Portable Speaker System
with Bluetooth and FM-radio
Congratulations on your purchase of the SVEN speaker system!
COPYRIGHT
© 2017. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
CONTENTS
RUS !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
UKR !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
ENG !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
2
7
12
BUYER RECOMMENDATIONS
Unpack the device carefully. Make sure there are no accessories left in the box. Check
up the device for damage; if the product was damaged during transportation, address
the rm which carried out the delivery; if the product functions incorrectly, address the
dealer at once.
Shipping and transportation equipment is permitted only in the original container.
Does not require special conditions for realization.
Dispose of in accordance with regulations for the disposal of household and com-
puter equipment.
APPLICATION
SVEN PS-72 portable multimedia speaker system with Bluetooth and FM-radio is
designed for operation with PC, notebooks and other mobile devices by means of data
transfer via Bluetooth protocol. They can be also used in internet telephony, during
video conferences, in multimedia applications, in interactive games, for speech recog-
nition and foreign language teaching. There is a built in FM-tuner, and player with USB
ash and with micro SD memory card.
PACKAGE CONTENTS
Speaker system 1 pc
3,5 mm mini-jack to 3,5 mm mini-jack signal cable 1 pc
USB to micro USB power cable 1 pc
Users Manual 1 pc
Warranty card 1 pc
SPECIAL FEATURES
Bluetooth wireless signal transmission
Wired/wireless audio signal transmission
Built-in player with USB ash and with micro SD memory card
Built-in FM tuner
Convenient handle for transportation
TF
USB
ON-OFF
DC5V
Speaker system description
a Microphone
b!Indicator
c Previous track (in layer mode and Bluetooth mode);
Next station (in Radio mode)
d!Play/Pause button (in layer mode and Bluetooth mode);
Start/Stop auto scan (long pressing in Radio mode);
Mute (short pressing in Radio mode and Line in);
Receive / nish an incoming call button
e Next track (in layer mode and Bluetooth mode);
Next station (in Radio mode)
f M: Switching modes button: Bluetooth / Radio / Player / Line in
g POWER button
h USB: USB-ash card slot
i Line in: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
j Micro USB jack for charger connecting, the USB port of laptop / PC
k!TF: Micro SD card slot
l!Volume control knob
Fig. 1. Speaker system description
cdf
e
MIC LED
b
a
Line In
l
ghi
k
j
ENG
13
Users Manual PS-72
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior to the application.
Speaker system battery charging
!Connect speaker system to a USB port of PC or USB charger using micro USB to
USB cable (included). During battery charging the indicator!b!is red. Indicator goes
out when the battery is charged.
!The battery is used in the speaker system as an integral part of the device, therefore
do not try to extract or replace it, because this can result in the warranty cancellation or
the device damage.
OPERATION MODES
Bluetooth mode
!Wireless data transfer via the Bluetooth protocol enables to connect speaker system!
to compatible devises. Maximum radius of action of data transfer is 10 m. Such
obstacles as walls or other electronic devices can interfere with the signal transfer.
!Turn on the speaker system Bluetooth mode press button!f several times until the
indicator b will start blinking blue color frequently.
!It is necessary to select the search mode of devices with Bluetooth on a signal source
(telephone, notebook, smartphone, etc.). SVEN PS-72 massage will be displayed
on the screen which is to be connected to*.
When connection is successful, there will be a short beep and the indication of the
search mode on speaker system is over**.
!The indi cat or !b!blinks blue shortly during the data exchange with a device con-
nected via Bluetooth.
Radio mode
To improve radio reception, connect the cable USB-microUSB cable (included) to the
input!j.
!Turn on the speaker system !press button!f!several times until, the radio mode will
not turn on. Long-term pressing button d activates auto search mode. After scanning
completion, the rst scanned radio station will start to operate automatically. With
buttons c and e select a desired radio station.
Player mode
Attention! The le system of a micro SD carrier is FAT32. Maximum volume is 32 GB.!
It is not recommended to use the micro SD Ultra Speed.
* You might have to enter 0000 code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second search
mode activation is not obligatory. Choose the item name SVEN PS-72 and the connect!
command on the source.
ENG
14
Portable Speaker System
with Bluetooth and FM-radio
TF
USB
ON-OFF
DC5V Line In
!The system will enter the Player mode automatically when a carrier (USB ash or SD
card) is connected to corresponding ports. Use button d to switch between Play /
Pause!modes. You can control tracks by using buttons c (previous track) and e (next
track).
The use in the wired mode (Line in)
Speaker system can be used as an external device for amplifying any audio source
with a 3.5 mm output mini-jack. To do this, connect a cable mini USB, plug 3.5 mini-
jack to the audio input Line in.
Fig. 2. Connection diagram
USB jack
Socket
Mobile device
USB to micro USB Power cable
PC
Mini-jack to mini-jack
signal cable
Technical support is on www.sven..
