Swegon ADAPT Free b Guide

1
ADAPTTM Free b
Installation – Commissioning – Maintenance, ADAPT Fb 20120718 / Art. No. 1545217
Montering
1. The commissioning box can be suspended from a ceiling
and connected to a duct system.The diffuser is secured
to the ceiling by connecting the M8 threaded rod (A)
into the popnut on the top of the diffuser, see figure 2.
2. Make sure that the orientation of the sensor module
aligns with the extension of the room, see figure 1. If
the connecting duct does not enter the room as in the
example in figure 3, the frontplate of the diffuser must
be dismantled and rotated in a direction with the sensor
module directed as shown in figure 1. Then fixate and
secure the diffuser with screws or pop rivets. Readjust
the hanger rods of the commissioning box if necessary.
3. The front plate is dismantled by pressing the fixing pins
of the bottom plate outward, which will loosen it from
the upper cone. Detach the safety cord that secures front
plate to the upper cone and disconnect the connector
(C, figure 2) from the top of the front plate. When reas-
sembling, press together the S-hook to prevent it from
coming loose.
A
B
C
Figure 2. ADAPT Free, installation.Figure 1. The orientation of the sensor module in a room or in
an office module. The LED’s of the sensor should be aligned with
the extension of the room in a straight line, facing the short sides
of the room as shown by the arrow in the figure.

2Swegon reserves the right to alter specifications. 20120718 www.swegon.com
WISE
Maintenance
The exterior surface of the ADAPT air diffusers can be
cleaned whenever necessary using lukewarm water with
dishwashing detergent added. Normally the best method
of cleaning is vacuuming with a brush nozzle.
The duct system is accessible through the air diffuser and
the commissioning box.
Commissioning
All the ADAPT Air terminals are delivered preset into com-
missioning mode, which means that the air diffuser is set to
max. airflow by force control.
When the ADAPT air diffuser is in commissioning mode,
the light-emitting diode shines orange. The different LED
indications:
• Steady green LED: Normal operation, the air diffuser is
operating normally.
• Flashing green LED: The air diffuser has just been ener-
gised and calibration is in progress.
• Steady red LED: Function failure, see separate docu-
mentation for TUNE Adapt.
• Steady orange LED: The commissioning mode, max.
airflow
• Flashing orange LED: Other commissioning modes
and all the forced control situations of the feed-back
control system.
More information about the commissioning process itself
can be read in the Project Manual for the Wise system and
in the documentation for TUNE Adapt.
Figure 3. Lighting fixtures or similar objects must not be installed
beneaht the diffuser as this disrupts the presence detection and
room temperature measurement.

3
Swegon reserves the right to alter specifications. 20120718 www.swegon.com
WISE
Electrical connections.
All the connections are wired to the CONNECT Adapt junc-
tion box. From there, the Master air diffuser is connected
by means of the LINK Adapt (RJ45) cable included in the
delivery. The slave air diffusers, if required, are connected
by means of the same type of cable to their respective slave
contacts. If there are more than 2 slave air diffusers, a SPLIT
Link Adapt should be used for further connection to the last
slave air diffuser. See Figure 6. If SPLIT Link Adapt is used,
the maximum length of LINK Adapt from the junction box to
the last air diffuser is 15 meters. If ADAPT is to be connected
through Modbus communication, this should be done with
the LINK Modbus (RJ12) cable. The maximum length of
SPLIT Link Modbus is 10 meters from the junction box to
the last air diffuser. Use double CONNECT Adapts if longer
distances are required. All cables and contacts are different
so that they will not be confused or incorrectly connected.
Electrical data
ADAPT is supplied with power via the junction box. See
the wiring diagram in figure 6 or relevant diagram from the
Swegon Templates application, containing details for the
specific installation. It is important that cables with appro-
priate cross-sectional area, transformers of correct size and
power supply cables of correct length are selected. This
can for example be carried out with the dimensioning tool
“Cable and Transformer Design”, available for download
from www.swegon.com (the application is available in
english and swedish language versions).
Supply voltage 24 V AC ±10 %
Max. power consumption (controller only) 3 VA
Cable rating (controller only) 0,6 A
Ambient temperature 0 °C - +50 °C
Figure 4. Commissioning with TUNE Adapt.
2
3
1
24 V
Modbus
Figure 5. Air diffuser connections.
1. Connection for LINK Adapt cable (RJ45)
2. Connection for the LINK Modbus cable (RJ12).
3. Direct 24 V connection if a junction box is not used and the air
diffuser will be completely “stand alone”.

4Swegon reserves the right to alter specifications. 20120718 www.swegon.com
WISE
20
Master
21
Slave
22
Slave
23
Modbus
5
1
6
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
65
4
3
9
8
7
55
7
10
- + C
A1 A2 1 3
G
G0
OUT1
1222
11
5
12 6
Figure 6. Wiring of Master/Slave air diffusers and accessories.
1. ADAPT Master air diffuser
2. ADAPT Slave air diffusers
3. CONNECT Adapt, wiring terminals
4. 230-24 V AC Transformer
5. LINK Adapt (5 m long RJ45 cable)
6. LINK Modbus (5 m long RJ12 cable)
7. DETECT Quality (3 VA) or TUNE Temp (1 VA)
8. ACTUATOR, Radiator control (max 3 valves at 6 VA)
9. ADAPT Relay, relay for lighting
10.Connection to main control system (Modbus RTU)
11. SPLIT Link RJ45
12. SPLIT Modbus RJ12, max. stab length, 10 m.
