Swegon KITE Ceiling a Series Guide

XXXX (DIFFUSER NAME)
Tomelilla
Sweden
XXX-XXX (Diffuser Size)
+ALSx XXX-XXX / XXX (ALS Size)
k = XX,X / XX,X
k
q
p
T
I
L
L
U
F
T /
S
U
P
P
L
Y
A
I
R
A
L
S
2
-
s
t
e
p
T
I
L
L
U
F
T /
S
U
P
P
L
Y
A
I
R
e
l
l
e
r
/
o
r
A
L
S
1
-
s
t
e
p
F
R
Å
N
L
U
F
T
/
E
X
T
R
A
C
T
A
I
R
kpq=
k
pq
=
( )2
Accessories
Commissioning box:
ALS. The commissioning box is made of galvanized sheet
steel and contains a removable commissioning damper, fixed
measurement tapping and sound-absorbing
material*) with reinforced surface layer.
The ALS commissioning box is available with one or two dif-
ferences in dimension between the inlet and the outlet and
also a version for low installation where a low overall height
is required. The ALS commissioning box is then supplied
without outlet branch.
*) Fire resistance rated to B-s1,d0 in accordance with EN ISO 11925-2
Frame:
SAR K. For aesthetic installation of a lowered diffuser plate.
Adapter:
ADAPTER for visible T-bars in modular suspended ceiling
systems.
Suitable for lay-in ceilings, e.g. 625 x 625 or 675 x 675.
Installation
• The face is easily removed with a simple action, see
figure 1.
• The inlet spigot of the air diffuser backing box can be
secured to the connecting duct by means of self-tapping
screws or blind rivets.
• For flush-mounting in fixed ceilings, secure the air diffuser
to the building structure through the top of the backing
box.
• The air diffuser and commissioning box with low installa-
tion height are centred with each other using the supplied
locking strip. Secure the diffuser in the correct position
with screws or pop rivets in the underside of the commis-
sioning box, see figure 3.
• For installation in suspended ceilings with a framework,
place the air diffuser directly down in the T-bar framework,
and then fix it to the duct system or to the commissioning
box.
• If an ALS commissioning box is used, it must be secured
to the building structure by means of hangers or moun-
ting brackets.
• The distance between the commissioning box and the air
diffuser can be increased up to 500 mm with circular
duct, without having to lengthen the measuring tubes
and damper adjustment cords. See figure 2.
Commissioning
• Commissioning should be carried out with the air diffuser
face mounted.
• Pull the measuring tubes and damper adjustment cords
out through the face.
• Connect a pressure gauge to the measuring tube/tubes.
• The red tube from the ALS commissioning box in the one-
step design is used for supply air.
• The blue tube from the ALS commissioning box in the
two-step design.
• For extract air, always use the transparent tube.
• K-factor label is located in the backing box.
• The adjusted damper position is saved by tying together
the damper cord in an adjustment knot.
• Measurement accuracy and straight section requirement
before the commissioning box, see figure 2.
• Figure 2 shows a bend, a change in dimension and
T-piece.
• Other types of disturbance require at least 2xD straight
section (D= connection dimension) to obtain a
measurement accuracy of ±10% on the flow.
• The K-factor is also specified in the relevant
commissioning instructions at www.swegon.com.
Maintenance
• The extract air diffuser can be cleaned, if necessary, using
lukewarm water with dishwashing detergent added.
• Alternatively a vacuum cleaner and brush nozzle is used
for cleaning.
• The duct system is cleaned by opening the air diffuser
face. If a type ALS commissioning box is used, swing the
air diffuser face to the side on its hinges so that you then
can grip the handle of the tubular damper casing and
rotate it out of its holder, see figure 4.
Figure 1. Commissioning.
q= measured flow l/s
p= current pressure reading (Pa)
k= commissioning factor
k-factor Easy access
KITE Ceiling a
Installation – Commissioning – Maintenance 14/07/2020

Installation
Figure 2. Installation options.
Figure 1. Dismantling of the front.
Figure 3. Installation of air diffusers and commissioning box with
low installation height.
Figure 4. Damper removal.
0xD / ±5% 0xD / ±5% 2xD / ±10%
Locate the “eyelid” and carefully press in the
legs towards the air diffuser
The face plate hangs on
the corresponding side by
the hinge
KITE Ceiling
2Swegon reserves the right to alter specications. 14/07/2020

Dimensions and weights
KITE CR
Size ØA Weight, kg
125 125 3.3
160 160 3.3
200 200 3.2
250 250 3.2
315 315 3.1
Size of the opening = 520 x 520
ØA
KITE CR with ALS - One step
Size ABCØD Ød E1 E2 F1 F2 G1 G2 H K Weight, kg
125-600 595 282 217 99 125 225 182 83 40 145 102 270 80 5.2
160-600 595 342 252 124 160 249 206 83 40 158 115 315 80 5.9
200-600 595 404 288 159 200 284 241 83 40 175 132 375 100 6.8
250-600 595 504 332 199 250 324 281 83 40 195 152 465 115 8.2
315- 600 595 622 388 249 315 385 342 83 40 220 177 575 140 10.9
KITE CR with ALS - Two steps
Size ABCØD Ød E1 E2 F1 F2 G1 G2 H K Weight, kg
160-600 595 342 252 99 160 225 182 83 40 145 102 315 80 5.5
200-600 595 404 288 124 200 249 206 83 40 158 115 355 80 6.2
250-600 595 504 332 159 250 284 241 83 40 175 132 450 100 7.4
315- 600 595 622 388 199 315 324 281 83 40 195 152 550 115 9.7
CL = Centreline
Figure 7. KITE Ceiling with ALS. Low installation height.
SAR K frame
Size LWeight, kg
600 595 1
Figure 8. Frame SAR K.
Figure 6. KITE Ceiling with ALS.
Figure 5. KITE Ceiling.
3
14/07/2020 Swegon reserves the right to alter specications.
KITE Ceiling

K-factor – KITE CR
Supply air
ALSd
Size
KITE CR
Size Standard Low version Colour of the
tube
100 -125 125-600 9.2 8.1 Red
100-160 160-600 12.8 11.2 Blue
125-160 160-600 13.9 11.6 Red
125-200 200-600 18.6 15.8 Blue
160-200 200-600 20.1 16.4 Red
160-250 250-600 24.5 20.4 Blue
200-250 250-600 25.6 20.3 Red
200-315 315- 600 29.8 25.8 Blue
250-315 315- 600 30.1 24.6 Red
Number of measuring tubes: 1
Extract air
ALSd
Size
KITE CR
Size Standard Low version Colour of the
tube
100 -125 125-600 4.9 4.2 Transparent
100-160 160-600 54.7 Transparent
125-160 160-600 7.2 6.5 Transparent
125-200 200-600 8.3 7.8 Transparent
160-200 200-600 11.7 10.5 Transparent
160-250 250-600 13.1 12.4 Transparent
200-250 250-600 17 14.9 Transparent
200-315 315- 600 19 17.5 Transparent
250-315 315- 600 21.6 19.3 Transparent
Number of measuring tubes: 1
KITE Ceiling
4Swegon reserves the right to alter specications. 14/07/2020
