Attention New Spa Owner!
Congratulations on the purchase of your new Sundance® 680 series
spa! The following is a list of automated functions and maintenance
recommendations for your new spa. Automated functions have been
listed below in an attempt to suppress any operational concerns you may
have during startup and the rst 24-hours of ownership! Maintenance
recommendations are listed in an attempt to stress their importance in
protecting your new spa.
Automated Operations
Approximately two minutes after power is applied to the spa, the rst
ltration/heating cycle turns on pump 1. In Burlington models, an automatic
ve minute “blow-out” function also activates pump 2 for a period of ve
minutes to ush all lines. Then, after ve minutes, pump 2 turns off and
pump 1 continues to operate for the duration of the cycle. Note: this function
only occurs during the rst ltration/heating cycle each day.
Maintain Healthy Spa Water
Always maintain your spa’s water chemistry within the following parameters
as dened by the Association of Pool And Spa Professionals/USA:
Always maintain your spa lter as outlined below to ensure healthy spa
water. Refer to page 29 for additional information.
Required Filter Maintenance
Your new spa is equipped with an advanced water ltration system that
provides unsurpassed water quality! To ensure maximum water quality at
all times, you should clean and reuse the lter cartridge every month. See
page 25 for detailed lter cleaning/replacement instructions.
Required Water Maintenance
You should replace the spa’s water every 3 months. The frequency
depends on a number of variables including frequency of use, number of
users, and attention paid to water quality maintenance. You will know it
is time for a change when you cannot control sudsing and/or you can no
longer get the normal feel or sparkle to the water, even though the key
water balance measurements are all within the proper parameters. See
page 29 for additional information.
pH 7.2 - 7.4
Free Chlorine 3-5 ppm
Free Bromine 4-6 ppm
Total Alkalinity 100-120 ppm
Calcium Hardness 150-250 ppm

Table of Contents
1.0 Important Spa Owner Information..................................1
2.0 FCC Notice........................................................................1
3.0 Important Safety Instructions.........................................2
3.1 Important CSA Safety Information (Canada Only).............4
3.2 Hyperthermia .....................................................................5
3.3 Cautions.............................................................................6
3.4 General Electrical Safety Instructions................................6
4.0 Choosing A Location.......................................................7
4.1 Outdoor Location ...............................................................8
4.2 Indoor Location ..................................................................8
5.0 Power Requirements .......................................................9
6.0 Electrical Wiring Instructions .......................................11
7.0 Spa Fill Up Procedure ...................................................14
8.0 Control Functions ..........................................................19
8.1 Control Panel ...................................................................19
8.2 Spa Features And Controls..............................................20
9.0 Operating Instructions ..................................................21
9.1 Setting Water Temperature ..............................................21
9.2 Activate Pumps ................................................................21
9.3 Light Button......................................................................22
9.4 Adjusting Individual Jet Flow ...........................................22
9.5 Selecting Desired Massage Action ..................................22
9.6 Air Controls ......................................................................22
10.0 Automatic Filtration Cycles ..........................................23
10.1 Standard Filtration/Heating Modes (F1 - F3)...................23
10.2 Economy Filtration/Heating Modes (F4 - F6)...................23
10.3 Lock Modes (L1 - L2).......................................................23
10.4 Selecting The Filtration/Heating Mode.............................23

11.0 Spa Maintenance............................................................25
11.1 Cleaning The Filter...........................................................25
11.2 Draining and Refilling.......................................................25
11.3 Cleaning The Spa Interior................................................27
11.4 Maintaining The Cover.....................................................27
11.5 Maintaining The Synthetic Cabinet..................................27
11.6 Winterizing .......................................................................28
11.7 Restarting Your Spa in Cold Weather..............................28
12.0 Water Quality Maintenance ...........................................29
12.1 pH Control........................................................................29
12.2 Sanitizing .........................................................................29
12.3 Optional CD Ozone Water Maintenance System ............30
13.0 Error Conditions/Error Messages ................................31
13.1 Panel Displays SN1 .........................................................31
13.2 Panel Displays SN2 .........................................................31
13.3 Panel Displays FL1..........................................................31
13.4 Panel Displays FL2..........................................................31
13.5 Panel Displays COL.........................................................31
13.6 Panel Displays ICE ..........................................................31
13.7 Panel Displays OH...........................................................32
13.8 Panel Displays - - - - .......................................................32
14.0 Troubleshooting Procedures ........................................33
14.1 None of The Components Operate..................................33
14.2 Pump Does Not Operate but Light Does.........................33
14.3 Poor Jet Action.................................................................33
14.4 Water is Too Hot ..............................................................33
14.5 No Heat............................................................................34
15.0 Denali/Tacoma Convertible Circuit Diagram (60Hz) ...35
16.0 Burlington Circuit Diagram (60Hz) ...............................36
17.0 Denali/Tacoma Export Circuit Diagram (50Hz)............37
18.0 Burlington Export Circuit Diagram (50Hz) ..................38

Page 1
1.0 Important Spa Owner Information
Your Sundance® 680 series spa is constructed to the highest standards
and is capable of providing many years of trouble-free use. However,
because heat retentive materials are utilized to insulate the spa for effi-
cient operation, an uncovered spa surface directly exposed to sunlight
and high temperatures for an extended period is subject to permanent
damage. Damage caused by exposing the spa to this abuse is not
covered by warranty. We recommend that you always keep the spa
full of water when it is exposed to direct sunlight and that you keep the
Sundance premium insulating cover in place at all times when the spa
is not in use. Read and carefully follow the requirements for your spa’s
support base found in section 4.0 titled, “Choosing a Location” (page 7).
Sundance constantly strives to offer the finest spas available,
therefore modifications and enhancements may be made which
affect the specifications, illustrations and/or instructions contained
herein.
2.0 FCC Notice
This equipment has been tested and found to comply with the limits for
a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
1. Rearrange or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from the
circuit connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party
responsible for FCC compliance could void the user’s authority to
operate this equipment.

Page 2
3.0 Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!
When installing and using this electrical equipment, basic safety precau-
tions should always be followed, including:
1. WARNING: To reduce the risk of injury, do not permit children to use
this product unless they are closely supervised at all times.
2. WARNING: A grounding wire connector is provided on this unit to
connect a minimum No. 8 AWG (8.4mm2) solid copper conduc-
tor between this unit and any metal equipment, metal enclosures
of electrical equipment, metal water pipe, or conduit within 5 feet
(1.5m) of the unit.
3. DANGER: Risk of Accidental Drowning. Extreme caution must be
exercised to prevent unauthorized access by children. To avoid
accidents, ensure that children cannot use this spa unless they are
supervised at all times.
4. DANGER: Risk of Injury. The suction fittings in this spa are sized to
match the specific water flow created by the pump. Should the need
arise to replace the suction fittings or the pump, be sure that the
flow rates are compatible. Never operate the spa if the suction fit-
tings are broken or missing. Never replace a suction fitting with one
rated less than the flow rate marked on the original suction fitting.
5. DANGER: Risk of Electric Shock. Install at least 5 feet (1.5m) from
all metal surfaces. As an alternative, a spa may be installed within
5 feet (1.5m) of metal surfaces if each metal surface is permanently
connected (bonded) by a minimum No. 8 AWG (8.4mm2) solid cop-
per conductor attached to the wire connector on the grounding lug,
inside the equipment compartment on the equipment box.
6. DANGER: Risk of Electric Shock. Do not permit any electrical appli-
ance, such as a light, telephone, radio, television, etc. within 5 feet
(1.5m) of a spa, unless such appliances are built-in by the manufac-
turer.
7. ELECTRICAL SUPPLY: The electrical supply for this product
must include a suitably rated switch or circuit breaker to open all
ungrounded supply conductors to comply with section 422-20 of the

Page 3
National Electrical Code/USA, ANSI/NFPA 70. The disconnect must
be readily accessible and visible to the spa occupant but installed at
least 5 feet (1.5m) from the spa water.
8. WARNING: To Reduce the Risk of Injury:
9. The water in a spa should never exceed 104°F (40°C). Water
temperatures between 100°F (38°C) and 104°F (40°C) are consid-
ered safe for a healthy adult. Lower water temperatures are recom-
mended for young children and when spa use exceeds 10 minutes.
10. Since excessive water temperatures have a high potential for caus-
ing fetal damage during the early months of pregnancy, pregnant or
possibly pregnant women should limit spa water temperatures to
100°F (38°C). If pregnant, please consult your physician before
using a spa.
11. Before entering the spa, the user should measure the water tem-
perature with an accurate thermometer since the tolerance of water
temperature-regulating devices may vary as much as +/- 5°F (2°C).
12. The use of alcohol, drugs, or medication before or during spa use
may lead to unconsciousness with the possibility of drowning.
13. Persons suffering from obesity or a medical history of heart disease,
low or high blood pressure, circulatory system problems, diabetes,
infectious diseases or immune deficiency syndromes should consult
a physician before using a spa. If you experience breathing dif-
ficulties in association with using or operating your spa, discontinue
use and consult your physician.
14. Persons using medication should consult a physician before using
a spa since some medication may induce drowsiness, while other
medication may affect heart rate, blood pressure, and circulation.
15. Always shower before and after using your spa. To reduce the pos-
sibility of contracting a waterborne illness, always maintain water
chemistry within the parameters listed on the inside cover of this
manual. If you or other bathers experience such a condition, dis-
continue use and seek medical attention.

Page 4
3.1 IMPORTANT CSA SAFETY INSTRUCTIONS (CANADA ONLY)
When using this electrical equipment, basic safety precautions should
always be followed, including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. A green colored terminal or a terminal marked G, Gr, Ground,
Grounding or the symbol* is located inside the supply terminal
box or compartment. To reduce the risk of electric shock, this
terminal must be connected to the grounding means provided in the
electric supply service panel with a continuous copper wire
equivalent in size to the circuit conductors that supply this
equipment (*IEC Publication 417, Symbol 5019).
3. At least two lugs marked “Bonding Lugs” are provided on the
external surface or on the inside of the supply terminal box/
compartment. To reduce the risk of electric shock, connect the local
common bonding grid in the area of the spa to these terminals with
an insulated or bare copper conductor not smaller than No. 6 AWG
(10mm2).
4. All field-installed metal components such as rails, ladders, drains
or other similar hardware within 10 feet (3m) of the spa shall be
bonded to the equipment grounding buss with copper conductors
not smaller than No. 6 AWG (10mm2).
5. SAVE THESE INSTRUCTIONS
WARNING: Children should not use spas without adult supervision.
WARNING: Do not use spas unless all suction guards are installed to
prevent body and hair entrapment.
WARNING: People with infectious diseases should not use a spa.
WARNING: To avoid injury, exercise care when entering or exiting the
spa.
WARNING: Do not use drugs or alcohol before or during the use of a
spa to avoid unconsciousness and possible drowning.

Page 5
WARNING: Pregnant or possibly pregnant women should consult a
physician before using a spa.
WARNING: Water temperature in excess of 38°C (104°F) may be
injurious to your health.
WARNING: Before entering the spa, measure the water temperature
with an accurate thermometer.
WARNING: Do not use a spa immediately following strenuous exercise.
WARNING: Prolonged immersion in a spa may be injurious to your
health.
WARNING: Do not permit electric appliances (such as light, telephone,
radio, television, etc.) within 5 feet (1.5m) of this spa unless factory
installed.
CAUTION: Maintain water chemistry in accordance with manufacturer’s
instructions.
WARNING: The use of alcohol or drugs can greatly increase the risk of
fatal hyperthermia in spas.
3.2 HYPERTHERMIA
Prolonged immersion in hot water may induce hyperthermia. A description
of the causes, symptoms, and effects of hyperthermia are as follows:
Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above the normal body temperature of 98.6°F
(37°C). The symptoms of hyperthermia include drowsiness, lethargy, and
an increase in the internal temperature of the body. The effects of hyper-
thermia include:
A Unawareness of impending hazard;
B. Failure to perceive heat;
C. Failure to recognize the need to exit spa;
D. Physical inability to exit spa;
E. Fetal damage in pregnant women; and
F. Unconsciousness and danger of drowning.

Page 6
3.3 CAUTIONS
1. Persons suffering from heart disease, diabetes, high or low blood
pressure, and any condition requiring medical treatment, pregnant
women, the elderly, or infants should consult with a physician before
using a spa.
2. The Consumer Products Safety Commission/USA has stated that
the water temperature in a spa should not exceed 104°F (40°C).
Immersion in water in excess of 104°F (40°C) can be hazardous to
your health.
3. Observe a reasonable time limit when using the spa. Long expo-
sures at higher temperatures can cause high body temperature.
Symptoms may include dizziness, nausea, fainting, drowsiness, and
reduced awareness. These effects could possibly result in drown-
ing.
4. Do not use the spa under the influence of alcohol, narcotics, or
other drugs. Use of the spa under these conditions may lead to seri-
ous consequences.
5. Always test the spa water temperature before entering the spa.
Enter and exit the spa slowly. Wet surfaces can be very slippery.
6. Never bring any electrical appliances into or near the spa. Never
operate any electrical appliances from inside the spa or when you
are wet unless such appliances are built-in by the manufacturer.
7. Proper chemical maintenance of spa water is necessary to maintain
safe water and prevent possible damage to spa components.
8. Use the straps and clip tie downs to secure the cover when not in
use. This will help to discourage unsupervised children from enter-
ing the spa and keep the spa cover secure in high-wind conditions.
There is no representation that the cover, clip tie-downs, or actual
locks will prevent access to the spa.
3.4 GENERAL ELECTRICAL SAFETY INSTRUCTIONS
Your new Sundance® spa is equipped with a “state-of-the-art” equip-
ment system. It contains the most advanced safety and self-protective
equipment in the industry. Nonetheless, this spa must be installed prop-
erly to ensure dependable usage. Please contact your local Sundance
dealer or local building department should you have any questions
regarding your installation.
Proper grounding is extremely important. Sundance spas are equipped
with a current collector system. A pressure wire connector is provided
on the surface of the control box, located outside the equipment door
(Figure-B, page 13) to permit connection of a bonding wire between

Page 7
this point and any ground metal equipment, metal water pipe or conduit
within 5 feet (1.5m) of the spa, or copper clad grounding rod buried
within 5 feet (1.5m) of the spa. Bonding wire must be at least No. 8
AWG (8.4mm2) solid copper wire. This is a most important safety assur-
ance feature.
Before installing your spa, check with your local building department to
insure installation conforms to local building codes.
120/240 Volt Denali And Tacoma Convertible Models
A spa connected to a 120 VAC electrical service must be located
close enough to a grounded, grounding-type electrical outlet so that
the included power cord can be plugged directly into it. DO NOT USE
AN EXTENSION CORD as this could cause damage to the spa’s
equipment due to insufficient voltage. The power supplied to this spa
must be a dedicated circuit with no other appliances or lights sharing
the power provided by the circuit.
4.0 Choosing A Location
IMPORTANT: Because of the combined weight of the spa, water and
users, it is extremely important that the base upon which the spa rests
be smooth, flat, level and capable of uniformly supporting this weight,
without shifting or settling, for the entire time the spa is in place. If the
spa is placed on a surface which does not meet these requirements,
damage to the skirt and/or the spa shell may result. Damage caused by
improper support is not covered under warranty. It is the responsibility of
the spa owner to assure the integrity of the support over time.
We recommend a poured, reinforced concrete slab with a minimum
thickness of 4 inches (10cm). Wood decking is also acceptable provided
it is constructed so that it meets the requirements outlined above. The
spa must be installed in such a manner as to provide drainage away
from the spa. Placing the spa in a depression without provisions for
proper drainage could allow rain, overflow and other casual water
to flood the equipment and create a wet condition in which it would
sit. For spas which will be recessed into a floor or deck, install so as
to permit access to the equipment, either from above or below, for
servicing. Make certain that there are no obstructions which would
prevent removal of the cabinet side panels and access to the jets
components, especially on the side with the equipment bay doors.

Page 8
4.1 Outdoor Location
In selecting the ideal outdoor location for your spa, we suggest that you
take into consideration the following:
• The proximity to changing area and shelter (especially in regions
subject to cold weather).
• The pathway to and from your spa (this should be free of debris so
that dirt and leaves are not easily tracked into the spa).
• The closeness to trees and shrubbery (remember that leaves and
birds could create extra work in keeping the spa clean).
• A sheltered environment (less wind and weather exposure can result
in lowered operation and maintenance costs).
• The overall enhancement of your environment. It is preferable not to
place the spa under an unguttered roof overhang since run-off water
will shorten the life expectancy of the spa cover.
4.2 Indoor Location
For indoor installations, be certain to make provisions for proper
ventilation. When the spa is in use, considerable amounts of moisture
will escape. This can damage certain surfaces over time. If you have
any questions regarding the placement or installation of your spa,
consult your authorized Sundance dealer.
WARNING: In addition to maintenance of filters and water
chemistry, proper ventilation is recommended to reduce the
risk of exposure to viruses and bacteria that could be present
in the air or water. Consult a licensed architect or building
contractor to determine your specific needs if installing your
spa indoors.

Page 9
5.0 Power Requirements
Sundance® spas are designed to provide optimum performance and
flexibility of use when connected to the maximum electrical service listed
in the tables below. If you prefer, your dealer can perform a minor circuit
board modification to allow your spa to accept an electrical service other
than the factory setting.
US/Canada Denali/Tacoma 1-Pump Convertible Models (60Hz)
120V/15A* 240V/30A* 240V/40A**
Voltage: 120 VAC 240 VAC 240 VAC
# of Wires: 3 (15A GFCI Cord - 4 (Hard 4 (Hard
US Models Only*) Wired Only) Wired Only)
Frequency: 60Hz 60Hz 60Hz
Current Draw: 12A 21A 30A
Circuit Breaker: 15A, 1-Pole 30A, 2-Pole 40A, 2-Pole
For 240 VAC Heater Operation: Move the red wire on the main terminal
strip (TB1) from position #1 to position #3. Make certain wires are connected
exactly as shown in Figure-D (page 13) before applying power. Failure to do
so will result in damage to the circuit board and/or related components and
void the manufacturer’s warranty.
* In the 15A/30A configuration, the heater will not operate at the same
time as the high-speed jets pump. The factory setting is 120V/15A.
Note: all Canadian spas must be hard wired (120 VAC or 240 VAC)
per CSA Canadian standards (page 4).
** If the spa is to be operated on 40A service, remove the jumper JP1
#1-2 on the circuit board to allow the heater to operate at the same time
as the high-speed jets pump (page 35).
US/Canada Burlington 2-Pump Models (60Hz)
240V/50A* 240V/40A**
Voltage: 240 VAC 240 VAC
# of Wires: 3 3
Frequency: 60Hz 60Hz
Current Draw: 36A 26A
Circuit Breaker: 50A, 2-Pole 40A, 2-Pole
* In 50A configuration, the heater will not operate while both jets pumps
are running in high speed. Note: pump 2 runs only in high speed. This is
the factory setting.
** In 40A configuration, the heater will not operate while either jets pump is
running in high speed. Note: pump 2 runs only in high speed.

Page 10
Export Denali/Tacoma 1-Pump Models (50Hz)
230V/20A* 230V/30A**
Voltage: 230 VAC 230 VAC
# of Wires: 3 3
Frequency: 50Hz 50Hz
Current Draw: 15A 21A
Circuit Breaker: 20A 30A
* In the 20A configuration, the heater will not operate while either jets
pump is running in high speed.. This is the factory setting.
** In the 30A configuration, the heater will operate with one pump running
at high speed.
Export Burlington 2-Pump Model (50Hz)
230V/20A* 230V/30A**
Voltage: 230 VAC 230 VAC
# of Wires: 3 3
Frequency: 50Hz 50Hz
Current Draw: 15A 23A
Circuit Breaker: 20A 30A
* In the 20A configuration, the heater will not operate while either jets
pump is running in high speed.. This is the factory setting.
** In the 30A configuration, the heater will operate with one pump running
at high speed.

Page 11
6.0 Electrical Wiring Instructions
IMPORTANT NOTICE: The electrical wiring of this spa must meet
the requirements of the National Electrical Code/USA (NEC) and any
applicable state or local codes. The electrical circuit must be installed
by a qualified electrician and approved by a local building/electrical
inspection authority.
1. Convertible 120/240V Denali/Tacoma Models Only:
• 120V “Plug-in” Operation: This spa must operate on the supplied
120V GFCI cord at its original length or must be hard-wired for
longer runs. Never use an extension cord for any reason!
• Convertible 120/240V Heater Operation: The included 120V GFCI
cord must be discarded for 240V heater operation. This spa must
be hard-wired. Supplying power to either configuration above which
is not in accordance with these instructions will void both the
independent testing agency listing and the manufacturer’s warranty.
2. Dedicated 230-240V Burlington Models:
This spa must be permanently connected (hard-wired) to the power
supply. No plug-in connections or extension cords are to be
used in conjunction with the operation of this spa. Supplying
power to the spa which is not in accordance with these instructions
will void both the independent testing agency listing and the
manufacturer’s warranty.
3. The power supplied to this spa must be a dedicated circuit with no
other appliances or lights sharing the power provided by the circuit.
4. To determine the current, voltage and wire size required, refer to
section 5.0 “Power Requirements” (page 9-10).
• Wire size must be appropriate per NEC and/or local codes.
• We recommend type THHN wire.
• All wiring must be copper to ensure proper connections. Do not
use aluminum wire.
• When using wire larger than #6 (10mm2), add a junction box near
the spa and reduce to short lengths of #8 (8.4mm2) wire to connect
to the spa.
5. The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with section 422-20 of the National Electrical Code/USA,

Page 12
ANSI/NFPA 70. The disconnecting means must be readily
accessible to the spa’s occupant but installed at least 5 feet (1.5m)
from spa water.
6. The electrical circuit supplied for the spa must include a suitable
ground fault circuit interruptor (GFCI) as required by NEC Article
680-42.
7. To gain access to the spa’s power terminal block, remove the
screws securing the cabinet panel on the side of the spa under the
control panel (page 20). Then remove the four control box door
screws and door (Figure-B).
8. Select the power supply inlet you want to use (Figure-A). Feed
power cable to control box, then install it through the large opening
provided in the bottom side of the box.
9. Connect wires, color to color, on terminal blocks TB1 and TB3
(Figures C-F). TIGHTEN SECURELY! All wires must be hooked up
securely or damage could result.
10. Install control box door and screws and reinstall the cabinet side
panels.
7
8
36
2 2
Figure-A
Equipment Area
1. Control Box
2. Power Supply Inlet(s)
3. 2-Speed Pump #1
4. Heater
5. Pump Drain Plug
6. 1-Speed Pump #2
7. Optional CD Ozonator
(Purchased Separately)
8. Ozone Injector
Flow
Note: Pump Locations Vary by Model
5 5
1
4
Burlington Model Illustrated

Page 13
BLUE
BLUE
BROWN
BROWN
1
2
US/Canada Burlington Models:
240 VAC, 3-Wire Connection (60Hz)
Figure-F
TB1
All Export Burlington/Denali/Tacoma Models:
230 VAC, 3-Wire (50Hz)
to Circuit
Board
BLK
RED
Power In
RED
RED
BLK
BLK
1
2
Figure-E
TB1
to Circuit
Board
Power In
Green
TB3
Green
TB3
GRN
WHT
WHT
BLK
BLK
BLK
RED
1
2
3
Figure-C
TB1
to Circuit
Board
Power In
GRN
WHT WHT
BLK
BLK
BLK
RED RED
1
2
3
All US/Canada Denali/Tacoma Convertible
Models: 120/240 VAC, 4-Wire Connection (60Hz)
Figure-D
TB1
to Circuit
Board
Power In
All US/Canada Denali/Tacoma Convertible
Models: 120 VAC, 3-Wire Connection (60Hz)
Figure-B - Control Box
1. Terminal Block
2. Bonding Lug
3. Grounding Terminal
TB1
3
2
1

Page 14
7.0 Spa Fill Up Procedure
FOR BEST RESULTS, READ EACH STEP IN ITS ENTIRETY
BEFORE PROCEEDING WITH THAT STEP.
1. Prepare The Spa For Filling
• Clear all debris from the spa. (Although the spa shell has been
polished at the factory, you may want to treat it with a specially
formulated spa cleaner. Consult your authorized Sundance
dealer for additional information prior to filling spa.
• Remove filter/skimmer lid (page 20), then remove filter cartridge
as outlined in section 11.1 (page 25).
2. Fill Spa
• Place the end of your garden hose into the empty filter bucket.
CAUTION: Never fill with water from a water softener. If your
water is extremely “hard”, it is preferable to fill half-way with
hard water and the rest of the way with softened water. Or,
you may fill entirely with hard water if you use a special water
additive available from your authorized Sundance dealer.
• Fill spa with clean tap water from garden hose until water covers
all jets (DO NOT OVERFILL!)
IMPORTANT: Always fill your spa through the filter bucket
after draining. Failure to do so may cause air to be trapped
in either pump, preventing the pump from circulating water.
Remove the hose and replace the filter cartridge. Note: DO
NOT overtighten filter cartridge, finger tight only!
3. Turn On Power
Turn on power to spa at the home’s circuit breaker. The heater
and filter pump will automatically activate. If the control panel LCD
flashes water temperature and “COOL” or “ICE”, refer to page 31 for
additional information.
4. Activate Jets Pump 1
Depress the JETS 1 button on the control panel once
to activate jets pump #1. On Burlington models, press
JETS 2 button to activate jets pump #2.
JETS 1
JETS 2

Page 15
5. Add Start-Up Chemicals
Add the spa water chemicals as recommended by your autho-
rized Sundance dealer. See section titled “WATER QUALITY
MAINTENANCE” (page 29) for general guidance.
6. Establish A Stable Sanitizer Reading
Establish a stable sanitizer reading between 3 ppm and 5 ppm
chlorine or 4 ppm and 6 ppm bromine. To ensure healthy water
conditions, always maintain a constant sanitizer reading within the
levels recommended by the Association of Pool And Spa Profession-
als/USA printed on the inside cover of this manual. If sanitizer levels
cannot be stabilized, perform the decontamination procedure steps
9-15 on the following page. Note: the “decontamination procedure”
steps 9-15 should also be used after the spa has been “Winterized”
(sec. 11.7) or has been sitting without power for an extended period.
7. Set Spa To Heat
To warm spa water to a comfortable temperature, follow these
steps:
• The LCD display on the control panel displays the actual
temperature of the spa water. Press either the COOLER
(Down) or WARMER (Up) button once to display the “set”
temperature for 5 seconds. If you want the water to
heat to a different temperature, simply press COOLER
or WARMER within 5 seconds. The set temperature
increases or decreases by one degree each time one of these
buttons is pressed.
• The heater will turn off when the temperature corresponding to the
thermostat setting is achieved.
Important Heater Details:
• The maximum temperature for which the spa can be set is 104°F
(40°C) and the minimum is 80°F (27°C).
• For 2-pump Burlington modes powered by a 40 amp service, jets
pump #1 must be set to low speed and jets pump #2 must be
turned off to operate the heater.
• Setting the thermostat at maximum will not accelerate the heating
process. This will only result in a higher ultimate temperature.
• The heater operates until the water reaches the programmed “set
temperature”, then turns off. The heater will reactivate after the
water cools to approximately 1.5° below the “set temperature.”

Page 16
8. Place Cover On Spa
• Keeping the insulating cover in place anytime the spa is not in use
will reduce the time required for heating, thereby minimizing
operating costs.
• The time required for initial heat-up will vary depending on the
starting water temperature.
DANGER: Risk of injury, always check water temperature
carefully before entering spa!
Decontamination Procedure (Steps 9-15)
Steps 9-15 below are only required when sanitizer levels are unstable
after performing steps 1-6 above. Disregard steps 9-15 below if sanitizer
levels remain stable at 3 ppm to 5 ppm after performing steps 1-6 above.
9. Add 2.5 ounces of sodium dichlor for every 100 gallons of water.
Refer to the table below for approximate water ll volume by model.
CAUTION: Never add chlorine tablets (trichlor) to your
spa for any reason! This chemical may damage components
within your spa and void the manufacturer warranty.
Water Fill Volume by Model
Spa Model Approximate Fill Volume
Denali ........................................ 220 US Gallons (833 Liters)
Tacoma ...................................... 105 US Gallons (397 Liters)
Burlington .................................. 340 US Gallons (1,287 Liters)
10. Leave spa cover open during this step to allow excessive chemical
vapors to exit spa, protecting plastic knobs and pillows on Tacoma
and Burlington models from chemical attack. If spa is indoors, open
doors and windows for proper ventilation. Turn on all
spa jets pumps for one hour, open all air controls. On
Denali models, place the Divert-A-Jet in their center
“combo” position as shown (right). Note: You will need
to press the jets pump button(s) every 20 minutes since
these functions have an automatic 20 minute time-out
function that turns them off.
B
