Sun System 1
Sun System 1
®
ETELLIGENT
CONTROLLER
INSTRUCTION
MANUAL
Vancouver, WA • Eureka, CA • Livermore, CA • Ontario, CA
Denver, CO • Detroit, MI • York, PA • Nashville, TN
Pompano Beach, FL • Vancouver, B.C. Canada
sunlightsupply.com
Control Sun System®1 Etelligent™Ballasts
with the same controller—operating on 2 separate channels.

Thank you for purchasing the Etelligent™ Controller for programming the Sun System® 1
Etelligent Ballasts with signal ports for on/off/dimming functions. This is a dual zone controller
which can control up to 400 lights (up to 200 in each of 2 zones).
1. Sun System One Controller
This low profile Etelligent Controller is designed to
be paired with Sun System 1 Etelligent Electronic
Ballasts. The Etelligent Controller enables a timed
on/off function, accurate temperature readings,
thermal protection shut off and a timed sunrise/
sunset function.
NOTE: Before connecting to controller, please
make sure the knob is rotated to RC position first.
(1) AC Adapter
(120-240V)
(1) Patch Cord (2) Control
Cables
For connecting ballast to ballast.
No magnetic ring on cable.
For connecting ballast to controller.
Magnetic rings on cable.
(2) Temperature
Probes
2. Sun System One Controller accessories
3. Connection between ballast and controller
ETELLIGENT
CONTROLLER
ZONE A (up to 200 ballasts) ZONE B (up to 200 ballasts)
The Sun System®1 Etelligent™Controller Kit #902245, allows wired control of the on/off/dimming capabilities of Sun System®1 ballast(s).
Connect the control cable from Zone A signal
output jack to SIG IN on the ballast
Control up to 400 Sun System®1 Ballasts with 1 Etelligent™Controller
SUN SYSTEM ONE CONTROLLER MANUAL

5. Interface connections
1Power input jack.
2ZONE A temperature probe input jack.
3ZONE A signal output jack.
4ZONE B temperature probe input jack.
5ZONE B signal output jack.
1 2 3 4 5
6. Indicator lights
1LED ON: Normal status (Temperature
probe is working normally).
LED OFF: Temperature Control line not
connected or temperature control fail.
LED SLOW FLASH: High temperature warning (reached preset value), ballast dimming
down to decrease temperature.
LED FAST FLASH: High temperature, exceeded preset value. Ballast turned off.
2LED LIGHT ON: Lamp on. LED LIGHT OFF: Lamp off.
3Same as 1.
4Same as 2.
1234
7. Setting the time
NOTE: Set controller time to your time zone.
1Press “tor u”, enter into “SYSTEM SETTING”.
2Press “tor u”, to the parameter you want to set
(Time for example: Hour / Minutes).
3Press “p”, “Hour” value will increase,
Press “q”, “Hour” value will decrease.
4Move cursor to set “M”, “D”, “Y”, “Hour”, “Time” or “Power” (W or%).
5Press “OK”. Time and Date setup is complete.
OPERATIONAL SETUP
4. Keypad operation
Page up or page down
Right shift
Increase parameters
Reduce parameters
Confirm/save

8. Setting the ZONE parameters
EXAMPLE: “ZONE A: 1000W”.
1Press “OK”, enter into “HOME”.
2Press “tor u”, select “ZONE A” or “ZONE B”.
Select “TYPE” power options: 250W, 400W,
600W or 1000W.
Select “POWER” options: Dimming 0% (OFF),
60% - 110% (ON).
R/S: Sunrise/Sunset options: Select duration time of 0 - 30 min.
Dim options: Temperature control range 32° - 104° F (0° - 40° C), power reduced 60%.
Delay: Protection delay time of 0 - 30 min.
3Press “tor u”, move cursor to the item you want to set.
4Press “por q”, to increase or decrease the value.
Press “”, “Hour” value will decrease.
5After setting, “tor u”, to “NEXT”, then press “OK” to enter into the “Time Setting”.
9. Setting the timer dimming
1Press “NEXT”, then “OK” to enter into “ZONE A”.
NOTE: Follow this same setup for ZONE B.
2Press “tor u”, choose “o”, choose time and
power percentage, press “por q”, t o “ þ”.
3Then press “tor u”, to choose the time and
power percentage, and press “por q”, to increase
or decrease the time and power percentage value.
4After all value settings are set, press “OK” to save and enter into the HOME page.
10. Setting output power
1Press “OK”, enter into “HOME”.
2Press “tor u”, enter into “ZONE A” or “ZONE B”.
3Press “tor u”, the choose “Power: ”.
4Press “por q”, to set the output power.
5Press “OK” to save the output power you set.
NOTE: If there is no activity for 10 seconds—while
setting up your unit, the controller will automatically
go back to the “HOME” page.

11. Operation example settings
Example: ZONE A control 1000W ballast, output power is
780W, sunrise time 08:35,(60% power), sunset time 9:00
(turn off), Sunrise and sunset duration time is 29min, if
ambient temperature is 30°C ≤temperature ≤40, dimming
down automatically to decrease power and temperature. If
temperature >40°C, turn off and enter into protection status.
12. Sun System®1 Etelligent™Controller technical parameters
Power DC5V/2A
Match ballasts 600W and 1000W
Control command time interval 2S
Power Dimming Scope 600W: 40%-110% (240W-660W)
1000W: 60%-115% (600W-1150W)
Power regulation accuracy 1%
Temperature-controlled
adjustable inspection scope 32° - 104°F (0° - 40°C)
Temperature-controlled
protection inspection scope 50° - 122°F (10° - 50°C)
Sunrise and sunset duration 0-30 min
Turn on delay protection time 0min, 5min, 10min, 15min, 20min, 25min and 30min
13. Sun System®1 Etelligent™Controller TROUBLESHOOTING
Problem Inspection method Troubleshooting
Controller doesn’t have any
display after plugging in power
Check the power supply Reset power supply
Check the adapter Change to another adapter
Check the controller Change to another controller
Fail to control ballasts
Check the connection of
controller and ballasts, make sure
each connection is good
Reconnect the wires
Controller doesn’t have any
temperature display after
temperature probe connected
Check if the temperature
probe is damaged
Change to another
temperature probe
Fail to turn on the lamp
Check the LED on the ballast to
ensure the LED indicator above
the out plug is flashing normally
Reconnect the wire
Ballast does not appear to
be functioning on desired
setting sent via controller
Check the sunrise and sunset
time setting Reset sunrise or sunset time
Check the temperature probe
and temperature-controlled value
you selected
Change the temperature-
control value you set
When some ballasts are
not functioning properly
on a channel
Check if the connection
wire between ballasts is
functioning properly
Replace connection wire
or unplug and then plug
in again
Check the connection
of the power cable Plug in and out to try again
Check if the ballast is
functioning properly Check the LED on ballast

No Condition Status LED
1
Maximum number of ignition attempts done without
success. This condition is also used to indicate a locked or
failed driver. (Ignition intervals 1-5-5-5-5)
Ballast locked Flash*1
2 Lamp stopped for unknown reason Output errors Flash*2
3 Mains voltage is too low Low input
voltage Flash*3
4 Maximum driver temperature exceeded Over temperature Flash*4
5 Mains voltage is too high or DC-bus voltage too high. High input voltage Flash*5
6 Ballast is trying to ignite the lamp. Ignition busy Flash*6
7 Lamp voltage is too high or too low Lamp fault Flash*7
14. LED failure indicator on electronic ballast
Note:
1Without controller connected:
Dimming LED indicator will remain on. If failure occurs, the Turbo LED indicator will flash
(one of seven possible issues listed above).
2With controller connected:
The controller LED will remain on and flash. (Controller LED will flash every 2 seconds,
indicating the controller is functioning normally).
If ballast does not receive signal from controller, either signal has been lost or the controller
has failed. This will be a rapid flash on the controller LED indicator on the ballast.
