Swegon PARASOL b Series Guide

1
PARASOL b
PARASOL b - m
Installation - Commissioning - Maintenance 2012-03-01
2. PARASOL 24" 2. PARASOL 48"
3.
Ø 4.92“
1.

2
PARASOL b - m
Swegon reserves the right to alter specifications 2012-03-01 www.swegon.com
5.
6. 7.
4.
1/4"
Max. recommended operating pressure: 230 psi
Max. permissible inlet flow temperature: 140°F
The optional damper must always be mounted with the knob to the left viewed in the direction of primary air flow, see figure 6.

3
PARASOL b
Installation - Commissioning - Maintenance 2012-03-01
PARASOL b - m
Water
Side
1 2 3 4
Air
Fan-shape
X-shape
Nozzle configuration
H M C L
H =
M =
C =
5/16
T-25
2
3
4
L =
The optional damper must always be mounted with the knob to the left viewed in the direction of primary air flow, see figure 6.

4
PARASOL b - m
Swegon reserves the right to alter specifications 2012-03-01 www.swegon.com
PARASOL b 48" LF / Double-module unit
Type Nozzle Side k-factor
LF L 1&3 short 4.15
LF L2&4 long 10.97
LF M 1&3 short 5.89
LF M2&4 long 15.52
LF H 1&3 short 10.03
LF H2&4 long 26.49
LF C 1, 2, 3, 4 0.00
PARASOL b 48" MF / Double-module unit
Type Nozzle Side k-factor
MF L 1&3 short 5.89
MF L2&4 long 15.52
MF M 1&3 short 8.46
MF M2&4 long 22.31
MF H 1&3 short 14.35
MF H2&4 long 37. 82
MF C 1, 2, 3, 4 0.00
PARASOL b 48" HF / Double-module unit
Type Nozzle Side k-factor
HF L 1&3 short 8.46
HF L2&4 long 22.31
HF M 1&3 short 14.71
HF M2&4 long 38.79
HF H 1&3 short 23.17
HF H2&4 long 61.10
HF C 1, 2, 3, 4 0.00
PARASOL b 24" MF / Single-module unit
Type Nozzle Side k-factor
MF L - 8.46
MF M - 14.71
MF H - 23.17
MF C - 0.00
Example Product Code:
PARASOL b 48-A-HF-HLMH
Side 1 = H k=23.2
Side 2 = L k=22.3
Side 3 = M k=14.7
Side 4 = H k= 61.1
k-factor HLMH = 23.2+22.3+14.7+61.1=121.3

5
PARASOL b
Installation - Commissioning - Maintenance 2012-03-01
PARASOL b - m
OPEN THIS SIDE
OPENTHISSIDE
OPENTHISSIDE
3
1
2
4
5
