0 ppm 2.0-4.0 ppm
Total Alkalinity 100-150 ppm 100-150 ppm
Calcium Hardness 150-250 ppm 150-250 ppm
IMPORTANT: CLEARRAY® Water Purication System is factory installed. If
the CLEARRAY® system is altered or is not operating efciently then follow
the “without CLEARRAY®” water chemistry parameters as dened by the
Association of Pool and Spa Professionals. CLEARRAY® requires an annual
bulb replacement to properly sanitize your water.
!TO DECREASE RISK OF INFECTION OR DISEASE! Always main-
tain your spa lter as outlined below to ensure healthy spa water. Refer to pages
38-39 for additional information.
Required Filter Maintenance
Your new hot tub is equipped with an advanced 2-stage MicroClean® water
ltration system that provides unsurpassed water quality! To ensure maximum
water quality at all times, you should clean and reuse the larger pleated lter
cartridge every month and replace (throw away) the smaller MicroClean lter
cartridge every 3 months, or earlier as necessary. The smaller MicroClean lter
cartridge is designed to be thrown away! Attempts to reuse this lter cartridge
may result in the re-release of unwanted particles back into the spa. See pages
38-39 for detailed lter cartridge replacement instructions.
Required Water Maintenance
!TO DECREASE RISK OF INFECTION OR DISEASE! You should
replace the spa’s water every 3 months. The frequency depends on a number
of variables including frequency of use, number of users, and attention paid
to water quality maintenance. You will know it is time for a change when you
cannot control sudsing and/or you can no longer get the normal feel or sparkle
to the water, even though the key water balance measurements are all within the
proper parameters. See pages 45-46 for additional information.

Table of Contents
1.0 Important Spa Owner Information............................................ 1
2.0 FCC Notice.................................................................................. 1
3.0 Important Safety Instructions for all Spa Owners .................. 2
3.1 Entrapment Risk .......................................................................... 6
3.2 Hyperthermia ............................................................................... 8
3.3 Important Additional Safety Instructions....................................... 8
3.4 General Electrical Safety Instructions.......................................... 9
4.0 Choosing A Location ............................................................... 10
4.1 Outdoor Location ....................................................................... 10
4.2 Indoor Location .......................................................................... 11
5.0 Power Requirements ............................................................... 12
6.0 Electrical Wiring Instructions ................................................. 13
7.0 Spa Fill Up Procedure.............................................................. 18
8.0 Control Functions.................................................................... 23
8.1 Control Panel ............................................................................. 23
8.2 General Spa Features And Controls.......................................... 24
9.0 Operating Instructions ............................................................ 25
9.1 Register Your New Hot tub......................................................... 25
9.2 Completing Your Registration .................................................... 26
9.3 Setting Water Temperature ........................................................ 26
9.4 Activate Jets Pumps .................................................................. 27
9.5 Selecting Desired Massage Action ............................................ 27
9.6 Air Controls ................................................................................ 28
9.7 Light On/Off Button .................................................................... 28
9.8 Light Mode Button...................................................................... 28
9.9 Jets ............................................................................................ 28
9.10 Waterfall Operation .................................................................... 29
9.11 Optional BLUEWAVE® Spa Stereo System .............................. 29
9.12 Blow-Out Cycle .......................................................................... 29
9.13 Cleanup Cycle............................................................................ 29
9.14 Optional SmartTub™ System (60Hz models only) .................... 29
10.0 Menu Features and Programming Instructions .................... 31
10.1 Primary Filtration Menu.............................................................. 31
10.2 Secondary Filtration Menu......................................................... 32
10.3 Programming the Heating Mode................................................ 33
10.4 Programming the Change Filter Timer....................................... 34
10.5 Programming the CLEARRAY® Timer ...................................... 34
10.6 Programming the Water Refresh Timer ..................................... 35
10.7 Programming the Time............................................................... 35
10.8 Programming the Date............................................................... 36
10.9 Programming the Temperature Format...................................... 36
© Sundance Spas, Inc. All Rights Reserved

10.10 Programming the Language ...................................................... 36
10.11 Programming the Lock Feature ................................................. 37
10.12 Resetting the Wi-Fi Connection (optional feature
for 50Hz models only)................................................................ 37
11.0 Spa Maintenance...................................................................... 38
11.1 Cleaning The Filter..................................................................... 38
11.2 Draining And Relling................................................................. 40
11.3 Pillow Care................................................................................. 41
11.4 Cleaning The Spa Interior.......................................................... 42
11.5 Vinyl Cover Care And Maintenance ........................................... 42
11.6 Maintaining The Synthetic Cabinet ............................................ 42
11.7 Winterizing ................................................................................. 43
11.8 Restarting Your Spa in Cold Weather ........................................ 44
11.9 EZ Access Door ......................................................................... 44
11.10 Stainless Steel Maintenance...................................................... 44
12.0 Water Quality Maintenance ..................................................... 45
12.1 pH Control.................................................................................. 46
12.2 Sanitizing ................................................................................... 46
12.3 CLEARRAY® Water Purication System................................... 46
12.4 CLEARRAY® Bulb Replacement and
Quartz Tube Maintenance.......................................................... 47
13.0 Error Conditions/Error Messages .......................................... 50
13.1 Summer Logic............................................................................ 50
13.2 Panel Displays COOL................................................................ 50
13.3 Panel Displays ICE .................................................................... 50
13.4 Panel Displays SN--1................................................................. 50
13.5 Panel Displays SN--2................................................................. 51
13.6 Panel Displays Change CLEARRAY Bulb ................................. 51
13.7 Panel Displays Change Filter..................................................... 51
13.8 Panel Displays Change Water ................................................... 51
13.9 Panel Displays FL--1.................................................................. 51
13.10 Panel Displays FL--2.................................................................. 51
13.11 Panel Displays FL--3.................................................................. 52
13.12 Panel Displays OH..................................................................... 52
13.13 Panel Displays (-- -- -- --) ........................................................... 52
14.0 Troubleshooting Procedures.................................................. 53
14.1 FL--1 and FL--2.......................................................................... 53
14.2 None of the Components Operate (e.g. Pump, Light) ............... 53
14.3 Pump Does Not Operate............................................................ 53
14.4 Poor Jet Action........................................................................... 54
14.5 Water is Too Hot......................................................................... 54
14.6 No Heat...................................................................................... 54

15.0 Circuit Board Diagrams........................................................... 55
15.1 North American Dover Convertible Circuit Diagram
(for a 3-wire 120V 60Hz connection) ......................................... 55
15.2 North American Dover Convertible Circuit
Diagram (for a 4-wire 240V 60Hz connection)........................... 56
15.3 North American Bristol/Chelsee/Hamilton/Hanover/
Montclair Circuit Diagram........................................................... 57
16.0 Dip Switch Settings and Wiring.............................................. 58
17.0 Optional BLUEWAVE® Hot tub Stereo System ..................... 59
17.1 Pairing the Remote and Stereo.................................................. 60
17.2 Audio Settings............................................................................ 60
17.3 Wireless Remote Control Functions .......................................... 62
17.4 Electronic Device Connections and Functions........................... 64
17.5 Wireless Remote Battery Replacement Procedure ................... 66
17.6 BLUEWAVE Spa Stereo System Specications ........................ 67
17.7 Stereo Cautions ......................................................................... 68

Page 1
780 Series
1.0 Important Spa Owner Information
Your new Sundance®780 Series spa is constructed to the highest
standards and is capable of providing many years of trouble-free use.
However, because heat retentive materials are utilized to insulate
the spa for efficient operation, an uncovered acrylic spa surface and
wall fittings directly exposed to sunlight and high temperatures for an
extended period are subject to permanent damage or discoloration.
Damage caused by exposing the spa to this abuse is not covered under
warranty. We recommend that you always keep the spa full of water
when it is exposed to direct sunlight and that you keep the insulating
cover in place at all times when the spa is not in use. Read and carefully
follow the requirements for your spa’s support base found in Section 4.0
titled, “Choosing a Location” (Page 10).
We constantly strive to offer the finest spas available, therefore
modifications and enhancements may be made which affect the
specifications, illustrations and/or instructions contained herein.
2.0 FCC Notice
This equipment has been tested and found to comply with the limits for
a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
1. Rearrange or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from the
circuit connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party
responsible for FCC compliance could void the user’s authority to
operate this equipment.

Page 2
780 Series
3.0 Important Safety Instructions for all Spa Owners
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!
This spa was manufactured to meet the standards and specications
outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB
Safety Act). When installing and using this spa, basic safety precautions
should always be followed, including:
1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
• Extreme caution must be exercised to prevent unauthorized access
by children.
• To avoid accidents, ensure that children do not use this spa unless
supervised at all times. Adult supervision is a critical safety factor in
preventing children from drowning.
• Use the straps and clip tie downs to secure the spa cover when not
in use. This will help discourage unsupervised children from entering
the spa. Keep the spa cover secure in high-wind conditions.
• There is no representation that the cover, clip tie-downs, or actual
locks will prevent access to the spa.
2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
• Keep hair, loose articles of clothing or hanging jewelry away from
suction ttings, rotating jets or other moving components to avoid
entrapment that could lead to drowning or severe injury.
• Never use the spa unless all suction guards, lter, lter lid, or
skimmer assembly are installed to prevent body and/or hair
entrapment.
• Never operate or use the spa if the lter, lter lid, or skimmer
assembly are broken or any part of the skimmer assembly is missing.
Please contact your dealer or nearest service center for service.
• The suction ttings and suction covers in this spa are sized to match
the specic water ow created by the pump(s). If it is necessary to
replace the suction ttings, suction covers or pump(s), be sure that
the ow rates are compatible and are in compliance with the VGB
Safety Act.
• Never replace a suction tting or suction cover with one rated less
than the ow rate marked on the original suction tting. Using
improper suction ttings or suction covers can create a body or hair
suction entrapment hazard that may lead to drowning or severe
injury.

Page 3
780 Series
3. !DANGER: RISK OF SEVERE INJURY FROM ELECTRIC
SHOCK OR DEATH FROM ELECTROCUTION!
• Install the spa at least 5 feet (1.5m), from all metal surfaces. As an
alternative, a spa may be installed within 5 feet of metal surfaces
if each metal surface is permanently connected (bonded) by a
minimum No. 8 AWG (8.4 mm²) solid copper conductor attached
to the wire connector on the grounding lug, inside the equipment
compartment on the equipment box.
• A grounding wire connector is provided on this unit to connect a
minimum No. 8 AWG (8.4 mm²) solid copper conductor between
this unit and any metal equipment, metal enclosures of electrical
equipment, metal water pipe, or conduit within 5 feet (1.5m) of the
unit.
• Never permit any electrical appliance, such as a light, telephone,
radio, television, etc. within 5 feet (1.5m) of a spa unless such
appliances are built-in by the manufacturer.
• Never bring any electrical appliances into or near the spa.
• Never operate any electrical appliances from inside the spa or when
you are wet.
• The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with section 422-20 of the National Electrical Code/USA,
ANSI/NFPA 70. The disconnecting means must be readily accessible
and visible to the spa occupant but installed at least 5 feet (1.5m),
from the spa.
• The electrical circuit supplied for the hot tub must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC Article
680-42.
4. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Extreme caution must be exercised to prevent diving or jumping
into the spa or slipping and falling, which could result in
unconsciousness, drowning, or serious injury. Remember that wet
surfaces can be very slippery.
• Never stand, walk or sit on the top railing of the spa.
5. !WARNING: RISK OF HYPERTHERMIA (OVER-HEATING)
CAUSING SEVERE INJURY, BURNS, WELTS OR DEATH!
• Water temperature in excess of 104°F (40°C) may be injurious to
your health.
• Refer to Section 3.2 Hyperthermia for specic causes and symptoms
of this condition.
• The water in the spa should never exceed 104°F (40°C). Water
temperatures between 100°F (38°C) and 104°F (40°C) are
considered safe for a healthy adult.
• Lower water temperatures are recommended for young children
(children are especially sensitive to hot water) and when spa use
may exceed 10 minutes.

Page 4
780 Series
• The Consumer Products Safety Commission/USA has stated that the
water temperature in a spa should not exceed 104°F (40°C).
• Always test the spa water temperature before entering the spa.
The user should measure the water temperature with an accurate
thermometer since the tolerance of water temperature-regulating
devices may vary as much as +/- 5°F (2°C).
6. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Since excessive water temperatures have a high potential for
causing fetal damage during the early months of pregnancy, if
pregnant or possibly pregnant, consult your physician before using a
spa.
• Pregnant or possibly pregnant women should limit spa water
temperatures to 100°F (38°C).
• Persons suffering from obesity or a medical history of heart disease,
low or high blood pressure, circulatory system problems, diabetes,
infectious diseases or immune deciency syndromes should consult
a physician before using a spa.
• If you experience breathing difculties in association with using or
operating your spa, discontinue use and consult your physician.
• Persons using medication should consult a physician before using
a spa since some medication may induce drowsiness, while other
medication may affect heart rate, blood pressure, and circulation.
• Persons suffering from any condition requiring medical treatment,
the elderly, or infants should consult with a physician before using a
spa.
• The use of alcohol, drugs, or medication before or during spa use
may lead to unconsciousness with the possibility of drowning.
7. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Prolonged immersion in a spa may be injurious to your health.
• Observe a reasonable time limit when using the spa. Exposures
at higher temperatures can cause high body temperature (over-
heating). Symptoms may include dizziness, nausea, fainting,
drowsiness, and reduced awareness. These effects could possibly
result in drowning or serious injury.
• Never use a spa immediately following strenuous exercise. Enter
and exit the spa slowly. Wet surfaces can be slippery.

Page 5
780 Series
8. !WARNING: TO DECREASE RISK OF INFECTION OR
DISEASE!
• To reduce the risk of contracting a waterborne illness (e.g. an
infection, bacteria or virus) and/or respiratory ailments, maintain
water chemistry within the parameters listed on the inside cover of
this manual and consult with a licensed engineer regarding proper
ventilation if installed indoors or in an enclosed area.
• People with infectious diseases should not use a spa to avoid water
contamination, which could result in spreading infections to others.
• Always shower before and after using your spa. Maintain water
chemistry in accordance with manufacturer’s instructions. Failure
to do so may result in contracting a waterborne illness (e.g. an
infection, bacteria or virus).
9. !WARNING: In addition to maintenance of lters and water
chemistry, proper ventilation is recommended to reduce the risk of
contracting a waterborne illness (e.g. an infection, bacteria or virus)
and/or respiratory ailments that could be present in the air or water.
Consult a licensed architect or building contractor to determine your
specic needs if installing your hot tub indoors.
10. CAUTION: TO DECREASE RISK OF PRODUCT DAMAGE.
• Maintain water chemistry in accordance with manufacturer’s
instructions.
• Proper chemical maintenance of spa water is necessary to maintain
safe water and prevent possible damage to spa components.
11. WARNING: RISK OF SEVERE INJURY OR DEATH!
The appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
12. NOTE: This spa is not intended nor designed to be used in a
commercial or public application. The spa buyer shall determine
whether there are any code restrictions on the use or installation
of this spa since local code requirements vary from one locality to
another.

Page 6
780 Series
Hot Tub Safety Literature
To ensure you have a safe and enjoyable hot tub experience,
learn all you can about hot tub safety and emergency procedures.
Especially useful are the brochures listed below:
• Children Aren’t Waterproof
• Pool and Spa Emergency Procedures For Infants and Children
• Layers of Protection
• The Sensible Way to Enjoy Your Spa or Hot Tub
The Association of Pool and Spa Professionals publishes these
brochures. To acquire a brochure:
• Ask your hot tub dealer (they may have copies)
• Go to http://www.apsp.org
• Conduct your own search on the internet
• Write to the following address:
The Association of Pool and Spa Professionals
2111 Eisenhower Avenue
Alexandria VA 22314
703.838.0083
3.1 Entrapment Risk
The Consumer Products Safety Commission/USA has reported that
users of pools and spas have become entrapped (stuck) to drain and/or
suction ttings causing death, drowning, or serious injury (see diagram
below). This spa was manufactured to meet the standards and specica-
tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”
(VGB Safety Act). Entrapment risk can be minimized if proper precau-
tions are taken.
DANGER: RISK OF PERSONAL INJURY OR DEATH!
Never operate the spa if a suction tting, suction cover, lter,
lter lid or skimmer assembly are broken, damaged or missing.
!
NOTE: Suction covers must be replaced every 5 years.
Suction Fittings,
Suction Covers
(locations vary
by models)
Filter, Filter
Lid, Skimmer
Assembly
(location and
style vary by
models)

Page 7
780 Series
1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Hair entrapment:May occur if hair is entangled, knotted or snagged
in a drain suction or skimmer assembly. This has been reported in
persons who when submerge themselves underwater, allowing hair
to come close and/or within the reach of the suction ttings, suction
covers or skimmer assembly.
• Keep hair away from suction ttings, suction covers, lter, lter lid or
skimmer assembly.
• Children are at risk for hair entrapment if swimming under water.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Limb entrapment: May occur when a limb becomes entrapped,
inserted or sucked into a suction or outlet opening.
• Always keep suction ttings, suction covers, lter, lter lid or skimmer
assembly in place when operating to avoid limb entrapment.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
3. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Body entrapment: May occur when part of the torso becomes
entrapped, inserted or sucked into a suction or outlet opening.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
4. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Evisceration (disembowelment) entrapment: May occur when the
buttocks becomes entrapped, inserted or sucked into a suction or
outlet opening.
• Never sit on suction ttings, suction covers, lter, lter lid or skimmer
assembly.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
5. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Mechanical entrapment: May occur when jewelry, swimsuit, or
hair accessories become entangled, knotted or snagged in a drain
suction or skimmer assembly.
• Never allow your jewelry, swimsuit, or hair accessories to come
close to the suction ttings, suction covers or skimmer assembly.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.

Page 8
780 Series
3.2 Hyperthermia
Prolonged immersion in hot water may induce hyperthermia (over-
heating). The use of alcohol or drugs can greatly increase the risk of fatal
hyperthermia in spas. A description of the causes, symptoms, and effects
of hyperthermia are as follows:
Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above the normal body temperature of 98.6°F
(37°C). The symptoms of hyperthermia include drowsiness, lethargy
(fatigue), and an increase in the internal temperature of the body (feeling
of being too hot). The effects of hyperthermia include:
• Unawareness of impending hazard;
• Failure to perceive heat;
• Failure to recognize the need to exit spa;
• Physical inability to exit spa;
• Fetal damage in pregnant women; and
• Unconsciousness and DANGER of drowning.
A Warning Sign is provided in your warranty packet. Please install at
a location near your spa, where it is visible to users of the spa. For
additional or replacement Warning Signs please contact your local
Sundance spas dealer and reference item number #6530-082.
3.3 Important Additional Safety Instructions
When using this electrical equipment, basic safety precautions should
always be followed, including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. A green colored terminal or a terminal marked G, Gr, Ground,
Grounding or the symbol*is located inside the supply terminal box
or compartment. To reduce the risk of electric shock, this terminal must
be connected to the grounding means provided in the electric supply
service panel with a continuous copper wire equivalent in size to the
circuit conductors that supply this equipment (*IEC Publication 417,
Symbol 5019).
3. At least two lugs marked “Bonding Lugs” are provided on the external
surface or on the inside of the supply terminal box/compartment. To
reduce the risk of electric shock, connect the local common bonding
grid in the area of the spa to these terminals with an insulated or bare
copper conductor not smaller than No. 6 AWG (10 mm²).
4. All eld-installed metal components such as rails, ladders, drains
or other similar hardware within 10 feet (3m) of the spa shall be
bonded to the equipment grounding buss with copper conductors not
smaller than No. 6 AWG (10 mm²).
5. SAVE THESE INSTRUCTIONS.

Page 9
780 Series
3.4 General Electrical Safety Instructions
Your new Sundance®780 Series spa is equipped with a "state-of-
the-art" equipment system. It contains the most advanced safety and
self-protective equipment in the industry. Nonetheless, this spa must
be installed properly to ensure dependable usage. Please contact your
local Sundance dealer or local building department should you have any
questions regarding your installation.
Proper grounding is extremely important. Sundance spas are equipped
with a current collector system. A pressure wire connector is provided
on the surface of the control box, located outside the equipment door
(Figure B, page 15) to permit connection of a bonding wire between
this point and any ground metal equipment, metal water pipe or conduit
within 5 feet (1.5m) of the spa, or copper clad grounding rod buried
within 5 feet (1.5m) of the spa. Bonding wire must be at least No. 8 AWG
(8.4 mm²) solid copper wire. This is a most important safety assurance
feature.
Before installing your spa, check with your local building department to
ensure installation conforms to local building codes.
120/240 Volt Dover Convertible Model
A spa connected to a 120 VAC electrical service must be located close
enough to a grounded, grounding-type electrical outlet so that the
included 10 feet (3m) power cord can be plugged directly into it. DO
NOT USE AN EXTENSION CORD as this could cause damage to the
spa’s equipment due to insufcient voltage. The power supplied to this
spa must be a dedicated circuit with no other appliances or lights sharing
the power provided by the circuit.

Page 10
780 Series
4.0 Choosing A Location
IMPORTANT: Because of the combined weight of the spa, water
and users, it is extremely important that the base upon which the
spa rests be smooth, at, level and capable of uniformly supporting
this weight, without shifting or settling, for the entire time the spa is
in place. If the spa is placed on a surface which does not meet these
requirements, damage to the skirt and/or the spa shell may result.
Damage caused by improper support is not covered under warranty.
It is the responsibility of the spa owner to assure the integrity of the
support over time. We recommend a poured, reinforced concrete
slab with a minimum thickness of 4 inches (10 cm). Wood decking
is also acceptable provided it is constructed so that it meets the
requirements outlined above.
WARNING: For spas that are to rest on balconies, roofs
or other platforms not specically tied into main structural
support, consult a professional Structural Engineer with
experience in this type of application.
!
The spa must be installed in such a manner as to provide drainage away
from it. Placing the spa in a depression without provisions for proper
drainage could allow rain, overow and other casual water to ood the
equipment and create a wet condition in which it would sit in. For spas
which will be recessed into a oor or deck, install so as to permit access
to the equipment, either from above or below, for servicing. Make certain
that there are no obstructions which would prevent removal of all side
cabinet panels and access to the jets components, especially on the side
with the equipment bay doors.
CAUTION: If the spa is indoors or located in an enclosed area,
proper ventilation should be discussed with an Engineer or authority
competent enough to understand the necessary provisions needed
to vent moist or heated air and air associated with chemical odors
outdoors. When the spa is in use considerable amounts of
moisture will escape potentially causing mold and mildew. This
can cause health risk. Over time, this can damage certain surfaces,
surroundings, and equipment.
4.1 Outdoor Location
In selecting the ideal outdoor location for your spa, we suggest that you
take into consideration the following:
• The proximity to changing area and shelter (especially in regions
subject to cold weather).
• The pathway to and from your spa (this should be free of debris so
that dirt and leaves are not easily tracked into the spa).
• The closeness to trees and shrubbery (remember that leaves and
birds could create extra work in keeping the spa clean).
• A sheltered environment (less wind and weather exposure can result
in lowered operation and maintenance costs).
!

Page 11
780 Series
• The overall enhancement of your environment. It is preferable not to
place the spa under an unguttered roof overhang since run-off water
will shorten the life expectancy of the spa cover.
• For spas that are to rest on balconies, roofs or other platforms not
specically tied into main structural support, consult a professional
Structural Engineer with experience in this type of application.
• In the unlikely event that you should ever need to access or gain
entry to any portion of the spa for servicing, it is highly recommended
that you plan your outdoor installation to provide full access to the
entire spa. Please take this into consideration when placing the spa
in a deck or enclosed by a surrounding.
• Consider locating your spa away from any reective surface or glass
to prevent any damage to the synthetic skirt.
• Do not shim the spa. To ensure proper support the spa must sit at
on the intended foundation.
4.2 Indoor Location
For indoor installations many factors need to be considered before
installing a spa indoors:
WARNING: In addition to maintenance of lters and water
chemistry, proper ventilation is recommended to reduce the
risk of contracting a waterborne illness (e.g. an infection,
bacteria or virus) and/or respiratory ailments that could be
present in the air or water. Consult a licensed architect
or building contractor to determine your specic needs if
installing your hot tub indoors.
!
• PROPER FOUNDATION: Consult a Structural Engineer when
considering a foundation that will adequately support the spa
the entire time it is in place. Proper support is critical especially if
the spa is to rest on a second story or higher. For spas that are to
rest on balconies, roofs or other platforms not specifically tied into the
main structural support, you should consult a professional Structural
Engineer with experience in this type of application.
• PROPER DRAINAGE: It is extremely important to have in place
measures to sufficiently handle excessive water spillage. Be sure
the flooring in which the spa rests on has adequate drainage and can
handle draining of the entire contents of the spa. Be sure to make
provisions for ceilings or any other structures that may be below the
spas installation. Areas around your spa can become wet or moist so
all flooring and subsequent furniture, walls and adjacent structures
should be able to withstand or resist water and moisture.
• PROPER VENTILATION: Proper ventilation should be discussed
with an Engineer or authority competent enough to understand
the necessary provisions needed to vent moist or heated air and
air associated with chemical odors outdoors. When the spa is in
use considerable amounts of moisture will escape potentially causing
mold and mildew, over time this can damage certain surfaces and or
surroundings.

Page 12
780 Series
• SUFFICIENT ACCESS: In the unlikely event that you should ever
need to access or gain entry to any portion of the spa for servicing,
it is highly recommended that you plan your indoor installation to
provide full access to the entire spa.
• WARRANTY: Damage caused by not following these guidelines
or any improper installation not in accordance with local codes or
authorities is not covered under the spas warranty. Please consult
your local state or city building ordinances.
• DO NOT SHIM THE SPA. To ensure proper support the spa must sit
at on the intended foundation.
5.0 Power Requirements
Sundance®hot tubs are designed to provide optimum
performance and exibility of use when connected to the
maximum electrical service listed on pages 12-13. If you
prefer, your qualified technician can perform a minor circuit
board modication to allow your spa to accept an electrical service other
than the factory setting.
Note: Refer to pages 55-58 for circuit board conguration details or
contact your authorized Sundance dealer.
North American Dover Convertible Models (60 Hz)
120V/15A* 240V/30A* 240V/40A**
Circuit Breaker: 15A, 1-Pole 30A, 2-Pole 40A, 2-Pole
Number of Wires: 3 (15A GFCI Cord
US Only*)
4 (Hard Wire
Only)
4 (Hard Wire
Only)
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 12A 20A 31A
*In 15A/30A conguration, the heater will not operate while the jets
pump is running on high speed. The factory setting is 120V/15A.
** In 40A conguration, the heater will operate while the jets pump is
running.
**CAUTION: (For a 4-wire 240 VAC Heater Operation): Make
certain wires are connected exactly as shown in Figure D (page 17)
before applying power. Failure to do so will result in damage to the
circuit board and/or related components and void the manufacturer's
warranty.

Page 13
780 Series
6.0 Electrical Wiring Instructions
IMPORTANT NOTICE: The electrical wiring of this spa must
meet the requirements of the National Electrical Code
(NEC) and/or any applicable state or local codes. The
electrical circuit must be installed by a qualied electrician
and approved by a local building/electrical inspection authority.
1. Convertible 120/240V Powered Dover Models Only:
•!DANGER: TO DECREASE THE RISK OF SHOCK,
PRODUCT DAMAGE OR ELECTRICAL FIRE.
120V “Plug-in” Operation: This spa must operate on the supplied
10 foot (3m) 120V GFCI cord at its original length or must be hard-
wired for longer runs. NEVER USE AN EXTENSION CORD FOR
ANY REASON!
• Convertible 120/240V Heater Operation: the included 120V GFCI
cord must be discarded for 240V heater operation. This spa must
be hard-wired. Supplying power to either conguration above
which is not in accordance with these instructions will void both the
independent testing agency listing and the manufacturer’s warranty.
2. Dedicated 240V Power Bristol/Chelsee/Hamilton/Hanover/Montclair
Models: These spas must be permanently connected (hard-wired)
to the power supply. No plug-in connections or extension cords
are to be used in conjunction with the operation of these spas.
Supplying power to these spas which is not in accordance with these
instructions will void both the independent testing agency listing and
the manufacturer’s warranty.
North American Bristol/Chelsee/Hamilton/Hanover/Montclair
Models (240V 60 Hz)
240V/40A* 240V/50A** 240V/60A***
Circuit Breaker (2-Pole): 40A 50A 60A
Number of Wires: 3 3 3
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 26A 37A 48A
*In 40A conguration, the heater will not operate while either jets
pump is running.
** In 50A conguration, the heater will not operate while both jets
pumps are running. This is the factory setting.
*** In 60A conguration the heater will operate while both jets pumps
are running.

Page 14
780 Series
3. The power supplied to this spa must be a dedicated circuit with no
other appliances or lights sharing the power provided by the circuit.
4. To determine the current, voltage and wire size required, refer to
Section 5.0 “Power Requirements” (pages 12-13).
• Wire size must be appropriate per NEC and/or local codes.
• The spa controller’s terminal block will accept a maximum wire size
of 6 AWG.
5. The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with Section 422-20 of the National Electrical Code, ANSI/
NFPA 70. The disconnecting means must be readily accessible and
visible to the hot tub’s occupant but installed at least 5 feet (1.5m)
from the hot tub.
6. The electrical circuit supplied for the spa must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC Article
680-42.
7. To gain access to the hot tub’s power terminal block, unlatch the door
mechanism, securing the cabinet panel, on the side of the hot tub
under the controls. Then remove the control box door screws and
door (Figures A-B).
8. Select the power supply inlet you want to use (Figure A, page 15).
Feed power cable to control box, then install it through the large
opening provided in the side of the box.
9. Connect wires on terminal block TB1 (Figures C, page 16).
TIGHTEN SECURELY! All wires must be hooked up securely or
damage could result.
10. Install control box door and screws and reinstall the cabinet panels.
11. The electrical supply for this product must include a suitably rated
isolating switch and circuit breaker to comply with local electrical
regulations. This RCD/GFCI circuit breaker must be installed at the
power supply in the house electrical box.
