Sven PS-50 User manual

www.sven.fi
OPERATION
MANUAL
PS-50
Portable Multimedia
Speaker System

Technical support is on www.sven.fi
ENG
1
Operation Manual PS-50
Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS .................................................. .............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS ..................................................
...................
4. TECHNICAL DESCRIPTION ....................................................
................
5. PREPARATION AND OPERATION ..........................................
.....................
6. OPERATION MODES ..........................................................................
7. TROUBLESHOOTING.................................. ..............................................
8. TECHNICAL SPECIFICATIONS ..................................................... ..........
1
2
2
2
4
5
6
6
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.

ENG
2
Portable Multimedia
Speaker System
2. PACKAGE CONTENTS
•Speaker system – 1 pc
•Mini-jack to mini-jack sygnal cable – 1 pc
•USB to mini USB cable – 1 pc
•Strap (string) for transportation – 1 pc
•Li-Ion battery (3.7 V, 800 mA · h) – 1 pc
•Operation Manual – 1 pc
•Warranty card – 1 pc
3. SAFETY PRECAUTIONS
•Do not open the multimedia speaker system (MSS) and do not perform repairs by yourself. Service
and repairs should be performed only by qualified specialists in an authorized service center. The
list of authorized service centers is available on www.sven.fi.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose it
to direct sunlight.
•Do not place open flame sources closely to MSS.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
PS-50 Multimedia Speaker System (MSS) is designed to play music and sound games, movies,
etc. The MSS has a built-in high-quality wideband loudspeaker, FM tuner, MP3 player, a slot to
connect SD micro, AUX stereo input, USB port to connect a USB flash to connect the MSS to PC,
notebook, МР3 or CD player or other sound sources.
Special features
•High-quality wideband loudspeaker
•LED display (light-emitting-diode display)
•Built-in FM tuner
•Built-in MP3 player
•USB port to connect a USB flash
•Slot to connect SD micro
•Additional AUX stereo input
•Headphone jack
•Possibility to charge the battery from a USB port of PC, notebook or peripheral charger (+5V DC)
with standard mini USB cable
•Li-Ion battery (3.7 V, 800 mA · h)

ENG
3
Operation Manual PS-50
j
k
l
h i
m
b
e
c
f
a
d
g
MSS design
aBattery charge indicator
bLED-display
cМ: signal source shift button (short
pressing);
automatic scan and storage of radio stations in
radio mode (long pressing, more than 2 sec)
d/ : playback/pause in player and radio
modes (short pressing);
ON/OFF for all modes (long pressing)
evol+/ : next track in player mode (short
pressing);
next station* in radio mode (short pressing);
volume increase (long pressing)
f/vol-: previous track in player mode
(short pressing);
previous station* in radio mode (short
pressing);
volume decrease (long pressing)
g
High-quality wideband loudspeaker
hAUX: additional AUX stereo input
i: headphone jack
jMicro SD: slot to connect micro SD card**
with musical files in МР3 format
kDC IN: USB mini jack to connect the MSS to
a charger or USB port of a notebook/PC
lUSB: jack for USB flash** with musical files
in МР3 format
m Li-Ion battery (3.7 V, 800 mA · h)
Fig. 1. Front panel
Fig. 2. Top panel
Fig. 3. Lower panel
Fig. 4. Side panel
Fig. 5. Rear panel
* These frequencies are switched with radio stations stored in
the memory.
** The time for command processing can be increased, when
using USB flash or Micro SD card with the capacity more than
8 Gb. It is not recommended to connect external hard disks
and other devices other than USB flash, because it can lead to
the MSS damage.

ENG
4
Portable Multimedia
Speaker System
Micro SD
5. PREPARATION AND OPERATION
Speaker placement
• Place the device in an easy-to-use place for a user.
• Place the MSS far away from monitors and TV sets, as insignificant image distortion in these
supersensitive devices is possible.
MSS connecting
PS-50 Portable Multimedia Speaker System can be connected to virtually any audio devices: PC,
notebook, МР3/МР4 players, etc. (see сonnection diagram in Fig. 6).
• Before making any connections, make sure the MSS is unplugged.
• Connect signal cable with 3.5 mm mini-jack (included) to AUX jack h, and then to a sound source
audio output (PC, notebook, CD/МР3/МР4 players, iPhone, iPod, etc.), as shown in the connection
diagram (see Fig. 6).
• Connect the power cable connector (included) to DC IN jack k, and then to a USB port of a PC or
5V DC power unit.
• Connect a USB flash carrier with musical files to USB jack l. Connect a Мicro SD card with mu-
sical files to Мicro SD slot j.
Fig. 6. Connection diagram
USB jack
Socket
USB flash
Mini-jack to mini-jack
signal cable
Headphones
PC
CD player
iPhone
iPod
MP4 player MP3 player
Mini USB to USB
power cable
3
USB

ENG
5
Operation Manual PS-50
• Then switch on the device by long pressing of the button d.
• Switch on an audio signal source.
•Control the master volume level by long pressing of buttons eor f.
•Connect headphones to the jack i(see Fig. 2).
Battery charging
•Connect the device using USB cable (included) to DC IN port k, and then to a USB port of PC or
to 5V DC power unit with output USB jack.
•If the battery is discharged, the indicator ablinks, but if it is charged – the indicator is red.
Notes:
• After using the MSS, mind to unplug the USB cable from a USB port of PC, notebook or 5V
DC power unit.
• To improve sound quality, use the Line-Out output of the sound card.
6. OPERATION MODES
Player Mode
• The system will go to the player mode automatically, if one of carriers (USB flash or micro SD
card)* is inserted into an appropriate jack lor j. Press the button M con the front panel to
select a desired source, when the MSS is turned on. LED display bwill show a selected source
“USB/CARD” and after that the playback time from the beginning. The playback will start auto-
matically. Press buttons for eshort on the front panel to select a track. LED will briefly show the
sequence number of a track and after that the playback time from the beginning.
* The operation can be incorrect, when using a micro SD card with the capacity less than 512 Mb.
The time for command processing can be increased, when using a USB flash with the capacity
more than 8 Gb.
Radio Mode
• Use the button Мcon the front panel to enter the radio mode when the MSS is on. The display
bwill show “FM” symbol and the frequency of a station received.
• Press and hold down the button Мcnot less than for 2 seconds for the automatic scan and to
store the found stations. The display bwill show a frequency during scanning and will show its
sequence number for short time during storing.
AUX Mode
• Use the button Мcon the front panel to enter the AUX mode, when the MSS is turned on. The
display bwill show “AUX/LINE”.
ON/OFF Mode
• Press and hold down the button don the front panel to turn on/offthe MSS.

ENG
6
Portable Multimedia
Speaker System
7. TROUBLESHOOTING
Problem
The MSS does not
turn on.
No sound or there is
too quiet sound of
speakers.
Distortion of sound.
Cause
Battery is discharged.
The volume level is set at minimum
value.
Improperly connected audio source.
Large amplitude of the input signal.
Solution
Connect the MSS to a charger,
USB port of a notebook or PC to
charge the battery.
Press the button «vol+» on the
front panel.
Connect/select audio sources
correctly.
Turn down the source volume
and the MSS volume.
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Parameter, measurement unit
Output power (RMS), W
Frequency range, Hz
Received frequency range in FM mode, MHz
Speaker diameter, mm
Voltage supply
Dimensions (W × H × D), mm
Weight, kg
Value
3
90 – 20,000
87.5 – 108
Ø 40
3.7 В/ 800 mА· h
113 × 53 × 29
0.116
8. TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications are subject to change without notice due to the improvement of
SVEN production.

Модель: PS-50
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi .
Гарантийный срок: 12 мес. Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка, Котолахдентие, 15.
Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
