suprema BioStation A2 User manual

English
Version 1.00
BioStation A2
INSTALLATION GUIDE
www.supremainc.com
EN 101.00.BSA2 V1.00A

Contents
Safety instructions............................................................................................3
Introduction ......................................................................................................5
Components ...................................................................................................................................................5
Name and function of each part ...............................................................................................................6
Cables and connectors ......................................................................................................................................................8
How to enroll a fingerprint ........................................................................................................................9
Selecting a finger for fingerprint input........................................................................................................................9
Fingerprint enroll method ................................................................................................................................................9
Installation ..................................................................................................... 10
Fixing the bracket and the product........................................................................................................10
Power supply connection...........................................................................................................................11
Network connection....................................................................................................................................11
TCP/IP ..................................................................................................................................................................................11
TTL input and output connection............................................................................................................12
Relay connection.........................................................................................................................................13
Fail Safe Lock ....................................................................................................................................................................13
Fail Secure Lock ................................................................................................................................................................13
Automatic door connection............................................................................................................................................14
Connecting as a standalone......................................................................................................................15
Connecting to Secure I/O 2 ......................................................................................................................16
Wiegand connection ...................................................................................................................................17
Product specifications.................................................................................. 18
Dimensions...................................................................................................................................................19
FCC compliance information ...................................................................... 20
EU Declaration of Conformity (CE) ........................................................... 20
Appendix ........................................................................................................ 21
Escape clause...............................................................................................................................................21
Copyright notice..........................................................................................................................................21

Safety instructions
3
Safety instructions
Observe the following instructions to use the product safely and prevent any risk of injury or property damage.
Warning
Noncompliance of instructions could lead to serious injury or death.
Installation
Do not install the product in a place with direct sunlight, moisture, dust, or soot.
•A fire or electric shock may occur.
Do not install the product in a place with heat from an electric heater.
•A fire or electric shock may occur due to overheating.
Install the product in a dry place.
•Otherwise, a product damage or electric shock may occur due to moisture.
Install the product in a place with no electromagnetic interference.
•Otherwise, a product damage or electric shock may occur.
The user should not install or repair the product independently.
•A fire, electric shock, or personal injury may occur.
•If the product has been damaged due to independent installation or repair of the product by the user, free A/S service will not be
provided.
Operation
Do not allow liquids such as water, beverages, or chemicals get into the product.
•A fire, electric shock, or product damage may occur.
Caution
Noncompliance of instructions could lead to minor injury or product damage.
Installation
Do not install the power supply cable in a place where people pass by.
•Product damage or physical injury may occur.
Do not install the product near a highly magnetic object such as a magnet, TV, (especially CRT) monitor, or speaker.
•A product failure may occur.
Use only a power supply adaptor of D.C 12 V and 500 mA or higher.
•If the proper power is not used, the product may not operate normally.
If installing the product outside where the product is completely exposed, it is recommended to install the product together with
the enclosure.
Use a separate power supply for Secure I/O 2, electric lock and BioStation A2 respectively.
•If connecting and using the power supply to these devices together, the devices may malfunction.
Keep at least 10cm distances between the devices when install multiple devices.
•Otherwise, RF performance is affect to the other device, the devices may not operate normally.

Safety instructions
4
Operation
Do not drop the product or apply an impact to the product.
•A product failure may occur.
Manage the password with care not to disclose it to others and change the password periodically.
•Otherwise, illegal intrusion may occur.
Do not press the buttons on the product forcibly or using a sharp tool.
•A product failure may occur.
Be careful not to contaminate or damage the fingerprint contact unit with a dirty hand or foreign substances.
•Deterioration in fingerprint authentication performance and a product failure may occur.
When cleaning the product, wipe the product with a soft and dry cloth and no water, benzene or alcohol.
•Otherwise, a product failure may occur.
BioStation A2 uses capacitive buttons. If the environment is moist from wet weather or the product surface is smeared with a lot of
water, wipe off the product with a dry towel before using it.
RTC battery
Replacing the battery with an incorrect type of battery may cause explosion.
Discard the battery according to the appropriate regional or international waste regulations.

Introduction
5
Introduction
Components
Components may vary according to the installation environment.
Note
BioStation A2
Wall bracket
Fixing screw
(4 EA)
PVC anchor
(4 EA)
Diode
(1 EA)
Connection cable
(2 pins 1 EA, 3 pins 2 EA, 4 pins 4 EA)
Ferrite core
(1 EA)
Drilling template
Quick guide
120 Ω resistor
(1 EA)

Introduction
6
Name and function of each part
Name Description
Microphone Delivers the voice of the user when the interphone is connected.
LCD screen Provides UI for operation.
Menu button ( ) Displays the list of menus.
Home button ( ) Navigates to the home screen.
Cancel button ( ) Navigates back to the previous screen.
Speaker Delivers sound.
LED lamp Indicates the operational status of the product with the color of the LED lamp.
Fingerprint authentication unit Part to scan the fingerprint for entrance.
RF card authentication unit Part to scan the card for entrance.
USB memory slot Connects USB memory.
Mini USB cable slot Will be supported in the future.
TTL input (4 pins) Connect the TTL input cable.
Fingerprint authentication unit
Menu button
LED lamp
Microphone
LCD screen
USB memory slot
TTL input (4 pins)
Power supply (2 pins)
Relay 0 (3 pins)
RF card authentication unit
Mini USB cable slot
Speaker
Camera
Home button
Cancel button
Ethernet
Relay 1 (3 pins)
Wiegand input (4 pins)
Wiegand output (4 pins)
RS-485 (4 pins)

Introduction
7
RS-485 (4 pins) Connect the RS-485 cable.
Relay 0, 1 (3 pins) Connect the relay cable.
Power supply (2 pins) Connect the power supply cable.
Ethernet Connect the Ethernet cable.
Wiegand input (4 pins) Connect the Wiegand input and output cable.
Wiegand output (4 pins) Connect the Wiegand input and output cable.

Introduction
8
Cables and connectors
Power supply
Pin Name Color
1
PWR +VDC
Red (white stripe)
2
PWR GND
Black (white stripe)
Relay
Pin Name Color
1
RLY NO
White
2
RLY COM
Blue
3
RLY NC
Orange
RS-485
Pin Name Color
1
485 TRXP
Blue
2
485 TRXN
Yellow
3
485 GND
Black
4
SH GND
Gray
TTL input
Pin Name Color
1
TTL IN0
Red
2
TTL IN1
Yellow
3
TTL GND
Black
4
SH GND
Gray
Wiegand input and output
Pin Name Color
1
WG D0
Green
2
WG D1
White
3
WG GND
Black
4
SH GND
Gray

Introduction
9
How to enroll a fingerprint
In order to improve the fingerprint authentication rate, register the fingerprint correctly. BioStation A2 can recognize a fingerprint even if
the angle and position of a user's fingerprint input change. If you register the fingerprint with attention to the following matters, the
authentication rate can be improved.
Selecting a finger for fingerprint input
•In preparation for the case that the fingerprint of a specific finger cannot be used, for example if
the user is lifting a load with one hand or a finger gets hurt, up to 10 fingerprints for each user can
be registered.
•In the case of a user whose fingerprint cannot be recognized well, the authentication rate can be
improved by enrolling the same finger twice repeatedly.
•If a finger has a cut or the fingerprint is blurry, select another finger for the fingerprint.
•It is recommended to use the index finger or the middle finger when scanning the fingerprint. The
authentication rate can be reduced if it is difficult to place another finger at the center of
fingerprint sensor accurately.
Fingerprint enroll method
1
When a message saying “Scan the fingerprint.” is displayed on the LCD screen for enrolling the fingerprint, place the finger with the
fingerprint to be registered on the fingerprint authentication unit and press the finger gently for better authentication.
2
When the re-input screen is displayed after a beep sound, scan the fingerprint of the registered finger again (scan the fingerprint of a
finger to be registered twice).
Cautions for enrolling a fingerprint
When a fingerprint is recognized, it is compared with the initially registered fingerprint, so the initial fingerprint enroll is the most important. Pay
attention to the following matters when enrolling the fingerprint.
•Place the finger deep enough to contact with the sensor completely.
•Place the center of the fingerprint in the center of the sensor.
•If a finger has a cut or the fingerprint is blurry, select another finger for the fingerprint.
•Scan the fingerprint correctly without moving according to the instruction on the screen.
•If you make the finger upright so that the contact area with the sensor has decreased or the angle of finger has warped, fingerprint authentication
may not be performed.
When the fingerprint recognition fails
BioStation A2 can recognize a fingerprint regardless of a change of season or finger condition. However, the authentication rate may vary according to
the external environment or fingerprint input method.
If the fingerprint authentication cannot be done smoothly, it is recommended to take the following measures.
•If the finger is smeared with water or sweat, dry off the finger and then scan the finger.
•If the finger is too dry, blow your breath on the fingertips and then scan the finger.
•If the finger has a cut, register the fingerprint of another finger.
•The initially registered fingerprint often may have not been scanned correctly, so register the fingerprint again according to ‘Cautions for enrolling
a fingerprint’.
Note

Installation
10
Installation
Fixing the bracket and the product
1Determine the correct position to install the bracket using the provided drilling template. Fix the bracket firmly using fixing screws
through the bracket to the position where BioStation A2 will be installed.
•If installing BioStation A2 on a concrete wall, drill holes, insert PVC anchors, and fix them with fixing screws.
•Keep at least 10cm distances between the devices when install multiple devices. Otherwise, RF performance is affect to the other device, the
devices may not operate normally.
2Assemble the cable cover and install BioStation A2 onto the fixed bracket.
3Connect BioStation A2 to the bracket by rotating the product fixing screw of BioStation A2.
Note
