USER MANUAL
Portable Speaker System
with Bluetooth and FM-radio
PS-285

ENG
2
Portable Speaker System
with Bluetooth and FM-radio
Congratulations on your purchase of the SVEN speaker system!
COPYRIGHT
© SVEN PTE. LTD. Version 1.0 (08.08.2021).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may
occur. The information in this Manual is given on “as is” terms. The author and the
publisher do not bear any liability to a person or an organization for loss or damage
which has arisen from the information contained in this Manual.
BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check
up the device for damage; if the product was damaged during transportation, address
the rm which carried out the delivery; if the product functions incorrectly, address
thedealer atonce.
•Check up the package contents and availability of the warranty card. Make sure
thewarranty card has a shop stamp, a legible signature or the seller’s stamp and pur-
chase date, and the goods number corresponds to that in the warranty card. Remem-
ber: in case of warranty card loss or discrepancy of numbers you forfeit the right for
warranty repairs.
•Before installing and using the speaker system, read this Manual carefully and keep
it for future reference.
•Do not expose it to direct sunlight.
•Shipping and transportation equipment is permitted only in the original container.
•Does not require special conditions for realization.
•Dispose of in accordance with regulations for the disposal of household and computer
equipment.
•The date of manufacture of the product is indicated on the box.
APPLICATION
SVEN PS-285 portable multimedia speaker system with Bluetooth and FM-radio is
designed for operation with PC, notebooks and other mobile devices by means of data
transfer via Bluetooth protocol. It can be also used in Internet telephony, during video
conferences, in multimedia applications, in interactive games, for speech recognition and
foreign language teaching. FM-tuner and the player with USB-flash and micro SD-cards
are included.
PACKAGE CONTENTS
•Speaker system — 1 pc
•3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
•USB to Type-C power cable — 1 pc
•User Manual — 1 pc
•Warranty card — 1 pc
Technical support is on www.sven..

ENG
3
User Manual PS-285
Fig. 1.
SPECIAL FEATURES
•Bluetooth wireless signal transmission
•Protection against the water (IPx7)
•Wireless connection of two speakers to one source
•Built-in audio files player from USB-flash and microSD card storage devices
•Built-in FM tuner
•Wired connection
Speaker system description
a+: Volume increase (short pressing);
Next track (long pressing in Player and Bluetooth mode);
Next station (long pressing)
b-: Volume decrease (short pressing);
Previous track (long pressing in Player and Bluetooth mode);
Previous station (long pressing)
c: Change backlight mode (short pressing);
Backlight on/off (long pressing);
Disconnect from device (double click in Bluetooth mode)
d: POWER button (long pressing);
Play/Pause button (short pressing in Player and Bluetooth mode);
Mute (short pressing in Radio mode or LINE);
Start/Stop auto scan (double click)
e: Connecting an additional speaker (short pressing в режиме Bluetooth)
Switch mode button: Bluetooth/FM/Player/LINE (long pressing)
f3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
gUSB-flash card slot
hUSB Type C jack for charger connecting speaker system to laptop/PC USB port
iMicro SD card slot
jIndicator

ENG
4
Portable Speaker System
with Bluetooth and FM-radio
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior to the application.
Speaker system battery charging
•Connect speaker system to a USB port of PC or USB charger using Type-C to USB cable
(included). When charging, the indicator jlights up in red. Indicator jgoes out if the
battery is charged.
•The battery is used in the speaker system as an integral part of the device, therefore
do not try to extract or replace it, because this can result in the warranty cancellation
or the device damage.
OPERATION MODES
Bluetooth mode
•Wireless data transfer via the Bluetooth protocol enables to connect speaker system to
compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as
walls or other electronic devices can interfere with the signal transfer.
•Turn on the speakers in Bluetooth mode.
•It is necessary to select the search mode of devices with Bluetooth on a signal source
(telephone, notebook, smartphone, etc.). «SVEN PS-285» massage will be displayed on
the screen which is to be connected to*.
•When connection is successful, there will be a short beep**.
Radio mode
To improve radio reception, connect USB-Type-C cable (included) to the input h.
•Turn on the speaker system – press button eseveral times until, the radio mode will
turn on. Double press button dactivates auto search mode. After scanning completion,
the first scanned radio station will start to operate automatically. With buttons aand b
select a desired radio station.
МР3 player mode
Attention! The file system of a micro SD or USB flash carrier is FAT32. Maximum volume
is 32 GB. It is not recommended to use the micro SD Ultra Speed.
•Insert the USB flash or micro SD carrier into appropriate slot. If the speaker system is
in turned on position, the playback will start automatically. Playback/Pause modes are
switched over with the help of the button d. Tracks can be controlled by buttons b
(previous track) and a(next track).
Connecting an additional speaker
For model «SVEN PS-285» you can connect an additional speaker (Bluetooth mode only):
•Connect one speaker to a signal source via Bluetooth.
•Briefly press button eon the connected speaker, to activate the search mode, the
second speaker must be in the search for BT.
•The speakers will connect with each other.
Note. At the subsequent inclusion of both speakers, they will be connected
automatically.
* You might have to enter «0000» code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second
search mode activation is not obligatory. Choose the item name «SVEN PS-285» and the
«connect» command on the source.

ENG
5
User Manual PS-285
The use in the wired mode (AUX)
•Speaker system can be used as an external device for amplifying any audio source
with a 3.5 mm output mini-jack. To do this, connect a cable 3.5 mini-jack – 3.5 mini-jack
to the audio input AUX f.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency range, Hz 60-20000
Output power (RMS), W 20 (2 × 10)
Membrane, mm Ø 52
Rated current consumption, A 0.23
Battery capacity, mA*h 3000
Power supply USB / 5 V
Weight, g 900
Dimensions, mm 90×210×92
Notes:
• Technical specifications given in this table are supplemental information and cannot
give occasion to claims.
• Technical specifications and package contents are subject to change without notice
due to the improvement of SVEN production.
Fig. 2. Connection diagram

Portable Speaker System
with Bluetooth and FM-radio
PS-285
Model: PS-285
Importer: Tiralana OY, Office 102, Kotolahdentie
15, 48310 Kotka, Finland.
Импортер в России: OOO «Регард»,
105082, г. Москва, ул. Фридриха Энгельса,
д. 75, стр. 5. Уполномоченная организация
в России: ООО «РТ-Ф», 105082, г. Мо-
сква, ул. Фридриха Энгельса, д. 56, стр. 1.
Условия гарантийного обслуживания смо-
трите в гарантийном талоне или на сайте
www.sven.fi. Гарантийный срок: 12 мес.
Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур,
427447. Произведено под контролем «Свен
Скандинавия Лимитед», 48310, Финлян-
дия, Котка, Котолахдентие, 15. Сделано
в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat
Road, № 02-02, Singapore, 427447.
Produced under the control of Oy Sven Scan-
dinavia Ltd. 15, Kotolahdentie, Kotka, Finland,
48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
