Swegon KDYa Series Guide

KDYa
Installation – Commissioning – Maintenance 20101125
Installation
Cut an opening in the duct according to dimensions I
x J in the dimensions table. Place the air diffuser over
the opening and secure it with screws to the duct. See
Figure 1.
Commissioning
A flow measuring damper installed in the duct upstream
of the first duct diffuser is recommended for commission-
ing and airflow measurements.
Maintenance
The air diffuser can be cleaned, if necessary, using luke-
warm water with dishwashing detergent added or by
vacuum cleaning using a brush nozzle.
Figure 1. Installation.
Figur 2. Installation alternative, no airflow beyond the arrange-
ment of discs.
Figure 3. Installation alternative, air also flows past the discs.
Standard KDY disc pattern
2 - 7
2 - 9
2 - 14
2 - 18
3 - 14
3 - 18
4 - 14
4 - 18
2 - 7
2 - 9
2 - 14
2 - 18
3 - 14
3 - 18
4 - 14
4 - 18
KDY disc pattern or diffused air distribution pattern
2 - 7
2 - 9
2 - 14
2 - 18
3 - 14
3 - 18
4 - 14
4 - 18
2 - 7
2 - 9
2 - 14
2 - 18
3 - 14
3 - 18
4 - 14
4 - 18

KDY
2Swegon reserves the right to alter specifications. 20101125
Dimensions and Weights
KDY-C
Size
A C I x J Number of
discs
Weight,
kg
2-7 550 126 132 x 510 14 2.0
2-9 690 150 132 x 650 18 2.4
2-14 1040 170 132 x 1000 28 3.1
2-18 1320 205 132 x 1280 36 3.7
3-14 1040 175 197 x 1000 42 3.9
3-18 1320 210 197 x 1280 54 5.0
4-14 1040 195 262 x 1000 56 4.9
4-18 1320 230 262 x 1280 72 6.7
Size of opening = I x J
Fits duct dimensions according to the specification matrix on
the last page.
Figure 4. KDY-C.
Figure 5. KDY-R.
KDY-R
Size A B C I x J Number of
discs
Weight,
kg
2-7 540 178 95 132 x 510 14 2.0
2-9 680 178 113 132 x 650 18 2.4
2-14 1030 178 160 132 x 1000 28 3.1
2-18 1310 178 190 132 x 1280 36 3.7
3-14 1030 243 160 197 x 1000 42 3.9
3-18 1310 243 190 197 x 1280 54 5.0
4-14 1030 307 160 262 x 1000 56 4.9
4-18 1310 307 190 262 x 1280 72 6.7
Size of opening = I x J
