Sunstream evolve EHS User manual

Assembly Manual
Australia - 1800 316 962 | New Zealand 0800 21 8020

Ensure that the 2 wires protruding from
front of floor base are stood up straight.
Place the sauna floor in the desired location.
It is necessary to position the floor out from your walls for assembly and move the sauna following assembly.
Prepare & Position the Sauna Floor
If you are assembling your sauna on a hard surface floor, it is recommended that
you apply the included adhesive felt to the bottom of the sauna floor.
Please note: It is important that the sauna floor is level. Checking with a large level is recommended. If the
floor is not level, shimming or other remedies should be applied before assembling the sauna.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Position the Back Wall
It is easiest if the Back Wall is placed behind the sauna floor base. Simply lean the Back Wall against
your room wall at this time.
Front Wall
Place the sauna front wall into the Floor
Base channel.
Take care with the 2 wires protruding from
floor base.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Right Side Wall
Place the Right Side Wall in the
Floor Base channel
Front Right Corner
Connect the Right Side Wall to the
Front Wall by raising the Side Wall
approx 1/2" then sliding down to
connect the 2 fasteners.
Cinch the two walls together by
applying pressure on the outside of the
Side Wall with the inside of your knee.
It is helpful if the second person applies pressure against the opposite edge of the Front Wall. This will help
ensure that the two walls remain in contact and the fasteners will connect.
NOTE: It is NOT necessary to lift the
entire Side Wall. Simply slide the
Side Wall upward at the front corner
of the sauna to connect to the Front
Wall
Australia - 1800 316 962 | New Zealand 0800 21 8020

Hold Front Wall DOWN while
sliding Side Wall UP
There are two sets of fasteners to join the saunas' corners together. After lowering the Side Wall, check
to ensure that both sets of fasteners have connected by looking at the corner inside of the sauna. It is
possible to connect one set of fasteners and miss the other. If there is an obvious gap in the corner
between the two walls at least one fastener has not connected and the raising and lowering procedure
will need to be repeated.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Position Back Wall
Place the Back Wall into the Floor Base channel.
Back Right Corner
Connect the Right Side Wall to the Back Wall by
raising the Side Wall approx 1/2" then sliding down
to connect fasteners
Back Wall
NOTE: It is NOT necessary to lift the entire Side Wall.
Simply slide the Side Wall upward at the back corner of the sauna to connect to the Back Wall
Hold Back Wall DOWN while sliding Side Wall UP
Australia - 1800 316 962 | New Zealand 0800 21 8020

Position Left Side Wall
Place the Left Side Wall into the Floor Base channel
Front Left Corner
Slide Left Side Wall up then down to connect
the Left Side Wall to Front Wall
Hold Front Wall DOWN while sliding Left Side Wall UP
Australia - 1800 316 962 | New Zealand 0800 21 8020

Position Back Wall
Place the Back Wall into the Floor Base channel
Back Left Corner
Slide Left Side Wall up then down to connect the Left Side Wall to Back Wall
Hold the Back Wall DOWN while sliding the Left Side Wall UP
Back Wall
Australia - 1800 316 962 | New Zealand 0800 21 8020

Under-Bench Electrical
NOTE: Do not connect main power cord to your wall outlet at this time.
Connect the circular connector to power supply
box. Align the groove in connector to properly
insert. Thread the cuff of the connector on fully.
Attach the 'D-Sub' computer
style connector as shown.
Plug in all heater leads to the
receptacles in the power supply box.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Feed the main Power Supply Cord in through the hole in the Back Wall and
insert in Power Supply Box.
Do NOT plug power cord into your wall outlet until all electrical connections are finished
inside of the sauna and for the roof.
Connect the 2 floor/front wall connectors and install wooden cover plate
Australia - 1800 316 962 | New Zealand 0800 21 8020

Remove Side Wall Heater Guards
The wooden lattice work in front of the
heaters is referred to as the Heater Guard.
These are held on with strong magnets.
It is necessary to remove the Heater Guards
from the two Side Walls in order to install the
Leg Heater and the sauna Bench.
Install the Leg Heater
Install the leg heater by lowering it into the
brackets mounted on the Side Walls.
Plug the Leg Heater into the Power Supply
Box in floor.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Connect the grounding
wire from bottom side of
Bench as shown
Install Bench
Angle the Bench into place to clear the Side Wall window
frames. The Bench installs foil side down.
Lower the Bench into Position Install the Door Handle
Australia - 1800 316 962 | New Zealand 0800 21 8020

Lift the Roof above the sauna Walls.
Lower the 2 corners of the Roof on the Right side while keeping Left side up.
Ensure that 12V DC
power line from the Roof
(with white plastic
connector) is accessible
before installing the Roof.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Connect the 12 V power line between the
Side Wall and Roof.
Tuck the white plastic connector inside of
the Roof and lower the Roof into place.
It may be necessary to gently push on the
inside or outside of the walls to align tops of
walls with the Roof channel.
Australia - 1800 316 962 | New Zealand 0800 21 8020

Heater Guards
The heater guards in your new Sun Stream Infrared Sauna are held to the wall with
strong earth magnets. If preferred, the heater guards can be screwed directly to the wall
for a more permanent and secure attachment. The heater guards are pre-drilled for the
attachment screws.
Screws are included to attach the heater guard to the wall. Select a drill
bit with a smaller diameter than the screw threads to drill a pilot hole
Australia - 1800 316 962 | New Zealand 0800 21 8020

Drill a pilot hole into the wall through
the holes in the heater guards.Do not
drill deeper than necessary for the
length of the screw.
NOTE: The pilot holes are important
to ensure that the tongue and groove
wall boards do not split when
installing screws.
Install screws to firmly
attach heater guard to the wall
Australia - 1800 316 962 | New Zealand 0800 21 8020

Ensure that the legs' ends are flush
with the bottom edge of the frames
Connect bench legs to the inside
corners of the frames using supplied
wood screws.
Attach the leg assembly to the bottom of the bench surface.Choose
which surface of the bench you prefer to be the top and bottom.
Option-L Movable
Bench Assembly
Australia - 1800 316 962 | New Zealand 0800 21 8020

Audio System
Music can be piped to the speakers in the sauna two different ways, either wireless via
the Bluetooth receiver or by directly connecting your device (smart phone, tablet, laptop
etc.) with a 3.5mm male to male audio cord.
1. Bluetooth Mode.
When you first plug the sauna into the wall outlet a beep will sound indicating the
Audio circuit board in the roof has power. The circuit board's colored LED indicator
lights will flash and these will continue to flash whenever the sauna is plugged into the
wall outlet.
To transmit audio to the sauna's speakers from your device, search for and connect
your device to the 'BT Speaker'
The Audio Circuit Board is shown inside the sauna roof
in Bluetooth Mode without an audio cord connected.
Australia - 1800 316 962 | New Zealand 0800 21 8020

2. Direct Connect Mode
(NO Bluetooth)
First, remove the access panels from
the roof by unscrewing wood screws.
Connect your device to the sauna's audio
system by inserting a 3.5 mm male to
male audio cord into the BT circuit board
as shown (Audio cords not included).
To completely eliminate the RF Bluetooth
signal, simply remove the Bluetooth
module from the circuit board as shown
Australia - 1800 316 962 | New Zealand 0800 21 8020

Reinstall the roof panels and feed your audio
cord through the hole in roof.
Enjoy your favorite audio while
relaxing in your new sauna!
