1
ROWb
Installation – Commissioning – Maintenance 20140116
Installation
• InstallationwiththeROWT,seepage1,Figure1.
• InstallationwiththeALV,seepage2,Figure2.
Installation with the ROWT
1. TheROWT1commissioningboxandtheROWT2
connectingductshouldbebuiltintothewall.Cutthe
openinginthewallstructurefortheROWsupplyair
wallterminalaccordingtothedimensionsspeciedin
thedimensiontableandthedimensionprint.
2.InsertthemountingplateintotheROWT1commis-
sioningbox.
3.Markthepositionsfortheboreholes.
4.Borethescrewholes.
5.Securethemountingplatewithscrewstothewall.
N.B.!Thescrewheadsshouldhaveaheightofmax.4
mmabovetheplatesurface.
6.Securethewallterminalfaceusingsteelblindrivets.
Figure 1. ROW + ROWT 1
Commissioning with the ALV
Commissioningshouldbecarriedoutwiththewall
terminalfacemounted.Pullthemeasurementhoseand
damperadjustmentcordsoutofthewallterminalthrough
theperforation.Connectamanometertothemeasuring
tube.Thedesiredcommissioningpressurecanbecalcu-
latedusingtheratedcoefcientofperformance(K-factor)
ofthewallterminal.Setthedampertothecorrectblade
position,tieacommissioningknotinthedampercordsto
indicatethedamperposition.Thenlockthecordsagainst
thelockingscrewintheairdistributionbafe.SeeFigure
2.
IftheROWTconnectingductaccessoryisused,werec-
ommendinstallingatypeCRMcommissioningdamper
upstreamofthewallterminalforadjustingtheairow
rate.
TheK-factor(COP)isspeciedontheproduct’sidentica-
tionlabel.K-factorsarealsospeciedintherelevantcom-
missioninginstructionsavailablefordownloadatwww.
swegon.com.
Maintenance
Thewallterminalcanbecleaned,ifnecessary,using
lukewarmwaterwithdishwashingdetergentaddedorby
vacuumcleaningusingabrushnozzle.Theductsystemis
accessedforcleaningbyboringoutthesteelblindrivets
andthenwithdrawingthewallterminaloutofitsspring
retainers.IfanALVcommissioningboxisused,withdraw
theacousticbafe,movethedistributionplatetothe
side,turnandwithdrawthedamperfromitsholderfrom
theinlet.SeeFigure2.
2
ROW
Swegonreservestherighttoalterspecications. 20140116 www.swegon.com
Installation with the ALV
1. Cutanopeninginthewallaccordingtothedimensions
speciedinthedimensiontableandthedimension
print.PlacetheALVcommissioningboxintheopening.
Insertthemountingframeintothecommissioningbox
andsecureitwithscrewsintheshortsidesthrough
thesidesofthecommissioningboxandintothewall
structure.
2.Insertthemeasurementhoseandthecordfordamper
adjustmentthroughtheairdistributionplateinthe
mountingplateandpressitintothemountingframe.
Themountingframeisheldinplacebyitsspring
retainers.Markthepositionsfortheboreholes.
p
q
ROWb 400 -150
Tomelilla
Sweden
+ALVd 400-150-125
k-faktor
B-ansl 10,0 / K-ansl 9,9
kpq⋅=
k
pq
=
( )2
q = uppmätt flöde l/s
p= aktuellt mättryck (Pa)
k= injusteringsfaktor
k
k-faktor
p
q
ROWb 400 -150
Tomelilla
Sweden
+ALVd 400-150-125
k-faktor
B-ansl 10,0 / K-ansl 9,9
kpq⋅=
k
pq
=
( )2
q = uppmätt flöde l/s
p= aktuellt mättryck (Pa)
k= injusteringsfaktor
k
k-faktor
Figure 2. ROW + ALV.
3.Borescrewholesinthewall.
4.Securethemountingplatewithscrewstothewall.
5.Commissioningiscarriedoutwiththewallterminal
facetemporarilysecuredwiththescrewssupplied.See
Commissioning.
6.Borethescrewholesinthemountingplateforthe
temporaryattachmentusinga5.5mmtwistdrill.The
measurementhoseandthecommissioningcordcan
beremoved,ifnecessary,bycuttingthemoff,level
withtheairdistributionplate.Ortheycanbepushedin
behindtheairdistributionplate.
7. Securethewallterminalfaceusingsteelblindrivets.
Q=Flowreading
P=Currentpressurereading
K=Commissioningfactor
3
ROW
Swegonreservestherighttoalterspecications. 20140116 www.swegon.com
Dimensions and weights
ROW + ROWT 1 + ROWT 2
Size Dimensions(mm)
ABCD E F
400x150 480 230 395 145 300 50
500x200 580 280 495 195 350 50
Size Dimensions(mm) Weight(kg)
GH*) ØD
400x150 80 86 124 13,5
500x200 80 105 159 18,0
ROW + ALV
Size Dimensions(mm)
ABØD FGG2
400x150 480 230 124 295 225 331
400x200 480 280 159 315 225 331
Size Dimensions(mm) Weight,
kg
K*) LM*) I J
400x150 85 180 240 405 155 6,0
400x200 100 145 225 405 205 6,5
CL=Centreline/Sizeoftheopening=IxJ
*)TheH,K,LandMdimensionsapplytoaside-connected
commissioningbox.
Figure 3. ROW + ROWT 1 and ROWT 2.
Figure 4. ROW + ALV.
K-factor – ROW with ALV
ALVd ROWb–supplyair
Size Size BK
400-150-125 400 -150 10 9,9
400-200-160 400-200 15 14,3
Connectionoptions:B=backside,K=shortside
Numberofmeasurementhoses:1/Colourofthehose:
Transparent
