Sundirect PE-Plus Installation instructions

PE-Plus IC-Plus GD-Plus MD-Plus
Infrared Panel Heater
Installation & Operation Instructions
Version: SDUM-1801-01
EN NL UHR

Table of Contents
1. Notice to purchaser
2. General Introduction
3. Safety Instructions
1. Product related safety warnings
2. Dangers for children and persons with limited abilities
3. Electric safety directions
4. Waterproof
4. How to care for your heater
1.Cleaning
4.2Using/Working
4.3Repair
4.4Disposal
5. Installation and operation guide
1. Description
2. Pair to Sundirect Smart control system
3. Dismiss the connection between receiver and remote control
4. Installation manual for PE-Plus Series
5. Installation manual for IC-Plus|GD-Plus|MD-Plus Series
6. Electric power connection
6. Technical specifications
7. Warranty
EN
2

3
1. Notice to Purchaser
Thanks for purchasing this Sundirect infrared heater.We hope you enjoy this innovative technology
and that this product will bring apleasant atmosphere to your home.
Please read these instructions carefully and keep safe for future use.Failure to comply with these
instructions will void your warranty.Do not disassemble or tamper with the product at any time!
Please pay special attention to the safety instructions and use the heater according to these
instructions.Sundirect Technology Ltd.shall not be liable for any damage or loss occurred
resulting from failure to follow these instructions.
2. General Introduction
Sundirect Infrared heaters heat objects instead of the air, making this heater much more efficient
than traditional convection heaters.
The Sundirect Plus series represents anew generation of infrared panel heaters, equipped with a
built-in thermostat receiver inside of the junction box (Article Number:Receiver01)on the
backside of the panel.It needs to be used in conjunction with the Sundirect control system -Smart
1.0 or Smart 1.0Pro (NOT included in the box) -in order to meet the Ecodesign legislation of the
EU/EC Directive 2009/125/EC.
Our remote control Smart 1.0 has the following features:
* 7days program, 4time zones each day
*Adaptive start
While remote control Smart 1.0Pro is an upgraded version of Smart 1.0 and has the following
features:
* 7days program, 4time zones each day
*Open window technology
*Adaptive start
*Remote controllable by Mobile APP.
You may find detailed specifications and instructions in the manual of Smart 1.0/1.0Pro
separate from this manual.
This product complies with the LVD guideline 2014/35/EU and the EMC guideline 2014/30/EU
and meets the following standards:
EN60335-1:2012+A11:2014
EN60335-2-30:2009+A11:2012
EN62233:2008
Rohs 2011/65/EU
RED2014/53/EU

Read the installation and operating instructions completely before
starting any installation works and save the instructions for later use.
3. Safetyinstructions
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
1. Product related safety warnings
•Sundirect infrared heaters operate at a surface temperature of around 95°C when wall
mounted. Do NOT touch the heater when switched on.
•Prolonged contact may cause injuries or burns.
•Do NOT cover the heater with anything. Covering may cause overheating and can result in fire.
•The heater should NOT be used to dry textiles and no objects shall be placed or leaned
against the heater.
•Keep adistance of at least 40cm in the front and 20cm on the sides to any object, wall or
ceiling. Failure to do so will cause heat to build up behind the heater and will void your warranty.
•If mounting the heater on the ceiling keep aminimum distance from the ceiling of 2cm to
ensure airflow avoiding overheating of the heater.
•If integrating the heater into aceiling grid make sure not to place any insulation material
directly onto the rear of the panel to avoid overheating.
3.2 Dangers for children and persons with limited abilities
•Children or persons with limited physical, mental or sensory abilities shall not be operating,
switching on, plugging in, regulating or cleaning the heater.
•Small children should be kept away from the heater unless constantly supervised.
•Do NOT operate the heater in small rooms when occupied by people not capable of leaving the
room by themselves. The surface of the heater can reach a surface temperature of up to 95°C,
keep out of reach of children and disabled persons.
•Keep away babies and children from all packaging material such as plastic bags to avoid danger
of suffocation.
4

5
3.3 Electric safety directions
•When installing, repairing or servicing the heater it must be turned off and disconnected from
power.Before installation please check if the heater is free of damages.
•If the heater or the power cord is damaged in any form do NOT use the heater and contact your
Sundirect dealer for repair or replacement.Repairs, maintenance or any changes must be carried
out by an authorized Sundirect dealer.
•Do NOT attempt to repair the heater by yourself, this will void your warranty.
•If the heater has been dropped do NOT operate it and contact your Sundirect dealer to make
sure it is free of any damages.
•If the safety glass from the GD-Plus/MD-Plus series is damaged in any way please dismount
the heater as soon as possible to avoid any injuries from possible impact of the falling glass.
•Sundirect heaters are designed to operate at 220-240V, 50Hz AC. If your supply mains do
not comply with this, do NOT use the heater.
3.4 Water Proof
Sundirect infrared heaters have different IP ratings on different models.Please make sure to only
install heaters with IP44 rating in humid rooms.Heaters with IPX2ratings are not suitable to be
installed in bathrooms etc.Please carefully check the specifications to confirm if your heater is
suitable for installation in humid rooms.
This heater is not suited for installation outdoors. Installations in humid rooms must be carried out
by aqualified electrician/installer and must comply with the local electrical safety requirements.
When installing the heater in humid rooms it must be secured in such way that there is no risk of
the heater falling into any water container.Never pour water on the device or put it in awater
container.The installer must make sure that switches and electrical controls cannot be touched by
any person in ashower/bathtub/swimming pool etc.
Sundirect shall not be liable for any injuries or damages resulting from inadequate mounting or
incorrect positioning close to water sources.
4. How to care for your Sundirect heater
1. Cleaning
Always unplug your heater and let it cool down completely before cleaning.Never dip into water
and never splash water on it.Clean the heater with asoft damp cloth.For glass models such as the
GD, MD series use asoft cloth and glass cleaner. Never use awet cloth and make sure to dry the
heater when clean with adry cloth.Do not use any abrasive materials, solvents or harsh cleaning
sponges as this could cause scratches or other irreparable damage.Before operating the heater
again it must be completely dry.
2. Using/Working
Please note that the heater may discolour with use.This is due to airborne pollution and is not a
fault.If you wish to add apicture print to your heater please contact aSundirect dealer.Do not
cover your heater with apicture foil and do not paint or print the heater yourself.This might cause
damage to the heating element and will void your warranty.

If you notice any noise, smells, visible changes or exceptionally high temperatures please
discontinue use and contact an authorized Sundirect dealer.
3. Repair
Repairs must be carried out by authorized Sundirect dealers or by Sundirect directly. If you
attempt to alter the product or to proceed with any repairs yourself it will void your warranty.
4. Disposal
Sundirect infrared heaters are electric appliances and therefore electric waste.At the
end of its working life please dispose the heater in accordance with local regulations
concerning electric waste.
6

5. Installation &Operation Guide
1. Description
This heater is equipped with our built-in
thermostat receiver -Receiver01 -on the
backside of the panel. Before starting the
installation, we recommend you to pair the
receiver to our remote control as afirst step.
Follow the guide below to finish the pairing
to the Smart control system (e.g. Smart 1.0,
Smart 1.0Pro).
On the right see the drawing of the signal
lights and button of Receiver01.
1)
2)
3)
4)
Pair status signal light (green light)
Heating status signal light (red light)
“P” button
Power switch
2.Pairing to Sundirect Smart control
system
Step1: Plug your heater to an electrical outlet, switch the Power switch of Receiver01 on,
double press the “P” button and the “Pair signal light” will start to flash and is ready for pairing.
Step2: Power-off the remote control Smart 1.0/Smart 1.0Pro, long press the “SET” button. The “PAIR”
signal will show on the screen of the remote control. Wait until the “Pair signal light” stops flashing
and glows green to finish the pairing. Now the pairing process is finished and the Receiver01 will
only be commanded by Smart 1.0/Smart 1.0Pro.
Note: After the pairing process and once Receiver01 and Smart 1.0/Smart 1.0Pro are paired, the
pair signal light will always be on and the Receiver01 will be only commanded by the Smart 1.0/
Smart 1.0Pro. One Receiver01 can only pair to one Smart1.0/Smart1.0 Pro, however, One Smart 1.0/
Smart 1.0Pro thermostat can be paired to several Receiver01 if they are in the same room.
3. Bypass mode
Long-press the “P” button on Receiver01 until the “Pair signal light” is off and the “Heating status
signal light “on, the panel will be reset to bypass mode. In the bypass mode, the Receiver01 is
disabled and the panel is connected directly to the electricity.
7

5.4 Mounting installation for PE-Plus series
Note:The kit supplied in the package is designed for mounting on asolid wall.If mounted onto
other types of walls, you will need appropriate fixings (not supplied).Please make sure the wall is
safe to mount.We highly recommend having the panel installed by aqualified electrician or
installer authorized by Sundirect.
If you wish to mount the above panels on the ceiling, please contact your Sundirect dealer to
purchase the right ceiling bracket.For PE380-Plus, you need the bracket BC005,and for the other
models, you will need BC004.You will find the mounting instruction in the package of BC004/
BC005 separately.
Step 1. Use the supplied
template to mark the
position of the holes on the
wall.
Step 2. Drill holes using a
8mm drill.
Step 3. Insert the dowels
into the holes.
Step 4. Screw in the
supplied screws to the wall.
Step 5. Mount the panel on
the screws.
Step 6. Move the panel to
the right or left side until it’s
secured.
1
Wall Installation Template
WALL
2
WALL
3
WALL
4
WALL
5
WALL
6
WALL
8

5.5 Mounting installation for IC-Plus/GD-Plus/MD-Plus series
The kit supplied in the package is designed for the mounting on asolid wall/ceiling.If mounted
onto other types of wall/ceiling, you will need appropriate fixings (not supplied).Please make sure
the wall/ceiling is safe to mount.We highly recommend to have the panel installed by aqualified
electrician or installer authorized by Sundirect.
Please note that GD-Plus/MD-Plus series are designed only for wall mounting, don’t mount them
on the ceiling.
Step 1. Use the supplied
mounting bracket to mark the
position of the holes on the
wall/ceiling. For vertical wall
mounting, “A” signal will be
the top of the mounting
bracket. For horizontal wall
mounting “B” signal will be
the top of the mounting
bracket.
Step 2. Drill holes using a
8mm drill.
Step 3. Insert the dowels into
the holes.
Step 4. Screw the screws into
the dowels through the holes
on the mounting bracket.
Step 5. Mount the panel on
the mounting bracket.
Step 6. Move the panel into
two directions to make sure
the panel is secured.
1
WALL
CEILING
2
WALL
CEILING
3
WALL
CEILING
4
WALL
CEILING
5
WALL
CEILING
6
WALL
CEILING
9

10
5.6 Electric power connection
Installation and electric connection should only be carried out by qualified personnel such as an
electrician.National electric safety standards must be considered when wiring to this panel.This is
aIEC protection Class 1appliance and it must be earthed.
Make sure the mains power is switched off before you start the installation when hardwiring.Any
fixed wiring outside the heater coming into contact with the heater must have a protection
sleeving that is heat resistant of at least 90°C. Make sure that cables are not coiling and that there is
no excess cable behind the heater.The length of the cable should be measured exactly to the
length needed.Do not connect aheater that is damaged in any way to the power network.Before
installation, make sure that the heater, cable and plug are completely free from damages.When in
doubt contact your local Sundirect dealer for assistance.
6. Technicalspecifications:
Panels covered by these instructions are listed in the table below.
Model
Power
Size
Weight
Mounting
Built
-in
t
hermostat
receiver
IP
Protection
PE350-Plus
350W
60*60cm
4.1Kg
Wall/Ceiling
Yes
IPX2
PE380-Plus
380W
30*120cm
4.3Kg
Wall/Ceiling
Yes
IPX2
PE540-Plus
540W
60*90cm
6.0Kg
Wall/Ceiling
Yes
IPX2
PE700-Plus
700W
60*120cm
7.8Kg
Wall/Ceiling
Yes
IPX2
PE1000-Plus
1000W
85*120cm
11.4Kg
Wall/Ceiling
Yes
IPX2
IC400-Plus
400W
60*60cm
8.0Kg
Wall/Ceiling
Yes
IPX2
IC700-Plus
700W
62*98cm
13.8Kg
Wall/Ceiling
Yes
IPX2
IC900-Plus
900W
68*123cm
18.0Kg
Wall/Ceiling
Yes
IPX2
IC1100-Plus
1100W
63*153cm
20.0Kg
Wall/Ceiling
Yes
IPX2
GD400-Plus
400W
66*66cm
12.4Kg
Wall only
Yes
IP44
GD600-Plus
600W
60*100cm
16.4Kg
Wall only
Yes
IP44
GD800-Plus
800W
70*130cm
24.1Kg
Wall only
Yes
IP44
MD300-Plus
300W
66*66cm
12.4Kg
Wall only
Yes
IP44
MD450-Plus
450W
60*100cm
16.4Kg
Wall only
Yes
IP44
MD650-Plus
650W
70*130cm
24.1Kg
Wall only
Yes
IP44
