OPERATION
MANUAL
2.0 Multimedia Speaker System
SPS-610

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION .......................................... ......................
6. TROUBLESHOOTING................................. ...............................................
7. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
3
4
5
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual SPS-610

ENG
2
2.0 Multimedia Speaker System
2. PACKAGE CONTENTS
• Speakers — 2 pcs
• 2RCA to mini-jack signal cable — 1 pc
• Audio cable — 1 pc
• Operation manual — 1 pc
• Warranty card — 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi.
•Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplifier or the ground, for it causes damage to the power amplifier output stage.
•Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
•Disconnect MSS from the mains system during a fuse replacement. Use fuses of the same type
and rated value. Do not use hand-made fuses.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
SPS-610 2.0 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies, etc. The MSS has a built-in power amplifier allowing to connect it to virtually any audio
source (CD/DVD-player, TV, PC, etc.) without using an additional power amplifier. One speaker is
active (it has a built-in power amplifier and a control panel), the other one is passive. The MSS can
be connected to an active subwoofer.
Special features
•Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound
sources
• Built-in transformer power supply
• Control knobs on the front сontrol panel
• Soft timbre control
• Headphone jack
• Magnetic shielding
•MDF speaker cabinets
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.

ENG
3
Operation Manual SPS-610
ac
bde
Fig. 1. Control panel
Active speaker front side
a: headphone jack
bPower LED
cTREBLE: treble control knob
dBASS: bass control knob
eVOLUME: volume control knob
fPOWER ON/OFF: power switch
5. PREPARATION AND OPERATION
Speaker placement
• Place the speakers symmetrically to the listeners at least one meter away.
• The bass reԜex port is located on the back panel of the speaker cabinet, please locate the
speakers 20–30 cm away from the wall or any other object.
• Place MSS far away from monitors and TV sets, as insigniԛcant image distortion in these su-
persensitive devices is possible.
MSS Connecting
SPS-610 Multimedia Speaker System can be connected to virtually any audio source: DVD/CD, PC
sound card, etc. (see Fig. 2).
•Before making any connections, be sure that all components are switched oԚ.
•Connect the speakers with the audio cable.
•Plug the RCA connectors of the included 2RCA to 3.5 mm mini-jack stereo signal cable into the
INPUT R/L jacks of the MSS, and connect the mini-jack of the signal cable to the output jack of your
PC sound card or to the audio output (Ø 3.5 mm jack) of any other sound source, as shown in Fig. 2.
Note. To connect the MSS to a CD/DVD/MP3 player or TV, use a 2RCA to 3.5 mm mini-jack
stereo signal cable (included) with a mini-jack to 2RCA adapter (not included), as shown in
Fig. 2 or use a 2RCA to 2RCA stereo signal cable (not included).
•Plug the power cord into the mains socket.
•Adjust the VOLUME eknob to the minimum; switch on the power supply with the power button f
on the side of the active speaker. The power LED blights up.
•Adjust the volume knob eto the necessary volume.
•Adjust the TREBLE cand BASS dknobs as desired.
•Connect your headphones to the headphone jack a(see Fig. 1).
Notes:
• After using the MSS, mind to shift the POWER switch on the rear panel of the active spea-
ker into the OFF position, and unplug the power cord.
• To enhance the sound quality, use the Line-Out port of your sound card.

If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
The MSS does not
turn on.
No sound.
There is too quiet
sound of speakers.
Distortion of
sound.
Cause
The MSS isn’t connected to a mains outlet.
The power switch is oԚ.
The volume level is set at minimum value.
Improperly connected audio source.
Volume level is set at minimum value.
Large amplitude of the input signal.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect audio sources correctly.
Adjust the volume control knob.
Turn down the source volume
and the MSS volume.
6. TROUBLESHOOTING
ƴctive
speaker
Passive
speaker
POWER
FUSE 0.5A
RLL-SPK
INPUT
ƴudio cable
Power
cord
CD
DVD
Fig. 2. Connection diagram
2RCA to mini-jack
signal cable
PC
Player
4
ENG
2.0 Multimedia Speaker System

7. TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Output power (RMS), W
Frequency range, Hz
Impedance, Ohm
Speaker diameter, mm
woofer
tweeter
Magnetic shielding
Voltage supply, V/Hz
Dimensions (one speaker) (W × H × D), mm
Weight, kg
Value
20 (2 × 10)
40 – 20,000
4
Ø 100
Ø 19
yes
~220/50
145 × 246 × 160
3.8
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due
to the improvement of SVEN production.
ENG
5
Operation Manual SPS-610

Модель: SPS-610
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024, РФ,
г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
