P.N.:6530-397D Rev. A 980™ Series
Owner’s manual
Kingston™ Claremont™

Attention New Hot Tub Owner!
Congratulations on the purchase of your new Sundance®Spas hot tub!
The following is a list of automated functions performed by your hot tub.
These functions are listed below in an attempt to suppress any operational
concerns you may have during the rst 24 hours of ownership! Also listed
below are important maintenance recommendations you should observe
on a regular basis to protect your new investment.
Maintain Healthy Spa Water
Always maintain your hot tub’s water chemistry within the following
parameters:
With CLEARRAY® Without CLEARRAY
pH 7.4-7.6 7.4-7.6
Free chlorine no less than 1.0 ppm 3.0-4.0 ppm
Free Bromine no less than 2.0 ppm 2.0-4.0 ppm
Total Alkalinity 100-150 ppm 100-150 ppm
Calcium Hardness 150-250 ppm 150-250 ppm
IMPORTANT: CLEARRAY Water Purication System is factory in-
stalled. If the CLEARRAY system is altered or is not operating efcient-
ly follow the “without CLEARRAY” water chemistry parameters. Such
parameters are dened by the Association of Pool and Spa Profes-
sionals. CLEARRAY requires an annual lamp replacement to properly
sanitize your water.
!TO DECREASE RISK OF INFECTION OR DISEASE!
Always
maintain your spa lter as outlined below to ensure healthy spa water.
Refer to pages 56-58 for additional information.
Required Filter Maintenance
Your new hot tub is equipped with an advanced MicroClean® Ultra water
ltration system that provides unsurpassed water quality! To ensure
maximum water quality at all times, you should replace the lter cartridge
every six months, or earlier as necessary. The lter cartridge is designed
to be thrown away! Attempts to reuse the lter cartridge may result in
the re-release of unwanted particles back into the hot tub. See pages
56-58 for detailed lter cartridge replacement instructions.
Required Water Replacement
!TO DECREASE RISK OF INFECTION OR DISEASE!
You
should replace the hot tub’s water every 3 to 6 months. The frequency
depends on a number of variables including frequency of use, number of
users, and attention paid to water quality maintenance. You will know it is
time for a change when you cannot control sudsing and/or you can no
longer get the normal feel or sparkle to the water, even though the key
water balance measurements are all within the proper parameters. See
pages 63-65 for additional information.
****** Spa operation subject to change without notice ******

980™ Series
Table of Contents
1.0 Important Hot Tub Owner Information............................1
2.0 FCC Notice ........................................................................1
3.0 Important Safety Instructions for all Spa Owners .........2
3.1 Entrapment Risk .......................................................................... 6
3.2 Hyperthermia ............................................................................... 7
3.3 Important Additional CSA Safety Instructions (Canada Only)...... 8
4.0 Locating Your Sundance Hot Tub ...................................8
4.1 Outdoor Location ......................................................................... 9
4.2 Indoor Location .......................................................................... 10
4.3 Location for the SunSmart™ 2.0 System................................... 11
5.0 General Electrical Safety Instructions..........................12
6.0 Electrical Installation Instructions (240V Service).......12
7.0 Power Requirements......................................................16
7.1 North American 60 Hz Power Options ....................................... 16
7.2 Export 50 Hz Power Options...................................................... 17
8.0 Hot Tub Fill Up Procedure..............................................18
9.0 Hot Tub Features ............................................................23
9.1 Claremont™ Hot Tub Features .................................................. 23
9.2 Claremont Massage/Waterfall Selector Diagram....................... 24
9.3 Claremont Air Controls Diagram ................................................ 25
9.4 Kingston™ Hot Tub Features..................................................... 26
9.5 Kingston Massage/Waterfall Selector Diagram ......................... 27
9.6 Kingston Air Controls Diagram................................................... 28
10.0 Registration and Start-up...............................................29
10.1 Start-up Sequence..................................................................... 29
10.2 Register Your New Spa.............................................................. 29
10.3 Home Menu ............................................................................... 31
11.0 Operating Instructions ...................................................33
11.1 Activating the Jets Pumps and Blower....................................... 33
11.2 Lights Menu ............................................................................... 34
11.3 Music Menu................................................................................ 37
11.4 Connecting the BLUEWAVE® System with
your Bluetooth® device.............................................................. 38
11.5 Acoustics Settings Menu............................................................ 39
11.6 CLEARRAY on Demand ............................................................ 40
11.7 Selecting The Desired Massage Action ..................................... 40
11.8 Adjusting Fluidix Reex, Nex, ST, Intelli-Jets
And Focus-Relief ....................................................................... 40
© Sundance Spas, Inc. All Rights Reserved

980™ Series
11.9 Air Controls ................................................................................ 41
11.10 Waterfall Control ........................................................................ 41
11.11 Fragrance Dispenser ................................................................. 41
12.0 Programming and Operation Instructions ...................42
12.1 Draining the SunCooler.............................................................. 43
12.2 Programming the Heating Mode................................................ 45
12.3 Programming the Primary Filtration ........................................... 46
12.4 Programming the Secondary Filtration ...................................... 47
12.5 Cleanup Cycle............................................................................ 48
12.6 Blow-Out Cycle .......................................................................... 48
12.7 Water Care Programming .......................................................... 48
12.8 SunSmart 2.0 Wi-Fi Setup ......................................................... 51
12.9 Programming the Time and Date ............................................... 52
12.10 Locking the Spa ......................................................................... 53
12.11 Programming the Language ...................................................... 54
12.12 Units Display.............................................................................. 55
12.13 System Information.................................................................... 55
13.0 Hot Tub Maintenance......................................................56
13.1 Cleaning/Replacing the Filter Cartridge..................................... 56
13.2 Removing the cabinet panels..................................................... 58
13.3 Draining And Relling................................................................. 59
13.4 Cleaning The Hot Tub Interior.................................................... 60
13.5 Pillow Care................................................................................. 61
13.6 Maintaining the Hot Tub Cabinet................................................ 61
13.7 Cover Care And Maintenance.................................................... 61
13.8 Winterizing ................................................................................. 62
13.9 Restarting Your Hot Tub in Cold Weather .................................. 63
14.0 Water Quality Maintenance............................................63
14.1 pH Control.................................................................................. 64
14.2 Sanitizing ................................................................................... 64
14.3 CLEARRAY Water Purication System ..................................... 65
14.4 CLEARRAY Bulb Replacement and Quartz
Tube Maintenance ..................................................................... 66
14.5 Other Additives........................................................................... 68
14.6 Handrail Maintenance................................................................ 68
15.0 Troubleshooting - Display Messages ...........................69
16.0 Troubleshooting - Procedures.......................................72
17.0 Typical Hot Tub Wiring Diagrams A-B
(North American 60 Hz Models Only)............................74

980™ Series
18.0 Circuit Board Electrical Wiring Diagram ......................75
18.1 North American 60 Hz Electrical Wiring Diagram ...................... 75
18.2 Export 50 Hz Electrical Wiring Diagram..................................... 76
18.3 North American 60Hz Dip Switch Settings................................. 77
18.4 Export 50Hz Dip Switch Settings ............................................... 78
18.5 Dual Service 50Hz Connection.................................................. 80
18.6 Single Service 50Hz Connection ............................................... 80
18.7 Three Service 50Hz Connection................................................ 81

Page 1
980™ Series
1.0 Important Hot Tub Owner Information
Your Sundance®Spa hot tub is constructed to the highest standards
and is capable of providing many years of trouble-free use. However,
because heat retentive materials are utilized to insulate the hot tub for
efcient operation, an uncovered hot tub surface and wall ttings directly
exposed to sunlight and high temperatures for an extended period are
subject to permanent damage or discoloration. Damage caused by
exposing the hot tub to this abuse is not covered under warranty. We
recommend that you always keep the hot tub full of water when it is
exposed to direct sunlight and that you keep the Sundance insulating
cover in place at all times when the hot tub is not in use. Read and
carefully follow the requirements for your hot tub’s support base found in
the Section 4.0 titled, “Locating Your Sundance Hot Tub” (page 8) or
as prescribed by your authorized Sundance Spas dealer.
Sundance hot tubs constantly strives to offer the nest hot tubs
available, therefore, modications and enhancements may be made
which affect the specications, illustrations and/or instructions contained
herein.
2.0 FCC Notice
This equipment has been tested and found to comply with the limits for
a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
1. Rearrange or relocate the receiving antenna;
2. Increase the separation between the equipment and receiver;
3. Connect the equipment into an outlet on a circuit different from the
circuit connected;
4. Consult the dealer or an experienced radio/TV technician for help.
(Changes or modications not expressly approved by the party
responsible for FCC compliance could void the user’s authority to
operate this equipment).

Page 2
980™ Series
3.0 Important Safety Instructions for all Spa Owners
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!
This spa was manufactured to meet the standards and specications
outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB
Safety Act). When installing and using this spa, basic safety precautions
should always be followed, including:
1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
• Extreme caution must be exercised to prevent unauthorized access
by children.
• To avoid accidents, ensure that children do not use this spa unless
supervised at all times. Adult supervision is a critical safety factor in
preventing children from drowning.
• Use the straps and clip tie downs to secure the spa cover when not
in use. This will help discourage unsupervised children from entering
the spa. Keep the spa cover secure in high-wind conditions.
• There is no representation that the cover, clip tie-downs, or actual
locks will prevent access to the spa.
2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
• Keep hair, loose articles of clothing or hanging jewelry away from
suction ttings, rotating jets or other moving components to avoid
entrapment that could lead to drowning or severe injury.
• Never use the spa unless all suction guards, lter, lter lid, or skimmer
assembly are installed to prevent body and/or hair entrapment.
• Never operate or use the spa if the lter, lter lid, or skimmer
assembly are broken or any part of the skimmer assembly is missing.
Please contact your dealer or nearest service center for service.
• The suction ttings and suction covers in this spa are sized to match the
specic water ow created by the pump(s). If it is necessary to replace
the suction ttings, suction covers or pump(s), be sure that the ow
rates are compatible and are in compliance with the VGB Safety Act.
• Never replace a suction tting or suction cover with one rated less
than the ow rate marked on the original suction tting. Using
improper suction ttings or suction covers can create a body or hair
suction entrapment hazard that may lead to drowning or severe injury.
3. !DANGER: RISK OF SEVERE INJURY FROM ELECTRIC
SHOCK OR DEATH FROM ELECTROCUTION!
• Install the spa at least 5 feet (1.5m), from all metal surfaces. As an
alternative, a spa may be installed within 5 feet of metal surfaces
if each metal surface is permanently connected (bonded) by a
minimum No. 8 AWG (8.4 mm²) solid copper conductor attached
to the wire connector on the grounding lug, inside the equipment
compartment on the equipment box.

Page 3
980™ Series
• A grounding wire connector is provided on this unit to connect a
minimum No. 8 AWG (8.4 mm²) solid copper conductor between
this unit and any metal equipment, metal enclosures of electrical
equipment, metal water pipe, or conduit within 5 feet (1.5m) of the
unit.
• Never permit any electrical appliance, such as a light, telephone,
radio, television, etc. within 5 feet (1.5m) of a spa unless such
appliances are built-in by the manufacturer.
• Never bring any electrical appliances into or near the spa.
• Never operate any electrical appliances from inside the spa or when
you are wet.
• The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with section 422-20 of the National Electrical Code/
USA, ANSI/NFPA 70. The disconnecting means must be readily
accessible and visible to the spa occupant but installed at least 5
feet (1.5m), from the spa.
• The electrical circuit supplied for the hot tub must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC Article
680-42.
4. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Extreme caution must be exercised to prevent diving or jumping
into the spa or slipping and falling, which could result in
unconsciousness, drowning, or serious injury. Remember that wet
surfaces can be very slippery.
• Never stand, walk or sit on the top railing of the spa.
5. !WARNING: RISK OF HYPERTHERMIA (OVER-HEATING)
CAUSING SEVERE INJURY, BURNS, WELTS OR DEATH!
• Water temperature in excess of 104°F (40°C) may be injurious to
your health.
• Refer to Section 3.2 Hyperthermia for specic causes and symptoms
of this condition.
• The water in the spa should never exceed 104°F (40°C). Water
temperatures between 100°F (38°C) and 104°F (40°C) are
considered safe for a healthy adult.
• Lower water temperatures are recommended for young children
(children are especially sensitive to hot water) and when spa use
may exceed 10 minutes.
• The Consumer Products Safety Commission/USA has stated that
the water temperature in a spa should not exceed 104°F (40°C).
• Always test the spa water temperature before entering the spa.
The user should measure the water temperature with an accurate
thermometer since the tolerance of water temperature-regulating
devices may vary as much as +/- 5°F (2°C).

Page 4
980™ Series
6. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Since excessive water temperatures have a high potential for
causing fetal damage during the early months of pregnancy, if
pregnant or possibly pregnant, consult your physician before using a
spa.
• Pregnant or possibly pregnant women should limit spa water
temperatures to 100°F (38°C).
• Persons suffering from obesity or a medical history of heart disease,
low or high blood pressure, circulatory system problems, diabetes,
infectious diseases or immune deciency syndromes should consult
a physician before using a spa.
• If you experience breathing difculties in association with using or
operating your spa, discontinue use and consult your physician.
• Persons using medication should consult a physician before using
a spa since some medication may induce drowsiness, while other
medication may affect heart rate, blood pressure, and circulation.
• Persons suffering from any condition requiring medical treatment, the
elderly, or infants should consult with a physician before using a spa.
• The use of alcohol, drugs, or medication before or during spa use
may lead to unconsciousness with the possibility of drowning.
7. !WARNING: RISK OF SEVERE INJURY OR DEATH!
• Prolonged immersion in a spa may be injurious to your health.
• Observe a reasonable time limit when using the spa. Exposures
at higher temperatures can cause high body temperature (over-
heating). Symptoms may include dizziness, nausea, fainting,
drowsiness, and reduced awareness. These effects could possibly
result in drowning or serious injury.
• Never use a spa immediately following strenuous exercise. Enter
and exit the spa slowly. Wet surfaces can be slippery.
8. !WARNING: TO DECREASE RISK OF INFECTION OR
DISEASE!
• To reduce the risk of contracting a waterborne illness (e.g. an infec-
tion, bacteria or virus) and/or respiratory ailments , maintain water
chemistry within the parameters listed on the inside cover of this
manual and consult with a licensed engineer regarding proper venti-
lation if installed indoors or in an enclosed area.
• People with infectious diseases should not use a spa to avoid water
contamination, which could result in spreading infections to others.
• Always shower before and after using your spa. Maintain water
chemistry in accordance with manufacturer’s instructions. Failure to
do so may result in contracting a waterborne illness (e.g. an infec-
tion, bacteria or virus).

Page 5
980™ Series
9. !WARNING: In addition to maintenance of lters and water
chemistry, proper ventilation is recommended to reduce the risk of
contracting a waterborne illness (e.g. an infection, bacteria or virus)
and/or respiratory ailments that could be present in the air or water.
Consult a licensed architect or building contractor to determine your
specic needs if installing your hot tub indoors.
10. CAUTION: TO DECREASE RISK OF PRODUCT DAMAGE.
• Maintain water chemistry in accordance with manufacturer’s
instructions.
• Proper chemical maintenance of spa water is necessary to maintain
safe water and prevent possible damage to spa components.
11. !WARNING: RISK OF SEVERE INJURY OR DEATH!
The appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
12. NOTE: This spa is not intended nor designed to be used in a
commercial or public application. The spa buyer shall determine
whether there are any code restrictions on the use or installation
of this spa since local code requirements vary from one locality to
another.
Hot Tub Safety Literature
To ensure you have a safe and enjoyable hot tub experience,
learn all you can about hot tub safety and emergency procedures.
Especially useful are the brochures listed below:
• Children Aren’t Waterproof
• Pool and Spa Emergency Procedures For Infants and Children
• Layers of Protection
• The Sensible Way to Enjoy Your Spa or Hot Tub
The Association of Pool and Spa Professionals publishes these
brochures. To acquire a brochure:
• Ask your hot tub dealer (they may have copies)
• Go to http://www.apsp.org
• Conduct your own search on the internet
• Write to the following address:
The Association of Pool and Spa Professionals
2111 Eisenhower Avenue
Alexandria VA 22314
703.838.0083

Page 6
980™ Series
3.1 Entrapment Risk
The Consumer Products Safety Commission/USA has reported that
users of pools and spas have become entrapped (stuck) to drain and/or
suction ttings causing death, drowning, or serious injury (see diagram
below). This spa was manufactured to meet the standards and specica-
tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”
(VGB Safety Act). Entrapment risk can be minimized if proper precau-
tions are taken.
DANGER: RISK OF PERSONAL INJURY OR DEATH!
Never operate the spa if a suction tting, suction cover, lter, lter
lid or skimmer assembly are broken, damaged or missing.
!
NOTE: SUCTION COVERS MUST BE REPLACED EVERY 5 YEARS.
1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Hair entrapment: May occur if hair is entangled, knotted or snagged
in a drain suction or skimmer assembly. This has been reported in
persons who when submerge themselves underwater, allowing hair
to come close and/or within the reach of the suction ttings, suction
covers or skimmer assembly.
• Keep hair away from suction ttings, suction covers, lter, lter lid or
skimmer assembly.
• Children are at risk for hair entrapment if swimming under water.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Limb entrapment: May occur when a limb becomes entrapped,
inserted or sucked into a suction or outlet opening.
• Always keep suction ttings, suction covers, lter, lter lid
or skimmer assembly in place when operating to avoid limb
entrapment.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
Filter, Filter Lid,
Skimmer Assembly
Suction Fittings,
Suction Covers
(locations vary
by models)

Page 7
980™ Series
3. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Body entrapment: May occur when part of the torso becomes
entrapped, inserted or sucked into a suction or outlet opening.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
4. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Evisceration (disembowelment) entrapment: May occur when the
buttocks becomes entrapped, inserted or sucked into a suction or
outlet opening.
• Never sit on suction ttings, suction covers, lter, lter lid or skimmer
assembly.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
5. !DANGER: RISK OF SEVERE INJURY OR DROWNING!
Mechanical entrapment: May occur when jewelry, swimsuit, or
hair accessories become entangled, knotted or snagged in a drain
suction or skimmer assembly.
• Never allow your jewelry, swimsuit, or hair accessories to come close
to the suction ttings, suction covers or skimmer assembly.
• Never allow children to play or get near the suction ttings, suction
covers, lter, lter lid or skimmer assembly.
3.2 Hyperthermia
Prolonged immersion in hot water may induce hyperthermia (over-
heating). The use of alcohol or drugs can greatly increase the risk of fatal
hyperthermia in spas. A description of the causes, symptoms, and effects
of hyperthermia are as follows:
Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above the normal body temperature of 98.6°F
(37°C). The symptoms of hyperthermia include drowsiness, lethargy
(fatigue), and an increase in the internal temperature of the body (feeling
of being too hot). The effects of hyperthermia include:
• Unawareness of impending hazard;
• Failure to perceive heat;
• Failure to recognize the need to exit spa;
• Physical inability to exit spa;
• Fetal damage in pregnant women; and
• Unconsciousness and danger of drowning.
A Warning Sign is provided in your warranty packet. Please install at
a location near your spa, where it is visible to users of the spa. For
additional or replacement Warning Signs please contact your local
Sundance spas dealer and reference item number #6530-082.

Page 8
980™ Series
3.3 Important Additional CSA Safety Instructions (Canada Only)
When using this electrical equipment, basic safety precautions should
always be followed, including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. A green colored terminal or a terminal marked G, Gr, Ground,
Grounding or the symbol* is located inside the supply termi-
nal box or compartment. To reduce the risk of electric shock, this
terminal must be connected to the grounding means provided in the
electric supply service panel with a continuous copper wire equiva-
lent in size to the circuit conductors that supply this equipment (*IEC
Publication 417, Symbol 5019).
3. At least two lugs marked “Bonding Lugs” are provided on the exter-
nal surface or on the inside of the supply terminal box/compartment.
To reduce the risk of electric shock, connect the local common bond-
ing grid in the area of the spa to these terminals with an insulated or
bare copper conductor not smaller than No. 6 AWG (10 mm²).
4. All eld installed metal components such as rails, ladders, drains or
other similar hardware within 10 feet (3m) of the spa shall be bonded
to the equipment grounding buss with copper conductors not smaller
than No. 6 AWG (10 mm²).
5. SAVE THESE INSTRUCTIONS.
4.0 Locating Your Sundance Hot Tub
WARNING: For spas that are to rest on balconies,
roofs or other platforms not specically tied into main
structural support, consult a professional Structural En-
gineer with experience in this type of application.
!
IMPORTANT: Because of the combined weight of the spa, water
and users, it is extremely important that the base upon which the
spa rests be smooth, at, level and capable of uniformly support-
ing this weight, without shifting or settling, for the entire time the
spa is in place. If the spa is placed on a surface which does not
meet these requirements, damage to the skirt and/or the spa shell
may result. Damage caused by improper support is not covered
under warranty. It is the responsibility of the spa owner to assure
the integrity of the support over time. We recommend a poured,
reinforced concrete slab with a minimum thickness of 4 inches (10
cm). Wood decking is also acceptable provided it is constructed so
that it meets the requirements outlined above.

Page 9
980™ Series
The spa must be installed in such a manner as to provide drainage away
from it. Placing the spa in a depression without provisions for proper
drainage could allow rain, overow and other casual water to ood the
equipment and create a wet condition in which it would sit in. For spas
which will be recessed into a oor or deck, install so as to permit access
to the equipment, either from above or below, for servicing. Make certain
that there are no obstructions which would prevent removal of all side
cabinet panels and access to components, especially on the side with
the equipment bay doors.
CAUTION: If the spa is indoors or located in an enclosed area,
proper ventilation should be discussed with an Engineer or authority
competent enough to understand the necessary provisions needed
to vent moist or heated air and air associated with chemical odors
outdoors. When the spa is in use considerable amounts of
moisture will escape potentially causing mold and mildew. This
can cause health risk. Over time, this can damage certain surfaces,
surroundings, and equipment.
4.1 Outdoor Location
In selecting the ideal outdoor location for your hot tub, we suggest that
you take into consideration the following:
• The proximity to changing area and shelter (especially in regions
subject to cold weather).
• The pathway to and from your hot tub (this should be free of debris
so that dirt and leaves are not easily tracked into the hot tub).
• The closeness to trees and shrubbery (remember that leaves and
birds could create extra work in keeping the hot tub clean).
• A sheltered environment (less wind and weather exposure can result
in lowered operation and maintenance costs).
• The overall enhancement of your environment. It is preferable not
to place the hot tub under an unguttered roof overhang since run-off
water will shorten the life expectancy of the hot tub cover.
• For spas that are to rest on balconies, roofs or other platforms not
specically tied into main structural support, consult a professional
Structural Engineer with experience in this type of application.
• In the unlikely event that you should ever need to access or gain
entry to any portion of the spa for servicing, it is highly recommended
that you plan your outdoor installation to provide full access to the
entire spa. Please take this into consideration when placing the spa
in a deck or enclosed by a surrounding.
• Consider locating your spa away from any reective surface or glass
to prevent any damage to the synthetic skirt.
• Do not shim the spa. To ensure proper support the spa must sit at
on the intended foundation.
!

Page 10
980™ Series
4.2 Indoor Location
For indoor installations many factors need to be considered before
installing a spa indoors:
WARNING: In addition to maintenance of lters and water
chemistry, proper ventilation is recommended to reduce the
risk of contracting a waterborne illness (e.g. an infection, bac-
teria or virus) and/or respiratory ailments that could be pres-
ent in the air or water. Consult a licensed architect or building
contractor to determine your specic needs if installing your
hot tub indoors.
!
• PROPER FOUNDATION: Consult a Structural Engineer when
considering a foundation that will adequately support the spa
the entire time it is in place. Proper support is critical especially
if the spa is to rest on a second story or higher. For spas that are
to rest on balconies, roofs or other platforms not specically tied
into the main structural support, you should consult a professional
Structural Engineer with experience in this type of application.
• PROPER DRAINAGE: It is extremely important to have in place
measures to sufciently handle excessive water spillage. Be
sure the ooring in which the spa rests on has adequate drainage
and can handle draining of the entire contents of the spa. Be sure
to make provisions for ceilings or any other structures that may be
below the spas installation. Areas around your spa can become wet
or moist so all ooring and subsequent furniture, walls and adjacent
structures should be able to withstand or resist water and moisture.
• PROPER VENTILATION: Proper ventilation should be discussed
with an Engineer or authority competent enough to understand
the necessary provisions needed to vent moist or heated air
and air associated with chemical odors outdoors. When the spa
is in use considerable amounts of moisture will escape potentially
causing mold and mildew, over time this can damage certain
surfaces and or surroundings.
• SUFFICIENT ACCESS: In the unlikely event that you should ever
need to access or gain entry to any portion of the spa for servicing,
it is highly recommended that you plan your indoor installation to
provide full access to the entire spa.
• WARRANTY: Damage caused by not following these guidelines
or any improper installation not in accordance with local codes or
authorities is not covered under the spas warranty. Please consult
your local state or city building ordinances.
• DO NOT SHIM THE SPA. To ensure proper support the spa must sit
at on the intended foundation.

Page 11
980™ Series
4.3 Location for the SunSmart™ 2.0 System
IMPORTANT! Choose an installation site with the front control panel
side pointing towards your home’s Wi-Fi router.
CAUTION: You must make sure that the spa control panel side
has a clear unobstructed line-of-site of the home Wi-Fi router. This
action ensures maximum signal strength between the spa and your
home’s Wi-Fi router.
Verify your home router’s Wi-Fi strength
at the proposed spa location. Front side of
spa must point towards your home’s Wi-Fi
router in your home as illustrated, Figure
4.3a. Stand near the proposed front control
panel side of the spa with your cell phone,
then login to the internet using your home
Wi-Fi router signal (not 3G or 4G) and verify
results as follows:
If the home Wi-Fi router signal is strong
(3-4 bars) and Internet access is stable,
the proposed installation site is a good choice. Visit our
website, www.SundanceSpas.com, for more information.
If the home router’s Wi-Fi signal is weak and Internet access is slow or
produces an error, the proposed installation site is not a good choice.
• It may be necessary to choose another spa installation site.
• Relocate your home Wi-Fi router closer to the spa.
• Install a “repeater” device in the room closest to the spa to boost the
home’s router Wi-Fi signal at the proposed spa installation site.
System and Wi-Fi Router Requirements
a. The hardware for the SunSmart 2.0 communicates over a 2.4 GHz
home network supporting 802.11b/g wireless technology.
Note: The system does not support 802.11 ac/n. If your Wi-Fi router
is either 802.11 ac or n, it may work with the module if it supports
802.11b/g. The hardware does not support 5 GHz networks.
b. Standard wireless setup supports only home network routers
congured to use open (no security) or WEP/WPA/WPA2.
c. Wi-Fi signal strength of -60 dBM or better is highly suggested to
ensure non-interrupted cloud service.
d. The wireless access is not supported on the following systems
• Guest networks/Hotspots that use a portal page to login.
• Enterprise access points congured to require certicates or
some other form of enterprise authentication (aka “802.1X”,
“RADIUS”, or “WPA/WPA2 Enterprise”).
e. The App is only compatible with Android or Apple Phones.
• Always make sure you have the latest operating system for your
phone.
Note: Router ports 3197 and 3199 need to be open.
Home WiFi
Router
6:45
Auto
100
Figure 4.3a

Page 12
980™ Series
5.0 General Electrical Safety Instructions
Your new Sundance Spas hot tub is equipped with the “state-of-
the-art” equipment system. It contains the most advanced safety
and self-protective equipment in the industry. Nonetheless, this
hot tub must be installed properly to ensure dependable usage. Please
contact your local Sundance Spas dealer or local building department
should you have any questions regarding your installation.
Proper grounding is extremely important. Sundance hot tubs are
equipped with a current collector system. A pressure wire connector is
provided on the surface of the control box, located inside the equipment
door (Figure C, page 15) to permit connection of a bonding wire
between this point and any ground metal equipment, metal water pipe or
conduit within 5 feet (1.5m) of the hot tub, or copper clad grounding rod
buried within 5 feet (1.5m) of the hot tub. Bonding wire must be at least
No. 8 AWG (8.4 mm²) solid copper wire. This is a most important safety
assurance feature.
Before installing your hot tub, check with your local government/electrical
authority to ensure installation conforms to local country/area state
codes.
6.0 Electrical Installation Instructions (240V Service)
IMPORTANT NOTICE: The electrical wiring of this hot tub must
meet the requirements of the National Electrical Code (NEC) and
any applicable state, local or country codes. The electrical circuit
must be installed by a qualied electrician and approved by a local
building/electrical inspection authority in your state or country.
1. !DANGER: TO DECREASE THE RISK OF SHOCK,
PRODUCT DAMAGE OR ELECTRICAL FIRE.
This hot tub must be permanently connected (hard-wired) to the
power supply. No plug-in connections or extension cords are
to be used in conjunction with the operation of this hot tub.
Supplying power to the hot tub which is not in accordance with these
instructions will void both the independent testing agency listing and
the manufacturer’s warranty.
2. The power supplied to this hot tub must be a dedicated circuit with no
other appliances or lights sharing the power provided by the circuit.
3. To determine the current, voltage and wire size required, refer to
Section 7.0 (page 16) for your specic hot tub model.
• Wire size must be appropriate per NEC and/or local/country codes.
• We recommend type THHN wire.
• All wiring must be copper to ensure proper connections. Do not use
aluminum wire.

Page 13
980™ Series
• When using wire larger than #6 (10 mm²), add a junction box near
the hot tub and reduce to short lengths of #6 (10 mm²) wire to
connect to the hot tub.
4. The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with Section 422-20 of the National Electrical Code, ANSI/
NFPA 70. The disconnecting means must be readily accessible and
visible to the hot tub’s occupant but installed at least 5 feet (1.5m)
from the hot tub.
5. For Australia/New Zealand, the spa should be supplied through
a residual current device (RCD) with a rated tripping current not
exceeding 30mA (IEC 60335-2-60).
6. The electrical circuit supplied for the hot tub must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC Article 680-42.
7. An appropriate size breaker must be used depending on the model,
see chart on page 16. The electrical supply for this product must
include a suitably rated isolating switch and circuit breaker to comply
with local electrical regulations. This RDC/GFCI circuit breaker must
be installed at the power supply in the house electrical box.
8. Select the power supply entrance you want to use (Figure B, page
14) and remove the cabinet panel from the front of the hot tub,
then feed cable through the large opening provided on the bottom of
the control box.
9. To gain access to the hot tub’s power terminal block you will need to
remove the front corner and center cabinet, (Figure A, page 14).
These cabinets are located under the SunCooler™ side of the hot tub.
10. Grab one of the corner panels, from the bottom, and gently pull
the cabinet forward to unsnap it from the holding clip. Then slide it
down to remove. Place the panel is a safe location to prevent from
damaging it. Repeat the steps to remove the other corner panel.
Reference Figure A, page 14.
11. Remove the center panel. Grab either the top left or top right side
of the front center panel. Gently pull the cabinet forward to unsnap
it from the holding clips. Make sure to support the cabinet as you
work your way down the side to completely unclip it from the hot
tub frame. Once completely unclipped, tilt slightly forward and lift
up to remove it from the hot tub frame. Note: Two people might be
required for this process. Reference Figure A, page 14.
12. Connect wires, color to color, on terminal blocks TB1 and TB3 (page
15). TIGHTEN SECURELY! All wires must be hooked up securely
or damage could result.
13. Install the control box door and reinstall the cabinet panel(s).

Page 14
980™ Series
Figure A
Figure B
Power
on
Lamp
on
DANGER!
TURNPOWER
OFF!DONOT
LOOKATLIT BULB.
SEVEREEYE
DAMAGEORBLINDNESS
CANOCCUR!
Power
on
Lamp
on
DANGER!
TURNPOWER
OFF!DONOT
LOOKATLIT BULB.
SEVEREEYE
DAMAGEORBLINDNESS
CANOCCUR!
Power
on
Lamp
on
DANGER!
TURNPOWER
OFF!DONOT
LOOKATLIT BULB.
SEVEREEYE
DAMAGEORBLINDNESS
CANOCCUR!
Power
on
Lamp
on
DANGER!
TURNPOWER
OFF!DO NOT
LOOKATLIT BULB.
SEVEREEYE
DAMAGEOR BLINDNESS
CANOCCUR!
7
22
3
11
1
4
10
13 5
9
15
16
18
19
18
17
14
12
8
6
Note: Equipment location (such as pumps, CLEARRAY® system,
drain, heater etc.) varies by model.
1. Control Box
2. Power Supply Entrance(s)
3. Blower
4. Jets Pump
5. Heater
6. Jets Pump
7. Pump Drain Plug(s)
8. Filter/Circulation Pump
9. CLEARRAY (Ultraviolet)
Water Purication System
10. Quick Drain
11. Hot Tub Drain
12. Control Panel
13. BLUEWAVE® 2.0 Wireless
Audio System (Optional)
14. SunSmart™ 2.0 Wi-Fi
15. CLEARRAY PRO3TECT™
(Optional)
16. Cabinet Mounting clips
17. Cabinet Mounting slot
18. SunCooler™
19. ABS Pan
Remove Corners
(unclip bottom
rst)
Unclip across
the top
