• Motion trigger recording function
• Support 2 removable HDDs (over 250GB), IDE type
• Wavelet Compression Format replaces Time Lapse VCR + Multiplexer
• Stand-alone design
• 4 Level video quality adjustable: Best / High / Normal / Basic
• Support 4 / 7 / 9 / 10 / 13 / 16 Channels Multiplexing function
• 16 Channels alarm input, one alarm output and ALARM display
• Video loss detected in each channel can record up to 160 events
• Power-loss memory function
• Quick Multiple Search by date / time, alarm and full list
• Security password protection
• RS-232 and RS-485 communication protocol
www.swannsecurity.com
Enquiries: [email protected]
Product Code: SW-R-DVR16
Home/Office Security System
16 Channel Digital Video Recorder
With Motion Detection and Audio
Monitoring & Recording
16 Ch Digital Multiplex recorder, is a device which uses digital technology to manage video image in HDD.
It includes features such as timer setting for searching, nice recording quality, fast / slow forward, reverse
search and user-friendly operations. It is the best device to replace Time Lapse VCR + 16 Ch Multiplexer
and the best unit to cover 4 Ch to 16 Ch DVR Installation.
Home/Office Security System
16 Channel Digital Video Recorder
With Motion Detection and Audio
Technical Specifications
Video format: NTSC/EIA or PAL/CCIR
Hard disk storage: IDE type, UDMA 66,
supported over 250GB HDD
Camera Input Signal &
Loop Back: Composite video signal
1 Vp-p 75O BNC, 16 channels
Main & Call
Monitor Output: Composite video signal
1 Vp-p 75O BNC
Audio input: 4 audio inputs, (RCA)
Audio output: 2 audio outputs, (RCA)
Motion Detect Area: 15 * 12 targets per camera (NTSC) /
15 * 14 targets per camera (PAL)
Video Loss Detection: Yes
Refresh Rate: Up to 120 fields/sec. for NTSC /
100 fields/sec. for PAL
Recording Rate: Up to 25 images/sec. for NTSC /
18 images/sec. for PAL
Picture in Picture: Yes (Movable)
Key Lock: Yes
Picture Zoom: 2*2 (Movable)
Video Adjustable: Color/ Contrast/
Brightness Adjustable
Alarm Input: TTL input, Hi (5V),
Low (GND)
Alarm Output: COM,/N.O.
Remote Control: RS-232 or RS-485
Power Source: AC100~240V
± 10% switching adaptor
Power Consumption: <45W
Operation Temperature: 10 ~ 40°C
RS-232C / RS-485 (bps) 115200, 57600, 19200,
9600, 4800, 3600, 2400, 1200
Dimension: (mm) 432(W) x 110(H)
x 325(D)
Net Weight: 5.7 kgs
Package Contents
DVR
Power Adaptor
Power Cable
Instructional Manual (Manual only available in English)
www.swannsecurity.com
Please note that the information
contained within this document is
subject to change without notification.
