ADAPTTM Extract d
Installation – Commissioning – Maintenance 20130610 / Art. No. 1545218
Installation
1. The commissioning box can be suspended from a
ceiling and connected to a duct system. Use hanger
system (A) or (B), see figure 2.
2. Plug the connector of the commissioning box into the
top of the diffuser (C, figure 2). The front plate does
not normally need to be removed when plugging the
connector in the diffuser.
3. Mount the diffuser into the outlet of the commission-
ing box. Make sure that the orientation of the sensor
module aligns with the extension of the room, see figure 1.
4. Fixate and secure the diffuser with screws or pop rivets.
Readjust the hanger rods of the commissioning box if
necessary, so that the air diffuser is firmly positioned
against the false ceiling.
A
B
C
Pins
insulation
Figure 2. ADAPT Extract, installation.
Figure 1. The orientation of the sensor module in a room or in
an office module. The LED’s of the sensor should be aligned with
the extension of the room in a straight line, facing the short sides
of the room as shown by the arrow in the figure.
Disassembly of the front plate
1. Dismantle the front plate from the diffuser body by
turning the three springs which enables separation of
the front plate from the pins of the diffuser.
2. When re-installing the front plate, position the three
springs to the match the same rungs as on delivery.

Swegon reserves the right to alter specifications. 20130610 www.swegon.com
WISE
2
Figure 3. Lighting fixtures or similar objects must not be installed
beneath the diffuser as this disrupts the presence detection and
room temperature measurement.
Maintenance
The exterior surface of the ADAPT air diffusers can be
cleaned whenever necessary using lukewarm water with
dishwashing detergent added.
The duct system is accessible through the air diffuser and
the commissioning box.
Commissioning
All the ADAPT Air diffusers are delivered preset into com-
missioning mode, which means that the air diffuser is set to
max. airflow by force control.
When the ADAPT air diffuser is in commissioning mode,
the light-emitting diode shines orange. The different LED
indications:
• Steady green LED: Normal operation, the air diffuser is
operating normally.
• Flashing green LED: The air diffuser has just been
powered on and calibration is in progress.
• Steady red LED: Function failure, see separate docu-
mentation in the TUNE Adapt manual.
• Steady orange LED: The commissioning mode, max.
airflow
• Flashing orange LED: Other commissioning modes and
all the forced control situations of the feedback control
system.
More information about the commissioning process itself
can be read in the Project Manual for the Wise system and
in the TUNE Adapt manual.

Swegon reserves the right to alter specifications. 20130610 www.swegon.com
WISE
3
Figure 4. Commissioning with TUNE Adapt.
2
3
1
24 V
Modbus
Electrical connections.
All the connections are wired to the CONNECT Adapt con-
nection box. From there, the Master air diffuser is connected
by means of the LINK Adapt (RJ45) cable included in the
delivery. The slave air diffusers, if required, are connected
by means of the same type of cable to their respective slave
contacts. If there are more than 2 slave air diffusers, a SPLIT
Link Adapt should be used for further connection to the last
slave air diffuser. See Figure 6. If SPLIT Link Adapt is used, the
maximum length of LINK Adapt from the connection box to
the last air diffuser is 15 meters. If ADAPT is to be connected
through Modbus communication, this should be done with
the LINK Modbus (RJ12) cable. The maximum length of
SPLIT Link Modbus is 10 meters from the connection box to
the last air diffuser. Use double CONNECT Adapts if longer
distances are required. All cables and contacts are different
so that they will not be confused or incorrectly connected.
Electrical data
ADAPT is supplied with power via the connection box. See
the wiring diagram in figure 6 or relevant diagram from the
Swegon Templates application, containing details for the
specific installation. It is important that cables with appro-
priate cross-sectional area, transformers of correct size and
power supply cables of correct length are selected. This
can for example be carried out with the dimensioning tool
“Cable and Transformer Design”, available for download
from www.swegon.com (the application is available in
english and swedish language versions).
Supply voltage 24 V AC ±10 %
Max. power consumption (controller only) 3 VA
Cable rating (controller only) 0,6 A
Ambient temperature 0 °C - +50 °C
Figure 5. Air diffuser connections.
1. Connection for LINK Adapt cable (RJ45)
2. Connection for the LINK Modbus cable (RJ12).
3. Direct 24 V connection if a connection box is not used and the
air diffuser will be completely “stand alone”.

Swegon reserves the right to alter specifications. 20130610 www.swegon.com
WISE
4
20
Master
21
Slave
22
Slave
23
Modbus
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4
3
565
10
- + C
22
12 6
Figure 6. Connection of slave air diffusers and accessories. For
the ADAPT E, one slave air diffuser is normally connected to the
Connection box of the Master air diffuser.
1. ADAPT Master air diffuser (not shown in picture)
2. ADAPT E
3. CONNECT Adapt, wiring terminal for the Master air diffuser
4. 24 V AC Transformer
5. LINK Adapt, 5 m long (RJ45 cable)
6. LINK Modbus, 5 m long (RJ12 cable)
10. Connection to main control system (Modbus RTU)
12. SPLIT Modbus RJ12, max. stab length, 10 m
