Sven SB-550 User manual

www.sven.ѵ
OPERATION
MANUAL
SB-550
Soundbar with Wireless
Subwoofer

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION ..........................................
......................
6. TROUBLESHOOTING.................................
...............................................
7. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
4
7
7
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual SB-550

2. PACKAGE CONTENTS
•Subwoofer – 1 pc
•Soundbar (3 elements when unassembled: center control bar, left speaker, right speaker) – 1 pc
•Remote control – 1 pc
•CR-2025 battery (installed in the RC) – 1 pc
•Mini-jack to mini-jack signal cable – 1 pc
•3 RCA to 3 RCA composite AV cable – 1 pc
•Power adapter – 1 pc
•Power cable – 1 pc
•Fixing axle – 2 pcs
•Table stand – 1 pc
•Wall-mounting set:
3 × 8 mm screw – 2 pcs
4 × 35 mm self-driving screw – 2 pcs
rubber stopper (for attaching the screws to the wall) – 2 pcs
wall-mounting bracket – 1 pc
•Operation manual – 1 pc
•Warranty card – 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
SB-550 soundbar with a wireless subwoofer provides virual surround sound. The device is
designed for playing music and sounding games, movies, etc. The soundbar is equipped with a
built-in power amplifier and an equalizer, and compatible with TVs and DVD/CD/Media players.
Remote control is included.
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
ENG
2
Soundbar with Wireless
Subwoofer

Special features
•Gamepad, TV, DVD/CD/Media player compatible
•Wireless pairing with the subwoofer
•Wall mountable soundbar
•Separate subwoofer volume control
•Built-in equalizer
•LED display
•2 HDMI inputs
•HDMI output for video signal transmission
•Remote control
•Wooden (MDF) subwoofer cabinet
r
q
p
on
ml
Fig. 1. Front control panel
Fig. 2. Rear control panel
ab c d
g
hi j k
ef
ENG
3
Operation Manual SB-550
Soundbar front and rear control panels
aPower LED
bPOWER/STANDBY: power on/oԚbutton
cSOURCE: audio source selection button
dDigital LED display
eVOLUME–: volume down button
fVOLUME+: volume up button
gTable stand
hDC IN: power cable connection jack
iLine IN: line input jack
jVIDEO 1: video signal input jack 1
kL/R: audio signal input jacks 1
lVIDEO 2: video signal input jack 2
mL/R: audio signal input jacks 2
nVIDEO OUT: video signal output jack
oPAIR: wireless pairing button
pHDMI IN 1: high-resolution HDMI input 1
qHDMI IN 2: high-resolution HDMI input 2
rHDMI OUT: high-resolution HDMI output

Fig. 3. Remote control
Remote control
a: go to standby mode
bVOL+: master volume up button
cSUB-: subwoofer volume down button
dVOL-: master volume down button
eEQ: equalizer option (Flat, Rock, Pop, Classic, Jazz)
selection button
fSOURCE: signal source selection button
gSUB+: subwoofer volume up button
hMUTE+: sound oԚ/on button
Note. Before operating the RC, extract the installed batte-
ry, remove the insulation strip the battery is packed with to
avoid discharging during transportation, and insert the
battery back into the RC.
5. PREPARATION AND OPERATION
Table placement
•The soundbar is packaged unassembled. Attach the left and
right speakers to the center bar with the ԛxing axles, (Steps 1
and 2, Fig. 4). Then connect the table stand to the bottom of the
soundbar (Step 3, Fig. 4) and place the device on the table. The
wireless subwoofer emits non-directional sound, therefore it can
be located in any place of the room where it sounds the best.
The installation is complete.
Wall mounting
•It’s recommended that the soundbar be wall mounted under
the TV set.
• Mark the places for mounting the bracket. Place the bracket
against the wall and and mark two locations where the bracket
will be secured. Place the bracket aside.
•Drill holes on the marked locations. Insert a rubber stopper
into each hole (Step 1, Fig. 5).
•Screw the 4 × 35 mm self-driving screws into the rubber
stoppers (Step 2, Fig. 5) so that the soundbar can be ԛxed on
them.
•Attach the bracket to the previously assembled soundbar with
3 × 8 mm screws (Step 3, Fig. 5).
•Fix the soundbar on the screws attached to the wall (Step 4,
Fig. 5), and tighten the screws hard.
af
g
h
c
e
b
d
Fig. 4. Soundbar assembly
3
1
2
ENG
4
Soundbar with Wireless
Subwoofer

Player
TV TV
Mini-jack to mini-jack
signal cable
2RCA to mini-jack
signal cable
DVD/CD/Media player
HDMI cable
3RCA to 3RCA
composite
AV cable
Fig. 6. Connection diagram
DŽDž
DVD/CD/Media player
RCA to RCA
signal cable
Subwoofer
Power
cable
Sockets
Power
adapter
MSS ǥonnecting and control
SB-550 soundbar with a wireless sub-
woofer can be connected to virtually
any audio source: DVD/CD player, TV,
PC, laptop, etc. (see connection dia-
gram in Fig. 6).
• Connect the power cable with the
power adapter (included). Then con-
nect it to the the DC IN hjack of the
soundbar (see Fig. 6). Connect the
subwoofer power cable to the mains
oulet.
12
Fig. 5. Wall mounting
34
ENG
5
Operation Manual SB-550

• To connect Speaker System to PCs, MP3/CD-players use included mini-jack to mini-jack signal
cable or 2RCA to mini-jack signal cable (not included). Connection diagram is shown in Fig. 6.
• To connect the system to a DVD/CD-player or a TV, use the 3RCA to 3RCA composite AV cable
(included). Insert the plugs of the 3 RCA to 3 RCA composite AV cable into the VIDEO 1 jor VIDEO 2 l
input jack and the audio input jacks (kor m) of the soundbar, and the opposite plugs – into the
video and audio output jacks of your DVD/DžD player or a TV. Match the RCA plugs and jacks by
colour (yellow to yellow, red to red, white to white). Then connect the VIDEO OUT njack of the
soundbar to your TV input jack, as shown in the diagram (Fig. 6).
• To connect the system to a TV and a DVD/DžD player with HDMI connectors*, use HDMI cables
(not included). Connect the HDMI output jack of your DVD/DžD player to the HDMI 1 por HDMI 2 q
input jack of the soundbar with your HDMI cable, and use another HDMI cable to connect the HDMI
OUT rjack of the soundbar to the HDMI jack of your TV (Fig. 6).
•Connect the power adapter to the mains oulet. The power LED aon the front control panel will
light up. Then switch on the subwoofer with the POWER switch (ON position) on the subwoofer rear
panel.
• To switch on the soundbar, press button aon the control panel or button aon the remote
control. The LED display dwill light up. To switch the soundbar oԚ, press the Standby mode button
again.
• When the system is switched on for the ԛrst time, the blue LEDs will Ԝash both on the display d
and on the subwoofer front panel.
• To initiate the wireless pairing of the soundbar and the subwoofer, press the PAIR obutton on
the soundbar rear panel, and the blue LED will Ԝash rapidly. Then press the PAIR button on the
subwoofer front panel and hold it down for 3-5 seconds. Or press both PAIR buttons (on the
soundbar and the subwoofer) at the same time and hold them down for 3-5 seconds.
• As soon as the pairing has been completed, the blue LED will stop Ԝashing**. The system is ready
for operation.
• Press the SOURCE fbutton and select the signal source. The display dwill show the following
inscriptions: HDMI 1, HDMI 2, AUXIN, AV1, AV2***.
•Adjust the master volume with the VOL+ band VOL- dbuttons on the RC.
• Adjust the subwoofer volume with the SUB+ gand SUB- cbuttons on the RC.
•Select the equalizer option (Flat, Rock, Pop, Classic, Jazz) by pressing the EQ ebutton on the RC.
• Press the MUTE hbutton on the remote control to turn oԚthe sound. To turn the sound on
again, press any of these buttons: MUTE h, VOL+ b, VOL- d, SUB- c, SUB+ g, EQ eor
SOURCE f.
• After using the MSS, mind to switch it oԚusing button aon the RC, switch oԚthe subwoofer
using the POWER switch (OFF position) on the subwoofer rear panel and unplug the power adapter
from the socket.
* With HDMI Version 1.3 interface.
** If the pairing has been completed once, there is no need to manually initiate the pairing again.
*** HDMI indicates the options HDMI 1> HDMI 2; AUX indicates the options AUXIN> AV1> AV2.
Note. Due to the constant development of the software, the actual MSS operation may differ
from that described in this manual. The most recent version of the manual is available at
www.sven.Н.
ENG
6
Soundbar with Wireless
Subwoofer

Parameter, measurement unit
Maximum power, W
soundbar
subwoofer
Output power (RMS), W
Frequency response, Hz
soundbar
subwoofer
Speaker diameter, mm
soundbar
subwoofer
Voltage supply, V/Hz
Power adapter
Dimensions, mm
soundbar
subwoofer
Weight, kg
7. TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to
the improvement of SVEN production.
Value
300 (2 × 75 + 150)
2 × 75
150
80 (2 × 20 + 40)
150 – 22,000
30 – 150
midrange (4 × Ø 57); tweeter (2 × Ø 25.4)
Ø 165
~100-240/50
DC 18V/3A
940 × 100 × 86 (133 with mounting bracket )
170 × 325 × 330
8.3
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
The system does
not turn on.
No sound or the
sound is too quiet.
Distortion of sound.
The remote control
is not working.
Cause
The system is not connected to a
mains outlet.
The power adapter is not connected.
Volume level is set at minimum value.
Improperly connected audio source.
Large amplitude of the input signal.
The battery is discharged.
Solution
Check the connection.
Connect the power adapter.
Adjust the volume control knob.
Connect the audio sources correctly.
Turn down the source volume
and the MSS volume.
Replace the battery with a new one.
6. TROUBLESHOOTING
ENG
7
Operation Manual SB-550

2.0 Multimedia Speaker System
Automatic Voltage Regulator
Стабилизатор напряженияСтабилизатор напряжения
Automatic Voltage Regulator
2.0 Multimedia Speaker System2.0 Multimedia Speaker System
SPS-619
Модель: SB-550
Импортер вРоссии: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. SB-550
Soundbar with Wireless
Subwoofer
