Supmeter BST106-B60S(L) User manual

BST106-B60S[L]
Weighing / Force Measuring Controller
Weight/Force Display, Peak Value Detection / Display Holding
Setpoint DO Output, AO/Digit Transmission
Operation Manual V5.0
Changsha Supmeter Technological Co.,Ltd.

1
Preface
Thank you very much for your purchase!
This manual covers safety precaution, technical specification, operation interface, installation&
connection, function&operation and so on. In order to make the product running at its best, please read this
manual in advance, and reserve it for the future reading.
The technology update, function enhancement and quality improvement may lead to some differences
between this manual and the physical product, please understand.
Without our authorization, the contents of this manual are not allowed to be copied and reproduced.
Main Features:
Applications: Weight/Force Display, Peak Value Detection&Display Holding, Setpoint DO
Output and AO/Digit Transmission.
4 Optional Setpoint DO Output Modes: Weight Limit DO Alarm Mode, Weight Increment DO
Output Mode, Weight Decrement DO Output Mode and Weight Section DO Output Mode.
EMC design with high anti-jamming capability, suitable for industrial environment.
32-bit ARM CPU with 48MHz clock & higher arithmetic speed.
5 Red LED digital tubes for English character and digit display.
Menu&Shortcut mode operation.
24-bit High-precision and high-speed ∑-△A/D conversion module with 1/1,000,000 internal
resolution and sampling frequency 1280Hz.
Special anti-vibration digital filtering algorithm for ensuring the weighing stability and accuracy
when there is strong vibration on the load receptor, and the rapid response capability when the
weight signal changes.
Optional weighing input signal mV, V and mA for connecting ‘【mV】Output Type Loadcell’,
‘【V】Voltage Output Type Weighing Transmitter’ and ‘【mA】Current Output Type Weighing
Transmitter’.
Auto Zero Initial Calibration after Power-on, Auto Zero Tracking, Zero Fine Adjustment, Zero
Calibration and Load Calibration functions available.
Optional Data Calibration, Segmenting Span Correction and Segmenting Weight Calculation
functions.
Auto-locking, Key-locking, Key-unlocking, Digital Setting&Calibration and I/O Testing
functions available.
1 Definable normally open switch input [DI].
2 Relay switches with normally open and normally closed contacts for outputting upper limit and
lower limit alarm signals.
1 Optional and definable analog signal output [AO: 4~20mA / 0~20mA / 0~5V / 0~10V / …].
Optional RS232 and RS485 communication ports for connecting Host IPC/PLC and LED
Remote Display.
With the multitasking mode, the processes of weighing, alarm output and signal transmission
will not be interrupted by parameter setting and the other operations.

2
Contents
1. SAFETYPRECAUTION.................................................................................................................3
2. TECHNICAL SPECIFICATION ....................................................................................................4
3. OPERATION INTERFACE ............................................................................................................5
3.1 OPERATION INTERFACE DIAGRAM......................................................................................................... 5
3.2 KEYPAD OPERATION.............................................................................................................................. 6
3.3 STATE INDICATION................................................................................................................................. 8
3.4ALARM SIGN ......................................................................................................................................... 8
4. INSTALLATION&CONNECTION................................................................................................9
4.1 INSTALLATION....................................................................................................................................... 9
4.2 TERMINAL........................................................................................................................................... 10
5. OPERATION PROCEDURE ........................................................................................................12
6. FUNCTION&OPERATION..........................................................................................................13
6.1 MAIN MENU........................................................................................................................................ 13
6.2 F1.SET PARAMETER SETTING............................................................................................................. 15
6.2.1 Weighing Parameters (SCAL)................................................................................................... 15
6.2.2 Calibration Parameters (CALP)................................................................................................. 17
6.2.3 Setpoint Parameters (SEtP) ....................................................................................................... 19
6.2.4 Communication Parameters (SErP)........................................................................................... 21
6.2.5 Display Parameters (dISP) ........................................................................................................ 22
6.2.6 A Sample of Parameter Setting.................................................................................................. 23
6.3 F2-CALSYSTEM CALIBRATION .......................................................................................................... 24
6.3.1 Zero Calibration (ZEro)............................................................................................................. 24
6.3.2 Data Calibration (dAtA)............................................................................................................ 25
6.3.2.1【mV】Data Calibration ............................................................................................... 25
6.3.2.2【mA】Data Calibration ............................................................................................... 26
6.3.2.3【V】Data Calibration .................................................................................................. 27
6.3.3 Load Calibration (LoAd)........................................................................................................... 28
6.3.4 Segmenting Span Correction (SEgC)........................................................................................ 29
6.4 F5-LOC KEY-LOCKER......................................................................................................................... 31
6.4.1 Key-unlocking (oPEn)............................................................................................................... 31
6.4.2 Key-locking (Locc) ................................................................................................................... 31
6.4.3 Password Set (PASS)................................................................................................................. 32
APPENDIXA. REGISTER TABLE OF HOST-SLAVE MODBUS[ASCII/RTU]........................33
APPENDIX B. DATA FRAME FORMAT OF CONTINUOUS SENDING[ASCII]....................36

3
1. Safety Precaution
Application environment
Make sure that this product works under the environment where is accord with the technical
specifications.
Do not open the shell before power-off.
Controller Protection
For avoiding bodily injury from electric shock accident and separating the controller from
strong interference, the metal shell of the controller should be grounded directly with the
ground resistance being less than 4Ω.
Scale Frame Protection
For avoiding bodily injury from electric shock accident and separating the loadcells from
strong interference, the scale frame should be grounded directly with the ground resistance
being less than 4Ω.
Cable Laying
Weighing signal, analog signal and communication signal cables should be laid in pipes, and
do not lay them together with power cables.
Power Supply
The power supply of the controller should be separated from the power supply of the driving
devices.
Please make sure that the inputted voltage is correct before power-on.
Environmental Protection
While being discarded as worthless, the product should be processed lawfully as leady
industrial waste for environment protection.
Other Notes
The installation, wiring and maintenance should be operated by the engineers with the
relevant professional knowledge and safety operation ability.
Although being not described in this manual, the relevant safety operating procedures and
standards should be followed.

4
2. Technical Specification
Executing Standard
CMC GB/T 7724-2008《Electronic Weighing Meter》PRC National Standard.
OMIL R76: 2006《Non-automatic Weighing Instruments》International Recommendation.
Accuracy Grade: III.
Verification Accuracy: 0.03%.
Static Weighing Accuracy: 0.2%~0.5%.
Display
5 Red LED digital tubes for English character and digit display.
Weight Display Range: -9,999~+99,999.
Scale Capacity: Setting Range 1~99,999.
Scale Division: Optional 1, 2, 5, 10, 20, 50, 100, 200, 500.
Display Resolution: 1/50,000.
Decimal Point: Optional 0, 0.0, 0.00, 0.000, 0.0000.
Display Refreshing Time: Setting Range 0.01~1.00s.
Keypad
4-key keypad for Menu&Shortcut mode operation.
Weighing Signal Interface
Excitation Voltage / Max. Current 1: DC5V/120mA for 8-350Ω loadcells.
Excitation Voltage / Max. Current 2: DC12V/100mA for weighing transmitter.
Optional weighing input signal mV, V and mA for connecting ‘【mV】Output Type Loadcell’, ‘【V】
Voltage Output Type Weighing Transmitter’ and ‘【mA】Current Output Type Weighing
Transmitter’.
【mV】Signal Input Range: 0~19.5mV [Output Sensitivity of Loadcell: 1.0~3.5mV/V].
【V】Signal Input Range: 0~2.5V, 0~5V, 0~10V.
【mA】Signal Input Range: 0~20mA.
24-bit ∑-△ADC with internal resolution 1/1,000,000.
Sampling Frequency: 1280Hz.
Special Anti-vibration Digital Filtering Algorithm for precise weighing, stable display and rapid
response.
Zero Drift: ±0.1μV/℃RTI (Relative to Input).
Gain Drift: ±5ppm/℃.
Non-linearity: 0.005%FS.
Switch&Analog Signal Interface
1 Definable normally open switch input [DI].
2 Relay switches with normally open and normally closed contacts for outputting upper limit and
lower limit alarm signals.
Contact Capacity of Relay Switch: AC250V/DC24V, 1A.

5
1 Optional&Definable Analog Signal Output [AO: 4~20mA / 0~20mA / 0~5V / 0~10V / …],
Non-linearity: 0.05%FS.
Digital Communication Interface
COM1: Optional RS232.
COM2: Optional RS485.
Connectable: Host IPC/PLC and LED Remote Display.
Operating Specification
Operating Voltage: DC24V±20%.
Max. Power Consumption: 5W.
Outline Size: 107×60×1 00mm [W×H×D].
Panel Cut-out Size: 94×47mm [W×H].
Operating Temperature: -25℃to +45℃.
Storage Temperature: -30℃to +60℃.
Relative Humidity: Max. 85%RH.
Protection Level of Front Panel: IP65.
Weight: Approx. 0.3kg.
3. Operation Interface
3.1 Operation Interface Diagram
AH
AL
NET
■
►
▲


6
3.2 Keypad Operation
If there is not any keypad operation in one minute and it’s not in the processes of ‘F2 System Calibration’ & ‘F6
Factory Adjustment’, the controller will return to ‘Main Display Interface’automatically.
*: Keep the key pressed for 2 seconds.
Menu Operation
Key Name
Description
【■】
Enter Main Menu / Exit.
【】
Enter / Save / Alarm Acknowledge.
【►】
Cursor shifts right.
Display the previous option.
【▲】
Display the next interface or option.
Digit input: +1 ( 0~9 loop).
Quick Operation Mode A
Parameter [904]= ‘0. dE’[Default Set]
Key Name
Description
【■】*
Key-locking.
Key-unlocking.
【►】
(【SET】)
Setpoint parameters setting.
【►】*
(【ZERO】)
(【→0←】)
[-ZEro]: Zero Calibration with Power-down Protection and Clearing Tare Weight.
[≡ZEro]: Zero Fine Adjustment without Power-down Protection and without Clearing
Tare Weight.
The controller will switch to Gross Weight display.
【▲】*
(【TARE】)
(【→T←】)
[≡tArE]: Manual Tare without Power-down Protection.
[-PStr]: Preset Tare Weight with Power-down Protection.
[-rStr]: Clear Tare Weight with Power-down Protection.
The controller will switch to Net Weight display.
【】
(【G/N】)
Gross Weight / Net Weight / Net Weight Peak Value display switch.
【】*
(【CLS】)
[-CLS] : Clear Screen [Clear the display value of Peak Value].

7
*: Keep the key pressed for 2 seconds.
Quick Operation Mode B
Parameter [904]= ‘1. Au’
Key Name
Description
【■】*
Key-locking (Excluding Key【ZERO】&【TARE】).
Key-unlocking.
【►】
(【ZERO】)
(【→0←】)
Zero Calibration with Power-down Protection and Clearing Tare Weight.
The controller will switch to Gross Weight display.
【▲】
(【TARE】)
(【→T←】)
Manual Tare with Power-down Protection.
The controller will switch to Net Weight display.
【】
(【G/N】)
Gross Weight / Net Weight / Net Weight Peak Value display switch.
【】*
(【CLS】)
[-CLS] : Clear Screen [Clear the display value of Peak Value].

8
3.3 State Indication
LED light
Description
Note
[AH]
Upper Limit Alarm.
Refer to Parameters [200]~[203].
[AL]
Lower Limit Alarm.
[NET]
OFF: Gross Weight display.
ON: Net Weight display.
Fast Blinking: In Peak Value detection process.
Slow Blinking: Detection result of Peak Value
display.
Initial display value after power-on:
[203]=0: Net Weight.
[203]=1: Gross Weight.
[203]=2: Net Weight Peak Value.
3.4 Alarm Sign
Sign
Alarm Cause
Solution
Err0
Weighing Signal Type Error.
Power-on again after making sure that the set value of
parameter [111] ‘Weighing Signal Type’ and the switch
position of DIP1/DIP2 are matched with the actual weighing
input signal.
Err1
RAM Failure.
Replace the chip RAM.
Err2.1/Err2.2
EEPROM Failure.
Replace the chip EEPROM.
Err3
Unused.
Err4
ADC Failure.
Replace the ADC module.
oV-Ad
Over ADC Range.
Weighing signal exceeds A/D conversion range.
1. Check if the loadcell is connected.
2. Check if the capacity of loadcell is too small.
3. Check if the loading weight is too big.
oL
Overload Alarm.
Gross Weight > (Scale Capacity + 9 ×Scale Division).
1. Check if the loadcell is connected.
2. Check if the capacity of loadcell is too small.
3. Check if the loading weight is too big.
oV-tr
Not meet the condition of
Maunal Tare.
When Gross Weight is at the state with negative value display,
overload alarm or dynamic variation, ‘Manual Tare’ will be
invalid.
oV-nZ
Over ‘Zero Fine Adjusting
Range’.
Refer to parameter [123] ‘Zero Fine Adjusting Range’.
tXX.XX
Preheating Time Countdown
[min.sec].
Refer to parameter [128] ‘Initial Zero Adjustment after
Power-on’, [129] ‘Initial Zero Adjusting Time’and [130]
‘Initial Zero Adjusting Range’.
Wait for the preheating time over or press any key to exit.
oV-Zr
Over ‘Initial Zero Adjusting
Range’.

9
4. Installation&Connection
4.1 Installation
Outline Size
W×H×D [mm]
Front Panel Size
W×H [mm]
Box Body Size
W×H [mm]
Panel Cut-out Size
W×H [mm]
107×6 0×100
107×6 0
93×4 6
94×4 7
Installation Mode
94
47
Panel Cut-out Size
Outline Size
Front Panel Size
100
60
107
(46)
(93)

10
4.2 Terminal
The set value of parameter [111] ‘Weighing Signal Type’and the switch position of DIP1/DIP2 should be
matched with the actual weighing input signal.
To 【V】/ 【mA】weighing signal, the terminal ‘SIG-’ and ‘EXC-’ should be shorted; otherwise, the
sampling signal will be unstable.
Select weighing signal via setting Switch DIP1/DIP2 and Parameter [111] ‘Weighing Signal Type’
Weighing Signal
0~19.5mV
0~20mA
0~2.5V
0~5V
0~10V
DIP1[in rear panel] Set
Left【mV】
Right【mA】
Middle【V】
Middle【V】
Middle【V】
Internal DIP2 Set
Left【NC】
Left【NC】
Left【NC】
Middle【5V】
Right【10V】
Parameter [111] Set
‘19.5EV’
‘20EA’
‘2.5V’
‘5V’
‘10V’
Default Set
√
DIP1
mV
V
mA
DIP2
NC
5V
10V
AO
COM2
AL
AH
AO+
AO-
B-
A+
SIG+
SIG-
EXC-
EXC+
TXD
RXD
GND
DC-
DC+
LOADCELL
COM1
POWER
PG
mV
V
mA
DI1

11
No.
Pin
Description
LOADCELL
【mV】Weighing Signal
【V】Weighing Signal
【mA】Weighing Signal
1
SIG+
Weighing Signal Input +.
Weighing Signal Input +.
Weighing Signal Input +.
2
SIG-
Weighing Signal Input -.
Weighing Signal Input -.
[‘SIG-’and ‘EXC-’ should
be shorted]
Weighing Signal Input -.
[‘SIG-’and ‘EXC-’ should
be shorted]
3
EXC-
Excitation Voltage -.
Excitation Voltage -.
Excitation Voltage -.
4
EXC+
Excitation Voltage +.
[DC5V]
Excitation Voltage +.
[DC12V]
Excitation Voltage +.
[DC12V]
COM1
RS232 Digital Communication Port
5
TXD
Transmit Data.
6
RXD
Receive Data.
7
GND
Signal Ground / Shield Ground.
8
DI1
Switch Signal Input 1.
POWER
DC24V[±20%] Power Input Port
9
DC-
DC Input -.
10
DC+
DC Input +.
The metal shell should be grounded directly. For separating the controller from the interference of the driving
devices, the DC24V power supply of the controller should not be shared by the DO.
No.
Pin
Description
AO
0~20mAAnalog Output Port [Definable]
1
AO+
AO Output +.
2
AO-
AO Output -.
COM2
RS485 Digital Communication Port
3
B-
Data -.
4
A+
Data +.
AL [DO1]
Relay DO1 Output Port
5
OP_1
DO1 Normally Open Contact.
6
COM_1
DO1 Common Terminal.
7
CL_1
DO1 Normally Closed Contact.
AH [DO2]
Relay DO2 Output Port
8
OP_2
DO2 Normally Open Contact.
9
COM_2
DO2 Common Terminal.
10
CL_2
DO2 Normally Closed Contact.
Contact Capacity of Relay Switch: AC250V/DC24V, 1A.

12
Note: Parameter [203] ‘Data Compared with Weight Setpoints”can be defined to ‘0: Gross Weight’/ ‘1: Net Weight’
/ ‘2: Net Weight Peak Value’.
5. Operation Procedure
Relay DO Output Signal
Port
Application Mode / Parameter [212] AP
AP=1.HL
AP=2.HH
AP=3.LL
AP=4.SEC
DO1
[203]≤SET1
[203]≥SET1
[203]≤SET1
SET1≤[203]≤SET2
DO2
[203]≥SET2
[203]≥SET2
[203]≤SET2
[203]<SET1
或[203]>SET2
Connection & Power on
Zero Calibration
Other Settings
Key-locking
Scale Setting
Auto Zero Tracking Range &
Zero Fine Adjusting Range Setting
Setpoint Setting
[Data Calibration]
Load Calibration
[Segmenting Correction]

13
6. Function&Operation
6.1 Main Menu
Main Menu
Second Menu
Sign
Function
Sign
Description
F1.SEt
Parameter
Setting
-SCAL
Scale parameters setting.
-CALP
Calibration parameters setting.
-SEtP
Setpoint parameters setting.
-SErP
Communication parameters setting.
-dISP
Display and operation interface parameters setting.
F2.CAL
System
Calibration
-ZEro
Zero Calibration without loading on the weigher to correct Zero
Value.
-dAtA
Data Calibration: Input the specification parameter values of
loadcell or weighing transmitter according to the actual
configuration of the weighing system to correct Span Coefficient. If
there is no access to get the specification parameter values for Data
Calibration, then it’s necessary to do Load Calibration.
[19.5EV]:【mV】Data Calibration.
Input Parameters: Total Capacity and Output Sensitivity of
Loadcell.
[≡20EA≡]:【mA】Data Calibration.
Input Parameters: Capacity, Zero Value and Full Value of Current
Output Type Weighing Transmitter.
[≡2.5V≡]:【2.5V】Data Calibration.
[≡5V≡]:【5V】Data Calibration.
[≡10V≡]:【10V】Data Calibration.
Input Parameters: Capacity, Zero Value and Full Value of Voltage
Output Type Weighing Transmitter.
-LoAd
Load Calibration: After doing Data Calibration, if there are
conditions for Load Caliration, do Load Caliration with loading
standard weight on the weigher to correct Span Coefficient further
for higher weighing accuracy.
-SEgC
Segmenting Span Correction: After doing Zero Calibration and
Load Calibration [or Data Calibration], it’s allowed to do
Segmenting Span Correction with loading standard weight on the
weigher by 10 Correction Points to get Span Correction Ratio of 10
linearity segments for higher weighing accuracy.

14
Main Menu
Second Menu
Sign
Function
Sign
Description
F3.rEC
Unused.
F4.CLn
Clear Screen: Clear the display value of Peak Value.
F5.Loc
Key-locker
-oPEn
Key-unlocking.
-Locc
Key-locking.
-PASS
Password Set.
Exfactory Passwords:
Operator Password: 000.
Administrator Password: 001.
F6.FAC
Factory
Adjustment
Special for manufacturer.
-SPAn
【mV】Exfactory Span Adjustment: Use standard weighing test
equipment to adjust the 【mV】weighing signal interface for
normalizing Span Coefficient to 1.
【mA】/【V】Exfactory Span Adjustment: Use precision current
source to adjust the【mA】/【V】weighing signal interface for
normalizing Span Coefficient to 1.
-AdtS
Weighing Signal Linearity Test.
[AD Value / Voltage Value / Current Value]
-AoZF
AO Zero/Full Adjustment.
-AotS
AO Linearity Test.
-dIdo
DI/DO Input&Output Test.
-dEFU
RAM Reset: Reset to factory defaults.
-dStS
Display/DO Reliability Test.
F7.InF
Product
Information
Only for query.
-VEr-
Version No.
--Sn-
Serial No.
-dAtE
Exfactory Date.

15
6.2 F1.SET Parameter Setting
6.2.1 Weighing Parameters (SCAL)
No.
Sign
Range
Default
Description
Set
100
Ut
0~3
1
Weight Unit
0: None
1: kg
2: t
3: g
101
dt
0~4
ooo.oo
Decimal Point
0: ooooo
1: oooo.o
2: ooo.oo
3: oo.ooo
4: o.oooo
102
SL
1~99999
10000
Scale Capacity
Max. allowed loading weight of the load receptor.
Scale Capacity≤(Loadcell Capacity × Loadcell
Quantity) –Self-weight of Load Receptor.
103
dV
1~500
1
Scale Division
1, 2, 5, 10, 20, 50, 100, 200, 500
104
ZE
-99999~
+99999
0
[*]
Zero Value
Only for query.
105
SP
>0
1.0000
[*]
Span Coefficient
Max. display value: 9.9999.
Only for query.
106
Sr
0~5
0
Stablity Judging Range [Division]
Set value = 0: No ‘Stablity Judging’.
Set value > 0: Weight Variance per [107] ‘Stablity
Judging Time’being in [106] ‘Stablity Judging
Range’means ‘Weight is stable’.
107
St
0.1~9.9
0.5
Stablity Judging Time [s]
[*]: ‘RAM Reset’operation has no effect on the parameter.

16
No.
Sign
Range
Default
Description
Set
108
Fc
1280
1280
Sampling Frequency [Hz]
1280
109
Ft
0~19
15
Anti-vibration Digital Filter1
Filter1’s 100Digit Set
Set Value
Cutoff Frequency
0
None
1
11.2Hz
2
8.0Hz
3
5.6Hz
4
4.0Hz
5
2.8Hz
6
2.0Hz
7
1.4Hz
8
1.0Hz
9
0.7Hz
Filter1’s 101Digit Set
Set Value
Anti-Vibration Grade
0
Medium
1
High
110
Sb
1~128
1
Weight Display Smooth Filter2
The bigger set value of Filter2 will make the weight
display value more stable with slower response
speed.
111
LC
1~5
1/2/3/4/5
[*]
Weighing Signal Type
1: 19.5EV [0~19.5mV ]
2: 20EA [0~20mA]
3: 2.5V [0~2.5V]
4: 5V [0~5V]
5: 10V [0~10V]
Operating Authorization: Administrator.
[*]: ‘RAM Reset’operation has no effect on the parameter.

17
6.2.2 Calibration Parameters (CALP)
No.
Sign
Range
Default
Description
Set
120
ZP
0~1
0
Auto Zero Tracking Permission
0: oFF
1: on (Only when weight is stable, Auto Zero
Tracking will be allowed. Refer to Parameter
[106]/[107])
121
Zt
1~10
1
Auto Zero Tracking Time T [s]
T = Set value ×[107] Stablity Judging Time.
122
Zr
0.1~50.0
0.2
Auto Zero Tracking Range [Division]
Zero Tracking Rate = [122] / [121].
Suggestion: Zero Tracking Rate ≤0.5[Division/s].
123
nZ
0~50000
50
Zero Fine Adjusting Range
If Gross Weight variation caused by Zero Value
changing is within this range, ‘Zero Fine
Adjustment’ will be valid.
Suggestion: Set value ≤(Scale Capacity ×4%).
124
dZ
0~99
5
Range of Displaying Zero
When the absolute value of weight is within this
range, the weight display value will return to zero.
125
tL
1~99999
12000
[*]
Total Capacity of Loadcells
Total Capacity of Loadcells = Loadcell Capacity ×
Loadcell Number.
Only for query.
126
SE
0.500~5.000
2.000
[*]
Output Sensitivity of Loadcell [mV/V]
Only for query.
127
Un
0
0
Unused
128
In
0~1
0
Initial Zero Adjustment after Power-on
0: oFF
1: on [without Power-down Protection]
129
It
0~1800
10
Initial Zero Adjusting Time [s]
130
Ir
0~5000
50
Initial Zero Adjusting Range
Suggestion: Set value ≤(Scale Capacity ×20%).
[*]: ‘RAM Reset’operation has no effect on the parameter.

18
No.
Sign
Range
Default
Description
Set
131
132
133
134
135
136
137
138
139
140
L1
L2
L3
L4
L5
L6
L7
L8
L9
LA[L10]
1~99999
[*]
1000
2000
3000
4000
5000
6000
7000
8000
9000
10000
Correction Point’s Loading Weight 1~10
Inputted Loading Weight value for Segmenting
Correction.
Demand: L1≤L2≤…≤L10.
Only for query.
141
142
143
144
145
146
147
148
149
150
d1
d2
d3
d4
d5
d6
d7
d8
d9
dA[d10]
-99999~
+99999
[*]
10000
20000
30000
40000
50000
60000
70000
80000
90000
99999
Correction Point’s AD Value 1~10
AD Value detected via Segmenting Correction.
Demand: d1≤d2≤…≤d10.
Only for query.
151
152
153
154
155
156
157
158
159
160
C1
C2
C3
C4
C5
C6
C7
C8
C9
CA[C10]
0.0100~
99.9999
[*]
1.0000
Span Correction Ratio 1~10
Span Correction Ratio of Linearity Segment got by
Segmenting Correction.
Linearity Segment 1：[Zero Value]~d1.
Linearity Segment 2：d1~d2.
Linearity Segment 3：d2~d3.
…
Linearity Segment 10：d9~[Max. AD Value].
Max. display value: 9.9999.
Only for query.
161
SC
0~1
0
[*]
Segmenting Weight Calculation Permission
0: oFF
1: on
Operating Authorization: Administrator.
[*]: ‘RAM Reset’operation has no effect on the parameter.

19
6.2.3 Setpoint Parameters (SEtP)
No.
Sign
Range
Default
Description
Set
200
Lo
0~99999
1000
DO1Weight Lower Limit / Weight Setpoint 1
201
HI
0~99999
9000
DO2 Weight Upper Limit / Weight Setpoint 2
202
nL
0~50000
50
Non-load Zero Range
‘Net Weight > Non-load Zero Range’for triggering
the Peak Value detection process.
‘Net Weight ≤Non-load Zero Range’for stopping
the Peak Value detection process.
203
dA
0~2
0
Data Compared with Weight Setpoints
0. groS [Gross Weight]
1. nEt [Net Weight]
2. PnEt [Net Weight Peak Value]
204
do
0~1
1
DO Output Permission
0: oFF
1: on
205
dL
0.1~5.0
0.5
DO Bounce-back Delay Time [s]
Used for avoiding that the DO alarm switch turns on
and off frequently with its related real-time data
being at the critical point.
Min. Interval Time for Peak Value Detection [s]
Only after the time delayed, the triggered Peak
Value detection process is allowed to be stopped by
‘Net Weight ≤Non-load Zero Range’. And only
after the time delayed, the stopped Peak Value
detection process is allowed to be triggered again by
‘Net Weight > Non-load Zero Range’.
206
Ao
0~3
0
AO Signal
0. groS [Gross Weight]
1. nEt [Net Weight]
2. dISP [Displayed Weight]
3. PnEt [Net Weight Peak Value]
207
AE
0.00~21.00
4.00
Min. AO Value of Weight Signal [mA or V]
It’s the AO current or voltage output value of
weight signal when ‘Weight value ≤0’.
